Phocos Any-Cell Series Operating manual

Phocos Any-Cell™ series
LFP Energy Storage System
ESS-L-5kWh-48V
User and Installation Manual
English
For further languages see
Für weitere Sprachen siehe
Pour autres langues voir
Para otros idiomas ver
对于其他语言请参阅
www.phocos.com

www.phocos.com 1 | P a g e
Contents
1.0 Abbreviations .................................................................................................................................2
2.0 About This Manual..........................................................................................................................2
3.0 Important Safety Information .......................................................................................................2
3.1 Response to emergency situations........................................................................................................................3
4.0 Regulatory Information .................................................................................................................4
5.0 Product Overview...........................................................................................................................5
5.1 Outline and Dimensions ............................................................................................................................................6
5.2 CAN communication interface pinout (CAN1 & CAN2) ..................................................................................8
5.3 LED Indicators................................................................................................................................................................9
6.0 Installation....................................................................................................................................10
6.1 Unpacking.................................................................................................................................................................... 10
6.2 Packing List.................................................................................................................................................................. 11
6.3 Installation Materials ................................................................................................................................................ 13
6.4 Installation Location................................................................................................................................................. 14
6.5 Installation Options .................................................................................................................................................. 15
6.6 Communications Connections ............................................................................................................................. 18
6.7 Wiring Specification.................................................................................................................................................. 19
6.8 Connecting a single Any-Cell to an Any-Grid.................................................................................................. 20
6.9 Connecting multiple Any-Cells to an Any-Grid............................................................................................... 21
6.10 Battery Terminal Connections............................................................................................................................... 22
7.0 Operation......................................................................................................................................23
7.1 Option A – Default BMS Power Switch............................................................................................................... 23
7.2 Option B – Remote BMS Power Switch Option............................................................................................... 23
7.3 System Startup with Any-Grid .............................................................................................................................. 24
7.4 Safety Shutoff Feature.............................................................................................................................................. 25
8.0 Troubleshooting...........................................................................................................................26
8.1 Any-Cell Warnings ..................................................................................................................................................... 26
8.2 General Issues............................................................................................................................................................. 26
9.0 Specifications................................................................................................................................27
10.0 Warranty........................................................................................................................................28
10.1 Conditions.................................................................................................................................................................... 28
10.2 Liability Exclusion ...................................................................................................................................................... 28

www.phocos.com 2 | P a g e
1.0 Abbreviations
Abbreviations
ESS-L
Energy Storage System-Lithium
BMS
Battery Management System
RoHS
Restriction of Hazardous Substances
AHJ
Authority Having Jurisdiction
2.0 About This Manual
SAVE THESE INSTRUCTIONS: This manual contains important instructions for the Any-Cell ESS-L-5kWh-48V
(referred to as Any-Cell ESS-L) that shall be followed during installation and maintenance of the Any-Cell ESS-
L. Read and save this manual for future reference.
This manual describes how to install the Phocos Any-Cell Energy Storage System LFP Series (ESS-L). Read this manual
before you attempt to install the product and follow the instructions throughout the installation process. If you are
uncertain about any of the requirements, recommendations, or safety procedures described in this manual, contact
Phocos for advice and clarification. The information included in this manual is accurate at the time of publication.
However, with regards to the product design and technical specification updates, our company reserves the right to
make changes at any time without prior notice. In addition, the illustrations in this manual are meant to help explain
system configuration concepts and installation instructions. The illustrated items may differ from the actual items at
the installation location.
3.0 Important Safety Information
For safety reasons, installers are responsible for familiarizing themselves with the contents of this manual and all
warnings before performing installation.
WARNING: The installation of this unit may only be undertaken by qualified personnel with
appropriate training. High voltages in and around the unit can cause serious injury or death. This
unit must be installed in accordance with rules and regulations at the site of installation.
CAUTION: A battery can present a risk of electrical shock, burn from high short-circuit current, fire
or explosion from vented gasses. Observe proper precautions.
General safety precautions
Failure to observe the precautions described in this section can cause serious injury to persons or damage to
property. Please observe the following precautions.
Risks of explosion
Do not subject the Any-Cell ESS-L to strong impacts.
Do not crush or puncture the Any-Cell ESS-L.
Do not dispose of the Any-Cell ESS-L in a fire.
Risks of fire
Do not expose the Any-Cell ESS-L to temperatures in excess of 60°C.

www.phocos.com 3 | P a g e
Do not place the Any-Cell ESS-L near a heat source, such as a fireplace.
Do not expose the Any-Cell ESS-L to direct sunlight.
Do not allow the battery connectors to touch conductive objects such as wires.
Risks of electric shock
Do not disassemble the Any-Cell ESS-L.
Do not touch the Any-Cell ESS-L with wet hands.
Do not expose the Any-Cell ESS-L to moisture or liquids.
Keep the Any-Cell ESS-L away from children and animals.
Risks of damage to the Any-Cell ESS-L
Do not allow the Any-Cell ESS-L to come in contact with liquids.
Do not subject the Any-Cell ESS-L to high pressures.
Do not place any objects on top of the Any-Cell ESS-L.
Battery handling guide
Use the Any-Cell ESS-L only as directed.
Do not use the Any-Cell ESS-L if it is defective, appears cracked, broken or otherwise damaged, or fails to
operate broken or otherwise damaged, or fails to operate.
Do not attempt to open, disassemble, repair, tamper with, or modify the Any-Cell ESS-L. The Any-Cell ESS-L is
not user serviceable.
To protect the Any-Cell ESS-L and its components from damage when transporting, handle with care.
Do not impact, pull, drag, or step on the Any-Cell ESS-L.
Do not subject the Any-Cell ESS-L to any strong force.
Do not insert foreign objects into any part of the Any-Cell ESS-L.
Do not use cleaning solvents to clean the Any-Cell ESS-L.
3.1 Response to emergency situations
The Phocos Any-Cell ESS-L comprises multiple cells that are designed to prevent hazards resulting from failures.
However, Phocos cannot guarantee their absolute safety.
Leaking batteries
WARNING: If the Any-Cell ESS-L leaks electrolyte, avoid contact with the leaking liquid or gas.
Electrolyte is corrosive and contact may cause skin irritation and chemical burns.
If one is exposed to the leaked substance, follow these steps:
•Inhalation: Evacuate the contaminated area and seek medical attention immediately.
•Eye contact: Rinse eyes with flowing water for 15 minutes and seek medical attention immediately.
•Skin contact: Wash the affected area thoroughly with soap and water and seek medical attention immediately.

www.phocos.com 4 | P a g e
•Ingestion: Induce vomiting and seek medical attention immediately.
Fire
In case there is a fire, always have an ABC or carbon dioxide extinguisher.
The Any-Cell ESS-L may catch fire when heated above 150°C.
If a fire breaks out where the Any-Cell ESS-L is installed, follow these steps
•Extinguish the fire before the Any-Cell ESS-L catches fire.
•Refer to your local AHJ to determine the best course of action in cases where it is impossible to extinguish the
fire, but you may have time to move the Any-Cell ESS-L to a safe area before it catches fire.
•If the Any-Cell ESS-L has caught fire, do not try to extinguish the fire. Evacuate the area immediately.
WARNING: If the Any-Cell ESS-L catches fire, it will produce toxic and poisonous gases.
Do not approach.
Wet batteries
If the Any-Cell ESS-L is wet or submerged in water, do not try to access it. First contact the local AHJ for advice on how
to proceed. If the battery has been recovered, and cleared by the AHJ, please reach out to your distributor or Phocos
for technical assistance.
Damaged batteries
WARNING: Damaged batteries are dangerous and must be handled with extreme caution. They
are not fit for use and may pose a danger to people or property.
•If the Any-Cell ESS-L seems to be damaged, take photos, pack it in its original container, and then return it to
your distributor.
•If the Any-Cell ESS-L is damaged, it may leak electrolyte or produce flammable gas. If you suspect your Any-Cell
ESS-L is damaged, immediately contact Phocos for advice and information.
4.0 Regulatory Information
This product is CE and RoHS (Restriction of Hazardous Substances) compliant.
Please find the CE declaration at www.phocos.com.
This equipment is suitable for use in non-hazardous locations only.
IEC62619, UL1973, and UN38.3 Certified.
RoHS

www.phocos.com 5 | P a g e
5.0 Product Overview
The Phocos Any-Cell™ESS-L LFP Series (ESS-L) is a Lithium Iron Phosphate (LiFePO4) battery product with an
integrated BMS (Battery Management System). The Any-Cell ESS-L is shipped with features including CAN
communication, undervoltage, over-voltage, over-current, over-temperature, and under-temperature protection
functions. Users can expect reliable operation with the safety of an LFP system over a long cycle life. Energy storage
systems implementing the Any-Cell ESS-L are expandable; up to 8 Any-Cell products may be used in parallel to
increase storage capacity accordingly. Users can also expect seamless integration of their Any-Cell ESS-L with new
and existing Any-Grid inverters designed for 48V battery systems.
NOTICE: The Any-Cell ESS-L may only be used with the Any-Grid™48V series of hybrid inverters with
accompanying Any-Bridge™AB-PLC-CAN gateway and monitoring device. This device facilitates closed loop
communication between the Any-Grid hybrid inverter and the Any-Cell ESS-L, which is necessary for normal
battery operation. Failure to include an AB-PLC-CAN in the installation of the Any-Cell ESS-L will result in a
non-functioning system.
Please see 7.3 System Startup with Any-Grid for additional details on setting up the Any-Grid ecosystem.

www.phocos.com 6 | P a g e
5.1 Outline and Dimensions
Figure 1.1: Dimensions
Number
Description
①
Front Logo
②
Handle
③
BMS Power Button
④
SOC (State of Charge) & Warning light indicator
⑤
Terminal Entry
The wiring port of the Any-Cell ESS-L is accessed by removing the x4 T15 screws holding the terminal cover plate and
lifting the cover plate from the unit. Please see the following pictures for details.

www.phocos.com 7 | P a g e
Figure 1.2: Terminal cover and Wiring port
Number
Description
Notes
①
Terminal Cover Plate
To cover and protect the electrical connections
②③
Battery+
Positive terminals of battery
④⑤
Battery-
Negative terminals of battery
⑥⑦
CAN1 ports
For battery-to-battery communication when in parallel
⑧⑨
CAN2 ports
For battery to Any-Bridge communication
⑩
Remote port
To enable installation of a remote BMS power switch

www.phocos.com 8 | P a g e
5.2 CAN communication interface pinout (CAN1 & CAN2)
The Any-Cell ESS-L has four modular 8P8C communication connectors for CANbus communication. CAN1 is used
exclusively for battery-to-battery communication between the BMSs of Any-Cell units when in parallel. CAN2 is used
to communicate between the BMS of one or multiple Any-Cells and the Any-Bridge gateway device. For installers
creating custom communication cables, the pinout of an Any-Cell CAN port is shown below.
There is no difference between the two ports labeled CAN1 - they may be used interchangeably, and both connect
to the same CANbus node. The same applies to the two CAN2 ports.
Figure 1.3: CAN interface pinout
Pin Number
Name
①②③
NC
④
CANH
⑤
CANL
⑥⑦⑧
NC
No grounded shield connection is required for proper communication for local cable runs.

www.phocos.com 9 | P a g e
5.3 LED Indicators
Figure 1.4: LED Indicators
Number
Name
LED Operation
①
BMS power button
White light, solid: BMS on
②
100% capacity indicator
Green light, solid: 100% SOC
③
75% capacity indicator
Green light, solid: >75% SOC
④
50% capacity indicator
Green light, solid: >50% SOC
⑤
25% capacity indicator
Green light, solid: >25% SOC
⑥
Warning indicator
Yellow light, solid: Normal
Yellow light, blinking: Warning
The warning indicator will blink when the Any-Cell BMS has encountered an error. See section 8 Troubleshooting for
details.
