Pioneer GM-2416ZSAX1B User manual

PIONEER CORPORATION 4-1, Meguro 1-Chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS SERVICE INC. P.O.Box 1760, Long Beach, CA 90801-1760 U.S.A.
PIONEER EUROPE N.V. Haven 1087 Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE.LTD. 253 Alexandra Road, #04-01, Singapore 159936
C PIONEER CORPORATION 2000 K-ZZS. MAR. 2000 Printed in Japan
ORDER NO.
CRT2516
AMPLIFIER
GM-2416ZSA X1B/WL
Service
Manual
SAAB
-This service manual should be used together with the following manual(s):
Model No. Order No. Mech. Module Remarks
GM-2416ZSA/WL CRT1894
VEHICLE DESTINATION PRODUCED AFTER PART No. ID No. PIONEER MODEL No.
SAAB 9-5 WORLD 1997 4617163 GM-2416ZSA/X1B/WL
EXPLODED VIEWS AND PARTS LIST
EXTERIOR(Page 10)
-EXTERIOR SECTION PARTS LIST
Part No.
Mark No. Description GM-2416ZSA/WL GM-2416ZSA/X1B/WL
9 Amp Unit CWM4352 UWM4352
ELECTRICAL PARTS LIST(Page 3)
Amp Unit
Part No.
Symbol and Description GM-2416ZSA/WL GM-2416ZSA/X1B/WL
C 369 CKSQYB823K25 CKSQYB823K50
C 370 CKSQYB823K25 CKSQYB823K50
C 827 CKSQYB104K25 CKSQYB104K50
C 828 CKSQYB104K25 CKSQYB104K50
C 829 CKSQYB104K25 CKSQYB104K50
C 830 CKSQYB104K25 CKSQYB104K50
C 831 CKSQYB104K25 CKSQYB104K50
C 832 CKSQYB104K25 CKSQYB104K50
C 833 CKSQYB104K25 CKSQYB104K50
C 834 CKSQYB104K25 CKSQYB104K50

GM-2416ZSA
PACKING(Page 11)
-PACKING SECTION PARTS LIST
Part No.
Mark No. Description GM-2416ZSA/WL GM-2416ZSA/X1B/WL
1 Cover CHW1584 UHW1584
2 Protector CHP1880 UHP1880
3 Polyethylene Bag CEG1042 UEG1042
4 Protector CHP1885 UHP1885
5 Protector CHP1881 UHP1881
6 Contain Box CHL3111 UHL3111
7 Protector CHP1882 UHP1882
