PICO MPP-14001 User manual

Pico Projector
MPP-14001
FCC ID:2ACX4MPP14001
User Manual

1
Overview
Dear Customer
Thank you for purchasing our Pico Projector. This product is a compact
pico projector and the best solution for business. The used DLP chip,
known for great cinema projectors, provides rich colors and high contrasts
with up to 80 Lumen brightness. Versatile connection options like HDMI-in,
AV-in, USB or Micro-SD card slot makes the product to the universal
projection machine. Use it in office, at home or on the road, share your
life, your ideas and your passion without compromises in quality or
brightness. We hope you enjoy your device and its many functions!
General Safety Information
1. Keep the device and packaging materials out of the reach of infants
and children.
2. Avoid subjecting the power adapter and other contacts to dripping or
splashing water and dry your hands before you use it. Do not place
objects filled with liquids such as vases, etc. on or near the device.
3. Make sure that the used power outlet is always readily available and
never hidden. In case of emergency, use the power adapter to
separate the device from the power network.
4. Keep your device away from all flames such as candles and do not set
them up in the vicinity of the device.
5. Keep the unit at least 10 cm away from other objects. Make sure the
ventilation is not covered by newspapers, tablecloths, curtains, etc.
6. For your own safety, do not use the projector during thunderstorms
or lightning.
7. The battery is integrated with the device. Do not dissemble and modify.
The battery should be replaced by an authorized service center only.
8. Ensure that the ambient room temperature is within -10-50°C.
9. During the operation, this product may heat lightly, which is normal.
10. Wait before using if the device has been moved from a cold location
into a warm one. Any condensation that has formed may in certain
circumstances destroy the device. As soon as the device has reached
room temperature it can be used without risk.
11. Handle the product with care. Avoid contact with sharp objects. Keep
device away from metallic objects.

2
12. Place the projector on a flat surface. Any collision or falling to the
ground is likely to damage the product.
13. Do not drop or disassemble the product otherwise the warranty
voids. Opening or removing covers may expose you to dangerous
voltage or other hazards. Refer all servicing to an authorized service
center.
14. Use only the accessories supplied by the manufacturer.
15. Both product and user’s manual are subject to further improvement
or supplement without further notice.
16. Avoid facing directly into the projector’s lens.
17. The device should not be used in a very dusty
environment. Dust particles and other foreign
Objects may damage the unit.
18. Do not expose the device to extreme vibrations. It may damage the
internal components.
19. Use the enclosed power adapter (see Technical Data).
Check whether the mains voltage of the power supply matches the
mains voltage available at the setup location. The equipment
complies with the voltage type specified on the unit.

3
Package Contents
Please check if the following items are located in your packaging:
Mini Projector
AC Adapter
Remote Controller
USB Cable
Composite AV Cable
HDMI Cable (A to C)
Pouch
QSG & User Manual
You are cautioned that any change or modifications to the equipment not
expressly approved by the party responsible for compliance could void
your authority to operate such equipment.
If the time arises to throw away your product, please recycle all the
components possible.
Batteries and rechargeable batteries are not to be disposed in your
domestic waste!
Please recycle them at your local recycling point.
Together we can help to protect the environment.

4
Contents
Devices Overview.........................................................................................5
Getting Started ............................................................................................7
Charging the Product ..............................................................................7
Projecting from External Source .............................................................7
Connecting USB Device ...........................................................................9
Connecting your PC (Used as USB Storage Device).................................9
Using Headphone ..................................................................................10
Power Bank Function ............................................................................11
Functions and Operations..........................................................................12
Main Menu............................................................................................12
Videos....................................................................................................12
Pictures..................................................................................................13
Music .....................................................................................................13
Source....................................................................................................14
Browser .................................................................................................15
Settings..................................................................................................15
Notice for Long-time Projection ................................................................19
Specifications.............................................................................................20

5
Devices Overview
Projector
1. DC IN Jack
2. Headphone Jack
3. AV Jack
4. HDMI Jack
5. Micro-USB Jack
6. Power Switch
Under power off mode, slide
to turn on power bank mode
(the power bank indicator
lights) and slide and hold on
for about 3s to turn on the
device; under power on
mode, slide to enter standby
mode and slide again to
resume; slide and hold on
for about 3s to turn off the
device.
7. Battery Status Monitor
8. Reset Button
When the system halts, poke
it with tapering things such
as toothpick to reset.

6
9. Focus Wheel
10. Menu Button
11. Home Button
12. Return Button
13. USB Jack
14. Power Bank Indicator
15. Micro-SD Card Slot
16. Touchpad
Remote Controller
1. Power Button
2. Menu Button
3. Home Button
4. Search Button
5. Navigation Buttons
6. OK Button
7. Previous File Button
8. Return Button
9. Play / Pause Button
10. Next File Button
11. Volume Adjustment Button
Warning:
Improper use of the battery may cause overheating,
explosion or ignition, which can result in an injury or a
fire. Battery leakage may damage the remote controller.
Do not expose the remote controller unit to direct
sunlight.
Do not recharge, dissemble, deform or heat the battery.
Do not expose the battery to fire or water.
Immediately replace the exhausted battery.
Take out battery when the remote is not in use for a long
time.
30°
Infrared Receiver
30°

7
Note:
Before the first time you use the remote controller, please take off the
colorless plastic piece.
Getting Started
Charging the Product
The projector is built in Li-polymer battery for mobile use. Please charge
battery of the projector full before its first use.
Battery Status Monitor
During charging, the battery charge indicator is red. It turns colorless
automatically when the battery is fully charged.
Projecting from External Source
AV IN
1. Follow the figure below to connect the external AV output device
to the AV jack on the rear panel of the unit. Connection is
color-coded. After connection, ensure that the corresponding AV
signal (e.g.: Composite Video) is enabled.
2. Enter “Source” on main menu and select “AV” mode.

8
HDMI
1. Use HDMI cable to connect the mini HDMI port on rear the panel of
the projector to the external HDMI signal source. Ensure that the
HDMI input signal is enabled.
2. Enter “Source” on main menu and select “HDMI ”mode.
VGA
Use Mini HDMI to VGA cable (optional) to connect the HDMI port on the
rear panel of the projector to PC or other external source.
1. Plug one end of Mini HDMI to VGA Cable into the mini HDMI port
on the projector.
2. Plug the other end of the cable into the VGA connector on PC or
other external source.
3. Enter “Source” on main menu and select “VGA” mode.

9
Note:
1. Make sure the screen refresh frequency of your computer is 60Hz.
2. Supported screen resolution of PC:
-1920 x 1080 / 1600 x 1200 / 1280 x 1024
-1280 x 960 / 1280 x 720 / 1152 x 864
-1024 x 768 / 800 x 600 / 640 x 480
3. Many laptop computers can not automatically switch to projection
mode when the projector is connected. Please refer to your
computer manual to make relative settings.
Connecting micro-SD Card
A built-in memory card reader is available for reading micro-SD card.
Gently insert the card until it reached the bottom of the slot. To remove
the memory card, gently push the top edge of the card and pull it out.
Connecting USB Device
Connect USB storage device/mouse/keyboard
to the USB port as shown right:
Connecting your PC (Used as USB Storage Device)
The projector has internal memory for file storage. Please download
media files from your PC to the internal memory for projection:

10
1. Turn on the PC and the projector.
2. Connect the micro-USB port of the mini projector to PC via the USB
cable. A prompt information will appear on the projector to remind
you to turn on USB storage, select and press OK to turn on it. Now the
projector is in mass storage mode. You can copy pictures, videos, and
music from your PC to the internal memory or delete the files on the
internal memory.
Note: Please switch off USB debugging in Developer options of Setting
menu before connecting to PC.
Using Headphone
The projector equips stereo speakers for providing the best audio
performance. Additionally, you can connect the headphones to the
headphone jack of the unit. When headphone is connected, the speakers
will automatically turn off.
Note: Avoid Hearing Damage
Listening at high volume for a long period of time could

11
cause damage to your ears.
Power Bank Function
The projector can be used as a power bank for your mobile phone
charging.
1. When projector is off, you can slide the power switch to turn on/off
power bank function.
2. When projector is on, select Power Bank on the main menu and
activate it, the screen will popup an asking window, select OK to go to
the power bank mode.
Note: USB port output is 5V, 1A (max.).

12
Functions and Operations
Main Menu
Press to select the desired item and press OK to enter the
submenu; press to return to Main Menu.
Note: Before Video/Picture/Music playback, please store available files
into the flash memory or insert micro-SD card/connect USB device with
available files in firstly.
Videos
Select and play video files.

13
1. On the video menu, press to enter file selection mode and press
to navigate the file. Press OK to start playback of the
selected video. Tap the icon in left top corner of the screen for
more video settings
2. During playback, press to play the previous/next video.
3. Press to pause and press it again to resume.
4. Press / on remote controller to adjust the volume.
Note: The Projector supports the following video formats:
MJPEG, MPEG-1/2, MPEG-4,H.263, H.264.
Pictures
Select and play images.
1. The pictures are shown as thumbnail. Press to navigate
the image and press OK to play.
2. During picture playback, press to select the previous/next
picture; tap the touchpad or press OK to popup function key menu
and user can select to choose “slideshow” to playback the images
in slideshow mode.
Note: The projector supports the following Picture formats:
JPEG, BMP, PNG, GIF
Music

14
Select and play music.
1. On the music menu, press to select and press OK to start
the music playback. Tap the icon in top left corner of the screen
for more music settings.
2. Press / to adjust the volume and press the to mute.
3. During playback, press to play the previous/next song. Press
to pause the music and press it again to resume normal playback.
Note: The projector supports the following music formats:
MP3, WAV, WMA, AAC
Source
When projecting from external AV source (HDMI, AV or VGA), enter
“Source” on main menu to select the exact input connection.
Note: If the blue screen appears and shows “No Signal”after the
projector connecting with the external AV source, please follow the
instructions above to select the correct source or check whether the
cables work well.

15
Browser
On the main menu, press to select Browser and press OK to
open it and surf on Internet.
Press to return to Main Menu.
Settings
Wi-Fi
1. On the settings menu, select “Wi-Fi”, press to enter WiFi setting
and press OK to turn on WiFi.
2. A moment later, it will come up some available networks. Choose one

16
and enter the password, click Connect to finish. (The operation is the
same as that of Android smart phone)
Bluetooth
Note: before using this function, connect your projector with a mouse so
that you can use the function conveniently.
1. On the settings menu, select Bluetooth, press to enter Bluetooth
setting and press OK to turn on Bluetooth.
2. Turn on the Bluetooth function of the device you want to connect.
3. Pair your device with projector, after that, you can transfer your file
to projector.

17
4. Your projector screen will show a pairing request as below, then tap
the "Pair".
5. Transfer the files in your device, the bottom of the projector screen
will come up a tip, and disappear very quickly. Don’t worry about it.
6. Just drag down the task bar in the top left corner of the screen by
using a mouse, the screen will come up a window, tap to open and
then click Accept to begin receiving the incoming file sent by
Bluetooth.
7. After transfer finished, you can find the files in Pictures/Videos/

18
Music of main menu screen.
Display
Press to select Display and then press OK and to enter
submenu.
Power Save
Activate the function to save power.
Projector Mode
Press to select projection mode.
Language & Input
Press to select Language & Input and then press OK and to
enter submenu to set language and keyboard and input method, etc.
USB Debugging Function
Use USB cable to connect projector to PC.
Press to select Developer options, and then press OK and to
enter the submenu on the right, press to select USB debugging and
then press OK to switch on USB debugging mode, now you can download
or update software of projector from PC.
Backup & reset

19
Press to choose Backup & reset and press OK and to enter
submenu. Press to choose Factory data reset and press OK to enter.
Use direction buttons to select “Reset device” and “Erase everything”,
press OK, then the device will be back to default setting.
About device
Detailed information about the projector.
Notice for Long-time Projection
The built-in battery supports about 2hrs projection. For long time
projection, you are recommended to use AC adapter. If it is low battery
without charging, the projector will shut down automatically.
When the battery is too low to stay in operation, the low battery icon will
flash and it will popup a battery indication. Under this condition, you need
to charge the projector.
It’s normal that the projector gets warm with continuous work due to its
high performance. If the projector runs for a long time and is over-heated,
the High-Temperature icon will appear on the screen. The system will
shut down automatically.
