pico Technology PP877 User manual

Three Axis Accelerometer Kit
Quick Start Guide
TA143
Y
X
Z
Sensor
X
Y
Z
Interface
riešenia na presné meranie
http://www.elso.sk

Three Axis Accelerometer Kit Pico Technology
2 DO225-1
1. Introduction
Thank you for buying a Three Axis Accelerometer Kit from Pico Technology.
This Quick Start Guide will help you set up your interface and oscilloscope.
In conjunction with this guide, please also see the PicoScope help manual
installed with the software.
2. Safety warnings
Please review the following safety precautions to avoid injury and
prevent damage to both the interface and surrounding devices.
DO ensure that only Pico Technology approved sensors are used with this
unit.
DO NOT apply a voltage to the BNC or sensor connectors. The BNC connector
is designed to output signals only.
DO NOT use any of this equipment in explosive atmospheres.
The mounting magnet described in this guide has a strong magnetic
eld. Users of pacemakers and insulin pumps must avoid using
this item.
Magnetic media (such as credit cards), analogue watches,
televisions, computer monitors, sensitive electronic equipment,
and mobile storage devices, should all be kept away from this magnet to
avoid permanent damage.
This magnet can attract magnetic materials or other magnets from large
distances, causing trapping injuries. Care must always be taken to prevent
this hazard.
DO NOT give this magnet to small children.
3. Pack contents
Please check your Three-Axis Accelerometer Kit has the following contents:
• Accelerometer sensor
• 3-Axis Sensor Interface
• 3 BNC Cables
• Quick start guide
• Software and Reference CD
WARNING
WARNING
riešenia na presné meranie
http://www.elso.sk

Pico Technology Quick Start Guide
DO225-1 3
4. Battery replacement
To remove the battery:
1. Place the interface face down and remove
the four securing screws.
2. Remove the base cover
3. Lift the battery away from the connections
4. Place new battery in position, replace the
base cover and secure.
5. Connections
• Connect your PicoScope to your computer using the blue USB cable
supplied.
• Connect the interface box to the PicoScope
by means of the BNC cables.
• Open PicoScope.
• Connect the accelerometer to the three
axis interface.
6. Magnet mounting instructions
DO ensure a correctly prepared mounting surface is available. This is critical
for obtaining reliable measurements.
1. Verify the mounting surface is clean, at and smooth.
2. Slide the keeper off the mounting magnet.
3. Mount the magnet/sensor assembly to the prepared test surface by
gently rolling it into place. This will avoid damaging the surface.
DO ensure that when in storage and in transit the keeper is tted to the
magnet, to protect the magnet itself and nearby objects.
DO NOT mount the accelerometer carelessly as this has the potential to
generate very high (and damaging) glevels.
7. Troubleshooting
Problem Check Action
Interface not
working
Is LED
Flashing?
Yes Check BNC lead
No Connect or change sensor
Replace battery
NVH
Interface
TA143
Y
X
Z
Sensor
X
Y
Z
Interface
riešenia na presné meranie
http://www.elso.sk

Three Axis Accelerometer Kit Pico Technology
4 DO225-1
Issue history:
1) 26.04.13 First issue
Pico Technology
James House
Colmworth Business Park
PE19 8YP
United Kingdom
www.picotech.com
8. Specifications
Weight (Interface/Vibration Sensor) 120 g / 80 g
Dimensions
Sensor Interface (inc. BNCs)
Magnet (inc. tted grub screw)
105 mm x 65 mm x 27 mm
12 mm x ø18 mm
Battery (Lithium Primary Cell) CR123(A) 3 V
Battery life (Shelf/Vibration mode) 10 years / 6 months
Maximum measurable acceleration ±5 g
Output BNC 0-2 V DC coupled
Vibration frequency (3 dB) DC to 350 Hz
BNC overvoltage protection 30 V
Shock survivability (sensor head) 10,000 g
Temperature range (operating)
Sensor head -40 °C to 85 °C
Thread mounting (sensor) 1/4” x 28 UNF
EMC approvals CE: Meets EN61326-1:2006
Output scaling 99 to 122 mV/g
0goutput (all axes) 0.85 to 1.15 V
Part Number Description
PP877 Three Axis Accelerometer Kit
TA149 Three axis interface
TA143 Accelerometer
TA096 Mounting magnet
TA091 BNC to BNC Cable (5 m)
Pico Technology is a registered trademark of Pico Technology Ltd.
Copyright © Pico Technology Ltd. 2013
Manufactured in the United Kingdom
