Philips MCM7000/12 User manual

MCM7000
Register your product and get support at
www.philips.com/welcome
EN User manual 3
FR Mode d’emploi 21
ES Manual del usuario 41
DE Benutzerhandbuch 61
NL Gebruiksaanwijzing 81
IT Manuale utente 101
PT Manual do utilizador 121
SV Användarhandbok 141

(in standby mode)
(in standby mode)

3
English
EN
6 Other features 16
Set alarm timer 16
Set the sleep timer 16
Listen to external audio device 16
Listen through headphone 16
7 Product information 17
Specifications 17
USB playability information 18
Supported MP3 disc formats 18
8 Troubleshooting 18
Contents
1 Important 4
Safety 4
Notice 6
2 Your Micro Hi-Fi System 7
Introduction 7
What’s in the box 7
Product overview 8
3 Get started 10
Connect speakers 10
Connect FM antenna 11
Connect power 11
Prepare the remote control 11
Set clock 12
Demonstrate the unit’s features 12
Adjust brightness of display panel 12
Turn on or off LED light 12
Turn on 12
Switch to standby mode 12
4 Play 13
Basic play operations 13
Play from disc 13
Play from USB 13
Adjust sound 14
5 Listen to FM radio 14
Plug and play installation 14
Tune to FM radio stations 14
Program radio stations automatically 15
Program radio stations manually 15
Tune to a preset radio station 15
Show RDS information 15

4
hDo not install near any heat sources
such as radiators, heat registers, stoves,
or other apparatus (including amplifiers)
that produce heat.
iProtect the power cord from being
walked on or pinched, particularly at
plugs, convenience receptacles, and
the point where they exit from the
apparatus.
jOnly use attachments/accessories
specified by the manufacturer.
kUse only with the cart, stand, tripod,
bracket, or table specified by the
manufacturer or sold with the apparatus.
When a cart is used, use caution when
moving the cart/apparatus combination
to avoid injury from tip-over.
lUnplug this apparatus during lightning
storms or when unused for long periods
of time.
mRefer all servicing to qualified service
personnel. Servicing is required when
the apparatus has been damaged in any
way, such as power-supply cord or plug
is damaged, liquid has been spilled or
objects have fallen into the apparatus,
the apparatus has been exposed to rain
or moisture, does not operate normally,
or has been dropped.
nBattery usage CAUTION – To prevent
battery leakage which may result in
bodily injury, property damage, or
damage to the unit:
Install all batteries correctly, + and -•
as marked on the unit.
Do not mix batteries (old and new•
or carbon and alkaline, etc.).
1 Important
Safety
Know these safety symbols
This ‘bolt of lightning’ indicates uninsulated
material within your unit may cause an
electrical shock. For the safety of everyone
in your household, please do not remove
product covering.
The ‘exclamation mark’ calls attention to
features for which you should read the
enclosed literature closely to prevent
operating and maintenance problems.
WARNING: To reduce the risk of fire or
electric shock, this apparatus should not be
exposed to rain or moisture and objects filled
with liquids, such as vases, should not be
placed on this apparatus.
CAUTION: To prevent electric shock, fully
insert the plug. (For regions with polarized
plugs: To prevent electric shock, match wide
blade to wide slot.)
Important Safety Instructions
aRead these instructions.
bKeep these instructions.
cHeed all warnings.
dFollow all instructions.
eDo not use this apparatus near water.
fClean only with dry cloth.
gDo not block any ventilation openings.
Install in accordance with the
manufacturer’s instructions.
EN

5
Hearing safety
Listen at a moderate volume.
Using headphones at a high volume can•
impair your hearing. This product can
produce sounds in decibel ranges that
may cause hearing loss for a normal
person, even for exposure less than a
minute. The higher decibel ranges are
offered for those that may have already
experienced some hearing loss.
Sound can be deceiving. Over time your•
hearing ‘comfort level’ adapts to higher
volumes of sound. So after prolonged
listening, what sounds ‘normal’ can
actually be loud and harmful to your
hearing. To guard against this, set your
volume to a safe level before your hearing
adapts and leave it there.
To establish a safe volume level:
Set your volume control at a low setting.•
Slowly increase the sound until you can•
hear it comfortably and clearly, without
distortion.
Listen for reasonable periods of time:
Prolonged exposure to sound, even•
at normally ‘safe’ levels, can also cause
hearing loss.
Be sure to use your equipment•
reasonably and take appropriate breaks.
Be sure to observe the following guidelines
when using your headphones.
Listen at reasonable volumes for•
reasonable periods of time.
Be careful not to adjust the volume as•
your hearing adapts.
Do not turn up the volume so high that•
you can’t hear what’s around you.
You should use caution or temporarily•
discontinue use in potentially hazardous
situations. Do not use headphones while
operating a motorized vehicle, cycling,
skateboarding, etc.; it may create a traffic
hazard and is illegal in many areas.
Remove batteries when the unit is•
not used for a long time.
Batteries (battery pack or batteries•
installed) shall not be exposed to
excessive heat such as sunshine, fire
or the like.
oApparatus shall not be exposed to
dripping or splashing.
pDo not place any sources of danger on
the apparatus (e.g. liquid filled objects,
lighted candles).
qWhere the MAINS plug or an appliance
coupler is used as the disconnect device,
the disconnect device shall remain
readily operable.
Warning
Never remove the casing of this apparatus.• Never lubricate any part of this apparatus.• Never place this apparatus on other electrical• equipment.
Keep this apparatus away from direct sunlight,
• naked flames or heat.
Never look into the laser beam inside the
• apparatus.
Ensure that you always have easy access to the
• power cord, plug or adaptor to disconnect the
apparatus from the power.
Caution
Use of controls or adjustments or• performance of procedures other than herein
may result in hazardous radiation exposure or
other unsafe operation.
English
EN

6
Environmental information
All unnecessary packaging has been omitted.
We have tried to make the packaging easy to
separate into three materials: cardboard (box),
polystyrene foam (buffer) and polyethylene
(bags, protective foam sheet.)
Your system consists of materials which can
be recycled and reused if disassembled by
a specialized company. Please observe the
local regulations regarding the disposal of
packaging materials, exhausted batteries and
old equipment.
The making of unauthorized copies of
copy-protected material, including computer
programs, files, broadcasts and sound
recordings, may be an infringement of
copyrights and constitute a criminal offence.
This equipment should not be used for such
purposes.
This apparatus includes this label:
Class II equipment symbol
This symbol indicates that the unit has a
double insulation system.
Note
The type plate is located at the rear of the• apparatus.
Notice
Any changes or modifications made to this
device that are not expressly approved by
Philips Consumer Lifestyle may void the user’s
authority to operate the equipment.
This product complies with the radio interference
requirements of the European Community.
Your product is designed and manufactured
with high quality materials and components,
which can be recycled and reused.
When this crossed-out wheeled bin symbol
is attached to a product it means that the
product is covered by the European Directive
2002/96/EC.
Please inform yourself about the local separate
collection system for electrical and electronic
products.
Please act according to your local rules and
do not dispose of your old products with your
normal household waste. Correct disposal of
your old product helps to prevent potential
negative consequences for the environment
and human health.
Your product contains batteries covered by
the European Directive 2006/66/EC, which
cannot be disposed with normal household
waste.Please inform yourself about the local
rules on separate collection of batteries
because correct disposal helps to prevent
negative consequences for the environmental
and human health.
EN

7
What’s in the box
Check and identify the contents of your
package:
Main unit•
2 speakers•
Remote control•
2 AAA batteries•
AC power cord•
2 speaker wires•
MP3-LINK cable•
FM antenna•
User manual•
2 Your Micro Hi-
Fi System
Congratulations on your purchase, and
welcome to Philips!To fully benefit from the
support that Philips offers, register your product
at www.Philips.com/welcome.
Introduction
With this unit, you can:
enjoy audio from discs, USB storage•
devices, and other external devices
listen to radio stations•
You can enrich sound output with these sound
effects:
treble & bass control•
loudness control•
The unit supports these media formats:
English
EN

8
g
Open or close the disc•
compartment.
hVOLUME
Adjust volume.•
Adjust time.•
iIR sensor
Detect signals from the remote•
control. Always point the remote
control at the IR sensor.
jDisplay panel
Display information about current•
source.
kDisc compartment
Hold the disc.•
l
Headphone socket.•
Product overview
Main unit
a
Switch to ECO Power or standby•
mode.
bSOURCE
Select a source.•
c/
Skip to the previous/next track.•
Skip to a preset station.•
d
Start or pause play.•
e/
Search backward or forward.•
Search to a radio station.•
f
Stop play.•
Erase a program.•
(In standby mode) Turn on/off Demo•
mode.
SOURCE
abc defg
hji
klmn
EN

9
cSHUFFLE
Play tracks randomly.•
dSLEEP
Set the sleep timer.•
e
Navigate through menu.•
• ALBUM/: Skip to previous/next
album.
OK
Confirm an entry or selection.•
Select FM stereo or mono.•
fRDS/INFO
For selected FM radio stations:•
display RDS information.
Display the current status or the disc•
information.
Display the ID3 information•
(if available) of MP3 tracks.
g/
Skip to the previous next track or•
radio station.
h
Stop play.•
Erase a program.•
(In standby mode) Turn on/off Demo•
mode.
i/
search backwards or forward.•
Search to a radio station.•
jTREBLE / BASS
Activate treble/bass adjustment.•
kCLOCK
Set the clock.•
Display the set clock.•
lNumeric keypad.
Select a track directly.•
mSHIFT
Enter a two or three-digit number•
(with the numeric keypad).
mMP3 LINK
Connect to an external audio device.•
n
Connect to a USB flash drive.•
Remote control
a
Switch to ECO Power or standby•
mode.
bDIM
Adjust brightness of display panel.•
(Press and hold) Turn on or off the•
LED light at the bottom of the unit
and at the volume knob.
n
a
b
d
e
f
k
i
h
m
j
l
c
g
o
p
q
r
s
t
u
v
w
English
EN

10
3 Get started
Caution
Use of controls or adjustments or• performance of procedures other than herein
may result in hazardous radiation exposure or
other unsafe operation.
Always follow the instructions in this chapter in
sequence.
If you contact Philips, you will be asked for the
model and serial number of this apparatus.The
model number and serial number are on the
back of the apparatus.Write the numbers here:
Model No. __________________________
Serial No. ___________________________
Connect speakers
Note
Ensure that the colors of the speaker wires and• terminals are matched.
For optimal sound, use the supplied speakers
• only.
Connect only speakers with impedance that is
• the same or higher than the supplied speakers.
Refer to the Specifications section of this
manual.
For the main unit side:
Connect the speaker wires and the main unit as
the following graphic indicates:
nPROGRAM
Program radio stations.•
Program tracks.•
oVOL +/-
Adjust volume.•
Adjust time.•
pLOUDNESS
Turn on or off automatic loudness•
adjustment.
q
Mute or restore volume.•
r
Start or pause play.•
sMENU
Access menu.•
This button is not workable for this•
model.
tTIMER
Set alarm timer.•
u
Open or close the disc•
compartment.
vREPEAT
Select a repeat play mode.•
wSource buttons
Select a source.•
DOCK source is not available for this•
unit.
EN

11
Connect power
Caution
Risk of product damage! Ensure that the• power supply voltage corresponds to the
voltage printed on the back or the underside
of the unit.
Risk of electric shock! When you unplug the
• AC power cord, always pull the plug from the
socket. Never pull the power cord.
Before you connect the AC power cord,
• ensure that you have completed all other
connections.
1Connect the power cord to:
the• AC~ socket on the main unit.
the power outlet.•
Prepare the remote control
Caution
Risk of explosion! Keep batteries away from• heat, sunshine, or fire. Never discard batteries
in fire.
To insert the remote control battery:
1Open the battery compartment.
2Insert 2 AAA batteries with correct
polarity (+/-) as indicated.
3Close the battery compartment.
RR
AUX INLINE OUT
LL
DEMO
ANTENNA
FM
For the speaker side:
1Unscrew the speaker connectors.
2For the left speaker, identify the speaker
cable that is connected to the left
connectors on the main unit.
3Insert fully the red end of the speaker
cable into the red (+) connector.
4Screw the red (+) connector to secure
the cable.
5Insert fully the silver end of the speaker
cable into the black (-) connector.
6Screw the black (-) connector to secure
the cable.
7Repeat steps 2-6 for the right speaker.
Connect FM antenna
Tip
For optimal reception, fully extend and adjust• the position of the antenna.
For better FM stereo reception, connect an
• outdoor FM antenna to the FM ANTENNA
socket.
The unit does not support MW radio
• reception.
1Connect the supplied FM antenna to the
FM ANTENNA socket on the main unit.
RR
AUX INLINE OUT
LL
DEMO
ANTENNA
FM
FM
English
EN

12
Demonstrate the unit’s
features
1In the standby mode, press until
“DEMO ON” is displayed.
Available features are displayed one»
by one.
To turn off the demonstration, press•
again.
Adjust brightness of display
panel
Press DIM repeatedly to select different
brightness levels.
Turn on or off LED light
1In power-on mode, press and hold DIM
to turn on or off the LED light at the
bottom of the unit and at the volume
knob.
Turn on
1Press .
The unit switches to the last selected»
source.
Switch to standby mode
To switch the system to Eco Power Standby
mode:
In standby mode, press and hold for 2
seconds.
»[ECO POWER] (Eco power) scrolls on
the display, then the backlight turns off.
Note
If you are not going to use the remote control• for a long time, remove the batteries.
Do not use old and new or different types of
• batteries in combination.
Batteries contain chemical substances, so they
• should be disposed of properly.
Set clock
1In standby mode, press CLOCK for three
seconds to activate clock setting mode.
»[CLOCK SET] scrolls on the display,
then the time format [24H] or [12H]
is displayed.
2Press VOL +/- to select 24H or 12H, then
press CLOCK to confirm.
The hour digits begin to blink.»
3Press VOL +/- to set hour, then press
CLOCK again.
The minute digits begin to blink.»
4Press VOL +/- to set minute.
5Press CLOCK to confirm the clock
setting.
Note
If no button is pressed in 90 seconds, the• system exits clock setting mode automatically.
a
b
c
EN

13
Play from USB
Warning
Make sure that the USB storage device• contains playable audio contents for supported
formats.
1Flip open the cover marked on the
front panel.
2Insert the USB storage device into the
USB socket.
3Press USB to select the USB source.
Play starts automatically. If not, press»
ALBUM/to select a folder and /
to select a file. System starts to play
automatically.
4 Play
Basic play operations
You can control play through following
operations.
Key Function
/Press and hold to fast-forward/fast-
reverse the track during playback,
then release to resume play.
To pause/resume play during
playback.
INFO Select different play information.
REPEAT To select a repeat play mode:
[REP] (repeat): play current track
repeatedly.
[REP ALL] (repeat all): play all
tracks repeatedly.
Press again to return to normal play.
SHUFFLE To play tracks randomly.
Press again to return to normal
play.
Play from disc
1Press DISC to select the CD source.
2Press .
The disc compartment opens.»
3Place a disc with the printed side facing
up, then press .
4The unit starts to play automatically.
If the play does not start, press• / to
select a track, then press .
English
EN

14
5 Listen to FM
radio
Plug and play installation
When the unit turn to radio mode, and no
radio stations are stored, [AUTO INSTALL -- PRESS
PLAY -- STOP CANCEL] (to auto install, press
; to cancel, press ) displays.
1Press on the main unit to start
installation.
The unit automatically stores radio»
stations with sufficient signal strength.
When all the available radio stations»
are stored, the first preset radio station
broadcasts automatically.
2To exit plug and play installation mode,
press source keys or on the remote
control.
The system switches to the designated»
source mode or standby mode.
Tune to FM radio stations
Warning
Make sure that you have connected and fully• extended the supplied FM antenna.
1Press RADIO.
2Press and hold / to search a radio
station.
3When the frequency starts to change,
release the button.
The unit automatically stores radio»
stations with sufficient signal strength.
4Repeat steps 2-3 to tune to more
stations.
To tune to a weak station:
Press / repeatedly until you find the
optimal reception.
Adjust sound
During play, you can change volume through
following operations.
Key Function
VOL +/- To increase/decrease the
volume.
To mute/restore sound.
LOUDNESS To turn on/off automatic
loudness control.
BASS To activate bass, press BASS
and then change the bass level
with VOL +/-.
TREBLE To activate treble, press
TREBLE and then change the
treble level with VOL +/-.
EN

15
4Repeat the previous steps to program
other stations.
Note
To overwrite a programmed station, store• another station in its place.
Tune to a preset radio station
1Press / to select a preset number
that you want.
Show RDS information
RDS (Radio Data System) is a service
that allows FM stations to show additional
information. If you tune to a RDS station, a RDS
icon and the station name are displayed.
1Tune to a RDS station.
2Press repeatedly to scroll through the
following information (if available):
Station name»
Program type such as»[NEWS] (news),
[SPORT] (sport), [POP M] (pop music)...
RDS clock»
Frequency»
Synchronize clock with RDS
You can synchronize time shown on the unit
with that on the RDS station.
1Tune to a RDS radio station that
transmits time signals.
2Press RDS for over 2 seconds.
»[CT SYNC] is displayed and the unit
reads RDS time automatically.
If no time signal is received,»[NO CT]
is displayed.
Note
The accuracy of the transmitted time depends• on the RDS station that transmits the time signal.
Note
• [STEREO] is default setting for tuner mode.
Tip
Under tuner mode, you can press• OK repeatedly
to toggle between [STEREO] and [MONO], and
the unit memorizes your setting even if you turn
off the unit or turn to other sources.
Program radio stations
automatically
Note
You can program a maximum of 20 preset• radio stations.
1In tuner mode, press and hold
PROGRAM for two seconds to activate
automatic program mode.
[AUTO] (auto) is displayed and begins»
to blink.
The unit automatically stores radio»
stations with sufficient signal strength.
The first programmed radio station»
broadcasts automatically.
Program radio stations manually
Note
You can program a maximum of 20 preset• radio stations.
1Tune to a radio station.
2Press PROGRAM to activate
programming.
3Press / to allocate a number from 1
to 20 to this radio station, then press
PROGRAM to confirm.
The preset number and the frequency»
of the preset station are displayed.
English
EN

16
Set the sleep timer
This unit can switch to standby automatically
after a set period of time.
1When the unit is turned on, press SLEEP
repeatedly to select a set period of time
(in minutes).
When sleep timer is activated, the»
display shows .
To deactivate sleep timer
1Press SLEEP repeatedly until “SLEEP
OFF” is displayed.
When sleep timer is deactivated,»
disappears on the display.
Listen to external audio
device
You can listen to an external audio device such
as MP3 player through this unit.
1Connect the audio device.
For audio device with red/white•
audio output sockets:
Connect a red/white audio cable
(not supplied) to the AUX IN
sockets and to the audio output
sockets on the audio device.
For audio device with headphone•
sockets:
Connect the supplied MP3 Link cable
to the MP3 LINK socket and to the
headphone socket on the audio
device.
2Select MP3 LINK/AUX source.
3Play the device.
Listen through headphone
1Plug a headphone into the socket on
the unit.
6 Other features
Set alarm timer
This unit can be used as an alarm clock.You can
select CD, FM or USB as alarm source.
Note
Make sure that you have set the clock• correctly.
1In standby mode, press and hold TIMER
until [TIMER SET] scrolls on the display.
2Press source buttons on the remote
control to select a source: CD/MP3,
TUNER, USB.
3Press TIMER to confirm.
The hour digits are displayed and begin»
to blink.
4Press VOL +/- repeatedly to set hour,
then press TIMER again to confirm.
The minute digits are displayed and»
begin to blink.
5Press VOL +/- to set minute, then press
TIMER to confirm.
»VOL (volume) is displayed and begins
to blink.
6Press VOL +/- to adjust volume, then
press TIMER to confirm.
Activate/deactivate alarm timer
1In standby mode, press TIMER repeatedly
to activate or deactivate timer.
If timer is activated,»is displayed.
Tip
Alarm timer is not available in MP3 LINK• mode.
If CD/USB source is selected, yet no disc is
• placed or no USB connected, the system
switches to the tuner source automatically.
EN

17
Tuner-Specs
Tuning Range FM: 87.5 - 108 MHz
Tuning grid 50KHz
- Mono, 26 dB S/N Ratio
- Stereo, 46 dB S/N Ratio
<22 dBf
<43 dBf
Search Sensitivity <28 dBf
Total Harmonic
Distortion
<2%
Signal to Noise Ratio >55 dB
Speakers
Speaker
Impedance
4 ohm
Speaker Driver 13 cm woofer + 2.5 cm
Dome tweeter
Sensitivity >86 dB/m/W ± 4dB/m/W
General information
AC power 220-240 V, 50/60 Hz
Operation Power
Consumption
30 W
Headphone output 2X15 mW 32 ohm
USB Direct version 2.0 FS
Dimensions
- Main Unit
(W x H x D)
- Speaker Box
(W x H x D)
250 x 92 x 285 mm
174 x 260 x 240 mm
Weight
- With Packaging
- Main Unit
- Speaker Box
10 kg
2.5 kg
6.1 kg
7 Product
information
Note
Product information is subject to change• without prior notice.
Specifications
Amplifier
Rated Output
Power
2 X 30 W RMS
Frequency
Response
20-20000 Hz, ±3 dB
Signal to Noise
Ratio
>82 dBA
Aux Input 1000 mV RMS 22k ohm
Disc
Laser Type Semiconductor
Disc Diameter 12 cm/8 cm
Support Disc CD-DA, CD-R, CD-RW,
MP3-CD, WMA-CD
Audio DAC 24Bits / 44.1 kHz
Total Harmonic
Distortion
<0.8% (1 kHz)
Frequency
Response
4 Hz - 20 kHz (44.1 kHz)
S/N Ratio >82 dBA
English
EN

18
8 Troubleshooting
Warning
Never remove the casing of this apparatus.•
To keep the warranty valid, never try to repair
the system yourself.
If you encounter problems when using this
apparatus, check the following points before
requesting service. If the problem remains
unsolved, go to the Philips web site (www.
philips.com/welcome).When you contact
Philips, ensure that the apparatus is nearby
and the model number and serial number are
available.
No power
Ensure that the AC power cord of the•
unit is connected properly.
Ensure that there is power at the AC•
outlet.
As a power-saving feature, the system•
switches off automatically 15 minutes
after track play reaches the end and no
control is operated.
No sound or poor sound
Adjust the volume.•
Disconnect the headphones.•
Check that the speakers are connected•
correctly.
Check if the stripped speaker wires are•
clamped.
No response from the unit
Disconnect and reconnect the AC power•
plug, then turn on the unit again.
As a power-saving feature, the system•
switches off automatically 15 minutes
after track play reaches the end and no
control is operated.
Remote control does not work
Before you press any function button,•
first select the correct source with the
remote control instead of the main unit.
USB playability information
Supported USB storage devices:
USB flash memory (USB 2.0)•
Supported formats
MP3 (bit rates 32-320 kbps)•
WMA (bit rates 32-320 kbps)•
MP3 ID3 tag (Ver 2.0)•
WMA ID3 tag•
Unsupported formats:
Empty albums: an empty album is an•
album that does not contain MP3/
WMA files, and is not shown in the
display.
Unsupported file formats are•
skipped. For example, Word
documents (.doc) or MP3 files with
extension .dlf are ignored and not
played.
Video and photo files.•
AAC, WAV, PCM audio files•
DRM protected WMA files (.wav,•
.m4a, .m4p, .mp4, .aac)
WMA files in Lossless format•
Supported MP3 disc formats
ISO9660, Joliet•
Maximum title number: 512 (depending•
on file name length)
Maximum album number: 255•
Supported sampling frequencies: 32 kHz,•
44.1kHz, 48 kHz
Supported Bit-rates: 32~320 (kbps),•
variable bit rates
EN

19
Reduce the distance between the remote•
control and the unit.
Insert the battery with its polarities (+/–•
signs) aligned as indicated.
Replace the battery.•
Aim the remote control directly at the•
sensor on the front of the unit.
No disc detected
Insert a disc.•
Check if the disc is inserted upside down.•
Wait until the moisture condensation at•
the lens has cleared.
Replace or clean the disc.•
Use a finalized CD or correct format disc.•
Cannot display some files in USB device
The number of folders or files in the USB•
device has exceeded a certain limit. This
phenomenon is not a malfunction.
The formats of these files are not•
supported.
USB device not supported
The USB device is incompatible with the•
unit. Try another one.
Poor radio reception
Increase the distance between the unit•
and your TV or VCR.
Fully extend the FM antenna.•
Connect an outdoor FM antenna instead.•
Timer does not work
Set the clock correctly.•
Switch on the timer.•
Clock/timer setting erased
Power has been interrupted or the power•
cord has been disconnected.
Reset the clock/timer.•
English
EN

© 2011 Koninklijke Philips Electronics N.V.
All rights reserved.
MCM7000_12_UM_V1.1
