PiezoDrive PDUS210 User manual

PDUS210 Quick start guide
Installation
Open installation file and unzip to a convenient location, e.g. Desktop/PDUS210
To Start
Run PiezoDrive.exe
User Interface Overview
Voltage and current
waveform plots. Double
click to auto scale.
Enable/disable
amplifier
output.
Will reset an
overload
shutdown.
Enable/disable
phase tracking
Enable/disable
power tracking
Show
settings
Show
frequency
sweep
mode
Save current settings
to amplifier memory

Settings Overview
Update firmware.
Requires internet.
Serial number
Version notes
Display Size
Latest firmware
version available
Current firmware
version installed on
connect amplifier

Frequency Sweep Overview
Start sweep
Phase and impedance frequency response
plots. Double click to auto scale.
Sweep settings
Voltage control

To Track a Resonance
1) Perform a frequency
sweep to identify the
resonance of interest
Start with a low voltage,
e.g. 1 Vpp
Identify the frequency
limits and the desired
phase
Increase voltage to
improve resolution
Enter the tracking settings. In
this example, the target
resonance (low impedance) is
at 49.9 kHz with a phase of
zero degrees, therefore the
min frequency is set to 48
kHz, the max frequency is set
to frequency to 55 kHz, and
the initial frequency is set to
49.9kHz.
To track a resonance, set the
control gain to a positive
value, typically 1.
Enable the output.
Enable phase tracking.
Once the amplifier is
successfully tracking the
resonance, i.e. when the
measured phase equals the
desired phase, the voltage
2) Enter the frequency limits
and desired phase set point
(usually zero degrees)
To track an impedance
minima, set the control
gain to a positive value,
e.g. +1
To track an impedance
maxima, set the control
gain to a negative value,
e.g. -1
Enable the output
Enable phase tracking
Check the measured
phase is reaching the set
point

Power Tracking
Successfully track a
resonance using phase
tracking and manual
voltage control
Enter the desired power
setpoint
Set the control gain to 0.2,
this controls the rate at
which the voltage is
updated.
Enable power tracking
The voltage will be
updated to achieve the
desired load power
dissipation

To Update Firmware
Enter settings mode
Update firmware
Restart amplifier when
prompted
Latest compatible
firmware will be
downloaded and
installed
Desktop software and
amplifier will restart
when complete.
