Photron FASTCAM ultima APX-i2 User manual

FASTCAM-ultima APX-i2
Hardware Manual
Rev. 1.04
PHOTRON LIMITED
SEP, 2007

FASTCAM-ultima APX-i2 Hardware Manual

FASTCAM-ultima APX-i2 Hardware Manual
-1-
Table of contents
Chapter 1. Introduction.....................................................5
1.1. Preface...........................................................................................6
1.2. Warranty.........................................................................................7
1.3. How to Use This Manual...............................................................8
1.4. Precautions....................................................................................9
Chapter 2. Set Up ............................................................ 12
2.1. To Start.........................................................................................13
2.1.1. Unpacking ..................................................................................... 13
2.1.2. Optional Accessories..................................................................... 13
2.2. Names of Components ...............................................................14
2.2.1. Processor ...................................................................................... 14
2.2.2. Camera Head................................................................................ 15
2.2.3. Remote Control Keypad................................................................ 16
2.2.4. AC `Power Adapter for APX-i2 Camera ........................................ 17
2.2.5. GENERAL IN Cable ...................................................................... 18
2.2.6. GENERAL OUT Cable .................................................................. 19
2.2.7. MCDL / RS422 Cable.................................................................... 20
2.2.8. DC Power-IN Cable....................................................................... 22
2.3. System Connection.....................................................................23
2.3.1. Connecting Camera Head ............................................................ 23
2.3.2. Connecting Remote Control Keypad ............................................ 24
2.3.3. Connecting Video Monitor............................................................. 25
2.3.4. Power Connection......................................................................... 26
2.4. Switching Power on....................................................................27
2.5. Basics of Remote Control Keypad Operation...........................28
2.5.1. Details of Controls on Keypad....................................................... 28
2.5.2. Menu Display ................................................................................ 29
2.5.3. Menu Selection ............................................................................. 29
2.5.4. Canceling Menu Selection ............................................................ 29
2.6. System Setup (Date, Time and Revision)..................................30
2.6.1. Setting Date and Time................................................................... 30
2.6.2. Switching Date / Time ................................................................... 31
2.6.3. Displaying System Revision.......................................................... 32
Chapter 3. Before Recording...........................................34
3.1. Operation of Image Intensifier ...................................................35
3.1.1. I.I. Protection Circuit...................................................................... 35
3.1.2. I.I. (Image Intensifier) menu operation .......................................... 36
3.1.3. Storing settings.............................................................................. 41

FASTCAM-ultima APX-i2 Hardware Manual
-2-
3.1.4. Operation before Recording.......................................................... 42
3.1.5. Switching intensifier off ................................................................. 46
Chapter 4. Recording ......................................................48
4.1. Initialization (Calibration) ...........................................................49
4.1.1. Start Calibration............................................................................. 49
4.1.2. Saving Calibrated Setting ............................................................. 50
4.1.3. Loading Calibrated Settings.......................................................... 50
4.2. Selecting Frame Rate..................................................................51
4.3. Selecting Resolution...................................................................52
4.4. Selecting Shutter Speed.............................................................53
4.4.1. Switching Shutter Speed Steps..................................................... 54
4.4.2. Switching SHUTTER MODE......................................................... 55
4.5. Selecting Trigger Mode...............................................................56
4.5.1. START Mode................................................................................. 57
4.5.2. CENTER Mode ............................................................................. 58
4.5.3. END Mode..................................................................................... 59
4.5.4. MANUAL Mode ............................................................................. 60
4.5.5. RANDOM Mode ............................................................................ 63
4.5.6. RANDOM RESET Mode ............................................................... 66
4.5.7. RANDOM CENTER Mode ............................................................ 68
4.5.8. RANDOM MANUAL Mode ............................................................ 71
4.5.9. DUAL FRAMING RATE Mode....................................................... 75
4.6. Partitioning Memory....................................................................78
4.6.1. Prepare for Memory Partitioning (Set Number of Sections) ......... 78
4.6.2. Recording into Divided Sections ................................................... 79
4.6.3. Playback of Recorded Sections .................................................... 79
4.6.4. PARTITION MODE........................................................................ 79
4.7. Look-Up Table (LUT) Operation .................................................80
4.7.1. Operating Preset LUT ................................................................... 80
4.7.2. Customizing LUT Patterns ............................................................ 83
4.8. Extended Dynamic Range Mode................................................84
4.9. External Trigger Input.................................................................85
4.9.1. Input of External Trigger Signals................................................... 85
4.9.4. Output of Trigger Signals to External Equipment.......................... 87
4.10. Input of External Sync Signals.................................................88
4.10.1. Input of External Sync Signals .................................................... 88
4.10.2. Output of External Sync Signals ................................................. 89
4.10.3. Sync Operation of Multiple APX-i2 Systems............................... 90
4.10.4. Sync Operation with External Equipment ................................... 92
4.10.5. Sync Operation of APX-i2 and Other Models of Cameras.......... 94
4.11. Setting GENERAL IN / OUT Signals.........................................96
4.11.1. Setting GENERAL IN Signals...................................................... 96
4.11.2. Setting GENERAL OUT Signals.................................................. 97
4.12. Event Marker Function..............................................................98

FASTCAM-ultima APX-i2 Hardware Manual
-3-
4.13. MCDL - Multi-Channel Data Link (Data acquisition)...............99
4.14. IRIG Time Code........................................................................100
Chapter 5. Playback ......................................................101
5.1. Playing Recorded Images.........................................................102
5.2. Searching Images of Interest (Fast Forward/Rewind Play) ...103
5.3. Slow Playback (Jog)..................................................................104
5.4. Zooming (Zoom/Fit/Scroll)........................................................105
5.4.1. Fitting Image Frame to Video Screen ......................................... 106
5.4.2. Zooming Playback Image Frame ................................................ 107
5.4.3. Scrolling Playback Image Frame ................................................ 108
5.5. Block Playback (Playback of Clips of Interesting Scenes)....109
5.6. Text Display – Hide / Unhide ....................................................110
5.7. Displaying Crosshair Cursor.................................................... 111
5.8. Switching NTSC / PAL Video Output .......................................112
5.9. Automatic Playback ..................................................................113
5.10. Playback Event Markers.........................................................114
Chapter 6. Connecting APX-i2 to a PC..........................115
6.1. Connecting APX-i2 to a PC.......................................................116
6.1.1. APX-i2 with IEEE1394 Interface ..................................................117
6.1.2. APX-i2 with Ether Interface ..........................................................117
6.1.3. Connection with Optical Interface ................................................118
6.2. Connecting Multiple APX-i2’s to a PC .....................................124
Chapter 7 Specifications...............................................126
7.1. Specifications............................................................................127
7.1.1. Product Specifications................................................................. 127
7.1.2. Image Intensifier (I I) Specification.............................................. 127
7.1.3. Miscellaneous ............................................................................. 128
7.1.4 Accessories .................................................................................. 129
7.1.5. Optional Items ............................................................................. 129
7.1.6. Frame Rates and Resolutions .................................................... 130
7.1.7. Number of Recorded Images vs. Resolution .............................. 132
7.1.8. RS422 Serial Control Commands............................................... 133
7.1.9. STATUS OUT .............................................................................. 139
7.1.10. Shutter Speed Table (COARSE Steps) ..................................... 140
7.2. Mechanical Data........................................................................141
7.2.1. Camera Head (millimeters) ......................................................... 141
7.2.2. Processor (millimeters) ............................................................... 142
7.2.3. Keypad (millimeters) ................................................................... 143
7.3. Care of Lenses ..........................................................................144

FASTCAM-ultima APX-i2 Hardware Manual
-4-
Memo

FASTCAM-ultima APX-i2 Hardware Manual
-5-
Chapter 1. Introduction
1.1. Preface
1.2. Warranty
1.3. How to Use This Manual
1.4. Precautions

FASTCAM-ultima APX-i2 Hardware Manual
-6-
1.1. Preface
The FASTCAM-ultima APX I.I. (Image-Intensified model, referred to as “APX-i2”
hereinafter) High-Speed Video Camera System will prove itself a truly powerful
visualization tool giving solution to engineers and scientists in such fields as general
research and development, designing, manufacturing, quality assurance, scientific
researches, medical and biological researches, space and aeronautics engineering.
With its mega-pixel, ultra-high sensitivity imaging sensor that enables framing under
extremely low level of light, the APX-i2 offers a great basic feature of extremely
high-speed recording. Another outstanding feature is that it promises an excellent
user-friendliness of intuitive recording of subjects moving at a very high speed thanks to
its real-time video output and easy-to-operate keypad-type remote control unit. Also,
the hybrid-design scheme of the APX-i2 makes it possible to seamlessly connect with a
PC via a high-speed digital interface, combined with easy-to-use control software, to
form an image recording and processing system that offers a much easier means for
analyzing captured events immediately, which has been very difficult with conventional
systems.
You will find this new recording technology most useful to capture the image of
high-speed moving subjects for subsequent slow-motion observation and motion
analysis, and image processing applications. This manual presents the technical details
of the APX-i2 system and how to operate it.
Remarks:
1. For the best use of the system, please read through this manual.
2. The content of this manual is based on the best knowledge of the manufacturer.
However, in case any error or missed information is found in this manual, please inform
the manufacturer of such shortcomings. Notwithstanding the above, the manufacturer
is not responsible for any results of the use of this equipment.
3. Copying all or any part of this manual without permission is prohibited.
4. The content of this manual may be changed any time without prior notice.
5. The manufacturer assumes no responsibility for any direct or indirect damages or
loss of profit resulting from the use of this equipment
6. The manufacturer assumes no responsibility for any result of the use of this
equipment.
7. Copying all or any part of the software included in this system without prior written
permission by the author is an infringement of copyright.

FASTCAM-ultima APX-i2 Hardware Manual
-7-
1.2. Warranty
New Equipment Warranty
PHOTRON FASTCAM-ultima APX-i2
PHOTRON LIMITED warrants this PHOTRON FASTCAM-ultima APX-i2 (“APX-i2”) and accessories
manufactured by PHOTRON LIMITED to function properly for one year from the date of shipment, provided the
warranty registration card was filled out and returned to PHOTRON USA, INC. or PHOTRON EUROPE LIMITED
within thirty days of shipment. PHOTRON LIMITED, in conjunction with PHOTRON USA, INC. or PHOTRON
EUROPE LIMITED, agrees to perform the following equipment warranty services:
1. Repair service: If shipped to PHOTRON at any of the addresses shown below, repairs will be made at no
charge.
2. Parts replacement: Replacement parts installed under warranty will be provided at no charge.
Special remarks:
The image intensifier (“II”) tube used in the FASTACAM APX-i2 carries a life
warranty of a period of 12 months after shipment by Photron for defects in
material and workmanship.
Because the II tube is subject to deterioration by use, this warranty is not
applied to the deterioration caused by use even if the tube is within the
warranty period.
The warranty expires twelve (12) months after the date of shipment by
Photron.
THIS WARRANTY DOES NOT APPLY UNDER THE FOLLOWING CONDITIONS:
Failure to operate the APX-i2 in accordance with Photon’s written instructions, including environmental
specifications listed in the User’s Manual.
If there is evidence of the APX-i2 being subjected to accidental damage, misuse or abuse.
If the APX-i2 has been repaired or tampered with by persons other than PHOTRON personnel, customer
personnel trained by PHOTRON or without permission of PHOTRON.
Shipping damage is not covered by this warranty. The purchaser has the responsibility to place a claim of
damage in shipment with the carrier.
PHOTRON LIMITED makes no other warranties, express or implied, including the implied warranties of
merchantability and fitness for a particular purpose. If this APX-i2 does not function properly during the warranty
period, PHOTRON LIMITED will repair it without charge according to the terms stated above. Repair without
charge is PHOTRON LIMITED’s only obligation under this warranty. PHOTRON LIMITED, PHOTRON USA, INC.
or PHOTRON EUROPE LIMITED will not be responsible for any consequential or incidental damages resulting
from the sale, use or improper functioning of this equipment even if loss or damage is caused by the negligence
or other fault of PHOTRON LIMITED, PHOTRON USA, INC. or PHOTRON EUROPE LIMITED.
Return the equipment that needs warranty service to:
In Americas & Antipodes
PHOTRON USA, INC.
9520 Padgett Street
Suite 110
San Diego, CA 92126-4446
USA
Phone: [phone]
Fax: [phone]
E-mail:[email protected]
www.photron.com
In Europe:
PHOTRON EUROPE LTD.
Willowbank House
84 Station Road
Marlow, Bucks SL7 1NX
U. K.
Phone:[phone]
Fax: [phone]
E-mail:[email protected]
www.photron.com
In other areas:
PHOTRON LIMITED
Fujimi 1-1-8, Chiyoda-Ku
Tokyo 102-0071
Japan
Phone: [phone]
Fax: [phone]
E-mail:[email protected]
www.photron.co.jp

FASTCAM-ultima APX-i2 Hardware Manual
-8-
1.3. How to Use This Manual
DEFINITION OF TERMS
You will notice that some of the information in this manual is presented as a NOTE,
CAUTION or WARNING. It is important that you understand the significance of these
three terms. For safe operation of the system, please follow the safety instructions
below:
“Note” includes information that should be emphasized regarding the operation of the
APX-i2.
“Caution” includes important information regarding operation. If it is neglected and the
equipment is used in the wrong manner, damage may be caused to the content of
recording, the equipment and related peripheral devices.
“Warning” presents very important information regarding safety of the operators. If it is
neglected and the equipment is used in the wrong manner, a serious hazardous
sequence involving human injury or death may result. It must not be disregarded.
Chapters
This manual is divided into six chapters each discussing subject matters related to its
chapter title.
Chapter 1. Introduction
Contains Warranty, precautions, introduction and how to use this manual.
Chapter 2. Set Up
Introduces you to the components of the APX-i2 and explains the use of each
connector, keypad operation and parameter settings to make ready for recording.
Chapter 3. Recording
Explains the operation of the APX-i2 for recording.
Chapter 4. Playback
Discusses playback of recorded images and filing image data.
Chapter 5. Connection to a PC
Shows how to connect and operate the APX-i2 to a PC (Operation of the APX-i2 from
PC is discussed in the PFV Software Manual).
Chapter 6. Specifications
Provides detailed specifications of the APX-i2 system.

FASTCAM-ultima APX-i2 Hardware Manual
-9-
1.4. Precautions
Ambient Temperature
Photron FASTCAM-ultima APX-i2 has been designed to work properly in an ambient
temperature range of 0 to 35 degrees Celsius (32 to 95 degrees Fahrenheit), no
condensation.
Storage Temperature
The APX-i2 must be stored in a place with an ambient temperature range of -20 to +70
degrees Celsius (-4 to +158 degrees Fahrenheit), no condensation.
Transportation
Save the original carton the unit came in for future transportation.
Do not apply excessive shocks or vibration during transportation, storage or operation.
The image intensifier has a glass tube that is fragile and operates at a high degree of
vacuum. Excessive shocks or vibration may cause failures or malfunctions.
Do not transport the unit under ambient temperature of below -20 degrees Celsius (-4
degrees Fahrenheit) or above 70 degrees Celsius (+158 degrees Fahrenheit).
No condensation should be allowed during transportation, storage or operation.
FEDERAL COMMUNICATIONS COMMISSION STATEMENTS
WARNING: This equipment generates, uses and can radiate radio frequency energy
and if not installed and used in accordance with the instruction manual, may cause
interference to radio communications. It has been tested and found to comply with the
limits for a Class computing device pursuant to Subpart A of Part 15 of the FCC Rules
and VDE 0871 Class B which are designed to provide reasonable protection against
such interference when operated in a commercial environment. Operation of this
equipment in a residential area is likely to cause interference in which case the user at
his own expense will be required to take whatever measures may be required to correct
the interference.
This device complies with Part 15 of the FCC Rules and VDE 0871. Operation is
subject to the following two conditions: (1) this equipment may cause harmful
interference, and (2) this equipment must accept any interference received including
interference that may cause undesired operation.
WARNING
This product is grounded through the power cord. This protective ground connection is
essential for safe operation of the equipment. Avoid electrical shock by plugging the
power cord into a properly wired power outlet. A loss of the protective grounding, for
any reason, could result in electrical shock. Use the proper power cord and insure that
it is in good condition.
Do not touch or allow any object to come in contact with the input window of the image
intensifier at any time. The input window can be easily damaged and electrical shocks
(static discharge) or failures may result. Never attempt to touch an internal part of
image intensifier while it is in operation.
CAUTIONS
The Image intensifiers is an extremely sensitive optical device. When operating the
system, exercise caution to gradually increase light falling on the light-entrance window

FASTCAM-ultima APX-i2 Hardware Manual
-10-
of the intensifier surface by slowly opening the lens iris starting at the largest f-stop (f32
or f16) of the lens. Slowly open the lens iris and watch the image brightness, while
viewing live image on the monitor, until an optimum level of brightness is reached.
Do not expose the light-entrance window (the intensifier’s front surface) to strong light,
such as sun light, while operating or storing the intensifier. Bright light falling on the
light-entrance window of the image intensifier surface, even when the device is not
operating, can damage the image intensifier. Always store the camera head with an
appropriate body cap or lens and lens cap in place when not in use.
Operating the image intensifier while it is exposed to bright light (e.g. ambient room
illumination) will cause serious damage to the intensifier’s photocathode.
Always adjust the intensifier (and camera) while watching live image on the
monitor.
Switch the intensifier off when done with a recording or test. Avoid exposing the
light-entrance window of the intensifier to bright light while changing lenses
regardless of whether the intensifier is powered. The intensifier tube can be
damaged by excessive light with or without power on.
If a lens whose iris does not completely close is used, install a lens cap to avoid
exposing the intensifier to excessive light while not in use.
When installing the image-intensified camera on a microscope, make sure there is
no leakage of light from other than the microscope’s light source.

FASTCAM-ultima APX-i2 Hardware Manual
-11-
Memo

FASTCAM-ultima APX-i2 Hardware Manual
-12-
Chapter 2. Set Up
2.1. To Start
2.2. Names of Components
2.3. System Connection
2.4. Switching power on
2.5. Basics of Remote Control Keypad Operation
2.5. System Setup

FASTCAM-ultima APX-i2 Hardware Manual
-13-
2.1. To Start
2.1.1. Unpacking
The APX system consists of the following items. Make sure if all the components are
found in the package.
1. Camera Head 1 ea.
2. Processor 1 ea.
3. Remote Control Keypad 1 ea.
4. AC Power Adapter (attached to processor unit)/AC Cable 1 ea.
5. AC Power Adapter for II Camera 1 ea.
6. Camera Cable (5 meters long) 1 ea.
7. C-Mount Lens Adapter 1 ea.
8. Allen Wrench for Changing Lens Mount 1 ea.
9. Lens Mount Cap 1 ea.
10. GENERAL IN Cable 1 ea.
11. GENERAL OUT Cable 1.ea.
12. MCDL/IRIG Compound Cable 1 ea.
13. Ferrite Core for Cable 1 ea.
14. CD-ROM for Driver/Application Setup 1 ea.
15. FASTCAM-ultima APX-i2 Hardware Manual 1 ea.
16. FASTCAM Control Software Operation Manual 1 ea.
17. Warranty Registration Card 1 ea.
18. CD-ROM for I.I. Data Storage 1 ea.
19. Optical PCI Interface Board 1 ea.
20. Optical Cables (5 meters long) 2 units
Note: Items 19 and 20 are for APX-i2 with optical interface only.
Note: Item 19, the optical cable is a single mode fiber cable 9/125 micrometers SMF (5
meters long).
2.1.2. Optional Accessories
The following optional items are available for the APX-i2:
1. Additional Memory Unit (to be installed at factory only)
2. IEEE1394 Optical Link (IEEE1394 Optical fiber extension unit)

FASTCAM-ultima APX-i2 Hardware Manual
-14-
2.2. Names of Components
The APX system consists of a processor, camera head, remote-control keypad and
control software.
2.2.1. Processor
The APX processor is designed to have a set of IC memory with a capacity of 2.6GB,
standard, and a maximum of 8GB, to store non-compressed digital data of high-speed
recorded images. The processor has a video output connector to display the recorded
images on the video monitor, an IEEE1394 digital interface to control the camera from a
PC and download recorded image data, input and output connectors for external sync
and trigger signals, and a port to accept IRIG time code and MCDL analog waveform
signals.
Names of Components
No. Name No. Name
1 Camera Cable Connector 1 8 MCDL/RS422 Connector
2 Camera Cable Connector 2 9 DC Power IN Connector
3 IEEE1394 Interface Connector 10 DC Power OUT Cable
4 Remote Control Keypad
Connector
11 Fuse Box
5 GENERAL IN Connector 12 AC Power IN Connector
6 GENERAL OUT Connector 13 AC Power Switch
7 VIDEO OUT Connector
Ｋ
ＦＵＳＥ ＲＡＴＩＮ Ｇ： ２５０Ｖ Ｔ２Ｈ Ａ
ＤＣ１２Ｖ ＊．＊Ａ
ＡＣ ＩＮ
ＰＯＷＥＲ
ＭＣＤＬ
ＲＳ４２２
ＶＩＤＥＯ
ＯＵＴ
ＩＮ
ＯＵＴ
ＧＥＮＥＲＡＬ
ＦＵＳＥ
ＤＣ ＯＵＴ
ＲＥＭＯＴＥ
ＤＣ
ＰＯＷＥＲ
34
5
6
7
8
10
11
12
13
9
1
2

FASTCAM-ultima APX-i2 Hardware Manual
-15-
2.2.2. Camera Head
The light-weight and compact-sized APX camera head has been designed for ease of
handling under various recording conditions and environments. The lens mount can be
selected from C-type or F-type to the user’s application. The camera head has
tripod-mounting screw holes on its base plate.
ＯＵＴ
ＭＯＮＩＴ ＯＲ
ＩＮ
ＥＸＴＥＲＮＡＬ
ＯＮ
ＯＦＦ
ＰＯＷＥＲ
１２
ＭＯＤＥＬ
ＳＥＲＩＡＬ ＮＯ．
ＰＲＯＴＥ ＣＴ
ＯＮ２ＯＦＦ ＯＮ１ ＤＣ５Ｖ ５Ａ
No. Description
1 Camera cable connector 1 (connects to processor)
2 Camera cable connector 2 (connects to processor)
3 Cable clamp (clamps AC adapter cable)
4 DC-IN connector (from AC power adapter)
5
6
Protection mode SW (with yellow LED)
MONITOR OUT (Gate pulse, BNC connector)
7 EXTERNAL IN (Gate pulse, BNC connector)
8 Power ON/OFF switch (with green LED)
9 Lens mount
10 Tripod mounting screw holes
① ②
③
④ ⑤ ⑥ ⑦
⑧
⑨
⑩

FASTCAM-ultima APX-i2 Hardware Manual
-16-
2.2.3. Remote Control Keypad
The APX Remote Control Keypad connects to the processor and controls all the
functions of the camera system. The keypad is of “hot-plug” type and can be connected
or disconnected with power on.
Connector on
Processor Signal Connector Model
(On Processor)
Connector Model
(On Keypad)
REMOTE Remote Keypad
Signal
HR10A-10R-12SC
(Hirose)
HR10A-10P-12P
(Hirose)
ＢＬＯＣＫ
ＥＮ ＤＯＮ／Ｏ ＦＦＳＴＡＲＴ
ＲＥＣＲＥＣ
ＲＥ Ｃ ＲＥ ＡＤ Ｙ
ＰＵＳＨ
ＥＮＴＥＲ
ＳＴＯＰ
ＰＡＲＴＩＴＩ ＯＮ
ＲＡ ＴＥ
ＤＩＳＰＬＡＹ
ＰＡＵＳＥ
ＦＦＰＬ ＡＹＲＥＶＦＲ
ＬＩＶＥ
ＭＥＭＯＲＹ
ＭＥＮＵ ＺＯＯ Ｍ
ＳＣＲＯＬＬ
ＦＩＴ
ＳＴ ＯＲ Ｅ
ＦＲＡＭ Ｅ ＲＡ ＴＥ ＳＨ ＵＴ ＴＥ Ｒ ＲＥ ＳＯ ＬＵＴＩ ＯＮ ＴＲ ＩＧ ＧＥ Ｒ
ＰＡＲＴＩＴＩ ＯＮ
ＲＡ ＴＥ
ＤＩＳＰＬＡＹ
ＳＴ ＯＰ
ＰＡＵＳＥ
ＦＦＰＬ ＡＹＲＥＶＦＲ

FASTCAM-ultima APX-i2 Hardware Manual
-17-
2.2.4. AC `Power Adapter for APX-i2 Camera
Connect the DC power supply plug from the AC power supply adapter to the DC-IN jack
on the back of the camera. Use the cable clamp mounted on the side of the camera to
hold the cable securely.
AC cable connector
Plug: RC6705 (center positive)
Connect to DC-IN jack on
the back of the camera.
DC power plug
Use this cable clamp to hold the DC power cable
securely.

FASTCAM-ultima APX-i2 Hardware Manual
-18-
2.2.5. GENERAL IN Cable
The APX can be used as an integral part of a testing system by its capability to work in
sync with external trigger and sync signals from other devices and equipment within the
system. The processor has a GENERAL IN connector on its rear panel, which
combines relevant input signal lines into one connector.
【GENERAL IN Pins】
1
2
3
456
7
8
9
10
11 12
HR10A-10TR-12PB (Hirose)
Connector
Name Signal Name Pin No.
Connector on
Processor
Model
(Manufacturer)
Connector on
Cable
Model
(Manufacturer)
Input
Connect
ors
Trigger SW
IN 1
GND 2
BNC
Trigger TTL
IN 3
GND 4
BNC
EXT_V IN 5
GND 6 BNC
General IN 7
GND 8 BNC
IRIG IN 9
GENERAL
IN
GND 10
HR10A-10TR-12
PB (Hirose)
HR10A-10TPA-
12S
(Hirose)
BNC
IRIG IN
TRIGGER SW IN
TRIGGER TTL IN
GENERAL IN
EXT_V IN
GENERAL IN
