PI E-665.SR User manual

Physik Instrumente (PI) GmbH & Co. KG, Auf der Roemerstrasse 1, 76228 Karlsruhe, Germany
Phone [phone], Fax [phone], Email [e-mail], www.pi.ws
This document describes the
following
products:

E-665.SR
LVPZT Controller, Single-Channel, for Strain
Gauge Sensor

E-665.CR
LVPZT Controller , Single-Channel, for
Capacitive Sensor
PZ127E User Manual
E-665 LVPZT Controller / Amplifier
Release: 1.7.2 Date: 2017-05-22

Physik Instrumente (PI) GmbH & Co. KG is the owner of the following company names and
trademarks:
PI®, NanoCube®, PICMA®, PILine®, NEXLINE®, PiezoWalk®, NEXACT®, Picoactuator®,
PInano®, PIMag®, Q-Motion®
The following designations are protected company names or registered trademarks of third
parties:
Microsoft, Windows, LabView
Copyright 1999–2017 by Physik Instrumente (PI) GmbH & Co. KG, Karlsruhe, Germany.
The text, photographs and drawings in this manual enjoy copyright protection. With regard
thereto, Physik Instrumente (PI) GmbH & Co. KG reserves all rights. Use of said text,
photographs and drawings is permitted only in part and only upon citation of the source.
First printing 2017-05-22
Document Number PZ127E Eco, BRo, Release 1.7.2
E-665_User_PZ127E172.doc
Subject to change without notice. This manual is superseded by any new release. The newest
release is available for download at www.pi.ws (http://www.pi.ws).

About This Document
Users of this Manual
This manual is designed to help the reader to install and operate the E-665 LVPZT Controller /
Amplifier. It assumes that the reader has a fundamental understanding of basic servo systems,
as well as motion control concepts and applicable safety procedures.
The manual describes the physical specifications and dimensions of the E-665 LVPZT
Controller / Amplifier as well as the installation procedures which are required to put the
associated motion system into operation.
Updated releases are available for download from www.pi.ws or via email: contact your Physik
Instrumente Sales Engineer or write [email protected].
For customized devices based on the E-665.SR and .CR standard models, separate Technical
Notes are in the scope of delivery in addition to this manual. The Technical Notes describe the
differences between the corresponding E-665 standard model and the customized devices.
Examples:
For the E-665K007 device, the E665T0005 Technical Note is provided in addition to this
manual.
For the E-665K018 device, the E665T0011 Technical Note is provided in addition to this
manual.
Conventions
The notes and symbols used in this manual have the following meanings:
WARNING
Calls attention to a procedure, practice or condition which, if not
correctly performed or adhered to, could result in injury or death.
DANGER
Indicates the presence of high voltage (> 50 V). Calls attention to
a procedure, practice or condition which, if not correctly
performed or adhered to, could result in injury or death.
CAUTION
Calls attention to a procedure, practice, or condition which, if not
correctly performed or adhered to, could result in damage to
equipment.
NOTE
Provides additional information or application hints.
Related Documents
The positioning stages and the software tools which might be delivered with the E-665 LVPZT
Controller / Amplifier are described in their own manuals. All documents are available as PDF
files. Updated releases are available for download from www.pi.ws or via email; contact your
Physik Instrumente Sales Engineer or write [email protected].
!

Contents
1Introduction 3
1.1 How to use the Documentation .................................................3
1.2 Intended Use ............................................................................5
1.3 Safety Precautions....................................................................6
1.4 Model Survey............................................................................8
1.5 Unpacking.................................................................................8
1.6 Additional Components.............................................................9
2Quick Start 10
2.1Line Voltage Connection.........................................................10
2.2 First Steps...............................................................................11
3Operation 14
3.1 Front and Rear Panel Elements..............................................14
3.1.1 Front Panel Elements............................................................... 14
3.1.2 Rear Panel Elements............................................................... 17
3.2 Modes of Operation ................................................................18
3.2.1 Control Modes.......................................................................... 18
3.2.2 Servo Modes (ON / OFF)......................................................... 19
3.3 Networking on I2C Bus............................................................21
3.4 User Electronics and Sensor Monitor Signal ...........................24
4Electronics Design 25
4.1 Block Diagrams.......................................................................25
4.1.1 E-665.CR Models..................................................................... 25
4.1.2 E-665.SR Models..................................................................... 26
4.2 Adjustment Elements on Main Board ......................................27
4.2.1 Elements on E-665.CR Models................................................27
4.2.2 Elements on E-665.SR Models................................................29
4.3 Servo and Sensor Submodules...............................................29
5Calibration 30
5.1 Opening the Case...................................................................30
5.2 Sensor Connection and Adjustment........................................30
5.2.1 Open-Loop Zero-Point Adjustment .......................................... 32
5.2.2 Open-Loop Sensor Range (Gain) Adjustment......................... 33
5.2.3 Static Gain Adjustment for Closed-Loop Operation.................35
5.2.4 Second Order Polynomial Linearization (E-665.CR only)........37

Contents
5.3 Servo-Control Dynamic Characteristics...................................38
6Maintenance 39
6.1 Cleaning..................................................................................39
6.2 AC Power and Line Power Fuses ...........................................39
6.3 Transformer Secondary Winding Fuses..................................41
7Troubleshooting 42
8Customer Service 46
9Old Equipment Disposal 47
10 Technical Data 48
10.1 Specifications..........................................................................48
10.2 Frequency Response..............................................................49
10.3 Pin Assignments.....................................................................50
10.3.1 PZT Socket on E-665-CR Models............................................ 50
10.3.2 PZT Socket on E-665.SR Models............................................50
10.3.3 Sensor Socket on E-665.SR Models ....................................... 51
10.3.4 I/O Connector........................................................................... 52
10.3.5 E-665.CN Network Cable......................................................... 53
10.3.6 E-625.CN Network Cable......................................................... 53
11 Appendix 54
11.1 EC Declaration of Conformity..................................................54
11.2 KC-Statement for Class A Equipment.....................................54

Introduction
www.pi.ws E-665 PZ127E Release 1.7.2 Page 3
1Introduction
The E-665 is a bench-top device for operating stages with low-
voltage piezoelectric translators (LVPZTs). All E-665 models
have RS-232, USB and I2C interfaces for computer control and
networking, a power amplifier, sensor excitation and readout
circuitry with different filters and a proportional-integral (P-I)
servo-controller. The integrated amplifier can output and sink a
peak current of 360 mA and an average current of 150 mA over
an extended voltage range of -30 to 130 V. The units can be
operated in both open-loop and closed-loop modes. Different
models are available for use with LVPZTs equipped with strain
gauge (SGS) or capacitive displacement sensors.
The E-665 can be operated manually by front-panel
potentiometers, by external analog signals or by computer over
a USB or RS-232 communications link. Up to 12 E-665s can be
controlled off a single computer interface. The block diagram on
p. 25 answers most questions about how the various elements
interact with each other. Commands are compatible with the PI
General Command Set (see the E-816 User Manual for
computer interfacing and command set details).
E-665s can be used for both static and dynamic applications.
High output stability and low noise assures stable
micropositioning. Because LVPZT translators have high
capacitances, the amplifier is designed to supply appropriately
high peak currents for dynamic applications. Excellent linearity
and stability allow the use of E-665s in precision measurement
and control systems.
1.1 How to use the Documentation
E-665 User Manual (this document)
This User Manual enables you to put your stage with the E-665
into operation for the first time. Furthermore, it gives an
overview of the E-665 functions and specifications.
Always keep this user manual available by the E-665.
The latest versions of the user manuals are available for
download on our website (www.pi.ws).
Add all information given by the manufacturer to the User
Manual, for example supplements or Technical Notes.

Introduction
www.pi.ws E-665 PZ127E Release 1.7.2 Page 4
If you pass the E-665 on to other users, also turn over
this User Manual as well as all other relevant information
provided by the manufacturer.
Only use the device on the basis of the complete User
Manual. Missing information due to an incomplete User
Manual can lead to injury as well as property damage.
Only install and operate the E-665 after having read and
understood this User Manual.
E-816 User Manual (E-816_User_PZ116Exxx.pdf)
provided on the E-816 CD
Remote control via computer interface ("computer-controlled
mode", p. 19) makes use of the E-816 computer interface
module which is integrated in the E-665. For detailed
instructions, descriptions and examples, refer to the E-816 User
Manual.
Software Manuals provided on the E-816 CD
During remote control via computer interface, the E-665 is
identified as “E-816”. Use the PC software and the
corresponding software documentation provided on the E-816
CD.
E-802 User Manual (PZ150E) and E-801 User
Manual (PZ117E) available for download at
www.pi.ws
In addition to the E-816 computer interface module, the
following submodules are integrated in the E-665:
E-802.55 servo-control submodule
With E-665.SR models only: E-801 sensor processing
submodule
The information given in the User Manuals of those submodules
is only relevant if you should ever need to re-calibrate your
system. For normal operation of the E-665, you do not need
those manuals because your system will be fully calibrated
before being shipped. Note that re-calibration should only be
done by adequate trained personnel and after consultation with
PI.

Introduction
www.pi.ws E-665 PZ127E Release 1.7.2 Page 5
Updated releases of all documents are available for download
at www.pi.ws.
1.2 Intended Use
Based on their design and realization, E-665 LVPZT Amplifier
and Position Servo-Controllers are intended to drive capacitive
loads, in the present case, piezoceramic actuators. E-665 must
not be used for applications other than stated in this manual,
especially not for driving ohmic (resistive) or inductive loads.
E-665s can be operated in closed-loop mode using position
sensors (SGS or capacitive sensors). Appropriate sensors are
provided by PI and integrated in the stages according to their
product specifications. Other sensors may be used as position
sensors only with permission of PI.
Observe the safety precautions given in this User Manual.
If the E-665 is used in a manner not specified by PI, the
protection provided by the E-665 may be impaired.
E-665s meet the following minimum specifications for operation*
Indoor use only
Altitude up to 2000 m
Temperature range 5°C to 40°C
Max. relative humidity 80% for temperatures up to 31°C,
decreasing linearly to 50% relative humidity at 40°C
Line voltage fluctuations not greater than ±10% of the
line voltage
Transient overvoltages as typical for public power supply
Note: The nominal level of the transient overvoltage is the standing surge
voltage according to the overvoltage category II (IEC 60364-4-443).
Degree of pollution: 2
*Any more stringent specifications in the Technical Data table are, of course,
also met.

Introduction
www.pi.ws E-665 PZ127E Release 1.7.2 Page 6
1.3 Safety Precautions
DANGER
Read This Before Operation:
E-665s are amplifiers generating voltages up to 130 V for
driving LVPZTs. The output power may cause serious
injury.
Only connect original PI parts to the »PZT« socket of the
E-665.
All work done with and on the devices described here
requires adequate knowledge and training in handling High
Voltages.
We strongly advise you to follow general accident
prevention regulations. Never touch any conductive
surface that might be connected to the High Voltage circuit.
Procedures which require opening the case should be
carried out by authorized, qualified personnel only.
Disconnect unit from power when opening the case, and
when resetting internal switches or jumpers.
Procedures which require operating the device with the
case open require adequate knowledge and training in
handling High Voltages and should be carried out by
authorized, qualified personnel only. When the unit must
be operated with the case open, voltages of up to 130 V
can be exposed. Do not touch internal conductors.
WARNING
Connect the AC power cord of the E-665 to a grounded
wall socket (115 VAC or 230 VAC).
Only use the supplied power cord or a sufficiently
dimensioned power cord to connect the E-665 to the power
source (ratings see table on p. 10).
Two new line power fuses are required when changing the
supply voltage. See p. 39 for more information.
To disconnect the system from the power source
completely, remove the power plug from the wall socket, or
remove the power cord from the E-665.
Install this unit near the AC outlet and such that the AC
power plug can be reached easily.

Introduction
www.pi.ws E-665 PZ127E Release 1.7.2 Page 7
CAUTION
Calibration should only be done by qualified authorized
personnel after consultation with PI, otherwise internal
configuration data may be destroyed by erroneous
operation.
If you inform PI about your application, your E-665s will be
fully calibrated before being shipped. It is usually not
necessary for you to do anything more than adjust the zero
point before operating the system.
CAUTION
Place the E-665 in a location with adequate ventilation to
prevent internal heat build-up. Allow at least 10 cm
(4 inches) clearance from the top and the rear of the unit
and 5 cm (2 inches) from each side.
Never cover the ventilation slots as this will impede
ventilation.
CAUTION
Thermally stable systems have the best performance. For
a thermally stable system, switch on the E-665 at least one
hour before you start working with it.
CAUTION
If the stage starts oscillating (humming noise):
In closed-loop operation, switch off the servo immediately.
The load and / or the dynamics of operation probably differ
too much from the setup for which the system was
calibrated.
In open-loop operation, stop the motion immediately. Do
not operate the piezo stage at its resonant frequency even
though the notch filter by default is also active in open-loop
operation.
Otherwise the piezo stage could be irreparable damaged.
!
!
!
!

Introduction
www.pi.ws E-665 PZ127E Release 1.7.2 Page 8
1.4 Model Survey
The following models are available to support different position
sensor types.
E-665.SR Equipped with DC sensor excitation and readout
circuitry for SGS (strain gauge sensor), sensor
circuitry implemented on the E-801.1x
submodule (see the E-801 User Manual for
details)
E-665.CR Equipped with capacitive sensor excitation and
readout circuitry, implemented on the main board
The nameplate on the controller rear panel shows the model
type, the internal model number (PI-NO; model type plus suffix),
the serial number of the device (SN) and information about
applicable line voltage and current.
1.5 Unpacking
Unpack the E-665 LVPZT Controller / Amplifier with care.
Compare the contents against the items ordered and against
the packing slip. The following items should be included:
Controller unit (E-665)
3763 line cord, ratings see p. 10
RS-232 null-modem cable for PC connection (C-815.34)
USB cable (USB-A (m)/USB Mini-B (m)) for PC
connection (000036360)
User Manual for E-665 (PZ127E), this document
User Manual for E-816 Computer Interface and
Command Interpreter Submodule (PZ116E)
CD for E-816-interface devices with software and
documentation (E-816.CD)
Inspect the contents for signs of damage. If parts are missing or
you notice signs of damage contact PI immediately.
Save all packing materials in the event the product needs to be
shipped elsewhere.

Introduction
www.pi.ws E-665 PZ127E Release 1.7.2 Page 9
1.6 Additional Components
Contact your PI Sales Engineer or write [email protected], if you need
the following accessory:
E-665.CN network cable, 0.3 m, for networking of E-665 with E-
665 (I2C bus), see “Networking on I2C Bus” on p. 21 for details
and p. 53 for the pin assignment of the cable
E-625.CN network cable, 0.3 m, for networking of E-665.CR
with E-625.CR (I2C bus), see “Networking on I2C Bus” on p. 21
for details and p. 53 for the pin assignment of the cable

Quick Start
www.pi.ws E-665 PZ127E Release 1.7.2 Page 10
2Quick Start
2.1 Line Voltage Connection
WARNING
Connect the AC power cord of the E-665 to a grounded
wall socket (115 VAC or 230 VAC).
Only use the supplied power cord or a sufficiently
dimensioned power cord to connect the E-665 to the power
source (ratings see table below).
Two new line power fuses are required when changing the
supply voltage. See p. 39 for more information.
To disconnect the system from the power source
completely, remove the power plug from the wall socket, or
remove the power cord from the E-665.
Install this unit near the AC outlet and such that the AC
power plug can be reached easily.
Unless you request otherwise, upon delivery the E-665 will be
set up for the voltage predominant in your country, either
115 VAC or 230 VAC.
To adapt the E-665 to a different line voltage, the two line
power fuses must be replaced. See p. 39 for instructions and
for the required fuse types.
Depending on the ship-to country/region, the power cord (item
no. 3673) is delivered in the corresponding configuration with
the following ratings:
Country/
region
Power plug
Device
connector
Cable
Fuse in
power plug
EU
CEE(7) VII
16A/250V
C13
10A/250V
H05VV-F
3G 0.75 mm
2
-
UK
BS13/13
13A/250V
C13
10A/250V
H05VV-F
3G 1.0 mm
2
10 A
US
498G
15A/125V
C13
10A/125V
SVT
18/3C
-
JP
498G
15A/125V
C13
7A/125V
VCTF
0.75/3C
-

Quick Start
www.pi.ws E-665 PZ127E Release 1.7.2 Page 11
2.2 First Steps
DANGER
Read This Before Operation:
E-665s are amplifiers generating voltages up to 130 V for
driving LVPZTs. The output power may cause serious
injury.
Only connect original PI parts to the »PZT« socket of the
E-665.
All work done with and on the devices described here
requires adequate knowledge and training in handling High
Voltages.
We strongly advise you to follow general accident
prevention regulations. Never touch any conductive
surface that might be connected to the High Voltage circuit.
Procedures which require opening the case should be
carried out by authorized, qualified personnel only.
Disconnect unit from power when opening the case, and
when resetting internal switches or jumpers.
Procedures which require operating the device with the
case open require adequate knowledge and training in
handling High Voltages and should be carried out by
authorized, qualified personnel only. When the unit must
be operated with the case open, voltages of up to 130 V
can be exposed. Do not touch internal conductors.
CAUTION
Thermally stable systems have the best performance. For
a thermally stable system, switch on the E-665 at least one
hour before you start working with it.
CAUTION
If the stage starts oscillating (humming noise):
In closed-loop operation, switch off the servo immediately.
The load and / or the dynamics of operation probably differ
too much from the setup for which the system was
calibrated.
In open-loop operation, stop the motion immediately. Do
not operate the piezo stage at its resonant frequency even
though the notch filter by default is also active in open-loop
operation.
Otherwise the piezo stage could be irreparable damaged.
!
!

Quick Start
www.pi.ws E-665 PZ127E Release 1.7.2 Page 12
1 Make sure that the E-665 is switched off (on-/off switch
on the rear panel is in „OFF“ position ( )).
2 Connect the E-665 to the line power. Strictly observe
the instructions in “Line Voltage Connection” on p. 10
3 Set the desired control mode using the
“ANALOG/DIGITAL” toggle switch on the E-665 front
panel:
ANALOG = analog mode
DIGITAL = computer-controlled mode
See “Control Modes” on p. 18 for details
4 Set the desired servo mode using the “SERVO
ON/OFF” toggle switch on the E-665 front panel:
OFF (down) = servo off (open-loop operation)
ON (up) = servo on (closed-loop operation)
See “Servo Modes (ON / OFF)” on p. 19 for details.
Notes:
The servo must be ON in analog mode, when you want
to work with a computer-generated signal (e.g. from a
DAQ board) and the analog LabVIEW driver set from
PI (see step 8 below).
To give the E-816 computer interface submodule
complete control over the servo mode selection, the
“SERVO ON/OFF” toggle switch on the front panel
must be set to OFF (down).
5 Connect the stage to the E-665. In a calibrated system,
controller and stage are not interchangeable. Respect
the assignment given by the serial numbers marked on
the calibration label of the controller.
6 Optional: Connect a suitable measurement device to
the “SENSOR MONITOR” BNC socket. This socket
carries the filtered and processed sensor output value,
with 0 to 10 V representing nominal travel range. See
“User Electronics and Sensor Monitor Signal” on p. 24
for further specifications
7 If you want to work with multiple E-665s, interconnect
their I2C bus lines. See “Networking on I2C Bus” on
p. 21 for details
8 If you want to work in analog mode:
Connect a suitable signal source to the “CONTROL IN”
BNC socket. This input signal is used as control input
and can also be a computer-generated analog signal
(e.g. from a DAQ board). You can use the PI LabVIEW
Analog Driver set provided on the included E-816 CD

Quick Start
www.pi.ws E-665 PZ127E Release 1.7.2 Page 13
to generate that analog signal. Install that driver set by
running Setup on the E-816 CD. See the driver
documentation on the E-816 CD for operation
9 If you want to work in computer-controlled mode:
Connect a suitable trigger signal to pin 9 of the “I/O
Connector” socket in the E-665 rear panel, see p. 52
for details. This signal is used as trigger input for wave
table operation and triggered motion described in the
E-816 User Manual.
10 Switch on the E-665 (move on-/off switch on the rear
panel into „On“ position (I)).
11 Command motion of the connected stage:
Analog mode: Change the control input signal on
“CONTROL IN” in the range of 0 to 10 V, and/or use
the “DC-OFFSET” potentiometer
Computer-controlled mode: Follow the instructions in
“First Steps” in the E-816 Computer Interface
Submodule User Manual
If at the yellow “OFL” overflow LED glows in closed-loop
operation (servo ON), then a zero-point adjustment is
necessary. Follow the instructions for zero-point adjustment
given in Section “Open-Loop Zero-Point Adjustment” on p. 32.
To avoid an overflow of the amplifier in open-loop operation, do
not exceed the allowable control input range (-2 to +12 V).

Operation
www.pi.ws E-665 PZ127E Release 1.7.2 Page 14
3Operation
The E-665 amplifier/controller is a stand-alone desktop device
designed to drive and control the displacement of a stage with
low-voltage piezoelectric actuators (LVPZT) in a system with
sensor position feedback (SGS or capacitive sensors,
depending on model type).
Operation involves the user commanding a motion and the E-
665 supplying the required voltage on the piezo output line for
the piezo to execute the commanded motion.
3.1 Front and Rear Panel Elements
3.1.1 Front Panel Elements
Fig. 1: E-665.CR front panel
Fig. 2: E-665.SR front panel

Operation
www.pi.ws E-665 PZ127E Release 1.7.2 Page 15
Voltage and Position Displays
4½ digit displays for analog mode.
In computer-controlled mode both displays are off (position and
voltage values are always available over the computer
interface).
“DC-OFFSET” knob
10-turn DC-offset potentiometer, adds 0 to 10 V to the
“CONTROL IN” signal (only relevant in analog mode)
“ON-T” LED, green
On target signal from E-802 servo-control submodule, glows if
the distance from target is less than ±0.19% of the travel range.
The signal (TTL active-low) is also on pin 6 of the “I/O
Connector” socket on the rear panel, see p. 52.
“OFL” LED, yellow
Overflow signal, indicates power amplifier is so near the end of
its range that it is no longer able to follow input changes
properly. If this LED glows in closed-loop operation (servo ON),
a zero-point adjustment is necessary. Follow the instructions for
zero-point adjustment given in Section Open-Loop Zero-Point
Adjustment” on p. 32. To avoid an overflow of the amplifier in
open-loop operation, do not exceed the allowable control input
range (-2 to +12 V).
“S-ON” LED, green
Servo mode indicator, permanent glow indicates that the servo
is ON (closed-loop operation).
“SERVO ON/OFF” toggle switch
Servo mode selection:
OFF (down) = servo off (open-loop operation)
ON (up) = servo on (closed-loop operation)
To give the E-816 computer interface submodule complete
control over the servo mode selection, this switch must be set
to open-loop operation (= OFF).
“SENSOR MONITOR” BNC socket
Filtered and processed sensor output value, 0 to 10 V
representing nominal travel range.
“SENSOR ZERO” potentiometer
Trim pot accessible with small screwdriver for sensor zero-point
adjustment. Readjustment may become necessary with time or
if the load is changed. Do the adjustment with Servo OFF! See
“Open-Loop Zero-Point Adjustment” on p. 32 for more details.

Operation
www.pi.ws E-665 PZ127E Release 1.7.2 Page 16
Piezo and sensor connections:
E-665.CR Models
E-665.SR Models
“PZT”
Sensor input and piezo
actuator drive voltage
together on a combi-
sub-D socket. The drive
voltage output is in the
range of -30 to 130 V.
For pinout see p. 50.
“SENSOR”
4-conductor LEMO
EPL.0S.304.HLN for sensor input.
For pinout see p. 51.
“PZT”
2-conductor coaxial LEMO
ERA.00.250 for piezo actuator drive
voltage output. PZT ground is on
the outer conductor (tied to case),
PZT+ on the inner conductor. The
drive voltage output is in the range
of -30 to 130 V. For pinout see
p. 50.
“CONTROL IN” BNC socket
In analog mode, this control input voltage gives the target
(either as voltage or position, depending on the servo mode).
The input signal should always be in the range of 0 to 10 V
(excursions to -2 or +12 V may cause overflow, especially with
servo on, and reduce the lifetime of the piezo actuator).
The control input range can be shifted using the “DC-OFFSET”
potentiometer.
The control input voltage can also be a computer-generated
analog signal (e.g. from a DAQ board). You can use the PI
LabVIEW Analog Driver set provided on the E-816 CD to
generate that analog signal. See “Control Modes” on p. 18 for
details.
“ANALOG/DIGITAL” toggle switch
Control mode selection:
ANALOG = analog mode (use of “CONTROL IN” and “DC-
Offset” as control input)
DIGITAL = computer-controlled mode (control input given by
the E-816 computer interface submodule installed
in E-665)
The control mode determines the applicable control sources.
See “Control Modes” on p. 18 for details

Operation
www.pi.ws E-665 PZ127E Release 1.7.2 Page 17
3.1.2 Rear Panel Elements
Fig. 3: E-665 rear panel with I/O, RS-232, USB and power
connectors and fuse compartment (E-665.SR and .CR
models have identical rear panels)
RS-232
Serial connection to host PC. Sub-D 9 male, industry-standard
RS-232. See the User Manual for E-816 Computer Interface
and Command Interpreter Submodule (PZ116E) for more
information.
USB socket
Universal Serial Bus (USB Mini-B (m) socket) for connection to
host PC. See the User Manual for E-816 Computer Interface
and Command Interpreter Submodule (PZ116E) for more
information.
I/O Connector
Sub-D 9f socket with lines for networking (I2C bus). For pinout
see p. 52.
In computer-controlled mode, pin 9 is used as trigger input
signal for wave table operation and triggered motion (Active
HIGH; LOW: 0 to 0.5 V, HIGH: 3.0 to 5.0 V, maximum 10 V;
max. freq. 400 Hz; min. width: 5 μs). See the User Manual for
E-816 Computer Interface and Command Interpreter
Submodule (PZ116E) for more information.
Line power connection with fuse carrier and power
on/off switch
To adapt the E-665 to a different line voltage, the two line
power fuses must be replaced. See p. 39 for instructions and
for the required fuse types.
