Pioneer A-351r User manual

STEREO

AMPLIFIER

—

Po

aaih.

aa

1481845

voLuMe

je

cONTAOL

18

Operating

Instructions

@

PIONEER

srearo

ameuriea

A-351R

WIRELESS

REMOTE

CONTROL

/

ALL

SOURCE

DIRECT

active

*

S488

ona

conrAn.

TREBLE

INPUT

SELECTOR

powaR

.

:

.:

b

a

.

—|

.

:

.

;

. * . f

= =

=

7

:

*

: q

as

+

~

*

TUNER

-

LJ

SPEAKERS

partes

©

oo

©:

age

TAPE

Q/AOPT

Tape

1/DaT

Thank

you

for

buying

this

PIONEER

product.

Please

read

through

these

operating

instructions

so

you

will

know

how

to

operate

your

model

properly.

After

you

have

finished

reading

the

instructions,

put

them

away

in

a

safe

place

for

future

reference.

In

some

countries

or

regions,

the

shape

of

the

power

plug

and

power

outlet

may

sometimes

differ

from

that

shown

in

the

explanatory

drawings.

However,

the

method

of

connecting

and

operating

the

unit

is

the

same.

WARNING:

to

prevent

FIRE

OR

SHOCK

HAZARD,

DO

NOT

EXPOSE

THIS

APPLIANCE

TO

RAIN

OR

MOISTURE.

“This

product

complies

with

the

Radio

Interference

require-

ments

of

the

EC

(European

Community)

Directive

87/308/EEC.”

IMPORTANT

1

The

lightning

flash

with

arrowhead,

within

an

equilateral

triangle,

is

intended

to

alert

the

user

to

the

presence

of

uninsulated

‘dangerous

voltage’

within

the

product's

enclosure

that

may

be

of

sufficient

magnitude

to

constitute

a

risk

of

electric

shock

to

persons.

IMPORTANT

2

If

the

apparatus

is

fitted

with

AC

mains

power

outlet(s),

see

REAR

PANEL

FACILITIES

for

convenient

connection

of

additional

Hi-Fi

component(s).

Make

all

connections

to

the

AC

outlet(s)

and

the

signal

terminals

first.

Connect

the

plug

to

the

wall

socket

last

(make

sure

that

the

power

switch

is

off.)

CAUTION

RISK

OF

ELECTRIC

SHOCK

DO

NOT

OPEN

CAUTION:

TO

PREVENT

THE

RISK

OF

ELECTRIC

SHOCK,

DO

NOT

REMOVE

COVER

(OR

BACK).

NO

USER-

SERVICEABLE

PARTS

INSIDE.

REFER

SERVICING

TO

QUALIFIED

SERVICE

PERSONNEL.

FOR

USE

IN

THE

UNITED

KINGDOM

The

wires

in

this

mains

lead

are

coloured

in

accordance

with

the

following

code:

Blue:

Neutral

Brown:

Live

As

the

colours

of

the

wires

in

the

mains

lead

of

this

apparatus

may

not

correspond

with

the

coloured

marking

identifying

the

terminals

in

your

plug

proceed

as

follows:

V)

PIONEER’

The

Art

of

Entertainment

The

exclamation

point

within

an

equilateral

triangle

is

intended

to

alert

the

user

to

the

presence

of

important

operating

and

maintenance

(servicing)

instructions

in

the

literature

accompanying

the

appliance.

The

wire

which

is

coloured

blue

must

be

connected

to

the

terminal

which

is

marked

with

the

letter

N

or

coloured

black.

The

wire

which

is

coloured

brown

must

be

connected

to

the

terminal

which

is

marked

with

the

letter

L

or

coloured

red.

Do

not

connect

either

wire

to

the

earth

terminal

of

a

three

plug.

Equipment

sold

in

the

U.K.

is

not

supplied

with

a

power

plug.

CONTENTS

FEATURES

seep

actarcntee

niente

eedaccicanceeataeeies

2

INSTALLATION

scccrssieunsensewnst

daviveldeivkicaeniatnceors

2

PANEL,

PACILITIES

.iicunineydsndsinsany,

anwesriadaueetieccss

3

CONNECTIONS

sce2ticsnitskssgsespseedanpaandcsaaeeauswees

6

OPERATIONS

sigeaceinasasendteeiantienetanncnendtste

a

neaeanas

8

REMOTE

CONTROL:

cusicescceucparaier

ee

uit

9

TROUBLESHOOTING

1.00...

cceceeeeeeee

eee

teeeeteeaeneenes

11

SPECIFICATIONS

ieee

sxe

sve

taneneuneoaten

ernie

aeterines

12

FEATURES

m

Remote

control

integrated

amplifier

Convenience

is

combined

with

no-compromise

performance.

The

remote

provides

access

to

ail

Pioneer

audio

equipment

with

the

mark.

Power

output

of

45

+

45

watts

at

4

ohms,

DIN

(30

watts

per

channel,

at

8

ohms

from

20

Hz

to

20,000

Hz

with

0.07

%

total

harmonic

distortion.

_Low-impedance

driving

capability:

To

capably

drive

speaker

with

low

impedance

for

better

digital

sound.

“DIRECT”

button:

For

bypassing

the

tone

and

balance-control

circuits

—

highest

purity

results.

m

Active

tone

control:

Lows

and

highs

are

automatically

boosted

when

volume

is

lowered,

to

compensate

for

insufficient

bass

and

treble.

mw

6

inputs:

PHONO,

TUNER,

CD,

LINE,

TAPE

1/DAT,

TAPE

2/ADAPTOR.

gm

Large

insulators

mw

Connections

for

two

pairs

of

speaker

systems.

INSTALLATION

LOCATION

Install

the

amplifier

in

a

well-ventilated

location

where

it

will

not

be

exposed

to

high

temperature

or

humidity.

Do

not

install

the

amplifier

in

a

location

which

is

exposed

to

direct

rays

of

the

sun,

or

near

to

hot

appliances

or

radiators.

Excessive

heat

can

adversely

affect

the

cabinet

and

internal

components.

Installation

of

the

amplifier

in

a

damp

or

dusty

environment

may

result

in

malfunction

or

accident.

(Also

avoid

installation

near

cookers

étc.,

where

the

amplifier

may

be

exposed

to

smoke

from

oil,

steam

or

heat.)

2

POWER-CORD

CAUTION

Handle

the

power

cord

by

the

plug.

Do

not

pull

out

the

plug

by

tugging

the

cord

and

never

touch

the

power

cord

when

your

hands

are

wet

as

this

could

cause

a

short

circuit

or

electric

shock.

Do

not

place

the

unit,

a

piece

of

furniture,

etc.,

on

the

power

cord,

or

pinch

the

cord.

Never

make

a

knot

in

the

cord

or

tie

it

with

other

cords.

The

power

cords

should

be

routed

such

that

they

are

not

likely

to

be

stepped

on.

A

damaged

power

cord

can

cause

fire

or

give

you

an

electrical

shock.

Check

the

power

cord

once

in

a

while.

When

you

find

it

damaged,

ask

your

nearest

PIONEER

authorized

service

center

or

your

dealer

for

a

replacement.

MAINTENANCE

OF

EXTERNAL

SURFACES

e

Use

a

polishing

cloth

or

dry

cloth

to

wipe

off

dust

and

dirt.

¢

When

the

surfaces

are

very

dirty,

wipe

with

a

soft

cloth

dipped

in

some

neutral

cleanser

diluted

five

or

six

times

with

water,

and

wrung

out

well,

and

then

wipe

again

with

a

dry

cloth.

Do

not

use

furniture

wax

or

cleaners.

©

Never

use

thinners,

benzine,

insecticide

sprays

and

other

chemicals

on

or

near

this

unit,

since

these

will

corrode

the

surfaces.

PANEL

FACILITIES

FRONT

PANEL

(@)

POWER

STANDBY/ON

switch/indicator

To

use

the

amplifier,

press

the

POWER

STANDBY/ON

switch

to

ON,

so

that

the

STANDBY

indicator

goes

off.

When

the

STANDBY

indicator

lights,

the

unit

is

in

STANDBY.

When

set

to

the

STANDBY

position,

the

main

power

flow

is

cut

and

the

unit

is

no

longer

fully

operational.

A

minute

flow

of

power

feeds

the

unit

to

maintain

operation

readiness.

(2)

ACTIVE

TONE

CONTROL

The

effect

of

the

main

unit’s

tone

control

becomes

more

noticeable

when

the

volume

is

decreased,

so

it

can

be

adjusted

to

achieve

the

same

effect

as

the

Loudness

function.

TREBLE

tone

control

Use

to

adjust

the

high-frequency

tone

at

low

volume

level.

The

center

position

is

the

flat

(normal)

position.

When

turned

to

the

right,

high-

frequency

tones

are

emphasized;

when

turned

to

the

left,

high-

frequency

tones

are

de-emphasized.

NOTE:

¢

This

control

does

not

operate

when

DIRECT

button

is

in

the

on

position.

®

At

volume

levels

lower

than

“12”,

the

set

tone

control

effect

is

obtained.

At

volume

levels

higher

than

“12”,

the

effect

becomes

increasingly

weaker.

BASS

tone

control

Use

to

adjust

the

low-frequency

tone

at

low

volume

level.

The

center

position

is

the

flat

(normal)

position.

When

turned

to

the

right,

low-

frequency

tones

are

emphasized;

when

turned

to

the

left,

low-frequency

tones

are

de-emphasized.

WIRELESS

REMOTE

CONTROL

/

ALL

SOURCE

DIRECT

INPUT

SELECTOR

NOTE:

¢

This

control

does

not

operate

when

DIRECT

button

is

in

the

on

position.

©

At

volume

levels

lower

than

“12°,

the

set

tone

control

effect

is

obtained.

At

volume

levels

higher

than

“12”,

the

effect

becomes

increasingly

weaker.

(3)

BALANCE

control

Should

normally

be

left

in

the

center

position.

Adjust

balance

if

the

sound

is

louder

from

one

of

the

speakers.

If

the

right

side

is

louder,

turn

toward

the

L

position

and

if

the

left

side

is

louder,

turn

toward

the

R

position.

NOTE:

This

function

does

not

operate

when

DIRECT

button

is

in

the

on

position.

(4)

INPUT

SELECTOR

buttons/indicators

Use

to

select

the

playback

source.

TUNER:

For

AM

or

FM

broadcast

reception

with

a

tuner.

PHONO:

For

record

playback

with

a

turntable.

CD:

For

compact

disc

playback

with

a

CD

player.

LINE:

For

playback

with

a

component

connected

to

LINE

terminal.

TAPE

1/DAT:

For

playback

with

a

cassette

deck

or

digital

audio

cassette

deck

connected

to

TAPE

1/DAT

terminals.

TAPE

2/ADPT:

For

playback

with

a

cassette

deck

or

adaptor

connected

to

TAPE

2/

ADPT

terminals.

3

PANEL

FACILITIES

NOTE:

When

the

DIRECT

button

is

set

to

ON,

the

input

to

be

reduced

is

always

selected

with

the

INPUT

SELECTOR

except

TAPE

2/ADPT,

regardless

of

whether

the

TAPE

2/ADPT

indicator

lights

or

not.

Furthermore,

when

the

TAPE

2/ADPT

indicator

is

ON,

signals

input

through

TAPE

2/ADPT

are

output

at

TAPE

1/DAT

REC.

(6)

VOLUME

CONTROL

Use

to

adjust

the

volume

level.

NOTE:

This unit

is

equipped

with

a

circuit

that

attenuates

TONE

effect

as

volume

is

turned

up.

(6)

Remote

control

sensor

window

@

PHONES

jack

When

using

headphones,

insert

the

plug

into

this

jack.

SPEAKERS

A

selector

button

Use

this

button

to

listen

to

the

speaker

systems

connected

to

SPEAKERS

A

terminalis.

ON

(=):

Depressed

position:

Sound

is

heard

from

the

speaker

systems.

OFF

(4):

Released

position:

No

sound

is

heard

from

the

speaker

systems.

Set

to

this

position

when

listening

with

headphones.

(9)

SPEAKERS

B

selector

button

Use

this

button

to

listen

to

the

speaker

systems

connected

to

SPEAKERS

B

terminalis.

ON

(=):

Depressed

position:

Sound

is

heard

from

the

speaker

systems.

OFF

(ML):

Released

position:

No

sound

is

heard

from

the

speaker

systems.

Set

to

this

position

when

listening

with

headphones.

4

DIRECT

button/indicator

Use

this

button/indicator

when

you

do

not

wish

to

pass

the

output

from

input

terminal

equipment

through

the

various

frequency

adjusting

circuits

(BASS,

TREBLE,

BALANCE).

on:

The

indicator

lights:

The

signals

input

through

the

input

terminals

are

reproduced

without

passing

through

the

various

frequency

adjusting

circuits.

This

results

in

flat,

pure

sound

which

is

a

more

faithful

reproduction

of

the

input

source.

off:

The

indicator

goes

out:

The

signal

passes

through

the

various

frequency

adjusting

circuits.

PANEL

FACILITIES

REAR

PANEL

YD

@

Q@OOOD®O®

@)

PHONO

terminals

@

Turntable

ground

terminal

(GND)

(3)

TUNER

terminals

(4)

CD

terminals

()

LINE

terminals

(©)

TAPE

1/DAT

REC

terminals

(7)

TAPE

1/DAT

PLAY

terminals

(8)

TAPE

2/ADPT

REC

(OUT)

terminals

(9)

TAPE

2/ADPT

PLAY

(IN)

terminals

SPEAKERS

B

terminals

(right

channel)

()

SPEAKERS

B

terminals

(left

channel)

(2

SPEAKERS

A

terminals

(right

channel)

_@

SPEAKERS

A

terminals

(left

channel)

CONTROL

OUT

jack

This

jack

is

for

output

of

control

signals

when

operating

other

components

bearing

the

ij

mark

with

the

attached

remote

control

unit.

(15)

Power

cord

Connect

this

cord

to

an

AC

wall

socket,

or

the

AC

outlet

of

an

audio

timer.

5

CONNECTIONS

ee

=

TAPE/OA)

(o)

qT

EO

PLaY

SOOO

@)

Cassette

deck/DAT

@

Cassette,

deck/Adaptor

(3)

Speaker

system

B

(R)

()

Speaker

system

B

(L)

6)

Turntable

@)

Speaker

system

A

(L)

Speaker

system

A

(R)

@

To

an

AC

wall

socket.

6

Make

all

connections

after

unplugging

AC

cords.

CONNECTING

THE

SPEAKER

CORDS

1.

Strip

off

the

vinyl

covering

and

twist

the

tip

of

the

wire

core.

10

mm

Twist

the

wire

core.

2.

Raise

the

lever

in

the

direction

of

the

arrow

and

insert

the

exposed

conductor

into

the

hole.

3.

Now

return

the

lever

to

its

original

position

to

secure

the

cord.

NOTE:

Do

not

allow

any

of

the

cord

conductors

to

protrude

from

the

terminals

or

touch

any

other

conductors.

Malfunctioning

or

breakdowns

may

occur

when

conductors

come

into

contact

with

each

other.

Speaker

Impedance

When

speaker

systems

are

connected

to

only

SPEAKERS

A

or

SPEAKERS

B

terminals,

such

speakers

should

have

rated

impedance

in

the

range

of

4—16

Q.

When

speakers

are

connected

to

both

the

A

and

B

terminals,

they

should

have

a

rated

impedance

in

the

range

of

8—16

0.

CONNECTIONS

CONTROL

8)

CONNECTING

THE

INPUT/OUTPUT

CORDS

Connect

the

white

plug

@)

to

the

L

(left)

channel

(1),

and

the

red

plug

@)

to

the

R

(right)

channel

@).

Be

sure

to

insert

the

plugs

securely.

(1)

Left

channel

a

g;)

/

White

plug

a

(2)

Right

channel

6

Kw

Tas

ay

;

BO

(4)

Red

plug

The

INPUT/OUTPUT

jacks

of

this

unit

are

tinplated

for

high

audio

quality.

REMOTE

CONTROL

CORD

CONNECTIONS

[A|

By

interconnecting

the

CONTROL

jacks

of

Pioneer

units

with

the

mark,

the

entire

system

can

be

operated

with

this

remote

control

unit,

although

some

of

the

units

(AM/FM

tuner,

compact

disc

player,

cassette

deck,

etc.)

may

not

be

equipped

with

remote

sensors.

The

entire

system

can

be

operated

by

a

remote

control

unit

connecting

PIONEER

stereo

components

to

each

other

using

the

control

input

(CONTROL

IN)

jack

on

each

component.

Use

the

remote

control

cord

supplied

with

the

respective

unit

for

the

connection.

An

example

is

shown

in

the

fig.

[A].

As

long

as

you

connect

‘‘OUT”’

to

“‘IN’’,

the

connecting

sequence

is

arbitrary.

In

the

case

of

a

unit

which

has

only

an

‘IN’

connector,

however,

connect

it

last.

@)

Remote

control

unit

@)

A-351R

@)

Cassette

deck

(4)

Compact

disc

player

&)

FM/AM

tuner

7

OPERATIONS

BEFORE

BEGINNING

OPERATIONS

1.

Set

the

POWER

STANDBY/ON

switch

to

ON.

2.

Press

the

SPEAKERS

selector

button

corresponding

to

the

speaker

system

to

be

used.

3.

Set

the

DIRECT

button

to

off.

PLAYBACK

PROCEDURES

1.

Set

the

INPUT

SELECTOR

buttons

to

the

desired

playback

source.

¢

For

playback

with

the

equipment

connected

to

LINE

terminals:

Set

to

[LINE].

©

For

reception

of

an

AM/FM

broadcast:

Set

to

[TUNER].

©

For

playback

of

a

record:

Set

to

[PHONO].

¢

For

playback

of

a

compact

disc:

Set

to

[CD].

¢

For

playback

of

a

tape:

Set

to

[TAPE

1/DAT].

NOTE:

Always

be

sure

to

turn

off

TAPE

2/ADPT

when

not

using

TAPE

2/

ADPT.

.

Operate

the

equipment

to

begin

playback.

.

Adjust

playback

volume

with

VOLUME

CONTROL

on

this

unit.

4.

Adjust

the

tone

to

your

preference

using

BASS

and

TREBLE

controls,

and

BALANCE

control.

PLAYBACK

USING

A

GRAPHIC

EQUALIZER

The

sound

of

all

sources

can

be

finely

adjusted

with

a

graphic

equalizer

connected

to

TAPE

2/ADPT

terminals.

After

pressing

the

TAPE

2/ADPT

button

so

that

its

indicator

lights,

select

the

source

that

you

wish

to

play.

However,

the

graphic

equalizer

is

bypassed

when

DIRECT

button

is

on.

NOTE:

Be

sure

to

perform

this

operation

with

the

adaptor

component

power

switch

in

the

on

position.

Even

when

not

using

the

adaptor

component,

its

power

switch

must

be

left

on.

If

the

adaptor

component

is

switched

off,

no

sound

will

be

produced,

or

the

playback

sound

will

be

distorted.

WN

RECORDING

TAPES

1.

Select

the

recording

equipment

with

INPUT

SELECTOR

buttons.

2.

Begin

recording

by

operating

the

recording

equipment.

Refer

to

the

operating

instructions

for

your

cassette

deck

for

proper

operating

procedures.

USING

AN

AUDIO

TIMER

TO

PERFORM

TIMER

RECORDING

Connect

this

unit’s

power

cord

into

the

AC

power

outlet

of

an

audio

timer,

and

set

the

POWER

STANDBY/ON

switch

to

the

ON

condition

(STANDBY

indicator

goes

off)

when

making

timer

settings.

If

the

unit

is

left

in

the

standby

mode

(STANDBY

indicator

lights),

timer

operation

will

not

be

possible.

8

I

COPYING

TAPES

When

two

decks

are

used

{or

when

using

double

cassette

deck),

you

can

record

the

sounds

from

one

deck

onto

the

other.

Application

examples:

*

To

make

a

tape

copy

with

contents

identical

to

the

original

tape.

©

To

edit

a

recording

of

an

FM

broadcast

in

order

to

cut

out

unwanted

commercials,

recording

only

desired

material

onto

another

tape.

When

using

two

cassette

decks

1:

Load

tapes

for

playback

(pre-recorded

tape)

and

recording

(blank

tape)

into

the

respective

cassette

decks.

2.

Select

the

copying

direction

with

INPUT

SELECTOR

buttons.

e

When

copying

from

the

cassette

deck

of

TAPE

1/DAT

terminals

to

the

cassette

deck

of

TAPE

2/ADPT

terminals:

Press

the

INPUT

SELECTOR

button

[TAPE

1/DAT].

e

When

copying

from

the

cassette

deck

of

TAPE

2/ADPT

terminals

to

the

cassette

deck

of

TAPE

1/DAT

terminals:

Press

the

INPUT

SELECTOR

button

[TAPE

2/ADPT].

Set

INPUT

SELECTOR

to

anything

except

TAPE

1/DAT.

3.

Operate

the

cassette

decks

to

begin

copying.

Set

the

cassette

deck

with

the

blank

tape

to

the

recording

mode,

and

set

the

cassette

deck

with

the

original

(playback)

tape

to

the

playback

mode.

REMOTE

CONTROL

LOADING

BATTERIES

Open

the

battery

compartment

cover

on

the

back

of

the

remote

control

unit.

Insert

size

‘‘AAA”’

[IEC

RO3

(UM-4)]

dry

cell

batteries

into

the

battery

compartment

in

accordance

with

the

indications

(@),

©)

inside

the

compartment.

Close

the

cover

of

the

battery

case.

Incorrect

use

of

batteries

may

lead

to

leakage

or

rupture.

Always

be

sure

to

follow

these

guidelines:

1.

Always

insert

batteries

into

the

battery

compartment

correctly

matching

the

positive

G@

and

negative

©

polarities,

as

indicated

inside

the

compartment.

2.

Never

mix

new

and

used

batteries.

3.

Batteries

of

the

same

size

may

have

different

voltages,

depending

on

their

type.

Do

not

mix

different

types

of

batteries.

RANGE

OF

REMOTE

CONTROL

When

the

remote

control

unit

is

pointed

at

the

remote

sensor

window

on

the

stereo

amplifier

and

any

of

its

buttons

is

pressed,

the

unit

and

other

components

can

be

operated

by

remote

control.

Distance:

Within

a

range

of

approx.

7

meters

from

the

unit’s

remote

control

sensor

window.

Angle:

Within

approx.

30

degrees

from

the

center

of

the

unit’s

remote

control

sensor

window.

Remote

control

will

not

be

possible

if

there

is

an

obstacle

between

the

remote

control

unit

itself

and

the

unit’s

remote

control

sensor

window.

¢

The

accessory

remote

control

unit

can

be

used

to

control

some

functions

of

other

Pioneer

cassette

decks,

CD

players

and

tuners

(only

those

Pioneer

components

bearing

the

fm

mark).

Remote

control

sensor

window

9

REMOTE

CONTROL

@

®

©

@

©

BYEREO

AMPLIFIER

REMOTE

CONTROL

UNIT

@)

DECK

Il

button

To

operate

Deck

Il,

press

this

button

before

pressing

the

operating

buttons.

(2)

DECK

|

button

To

operate

Deck

I,

press

this

button

before

pressing

the

operating

buttons.

(3)

TAPE

SEL

button

Selects

the

cassette

No.

(1

to

6)

for

multi-cassette

changer.

(4)

TAPE

operation

buttons

<<,

me:

Tape

fast

forward

<4,

»

~

:

Playback

in

the

direction

of

the

arrows

|

:

Stop

(S)

DISC

SEL

button

Press

this

to

select

discs

on

a

multi-play

or

twin

tray

compact

disc

player.

(©)

CD

POWER

button

Switches

CD

player

power

on

and

off.

(7)

TUNER

POWER

button

Switches

TUNER

power

on

and

off.

AMP

POWER

button

Switches

the

amplifier

power

STANDBY/ON.

10

(9)

TAPE

2/ADPT

on

and

off

button

Switches

TAPE

2/ADPT

on

and

off.

CD

player

operation

buttons

j<a_:

Returns

you

to

the

start

of

the

track

playing.

(Track

search)

mr]:

Takes

you

to

the

start

of

the

(Track

search)

mw

:

Stop

m

:

Play

(@)

STATION

-,

+

buttons

Calls

stations

one

at

a

time.

(2)

FUNCTION

button:

Each

time

you

press

the

button,

the

setting

changes

as

follows.

ee

TAPE

1/DAT

+—

LINE

(3)

VOLUME

+,

-

buttons

See

aka

DWE

ENA

Magee

Lek

ad

wink

Reig

Wade

eahis

Chubaa

eres

Increases

the

volume.

Decreases

the

volume.

NOTE:

When

the

accessory

remote

control

unit

is

used

to

operate

other

Pioneer

components

with

the

§Rl|

mark,

it

cannot

be

used

to

operate

functions

which

do

not

correspond

to

the

functions

listed

on

the

remote

control

unit.

TROUBLESHOOTING

Incorrect

operations

are

often

mistaken

for

trouble

and

malfunctions.

If

you

think

that

there

is

something

wrong

with

this

component,

check

the

points

below.

Sometimes

the

trouble

may

lie

in

another

component.

Investigate

the

other

components

and

electrical

appliances

being

used.

If

the

trouble

cannot

be

rectified

even

after

exercising

the

checks

listed

below,

ask

your

nearest

PIONEER

authorized

service

center

or

your

dealer

to

carry

out

repair

work.

No

power

supplied

to

unit.

©

Power

plug

is

disconnected

from

outlet.

¢

The

component

power

plug

has

been

plugged

into

another

component

power

outlet

(e.g.

timer,

etc.)

but

power

to

that

unit

is

disconnected.

¢

POWER

STANDBY/ON

switch

is

set

to

STANDBY.

¢

Connecting

cords

are

disconnected

from

terminals,

or

connected

incorrectly.

¢

Terminals,

or

connecting

cords

plugs

are

dirty.

e

INPUT

SELECTOR

button

is

not

set

to

the

desired

input

source.

¢

Insert

plug

securely

into

outlet.

©

Turn

on

power

to

the

other

component.

*

Press

the

POWER

STANDBY/ON

switch

to

ON.

¢

Connect

securely.

e

Clean

terminals

and

plugs.

©

Set

the

INPUT

SELECTOR

button

correctly

(PHONO,

TUNER,

CD,

LINE,

TAPE

1/DAT,

TAPE

2/ADPT).

©

Consult

the

operating

instructions

for

the

other

-

components.

©

Set

one

button

or

both

buttons

to

ON

(am).

©

Operation

of

other

components

is

incorrect.

¢

Both

SPEAKERS

selector

buttons

are

set

to

OFF

(#L).

No

sound

from

one

speaker.

¢

Connecting

cords

or

speaker

cords

are

®

Connect

securely.

disconnected

on

that

side.

Cannot

record

tapes.

®

Connections

are

incorrect.

*

Reconnect

properly.

®

Operation

of

cassette

deck

is

incorrect.

¢

Consult

the

operating

instructions

for

the

Cannot

perform

tape

copying.

cassette

deck.

The

remote

control

unit

does

¢

Operation

of

cassette

deck

is

incorrect.

¢

Consult

the

operating

instructions

for

the

cassette

deck.

not

work.

(Other

components

¢

There

are

no

batteries

in

the

remote

control

unit.

|

¢

Load

the

remote

control

unit

with

batteries

cannot

be

operated.)

(see

page

9).

*

Operate

the

remote

control

unit

within

a

range

of

7

meters

and

an

angle

of

30

degrees

(refer

to

page

9).

e

Check

that

the

battery

compartment

cover

is

closed

correctly.

¢

Connect

correctly

(see

page

7).

¢

Move

so

fluorescent

light

does

not

shine

directly

on

amplifier

front

panel

remote

sensor

window.

*

The

remote

control

sensor

is

not

receiving

any

signals.

¢

The

battery

compartment

cover

is

not

perfectly

closed.

¢

The

remote

control

cord

is

not

connected.

¢

A

fluorescent

light

is

shining

on

the

remote

sensor

window.

¢

Malfunctions

may

occur

as

the

result

of

external

influences,

such

as

lightning

or

static

electricity.

In

this

case,

set

the

POWER

STANDBY/ON

switch

to

OFF

and

then

ON

again

to

restore

normal

operation.

11

SPECIFICATIONS

Amplifier

Section

Continuous

power

output

(both

channels

driven

at

20

Hz

to

20

kHz)

*

T.H.D.

0.07

%,

80)...

cecccceccceseneeeseeveneanes

30

W

+

30

W*

DIN

Continuous

power

output

(both

channels

driven

at

1

kHz)

THA.

Di

1

96)

Ai

Oe

ceccitoss

davvriiiexageddch

secs

ereiteseuxes

45W

+

45W

TA

Dyce

96.820

eixticevisv

Busnes

tus

butane

cutaeeond

beades

35

W

+

35

W

Dynamic

power

output

(on

EIA

dynamic

test

signal)

GD

id

daha

Maan

dase

tia

au

date

Pesan

seduauntoneiesdkue

seine

ws

bea

xilar

Medes

til

60

W

Total

harmonic

distortion

*

20

Hz

to

20

kHz,

30

W,

8Q.....

day

shite

de

cvinwiitnaieds

bapeers

0.07

%*

input

sensitivity/impedance

PHONO

(MIM)

........ccccscseceecseecueserecveedaceeeeeeeenens

2.5

mV/50

kQ

CD,

TUNER,

LINE,

TAPE

1/DAT,

TAPE

2/ADPT....

150

mV/50

kQ

PHONO

overload

level

1

kHz,

T.H.D.

0.1

%

(MM).........ccscesececeerseneteeesenteanas

150

mV

Output

level/impedance

TAPE

1/DAT,

TAPE

2/ADPT

output

.............:0c0000s

150

mV/1

kQ

Frequency

response

PHONO

(MM)

........ccccccceseeerereseeeeens

20

Hz

to

20

kHz

+

0.5

dB

CD,

TUNER,

LINE,

TAPE

1/DAT,

TAPE

2/ADPT

Sup

hair

Purnedallatanak

avo

nesdtedaeel

havea

5

Hz

to

70

kHz

+3:3

dB*

Tone

control

(volume

control

set

at

—

30

dB

position)

BASS

:GisivarseeaccavedeTs

aos

vevs

eatan

bonne

oo

guanas

en

keses

+8

dB

(100

Hz)

TREBLE

cisiiiatedcoaupeapsacacten

tad

ailacvaeneoiagecuee

ees

+8

dB

(10

kHz)

_

Signal-to-Noise

ratio

(IHF

short

circuit,

A

network)

PHONO

(MM,

5

mV

input)

............cccecseeseseceteceeveseeseees

84

dB*

CD,

TUNER,

LINE,

TAPE

1/DAT,

TAPE

2/ADPT............

103

dB*

Signal-to-Noise

ratio

(DIN,

continuous

power/50

mW)

PHONO

(MM)

.........:ccecccsecetecerseesseversnsaneeauacenes

69

dB/65

dB*

CD,

TUNER,

LINE,

TAPE

1/DAT,

TAPE

2/ADPT.....

89

dB/69

dB*

Power

Supply/Miscellaneous

Power

requirements

.........:cceeeeeeeeseeeeees

a.c.

240

Volts,

50/60

Hz

POWEr

CONSUMPTION

.........

2.

ccc

cceeceeeneneenseeaeeeereseneteeeaneeees

325

W

Dimensions

..........2ccsceeceeaeeeeees

420

(W)

x

336

(D)

x

125

(H)

mm

Weight

(without

package)

.........ccccceeesceseeeneversnteeseeeenenes

5.6

kg

Accessories

Remote

Control

Unit

.......ccccccececereserencetenerseeressasatesbeteseseanesens

1

Batteries

(IEC

RO3,

AAA)

.........:cccccccsseeeseseesteeeeereneerenenesenanes

2

Operating

INStrUCTIONS

1.0...

cc

ceceeeeee

es

eeneeeeeeeeeeesanaveueetaeuseeanenes

1

NOTE:

Specifications

and

design

subject

to

possible

modification

without

notice,

due

to

improvements.

*

Measured

with

DIRECT

button

set

to

on.

**

Measured

by

Audio

Spectrum

Analyzer.

Published

by

Pioneer

Electronic

Corporation.

Copyright

©

1992

Pioneer

Electronic

Corporation.

All

rights

reserved.

PIONEER

ELECTRONIC

CORPORATION

4-1,

Meguro

1-Chome,

Meguro-ku,

Tokyo

153,

Japan

PIONEER

ELECTRONICS

[USA]

INC.

2265

East

220th

Street,

Long

Beach,

California

90810,

U.S.A.

P.O.

BOX

1720,

Long

Beach,

California

90801,

U.S.A.

PIONEER

ELECTRONICS

OF

CANADA,

INC.

300

Allstate

Parkway

Markham,

Ontario,

LR

OP2,

Canada

PIONEER

ELECTRONIC

[EUROPE]

N.V.

Haven

1087

Keetberglaan

1,

9120

Melsele,

Belgium,

TEL:

03/750.05.11

PIONEER

ELECTRONICS

AUSTRALIA

PTY.

LTD.

178-184

Boundary

Road,

Braeside,

Victoria

3195,

Australia,

TEL:

[03]

580-9911

<

92EOOFF5W01

>

Printed

in

Japan

<ARB1355-A>
