phytron phySPACE User manual

Extreme. Precision. Positioning.
Manual 1313-A001 EN
How to Handle
Space Stepper Motors

phytron
11/2019 Manual 1313-A001 EN
How to Handle
Space Stepper Motors
TRANSLATION OF THE GERMAN ORIGINAL MANUAL

How to Handle Space Stepper Motors
2 MA 1313-A001 EN
Version
Modification
1
new
2019
All rights with:
Phytron GmbH
Industriestraße 12
82194 Gröbenzell, Germany
Tel.: [phone]
Fax: [phone]
Every possible care has been taken to ensure the accuracy of this technical manual. All infor-
mation contained in this manual is correct to the best of our knowledge and belief but cannot be
guaranteed. Furthermore, we reserve the right to make improvements and enhancements to the
manual and / or the devices described herein without prior notification.
We appreciate suggestions and criticisms for further improvement. Please send your comments to
the following
E-mail address: [e-mail]

phytron
MA 1313-A001 EN 3
Contents
1Legal Information........................................................................................................4
1.1 Qualified personnel...............................................................................................5
1.2 Safety Instructions ................................................................................................6
1.3 Handling instruction ..............................................................................................7
1.4 European Standards and CE Mark .......................................................................8
2Space Stepper Motors................................................................................................9
2.1 Heating in Vacuum Environment...........................................................................10
3Packaging...................................................................................................................11
3.1 Transport Package................................................................................................11
3.2 Outer Package......................................................................................................11
3.3 Protective Film and Transport Cover.....................................................................13
3.4 Rating Plate..........................................................................................................14
4Configuration and Use Limitation................................................................................15
4.1 Motor Selection.....................................................................................................15
4.2 Use limitation........................................................................................................16
5Mounting.....................................................................................................................17
6Electrical Connection..................................................................................................18
6.1 Maximum Allowable Phase Current ......................................................................19
6.2 Leads....................................................................................................................20
6.2.1 Marking of the Leads................................................................................20
6.2.2 Connecting the Leads ..............................................................................21
6.3 Direction of Rotation .............................................................................................22
7Temperature Measuring (Motors with Temperature Sensor).......................................23
7.1 Type K Thermal Element ......................................................................................23
7.2 Pt100 and Pt1000.................................................................................................24
8Conditioning Space Stepper Motors............................................................................26
8.1 Overview...............................................................................................................26
8.2 Baking out.............................................................................................................26
8.3 Final outgassing....................................................................................................26
9Storage.......................................................................................................................27

How to Handle Space Stepper Motors
4 MA 1313-A001 EN
1 Legal Information
i
This manual:
Read this manual very carefully before mounting, installing and operating the
device and if necessary further manuals related to this product.
- Please pay special attention to instructions that are marked as follows:
DANGER –
Serious injury!
Indicates a high risk of serious injury or
death!
DANGER –
Serious injury from
electric shock!
Indicates a high risk of serious injury or
death from electric shock!
WARNING –
Serious injury pos-
sible!
Indicates a possible risk of serious injury
or death!
WARNING –
Serious injury from
electric shock!
Indicates a possible risk of serious injury
or death from electric shock!
CAUTION –
Possible injury
from heat!
Indicates a possible risk of personal in-
jury from heat!
CAUTION –Possi-
ble injury!
Indicates a possible risk of personal in-
jury.
i
CAUTION –Possi-
ble damage!
Indicates a possible risk of damage to
equipment.
CAUTION –Possi-
ble damage due to
ESD!
Refers to a possible risk of equipment
damage from electrostatic discharge.
i
”Any heading“
Refers to an important paragraph in the
manual.

phytron
MA 1313-A001 EN 5
1.1 Qualified personnel
Observe the following safety instructions!
WARNING –Serious injury possible!
Serious personal injury or serious damage to the machine and drives could
be caused by insufficiently trained personnel!
Without proper training and qualifications, damage to devices and injury
might result!
- Design, installation and operation of systems may only be performed
by qualified and trained personnel.
- These persons should be able to recognize and handle risks emerg-
ing from electrical, mechanical or electronic system parts.
- The qualified personnel must know the content of this manual and
be able to understand all documents belonging to the product. Safe-
ty instructions are to be provided.
- The trained personnel must know all valid standards, regulations
and rules for the prevention of accidents, which are necessary for
working with the product.

How to Handle Space Stepper Motors
6 MA 1313-A001 EN
1.2 Safety Instructions
i
Intended use:
The space stepper motors are designed for operating in a space drive sys-
tem. - An installation is allowed only if the requirements of the EC Ma-
chinery and EMC Directives are conformed with.
i
Part of a machine:
This product is used as a part of a complete system, therefore risk evalua-
tions concerning the specific application must be made before using the
product.
- Safety measures have to be taken according to the results and be
verified.
- Personnel safety must be ensured by the concept of this overall
system (e.g. machine concept).
WARNING –Injury from the rotating shaft!
The rotating motor shaft can accelerate loosely attached parts. This can
result in injury.
- Make sure, that before operation, all moving parts are fixed.
WARNING –Injury from the rotating shaft!
Hair, clothes and jewellery can be wound up and trapped by the rotating motor shaft .
- Before starting to wire, make sure that clothing and jewellery are
tight and hair cannot be captured.
WARNING –Injury from conversion into a translational motion!
If the rotation in the customer system is converted into a translational motion
(e.g. via spindle) injuries can occur from crushing.
- Before operation, check the system structure.
WARNING –Serious injury from electric shock!
During electrical installation cables, connectors, etc. can be live.
- Do not plug or unplug the motor while powered.
- Do not plug or unplug the connectors while powered.
If the motor was energised, wait 3 minutes after power off to allow
the capacitors to discharge and ensure that there are no residual
charges on cables, connectors and boards.

phytron
MA 1313-A001 EN 7
CAUTION –Injury from touching the housing!
Stepper motors heat up during operation. The surface of the motor can be
heated over +100 °C.
- The motor must be mounted in such way that proper dissipation of
the generated heat is ensured.
- Wait until the stepper motor has completely cooled down.
- Ensure measures for contact protection
1.3 Handling instruction
i
CAUTION –Possible damage!
The stepper motor's rotor is strongly magnetic. Metal or soft iron particles
penetrating through openings might damage motor function.
- Metal particles must be kept away from the motor.
i
CAUTION –Possible damage!
Foreign substances, dirt or humidity penetrating through openings could se-
riously damage motor function or cause breakdown.
- Do not touch the stepper motor with bare hands. Wear security
gloves
- Handle the space stepper motor only in a very clean environment!

How to Handle Space Stepper Motors
8 MA 1313-A001 EN
i
CAUTION –Possible damage!
- Please note the wiring data on the specification and the permitted
mechanical loads (see technical data in the data sheet).
- Switch off the supply voltage before mounting and wiring the step-
per motor.
- Stepper motors must not be operated with mains voltage. Stepper
motors require special control units
- While press-fitting couplings or pinions on the motor shaft, the lat-
ter should be supported.
- Remove the PTFE tube only from the lead which you are just con-
necting (chapter 6.2.2).
- Never lift the motor by means of its cables or leads! Care for strain
relief when stripping or shortening the leads!
- Comply with EMC conform wiring (chapter 6.2.2).
- Do not open the stepper motor! If the casing is opened, the motor
may be damaged. Phytron's warranty does not apply if motors are
opened by the customer. When operating a motor that was as-
sembled improperly, danger to life could be caused by electric
shock.
- The customer must not carry out mechanical or electrical modifica-
tions of the motor. The warranty does not apply if the motor is mod-
ified by the customer without the manufacturer's permission
1.4 European Standards and CE Mark
When installed appropriately, space stepper motors fulfil the requirements of the EMC and
Low Voltage Directives. Space stepper motors are qualified to be marked CE and comply
with EN 60034-1 European Standard.
When wired correctly (see Fig. 5), space stepper motors fulfil the requirements of the EMC
Directive. Information concerning the connection of the motor cable to the control unit or
the power stage is given in the corresponding manuals.
According to the European Machine Directive, the stepper motor is only a part of a ma-
chine. Placing into operation is not allowed until the machine manufacturer takes appropri-
ate measures to ensure that the entire system fulfils the requirements of the applicable EU
Directives.

phytron
MA 1313-A001 EN 9
2 Space Stepper Motors
Phytron space stepper motors for in-vacuum and Cryo applications are precision drives
with protection class IP20.
Space stepper motors are manufactured, cleaned, tested and packed with great care and
accuracy. A 4-stage package protects the stepper motor against contamination, moisture
and mechanical damage.
On opening the packaging, several precautions must be observed to maintain the defined
stepper motor's specifications and functionality.
Fig. 1 : Space stepper motor –rear view
i
The two most important rules for handling space stepper motors:
- Do not touch the stepper motor with bare hands!
- Take care that no particles or moisture can get inside the motor
through openings.
Engraved serial number

How to Handle Space Stepper Motors
10 MA 1313-A001 EN
2.1 Heating in Vacuum Environment
Normally, the heat generated by a stepper motor in a vacuum is largely dissipated by con-
duction through the mounting surface.
To avoid overheating the motor, the maximum specified temperatures must be taken into
account when determining duty cycles for setting the peak, run and stop (holding) current
values.

phytron
MA 1313-A001 EN 11
3 Packaging
A special 4-stage package –transport package, outer package, transport cover and pro-
tective film –keeps the space stepper motor from contamination, moisture and mechanical
damage.
3.1 Transport Package
The type of transport package depends on the motor type, e.g. a cardboard box with
moulded foam, bubble wrap or similar material protects the motor during transport.
3.2 Outer Package
The outer package is a gas-tight, evacuated 100% LDPE foil package with the rating plate
fixed. A desiccant bag and humidity indicator are enclosed.
Fig. 2 : Outer package with rating plate
i
Outer package:
- Before opening the outer package:
Clean the outer package with a cleaning agent usual in vacuum
technology, e.g. IPA.
- Remove outer package just short before mounting the motor.
Shrink-wrapped
transport cover with
space motor
Humidity indicator
Desiccant bag
Rating plate

How to Handle Space Stepper Motors
12 MA 1313-A001 EN
Fig. 3 : Humidity indicator

phytron
MA 1313-A001 EN 13
3.3 Protective Film and Transport Cover
Fig. 4 : Space motor with the protective film
The space stepper motor is fixed in a transport cover and shrink-wrapped in evacuated
protective film.
i
Do not touch a space stepper motor with bare hands!
Wearing safety gloves helps to keep away finger sweat and oil residues
from the stepper motor. Such residues cannot be completely removed with
IPA and may need the motor to be returned to Phytron for cleaning.
- Before opening the protective film: Put on some safety gloves.
- After removing from the foil packaging the stepper motor has to be
stored in a clean box, clean room or closed container.

How to Handle Space Stepper Motors
14 MA 1313-A001 EN
3.4 Rating Plate
i
Rating plate
On the rating plate, you will find important information about the stepper mo-
tor.
- Keep the rating plate!
- Space stepper motors are only marked with a serial and item num-
ber, as well as model (FM / QM/ EM…). Therefore, we recommend
to remove the rating plate from the outer packaging and to stick it
on the service documents or in the field below.
Remove the rating plate
from the package
and stick it here!
Rated current: See explanations in section 6.1.

phytron
MA 1313-A001 EN 15
4 Configuration and Use Limitation
4.1 Motor Selection
Our sales team will assist you with the configuration. The following scheme will help you
select the suitable motor:
Fig. 5 : Selection of the motor (size/resolution/duty cycle/dynamics)

How to Handle Space Stepper Motors
16 MA 1313-A001 EN
4.2 Use limitation
Derating formulas:
Continuous operation without overheating at 400 rev/min max. and 1/2*INin vacuum.
Short-term operation with higher current (Ion) is possible depending on the duty cycle (ratio
ton to toff).
applies to speed <= 400 rev./min;
IN = nominal motor current;
Ion>IN: overcurrent
How long may last the switch-on time ton?
How long may last the stop tof?
What is the maximum current during the Ion switch-on phase?
Condition: Ion=1.3 xIN and ton<=10s

phytron
MA 1313-A001 EN 17
5 Mounting
CAUTION –Possible injury!
- Power down the installation area or the stepper motor control unit.
i
CAUTION –Possible damage!
The stepper motor's rotor is strongly magnetic. Foreign substances, which
penetrate through openings, could decrease motor function.
- Do not touch the space stepper motor with bare hands! Wear safe-
ty gloves!
- Therefore, take care when mounting the motor: metal or soft iron
particles must not penetrate through openings into motor or gear-
ing.
- When handling stepper motors, the environment should be kept
very clean. Penetrating foreign substances, dirt or humidity could
seriously damage motor function or cause breakdown. Keep away
metal particles from the motor! Space stepper motors should
only be handled in a very clean environment.
i
CAUTION –Possible damage!
When flanging the motor, axial or radial force effects on the shaft (e.g.
strokes) must be avoided. Lifetime of the ball bearings will be shortened by
all kinds of load or rough treatment.
- Do not exceed the maximum axial and radial loads!
Avoid high shaft loads, e.g. shock/transient forces. Use suita-
ble couplings.

How to Handle Space Stepper Motors
18 MA 1313-A001 EN
6 Electrical Connection
Phytron space stepper motors are 2-phase stepper motors. The windings can be connect-
ed differently: 4-leads parallel windings or cold redundant
4-leads parallel windings
Cold redundant
8-leads / unipolar or bipolar
control mode
4-leads / serial windings
bipolar control mode
5-leads / unipolar control mode
6-leads / unipolar control mode
Fig. 6 : Connection scheme for Phytron space stepper motors

phytron
MA 1313-A001 EN 19
8-leads stepper motors have two leads from each of the four motor windings (see Fig. 6).
These motors can be driven by all types of control units in bipolar and unipolar operating
modes.
4-leads stepper motors (windings parallel or serially connected (see Fig. 6) are designed
for bipolar operation mode.
Cold redundant stepper motors are designed for reliable operation within a drive system
(see Fig. 6).
Bipolar operation mode –parallel or series winding connection
Low control pulse frequency: When operated with maximum allowable phase current
(see table below), with both connection modes the same motor torque is generated.
With rising frequency, the torque drops off sooner with serial windings.
Reason: The motor's inductance is four times higher (compared to unipolar operation
or bipolar operation with parallel windings).
Operation with low control pulse frequencies
The motor has up to 40 % more torque in the bipolar mode (compared to unipolar control)
with the same phase current, at low frequencies.
5-lead or 6-lead stepper motors (Fig. 6) can be driven by unipolar control units.
The cable cross section for the connection leads should be selected according to the
cable length. Please follow the advice in the stepper motor power stage manual.
6.1 Maximum Allowable Phase Current
The motor rating plate has the rated phase current [A] as the last digits of the motor's type
number.
Example: phySPACE 25-2-1,2-Ti-red motor size 25, length 2, 1.2 A rated current
The rated current is the maximum allowable current at full step operation, at bipolar con-
trol mode, with parallel-connected windings (standard).
Maximum Allowable Phase Current
bipolar control mode
full step operation
unipolar control mode
full step operation
4-lead motor
parallel windings
cold redundant
4-lead motor
serial windings
5-lead motor
6-lead motor
rated current
50% of rated current
70.7% of rated current
70.7% of rated current
