Phytec phyCORE-PXA270 User manual

A product of a PHYTEC Technology Holding company
Carrier Board for
phyCORE-PXA270
Hardware Manual
PCB# 1220.3
Edition February 2006

Carrier Board phyCORE-PXA270
©PHYTEC Messtechnik GmbH 2006 L-668e_1
In this manual are descriptions for copyrighted products that are not explicitly
indicated as such. The absence of the trademark (™) and copyright (©) symbols
does not imply that a product is not protected. Additionally, registered patents and
trademarks are similarly not expressly indicated in this manual.
The information in this document has been carefully checked and is believed to be
entirely reliable. However, PHYTEC Messtechnik GmbH assumes no
responsibility for any inaccuracies. PHYTEC Messtechnik GmbH neither gives
any guarantee nor accepts any liability whatsoever for consequential damages
resulting from the use of this manual or its associated product. PHYTEC
Messtechnik GmbH reserves the right to alter the information contained herein
without prior notification and accepts no responsibility for any damages which
might result.
Additionally, PHYTEC Messtechnik GmbH offers no guarantee nor accepts any
liability for damages arising from the improper usage or improper installation of
the hardware or software. PHYTEC Messtechnik GmbH further reserves the right
to alter the layout and/or design of the hardware without prior notification and
accepts no liability for doing so.
©Copyright 2006 PHYTEC Messtechnik GmbH, D-55129 Mainz.
Rights - including those of translation, reprint, broadcast, photomechanical or
similar reproduction and storage or processing in computer systems, in whole or
in part - are reserved. No reproduction may occur without the express written
consent from PHYTEC Messtechnik GmbH.
EUROPE NORTH AMERICA
Address: PHYTEC Technologie Holding AG
Robert-Koch-Str. 39
D-55129 Mainz
GERMANY
PHYTEC America LLC
203 Parfitt Way SW, Suite G100
Bainbridge Island, WA 98110
USA
Ordering
Information: [phone]
[email protected] 1 [phone] [email protected]
Technical
Support: [phone]
[email protected] 1 [phone] [email protected]
Fax: [phone] [phone]
Web Site: http://www.phytec.de http://www.phytec.com
1st Edition February 2006

Contents
©PHYTEC Meßtechnik GmbH 2006 L-668e_1
Preface...........................................................................................................1
1 Introduction.........................................................................................3
1.1 Block Diagram .............................................................................5
1.2 Overview......................................................................................6
2 Port Pin Initialization.........................................................................9
3 Jumpers..............................................................................................13
4 Power Supply System .......................................................................15
5 Memory Configuration.....................................................................19
5.1 Interrupts ....................................................................................20
5.2 Control PLD (U7).......................................................................21
5.2.1 Control PLD (U7) Registers .........................................22
5.2.2 External Data and Address Bus ....................................30
5.3 IDE Interface and CF Card PLD (U6) .......................................31
5.3.1 IDE Interface.................................................................32
5.3.2 Compact Flash Interface ...............................................37
6 Ethernet Interface.............................................................................43
7 USB Host............................................................................................45
8 USB Client .........................................................................................47
9 LCD Interface....................................................................................49
10 RS-232 Interface................................................................................53
10.1 FF-UART ...................................................................................54
10.2 BT-UART...................................................................................55
10.3 IR-UART....................................................................................55
11 CAN Interface ...................................................................................57
12 AC97 Interface and Touch Controller............................................59
13 Quick Capture Interface ..................................................................63
14 MultiMedia Card..............................................................................65
15 Expansion Board...............................................................................67
16 Push Buttons and LEDs....................................................................71
17 Matrix Keyboard ..............................................................................73
18 GPIO Expansion Board Interface...................................................75
19 JTAG Interface (X29).......................................................................93
20 Technical Specifications ...................................................................95
21 Hints for Handling the Module........................................................97
22 Component Placement Diagram......................................................98
23 Revision History................................................................................99
Index..........................................................................................................101

Carrier Board phyCORE-PXA270
©PHYTEC Messtechnik GmbH 2006 L-668e_1
Index of Figures
Figure 1: Block Diagram of the Carrier Board......................................... 5
Figure 2: Carrier Board Overview (Top View)........................................ 6
Figure 3: Carrier Board Overview (Connector Side View)...................... 6
Figure 4: Expansion Board Overview (Top View) .................................. 7
Figure 5: Expansion Board Overview (Side View).................................. 7
Figure 6: Numbering of the Jumper Pads............................................... 13
Figure 7: Location of the Jumpers (Carrier Board)................................ 13
Figure 8: Location of the Jumpers (Expansion Board) .......................... 14
Figure 9: Power Supply Block Diagram................................................. 16
Figure 10: Battery Charger Circuitry........................................................ 17
Figure 11: VBAT Supply ......................................................................... 18
Figure 12: Control PLD U7...................................................................... 21
Figure 13: Decoupling the Data and Address Bus ................................... 30
Figure 14: CF Card and IDE Control PLD U6......................................... 31
Figure 15: IDE Hard Drive Mounting Location....................................... 32
Figure 16: IDE Circuitry........................................................................... 33
Figure 17: Compact Flash Interface on the Expansion Board.................. 37
Figure 18: Compact Flash Circuitry......................................................... 37
Figure 19: Ethernet Circuitry.................................................................... 43
Figure 20: Location of the Ethernet Socket.............................................. 43
Figure 21: USB Host Connector............................................................... 45
Figure 22: Location of the USB OTG Socket .......................................... 45
Figure 23: USB Client Connector ............................................................ 47
Figure 24: Active TFT LCD Connection ................................................. 49
Figure 25: LCD Inverter Circuitry............................................................ 51
Figure 26: RS-232 Connectors (FF-UART, BT-UART) ......................... 53
Figure 27: IR-UART Connector............................................................... 53

Contents
©PHYTEC Meßtechnik GmbH 2006 L-668e_1
Figure 28: P1 Pin Assignment, FF-UART................................................54
Figure 29: P2 Pin Assignment, BT-UART...............................................55
Figure 30: CAN Connector.......................................................................57
Figure 31: CAN Connector P3 Pinout......................................................58
Figure 32: Sound and Touch Controller Interfaces ..................................59
Figure 33: AC97 with WM9712L ............................................................60
Figure 34: MultiMedia Card.....................................................................65
Figure 35: Expansion Board, Top View...................................................67
Figure 36: Expansion Board, Side View ..................................................67
Figure 37: Location of Push Buttons and LEDs (Expansion Board) .......71
Figure 38: Location of Push Buttons and LEDs (Top View)...................72
Figure 39: Matrix Keyboard Connection..................................................73
Figure 40: GPIO Expansion Bus Numbering Scheme .............................75
Figure 41: Physical Dimensions (Carrier Board) .....................................95
Figure 42: Physical Dimensions (Expansion Board)................................96
Figure 43: Component Placement Diagram Carrier Board
(PCB Revision 1220.3) ...........................................................98
Figure 44: Component Placement Diagram Expansion Board.................98
Index of Tables
Table 1: Port Configuration GPIO0-39....................................................10
Table 2: Port Configuration GPIO40-80..................................................11
Table 3: Port Configuration GPIO80-121................................................12
Table 4: Jumper Functions and Section Reference..................................14
Table 5: Interrupt Assignment phyCORE-PXA270.................................20
Table 6: Interrupt Assignment Carrier Board...........................................20
Table 7: Control PLD U7 Overview and Reset Values ...........................22
Table 8: PLD U7 Control Register 0........................................................23
Table 9: PLD U7 Control Register 1........................................................23

Carrier Board phyCORE-PXA270
©PHYTEC Messtechnik GmbH 2006 L-668e_1
Table 10: PLD U7 Control Register 2........................................................ 24
Table 11: PLD U7 Control Register 3........................................................ 24
Table 12: PLD U7 Control Register 4........................................................ 25
Table 13: PLD U7 Control Register 5........................................................ 25
Table 14: PLD U7 Control Registers 6 and 7............................................ 26
Table 15: PLD U7 Control Register 8........................................................ 27
Table 16: PLD U7 Control Register 9........................................................ 28
Table 17: PLD U7 Control Register 10...................................................... 29
Table 18: PLD U7 Control Register 11...................................................... 29
Table 19: IDE Control Register with Reset Values................................... 33
Table 20: IDE Control Register 0 .............................................................. 33
Table 21: IDE Control Register 1 .............................................................. 34
Table 22: IDE Control Register 2 .............................................................. 34
Table 23: IDE Control Register 3 .............................................................. 35
Table 24: IDE Control Register 4 .............................................................. 35
Table 25: TrueIDE Memory Area Assignment.......................................... 36
Table 26: Physical Address Range of the IDE Interface ........................... 36
Table 27: CF Card Control Register with Reset Values............................ 38
Table 28: CF Card Control Register 0 ....................................................... 38
Table 29: CF Card Control Register 1 ....................................................... 39
Table 30: CF Card Control Register 2 ....................................................... 39
Table 31: CF Card Control Register 3 ....................................................... 40
Table 32: CF Card Control Register 4 ....................................................... 40
Table 33: CF Card Control Register 5 ....................................................... 41
Table 34: CF Card Control Register 6 ....................................................... 41
Table 35: Address Space for Ethernet Controller...................................... 44
Table 36: USB Host Jumpers..................................................................... 46
Table 37: LCD Jumpers ............................................................................. 50
Table 38: LCD Connector at X33.............................................................. 50

Contents
©PHYTEC Meßtechnik GmbH 2006 L-668e_1
Table 39: BT-UART Jumper Configuration ..............................................55
Table 40: IR-UART Connector at X19......................................................56
Table 41: IR-UART Jumper Configuration ...............................................56
Table 42: GPS Module Jumper Configuration...........................................56
Table 43: IR-UART Jumper Configuration for GPS Modul .....................56
Table 44: CAN Interface Jumper Configuration........................................57
Table 45: AC97 Expansion Socket at X24.................................................59
Table 46: Voltage Supervision with WM9712L........................................61
Table 47: Sound Jacks................................................................................61
Table 48: Quick Capture Interface Connector ...........................................64
Table 49: Quick Capture Interface Jumpers...............................................64
Table 50: Expansion Board Connector X30 Pinout...................................68
Table 51: Expansion Board Connector X31 Pinout...................................69
Table 52: Expansion Board LED Functions ..............................................71
Table 53: GPIO Expansion Bus X17 Pin Assignment...............................83
Table 54: Signal Pin Assignment for the phyCORE-PXA270 /
Carrier Board / Expansion Board..............................................91
Table 55: JTAG Connector X29 Pinout.....................................................93

Carrier Board phyCORE-PXA270
©PHYTEC Messtechnik GmbH 2006 L-668e_1

Preface
Preface
This manual describes only the functions of the PHYTEC
phyCORE-PXA270 Carrier Board. The controllers and relevant Single
Board Computers for use with the Carrier Board are not described
herein. Additional controller- and board-level information and
technical descriptions can be found in appropriate Hardware Manual
or User's Manual support documentation. If software is included
please also refer to additional documentation for this software.
In this hardware manual and in the attached schematics, low active
signals are denoted by a "/" in front of the signal name (i.e.: /RD). A
"0" indicates a logic-zero or low-level signal, while a "1" represents a
logic-one or high-level signal.
Declaration regarding Electro Magnetic Conformity
of the phyCORE-PXA270 Carrier Board
PHYTEC Carrier Boards (henceforth products) are designed for
installation in electrical appliances or as dedicated Evaluation Boards
(i.e.: for use as a test and prototype platform for hardware/software
development) in laboratory environments.
Note:
PHYTEC products lacking protective enclosures are subject to
damage by ESD and, hence, may only be unpacked, handled or
operated in environments in which sufficient precautionary measures
have been taken in respect to ESD dangers. It is also necessary that
only appropriately trained personnel (such as electricians, technicians
and engineers) handle and/or operate these products. Moreover,
PHYTEC products should not be operated without protection circuitry
if connections to the product's pin header rows are longer than 3 m.
©PHYTEC Meßtechnik GmbH 2006 L-668e_1 1

Carrier Board phyCORE-PXA270
2©PHYTEC Meßtechnik GmbH 2006 L-668e_1
PHYTEC products fulfill the norms of the European Union's Directive
for Electro Magnetic Conformity only in accordance to the
descriptions and rules of usage indicated in this hardware manual
(particularly in respect to the pin header rows or connectors, power
connector and serial interface to a host-PC).
Implementation of PHYTEC products into target devices, as well as
user modifications and extensions of PHYTEC products, is subject to
renewed establishment of conformity to, and certification of, Electro
Magnetic Directives. Users should ensure conformance following any
modifications to the products as well as implementation of the
products into target systems.
The phyCORE-PXA270 Carrier Board is one of a series of PHYTEC
Carrier Boards supporting the phyCORE-PXA270 Single Board
Computer module. PHYTEC supports common 8-, 16- and selected
32-bit controllers on two types of Single Boards Computers:
(1) as the basis for Rapid Development Kits which serve as a
reference and evaluation platform
(2) as insert-ready, fully functional micro-, mini- and phyCORE
OEM modules, which can be embedded directly into the user's
peripheral hardware, design.
PHYTEC's microcontroller modules allow engineers to shorten
development horizons, reduce design costs and speed project concepts
from design to market.

Introduction
©PHYTEC Meßtechnik GmbH 2006 L-668e_1 3
1Introduction
The Carrier Board phyCORE-PXA270 is a universal carrier board for
start-up and programming of the PHYTEC
phyCORE-PXA270 Single Board Computer module with two high
density SMT (160 pins each, 0.63 mm pitch) pin header connectors.
The Carrier Board is fully equipped with all mechanical and electrical
components necessary for the speedy and secure insertion and
subsequent programming of the high-density PHYTEC phyCORE
module. These components include TFT display connection, touch
screen interface, Ethernet transformer and connector, DB-9, USB and
power socket connectors.
The phyCORE module can be plugged like a "big chip" onto the
Carrier Board's mating Molex connectors. Once programmed, the
phyCORE module can be removed from the Carrier Board and
inserted like a "big chip" in a target hardware application. Given the
compact nature of the Carrier Board use of the complete hardware
platform as OEM part in human-machine-interface (HMI) applications
is also possible.
The hardware manual for this Carrier Board does not describe the
features and functions of the phyCORE-PXA270 SBC module, as this
is not relevant for the basic functioning of the Carrier Board. For
module and controller-specific features please refer to the
corresponding Hardware Manuals/User’s Manuals.

Carrier Board phyCORE-PXA270
4©PHYTEC Meßtechnik GmbH 2006 L-668e_1
The Carrier Board offers the following features:
•Molex connectors for mating with phyCORE-PXA270 SBC
module
•Connector for 8.4" Sharp TFT display with 640*480 pixel
resolution, incl. adjustable inverter for background illumination
•AC97 controller WM9712L with touch and sound interface (Line-
IN, Line-OUT, MIC-IN and 0.4 watts speaker)
•Two DB-9 sockets for RS-232 interface from FF-UART and
BT-UART, 2*5 pin header for IR-UART
•One DB-9 plug for CAN interface, optical isolation
•RJ-45 Ethernet connector with transformer for 100/10 MBit/s
•USB host socket for PXA270 USB host interface
•USB client socket for PXA270 USB client interface
•Power supply for unregulated input voltage from 12 V (optional
24 V). It supplies regulated +3.3 V for the
phyCORE-PXA270. Additional +5 V is created for the IDE and CF
card and LCD/inverter circuitry.
•Optional battery charger circuitry for NiMH batteries
•Power magement for MMC, CF, IDE and LC display
•Two user programmable LEDs
•Optional IDE interface for two 2.5" hard disks (Master / Slave)
•Interface for matrix keyboards
•JTAG interface
•AC97 expansion port
•Reset and GPIO push button
Expansion Board with:
•1* MultiMedia card
•1* Compact Flash
•1* Reset button
•1* GPIO button
•1* USB-OTG socket for PXA270 USB interface
•4* LEDs via PLD GPIOs

Introduction
1.1 Block Diagram
p h y C O R E - P X A 2 5 0
X 5
C O M P A C T - F L A S H
F r o n t p l a t i n e
p h y C O R E - P X A 2 7 0
X 2 0
I D E 2 , 5 "
X 2
M M C P I O - T a s t e r
S 2
R e s e t
S w i t c h
X 1 7 P o r t
x D A T A
x A D D R E S
P C M C I A
DATA/ADDR x D A T A / x A D D R
X 1
U S B - O T
L E D D 1 - D 5
S 1
P I O
S w i t c h
C o n t r o l P L D
S 1
P I O - T a s t e r
P I O
I n v e r t e r
P W M 0
5 V
T F T - L C D
6 4 0 * 4 8 0
L C D R B + P i x e l + F r a m e + L i n e + E n a b l e
U 4 8
W M 9 7 1 2 L
A C 9 7
X 2 6 - X 2 8
L i n e I N / O U T
M I C
T o u c h
A u d i o
X 2 1
2 * U S B H o s t
2 * U S B
X 2 2
U S B C l i e n t
P X A 2 5 5 U S B C l i e n t
U 4 5
O p t o P 3
C A N
C A N - H / - L
C A N _ R x D / C A N _ T x D
P 1 , P 2
2 * R S 2 3 2
F F - U A R T
U 4 2 R S 2 3 2
B T - U A R T I R - U A R T
X 1 8
A C 9 7 C o n n e c t
P o w e r
3 , 3 V V C C
5 V S y s t e m
5 V L C D
3 V L C D
X 3 4
M a t r i x
K e y b o a r d
E P I O 0 . . 2 3
X 1
P o w e r
C o n n e c t
3 . 3 V
5 V
5 V L C D
1 2 V
S 2
R e s e t
S w i t c h
R E S E T
U 4 6
C A N
D r i v e
3 , 3 V L C D
I D E / C F P L D
U 4 3
U S B P o w e r
X 2 3
1 0 / 1 0 0
E t h e r n e t
E t h e r n e t
X 1 9 I R - U A R T
X 2 9
J T A
S p e a k e r
S p e a k e r
1 2 V A K K U
C o n t r o l
N i M H
L i g t h
Figure 1: Block Diagram of the Carrier Board
©PHYTEC Meßtechnik GmbH 2006 L-668e_1 5

Carrier Board phyCORE-PXA270
1.2 Overview
AC97 OUT
AC97 IN
AC97 MIC
FF-UART
AC97-Connector
CAN USB
HOST USB
Client Ethernet
POWER
X30 X31
SPEAKER
JTAG
IrDA
GOLD
CAP
X17 A/B X17 C/D
phyCORE-PXA270
LIGHT
SW
GPIO SW RES
KEYBOARD
BT-UART
GPS
BT-TTL
INVERTER
QUICK CAPTURE
TFT CONNECTOR
X33
IDE CONNECTOR
IDE TFT
VCC
VBAT
5V
RUN
USER
BUSY
MMC1___2
CF
GPS
CAN
Figure 2: Carrier Board Overview (Top View)
OUT FF-UART CAN
USB
HOST USB
Client Ethernet POWER
BT-UART
IN MIC
A
B
TOUCH
TFT-DISPLAY
TOUCH
RESET
Figure 3: Carrier Board Overview (Connector Side View)
6©PHYTEC Meßtechnik GmbH 2006 L-668e_1

Introduction
MultiMedia Card
CompactFlash Card D5 D4 D2 D1
Reset Botton
GPIO Botton
USB
OTG
X3 Connector to Base Board
X4 Connector to Base Board
D3
SOUND
Figure 4: Expansion Board Overview (Top View)
USB
OTG
MultiMedia Card
CompactFlash Card
D5 D4 D2 D1
Taster Botto
n
GPIO Botton
D3
Sound
Figure 5: Expansion Board Overview (Side View)
©PHYTEC Meßtechnik GmbH 2006 L-668e_1 7

Carrier Board phyCORE-PXA270
8©PHYTEC Meßtechnik GmbH 2006 L-668e_1

Port Pin Initialization
©PHYTEC Meßtechnik GmbH 2006 L-668e_1 9
2Port Pin Initialization
The Intel PXA270 controller provides a wide variety of chip-level
features that are routed to GPIO pins with alternative functions. The
following functions are used on the phyCORE-PXA270 Carrier
Board:
•MMC Card 0/1
•PCMCIA interface
•16-bit LCD interface
•AC97 interface
•FF-UART, BT-UART and IR-UART
•SSP and NSSP
•I²C bus
•USB client and host
Either the operating system installed on the phyCORE-PXA270 or the
boot loader (e.g. U-Boot) must initialize the GPIO port pins in
questions as shown in the table below:

Carrier Board phyCORE-PXA270
10 ©PHYTEC Meßtechnik GmbH 2006 L-668e_1
Port I/O Configured as
GPIO0 I GPIO 0 (INT RTC)
GPIO1 I GPIO 1 (WAKE UP)
GPIO21I SYS_ENA
GPIO3 I PWR_SCL
GPIO4 I PWR_SDA
GPIO5 I POWER_CAP0
GPIO6 I POWER_CAP1
GPIO7 I POWER_CAP2
GPIO8 I POWER_CAP3
GPIO9 I GPIO9
GPIO10 I GPIO10
GPIO11 I GPIO11
GPIO12 I GPIO12
GPIO13 I GPIO13
GPIO14 I GPIO14 (L_VSYNC)
GPIO15 O /CS1
GPIO16 O PWM0
GPIO17 O PWM1
GPIO18 I READY input
GPIO19 I GPIO19 (L_CS)
GPIO20 I /SD_CS2
GPIO21 I /SD_CS3
GPIO22 I GPIO22
GPIO23 I SCLK SPI clock
GPIO24 I SFRM SPI frame signal
GPIO25 O SPI TxD transmit line
GPIO26 I SPI RxD receive line
GPIO27 I SPI EXTCLK external master clock
GPIO28 O AC97 BitCLK
GPIO29 I AC97 SDATA_IN0
GPIO30 O AC97 SDATA_OUT
GPIO31 O AC97 SYNC
GPIO32 I MMC_CLK
GPIO33 O /CS5
GPIO34 I FF-UART RxD
GPIO35 I FF-UART CTS
GPIO36 I FF-UART DCD
GPIO37 I FF-UART DSR
GPIO38 I FF-UART RI
GPIO39 O FF-UART TxD
Table 1: Port Configuration GPIO0-39
1: Ports shown in italic style have special function on the phyCORE-PXA270 and can not be
used externally.

Port Pin Initialization
©PHYTEC Meßtechnik GmbH 2006 L-668e_1 11
Port I/O Configured as
GPIO40 O FF-UART DTR
GPIO41 O FF-UART RTS
GPIO42 I BT-UART RxD
GPIO43 O BT-UART TxD
GPIO44 I BT-UART CTS
GPIO45 O BT-UART RTS
GPIO46 I STD-UART RxD
GPIO47 O STD-UART TxD
GPIO48 O /POE PCMCIA
GPIO49 O /PWE PCMCIA
GPIO50 O /PIOR PCMCIA
GPIO51 O /PIOW PCMCIA
GPIO52 O GPIO52 (INT ETHERNET)
GPIO53 I GPIO53
GPIO54 O /PCE_2
GPIO55 O /PREG PCMCIA
GPIO56 I /PWAIT PCMCIA
GPIO57 I /IOIS16 PCMCIA
GPIO58 O LDD0, data bus to LCD display
GPIO59 O LDD1, data bus to LCD display
GPIO60 O LDD2, data bus to LCD display
GPIO61 O LDD3, data bus to LCD display
GPIO62 O LDD4, data bus to LCD display
GPIO63 O LDD5, data bus to LCD display
GPIO64 O LDD6, data bus to LCD display
GPIO65 O LDD7, data bus to LCD display
GPIO66 O LDD8, data bus to LCD display
GPIO67 O LDD9, data bus to LCD display
GPIO68 O LDD10, data bus to LCD display
GPIO69 O LDD11, data bus to LCD display
GPIO70 O LDD12, data bus to LCD display
GPIO71 O LDD13, data bus to LCD display
GPIO72 O LDD14, data bus to LCD display
GPIO73 O LDD15, data bus to LCD display
GPIO74 O LCD_FCLK, frame clock
GPIO75 O LCD_LCLK, line clock
GPIO76 O LCD_PCLK, pixel clock
GPIO77 O LCD_ACBIAS BIAS or LCD_Enable
GPIO78 O /CS2
GPIO79 O /PSKSEL (/CS3)
GPIO80 O /CS4
Table 2: Port Configuration GPIO40-80

Carrier Board phyCORE-PXA270
12 ©PHYTEC Meßtechnik GmbH 2006 L-668e_1
Port I/O Configured as
GPIO81 I GPIO 81
GPIO82 I GPIO 82
GPIO83 I GPIO 83
GPIO84 I GPIO 84
GPIO85 O /PCE_1
GPIO86 I GPIO86
GPIO87 I GPIO87
GPIO88 I GPIO88
GPIO89 I GPIO89
GPIO90 I GPIO90
GPIO91 I GPIO91
GPIO92 I/O MMC_DAT0
GPIO93 I GPIO93
GPIO94 I GPIO94
GPIO95 I GPIO95
GPIO96 I GPIO96
GPIO97 I GPIO97
GPIO98 I GPIO98
GPIO99 I GPIO99
GPIO100 I GPIO100
GPIO101 I GPIO101
GPIO102 I GPIO102
GPIO103 I GPIO103
GPIO104 I GPIO104
GPIO105 I GPIO105
GPIO106 I GPIO106
GPIO107 I GPIO107
GPIO108 I GPIO108
GPIO109 I/O MMC_DAT1
GPIO110 O MMC_DAT2_CS0
GPIO111 O MMC_DAT3_CS1
GPIO112 I/O MMC_CMD
GPIO113 O AC97_RESET
GPIO114 I GPIO114
GPIO115 I GPIO115
GPIO116 I GPIO116
GPIO117 I/O I²C SDA
GPIO118 O I²C SCL
GPIO119 I GPIO119
GPIO120 I GPIO120
GPIO121 I GPIO121
Table 3: Port Configuration GPIO80-121
