Pifco P40002 User manual

16 INCH
PEDESTAL FAN
MODEL P40002
YOUR SAFETY &
INSTRUCTION MANUAL
PLEASE READ CAREFULLY
www.pifco.co

2
CUSTOMER SUPPORT TEAM: [phone]
DOCUMENTATION
We declare that this product conforms to the following product legislation in accordance with the
following directive(s):
2014/30/EU Electromagnetic Compatibility Directive.
2014/35/EU Low Voltage Directive.
2011/65/EU Restriction of Hazardous Substances Directive.
RK Wholesale LTD Quality Assurance, United Kingdom
WARRANTY
This product is guaranteed for 12 months from the date of original purchase. If any defect arises due
to faulty materials of workmanship, the faulty products must be returned to the place of purchase.
Refund or replacement is at the discretion of the retailer.
The following conditions apply:
• The product must be returned to the retailer with proof of purchase.
• The product must be installed and used in accordance with the instructions contained in this
instruction guide.
• It must be used only for domestic purposes.
• It does not cover wear and tear, damage, misuse or consumable parts.
• RK Wholesale LTD has limited liability for incidental or consequential loss or damage.
• This guarantee is only Valid in the UK and Eire Only.
An extended warranty is available for this appliance.
See back page for details.
TECHNICAL DATA
Description: 16 Inch Pedestal Fan
Model: P40002
Rated Voltage: 220 - 240V
Frequency: ~ 50Hz
Power consumption: 50W

3
www.pifco.co
WIRING SAFETY FOR UK USE ONLY
IMPORTANT
As the colours in the
mains lead of this
appliance may not
correspond with the
coloured markings
identifying the terminals
in your plug, please
proceed as follows:
The wires in the mains lead are coloured in
accordance with the following code:
Blue neutral [N] Brown live [L]
Green/Yellow [EARTH]
Plug Fitting Details (Where Applicable).
The wire coloured blue is the neutral and must
be connected to the terminal marked [N] or
coloured black.
The wire coloured brown is the live wire and
must be connected to the terminal marked [L] or
coloured red.
The wire coloured green/yellow must be
connected to the terminal marked with the letter
[E] or marked .
On no account must either the brown or the blue
wire be connected to the [EARTH] terminal .
Always ensure that the cord grip is fastened
correctly.
The plug must be tted with a fuse of the same
rating already tted and conforming to BS 1362
and be ASTA approved.
If in doubt consult a qualied electrician who will
be pleased to do this for you.
Non-Rewireable Mains Plug
If your appliance is supplied with a non-
rewireable plug tted to the mains lead and
should the fuse need replacing, you must use an
ASTA approved one (conforming to BS 1362 of
the same rating).
If in doubt, consult a qualied electrician who will
be pleased to do this for you.
If you need to remove the plug – disconnect
it from the mains – and then cut it o of the
mains lead and immediately dispose of it in a
safe manner. Never attempt to reuse the plug or
insert it into a socket outlet as there is a danger
of an electric shock.
WARNING:
This Appliance MUST be Earthed
FUSE

4
CUSTOMER SUPPORT TEAM: [phone]
PRODUCT SAFETY
When using any electrical appliance, basic safety precautions should
always be followed including the following:
• Check that the voltage of the
main circuit corresponds with
the rating of the appliance
before operating.
• Please ensure that the
appliance is used on a stable,
level, and heat resistant
surface.
• DO NOT immerse cords, plugs
or any part of the appliance in
water or any other liquid.
• DO NOT leave the appliance
unattended while it is operating.
• Close supervision is necessary
when any appliance is used by
or near children or pets.
• This appliance can be used
by children aged from 8 years
and above and persons with
reduced physical, sensory or
mental capabilities or lack of
experience and knowledge
if they have been given
supervision or instruction
concerning use of the appliance
in a safe way and understand
the hazards involved.
• Children shall not play with the
appliance.
• Cleaning and user maintenance
shall not be made by children
without supervision.
• Switch o at the wall socket
then remove the plug from
the socket when not in use or
before cleaning.
• If the supply cord or appliance
is damaged, stop using the
appliance immediately and seek
advice from the manufacturer
or its service agent or a similarly
qualied person.
• DO NOT let the cord hang over
the edge of a table or counter
or let it come into contact with
any hot surfaces.
• The use of accessory
attachments is not
recommended by the appliance
manufacturer, apart from those
supplied with this product.
• DO NOT pull the plug out by
the cord as this may damage
the plug and/or the cable.
• DO NOT use this product for
anything other than its intended
use.
• This appliance is for household
use only.
• DO NOT carry the appliance by
the power cord.
• DO NOT use the appliance
outdoors.

5
www.pifco.co
• DO NOT expose the fan to
excessive heat or humidity as
this can cause damage to the
electrical components.
• DO NOT run cord under
carpeting. DO NOT cover cord
with throw rugs, runners or the
like. Arrange cord away from
trac area to avoid anyone
from tripping over.
• DO NOT insert or allow foreign
objects to enter any ventilation
opening as this may cause an
electric shock, re, or damage
to an individual or a property.
• To prevent overload and blown
fuses, be sure that no other
appliance is plugged into the
same outlet (receptacle) or
into another outlet (receptacle)
wired into the same circuit.
• Never insert your ngers,
pencils or other objects through
the cage during operation.
• The fan should be set up on
a stable and level surface to
avoid it being knocked over.
• The fan should be kept out of
the reach of children.
• In the unlikely event the
appliance develops a fault,
stop using it immediately and
seek advice from the Customer
Support Team.
HIGH VOLTAGE ROTATING PARTS
WARNING:
DO NOT IMMERSE ANY ELECTRICAL PART
OF THE APPLIANCE IN WATER SUCH AS
MOTOR UNITS OR PLUGS.
PLEASE SEE CLEANING SECTION FOR
FURTHER INSTRUCTIONS.
DISPOSAL OF THE UNIT
Appliances bearing the symbol shown here
may not be disposed of in domestic rubbish.
You are required to dispose of old electrical
and electronic appliances like this separately.
Please visit www.recycle-more.co.uk or
www.recyclenow.co.uk
for access to information about the recycling
of electrical items.
Please visit www.weeeireland.ie for access to
information about the recycling of electrical
items purchased in Ireland.
The WEEE directive, introduced in August
2006, states that all electrical items must be
recycled, rather than taken to landll.
Please arrange to take this appliance to your
local Civic Amenity site for recycling, once it
has reached the end of its life.

6
CUSTOMER SUPPORT TEAM: [phone]
BEFORE YOUR FIRST USE:
1. Remove the parts from the packaging.
2. Assemble as instructed.
3. Your appliance is now ready for normal use.
4. Dispose of the packaging in a responsible manner.
Dispose of the packaging in a responsible manner.
WHAT’S IN THE BOX
Instruction Manual
Fan Unit
1. Top lock
2. Locking clips
3. Fan blades
4. Front guard
5. Extender
6. Adjustable pole
7. Base
8. Oscillation knob
9. Speed Dial
10. Adjustable Tilting Head Screw
1
2
3
4
5
6
7
8
10
9

7
www.pifco.co
ASSEMBLY OF THE UNIT
Before using, there is some assembly required
as follows:
1. Place the fan on a table (never place the fan
upside down - the cover can be broken).
2. Slide the base onto the end of the
adjustable pole.
3. Fit the weight underneath the base.
4. Put the washer and screw nut in place
under the weight, and turn the screw nut
clockwise to screw in to place.
ADJUSTABLE POLE:
The pole on the pedestal fan is adjustable. Use
the bottom extender to change the height.
With one hand holding the fan, unscrew the
extender.
Pull the adjustable pole upwards to extend the
height, or push down for less height.
When the fan is at the correct height, tighten
the extender by turning it clockwise until the
stand locks into place.
ADJUSTABLE TILTING HEAD:
Use the top two screws to adjust the angle of
the fan head.
Loosen the screws to move the head to the
desired angle, and tighten them to lock into
place.
FAN SPEED:
Choose one of the following 3 speeds using the
speed dial.
0 = stop
1 = minimum
2 = medium
3 = high
OSCILLATION
Push oscillation knob down and the fan will
begin to oscillate. Pull the oscillation knob
upwards to stop.
CLEANING AND CARE
• Before cleaning always switch o the
appliance and remove the plug from the
electrical socket.
• To clean the outside of the fan, wipe the
exterior with a soft, damp cloth.
• Never use an abrasive cleaner.
• When not in use, store the fan (preferably
in its original box) in a cool, clean and dry
location.
CLEANING THE FAN BLADES:
1. Remove the front guard by unclipping
the locking clips located around the
circumference of the guard. The top lock
does not unclip.
2. Use a small spanner to unscrew the nut
and bolt at that holds the bottom of the
front guard to the back guard.
3. With both hands, pull the front guard
downwards and away.
4. Clean the fan blades with a soft, damp
cloth.
5. Slide the front guard back into place, so it
ts into the top lock clip. Clip all the locks
back into place and screw the nut and
bolt back in.
Caution: Do not use the fan when the front
guard is not locked into place.

1117.V2
We hope you enjoy your appliance for many years.
As a thank you for purchasing one of our fantastic products,
we are oering you an extra 1 year peace of mind.
*To receive your extra 2 years guarantee, register your appliance online
within 28 days of purchase by visiting:
www.pifco.co
Should you have a problem
with your appliance or need any spare parts please call our
Customer Support Team on:
[phone]
Distributed throughout the UK by RK Wholesale LTD
