BenQ SH960+ User manual

BenQ America Corp.
15375 Barranca Parkway. Suite A-205. Irvine, CA 92618 Tel: [phone] www.BenQ.us
BenQ is a registered trademark of BenQ Corp. DLP®is a registered trademark of Texas Instruments. All rights reserved.
Product names, logos, brands, and other trademarks featured or referred to in this materials are the property of their respective trademark holders.
Specifications subject to change without notice.
I
SH960+
PROFESSIONAL
PROJECTOR
Features Specications
Native Full HD (1920x1080) Resolution
5500 ANSI Lumens, 3000:1 Contrast Ratio
Dual Lamp Design
H+V Lens Shift; 1.5x Zoom Ratio; 2D Keystone
HDMI x1, RJ45 (LAN Control)
Optional Lens Available
Projection System
Native Resolution
Brightness
Contrast Ratio
Display Color
Lens
Aspect Ratio
Throw Ratio
Image Size Diagonal
Zoom Ratio
Lamp Type
Lamp Life (Normal/Eco Mode)
Keystone Adjustment
Projection Offset
Resolution Support
Horizontal Frequency
Vertical Scan Rate
HDTV Compatibility
Video Compatibility
Interface
Dimensions (WxHxD)
Weight
Power Supply
Power Consumption
Audible Noise
On-Screen Display
Languages
Picture Mode
Accessories (Standard)
Accessories (Optional)
UPC code / Part #
DLP®
1080p (1920 x 1080)
5500 ANSI Lumens
3000:1 (Full on/Full off)
Full 1.07 Billion Colors Palette
F= 2.48~2.81, f= 24.1~36.15mm
Native 16:9 (5 aspect ratio selectable)
1.62 ~2.43 (55.7“@ 6.6 Feet)
28” ~ 500”
1.5x
Philips UHP 330W x2
2000/3000 hours
2D, Vertical & Horizontal +/- 30 degrees
V=125%±5%, H=40%±5%
VGA (640x480) to WUXGA (1920x1200)
31-92 kHz
23-85 Hz
480i, 480p, 576i, 576p, 720p, 1080i, 1080p
NTSC, PAL, SECAM, PAL 60
Computer In (D-Sub 15pin) x1
Monitor Out (D-Sub 15 pin) x1
HDMI x1
Composite Video In (RCA) x1
S-Video In (Mini DIN 4pin) x1
Component Video in x1 (Shared with D-sub 15pin)
Audio In (Mini Jack) x1
Audio Out (Mini Jack) x1
USB (Type Mini-B) x1 (Download)
Speaker 5W x 2 (Amp. 4W)
LAN (RJ45) x1 (LAN Control)
DC 12V Trigger (3.5mm Jack) X1
RS232 (DB-9-pin) x1
17.44” x 6.57” x 13.98” (443 x 167 x 355 mm)
≤29 lbs (13 kgs)
AC 100 to 240 V, 50/60 Hz
857W (Typical), Standby <1W
41/37/38/35 dBA (2 Lamp Normal/2 Lamp Eco/1 Lamp Normal/1 Lamp Eco)
English/ France/ Germany/ Italian/ Spanish/ Russian/ Traditional
English/ France/ Germany/ Italian/ Spanish/ Russian/ Traditional
Chinese/ Simplied Chinese/ Japanese/ Korean/ Swedish/ Dutch/
Turkish/ Czech/ Portuguese/ Thai/ Polish/ Hungarian/ Croatian/
Romanian/ Norwegian/ Danish/ Bulgaria/ Finnish/ Indonesian/ Greek/
Hindi/ Arabic (28 Languages)
Cinema/Dynamic/Presentation/sRGB/User 1/User 2
Remote Control w/ Battery, Power Cord, User Manual CD, Quick Start
Guide, Warranty Card, VGA (D-sub 15 pin) Cable, Component Cable
Universal Ceiling Mount: P/N: 5J.J4N10.001
Spare Lamp Kit #1 P/N: 5J.J4L05.001, #2 P/N: 5J.J4L05.021
Remote: P/N: 5J.J4L06.001
Long Throw Lens P/N: 5J.J8C14.001
Short Throw Lens P/N: 5J.J8C14.002
Standard Throw Lens P/N: 5J.J8C14.003
8400460-2797-1 / 9H.J4L77.16Z
SH960+ 04-24-13-BQus
*Lamp life results will vary depending on environmental conditions and usage.
1
2
3
4
5
6
7
8
9
10
Input and Output Terminals
Audio In (Mini Jack)
Audio Out (Mini Jack)
LAN (RJ45)
HDMI
USB Mini B
RS232 (DB-9pin)
Monitor Out (D-sub 15pin)
DC 12VTrigger (3.5mm)
Computer In (D-sub 15pin)
ComponentVideo In
CompositeVideo In (RCA)
S-Video In (Mini DIN 4pin)
11
12
12345678910 11 12
1080P
FULL HD

17.44
13.96
6.57
Optional Lense Throw Chart
Ceiling Mount Chart
Dimensions
Ceiling Mount Screws M6 x 8 (Max. L-8 mm)
16:9 Format
Units: inch
SH960+ Digital Projector
11.73
10.47
2.86
1.81
2.76
8.74
11.34
15.67
8.33
16.71 12.76
5.95 6.81
5.04
3.46
4.9 14.35
.94
4.17
16:9Format
LongThrowLens Focusrange(m) 2.0~20.0 Imagesize(") 30~460
P/N:5J.J8C14.001
DiagonalInches
HeightInches WidthInches Min(1.93)Feet Max(2.9)Feet Lowest/HighestLensPosition<E>
80 39.22 69.73 11.21 16.85 12
90 44.12 78.44 12.62 18.96 14
100 49.03 87.16 14.02 21.06 16
110 53.93 95.87 15.42 23.17 17
120 58.83 104.59 16.82 25.28 19
130 63.73 113.30 18.22 27.38 20
140 68.64 122.02 19.62 29.49 22
150 73.54 130.74 21.03 31.59 23
ShortThrowLens Focusrange(m) 0.5~3.0 Imagesize(") 30~175
P/N:5J.J8C14.002
DiagonalInches HeightInches WidthInches Fixed(.77) Lowest/HighestLensPosition<E>
80 39.22 69.73 4.47 12
90 44.12 78.44 5.03 14
100 49.03 87.16 5.59 16
110 53.93 95.87 6.15 17
120 58.83 104.59 6.71 19
130 63.73 113.30 7.27 20
140 68.64 122.02 7.83 22
150 73.54 130.74 8.39 23
StandardThrowLens Focusrange(m) 1.5~7.0 Imagesize(") 35~205
P/N:5J.J8C14.003
DiagonalInches HeightInches WidthInches Min(1.54)Feet Max(1.93)Feet Lowest/HighestLensPosition<E>
80 39.22 69.73 8.95 11.21 12
90 44.12 78.44 10.07 12.62 14
100 49.03 87.16 11.19 14.02 16
110 53.93 95.87 12.30 15.42 17
120 58.83 104.59 13.42 16.82 19
130 63.73 113.30 14.54 18.22 20
140 68.64 122.02 15.66 19.62 22
150 73.54 130.74 16.78 21.03 23
