Pioneer CRT4804P User manual

PIONEER CORPORATION 1-1, Shin-ogura, Saiwai-ku, Kawasaki-shi, Kanagawa 212-0031, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2012
DVH-840AVBT/XEUW5
CRT4804P
DVD AV RECEIVER
DVH-840AVBT /XEUW5
DVH-8480AVBT/XFBR
K-ZZZ JAN. 2012 Printed in Japan
PROVISIONAL

DVH-840AVBT/XEUW5
2
1234
1234
C
D
F
A
B
E
SAFETY INFORMATION
Where in a manufacturer’s service documentation, for example in circuit diagrams or lists
of components, a symbol is used to indicate that a specific component shall be replaced only
by the component specified in that documentation for safety reasons, the following symbol shall
be used:
This service manual is intended for qualified service technicians; it is not meant for the casual do-it-yourselfer.
Qualified technicians have the necessary test equipment and tools, and have been trained to properly and safety repair
complex products such as those covered by this manual.
Improperly performed repairs can adversely affect the safety and reliability of the product and may void the warranty.
If you are not qualified to perform the repair of this product properly and safety, you should not risk trying to do so
and refer the repair to a qualified service technician.
This product is a class 1 laser product, but
this product contains a laser diode higher
than Class 1. To ensure continued safety,
do not remove any covers or attempt to
gain access to the inside of the product.
CAUTION: USE OF CONTROLS OR
ADJUSTMENTS OR PERFORMANCE OF
PROCEDURES OTHER THAN THOSE
SPECIFIED HEREIN MAY RESULT IN
HAZARDOUS RADIATION EXPOSURE.
CAUTION: THE USE OF OPTICAL
INSTRUMENTS WITH THIS PRODUCT
WILL INCREASE EYE HAZARD.
-Safety Precautions for those who Service this Unit.
When checking or adjusting the emitting power of the laser diode exercise caution in order to get safe, reliable
results.
Caution:
1. During repair or tests, minimum distance of 13 cm from the focus lens must be kept.
2. During repair or tests, do not view laser beam for 10 seconds or longer.
CAUTION
Danger of explosion if battery is incorrectly replaced.
Replaced only with the same or equivalent type recommended by the manufacturer.
Discord used batteries according to the manufacturer's instructions.

DVH-840AVBT/XEUW5 3
5 678
5678
C
D
F
A
B
E
CONTENTS
SAFETY INFORMATION .....................................................................................................................................2
1. SERVICE PRECAUTIONS................................................................................................................................4
1.1 SERVICE PRECAUTIONS .........................................................................................................................4
1.2 NOTES ON SOLDERING...........................................................................................................................4
2. SPECIFICATIONS.............................................................................................................................................5
2.1 SPECIFICATIONS ......................................................................................................................................5
2.2 DISC/CONTENT FORMAT.........................................................................................................................8
3. BASIC ITEMS FOR SERVICE ..........................................................................................................................9
3.1 CHECK POINTS AFTER SERVICING .......................................................................................................9
3.2 PCB LOCATIONS.....................................................................................................................................10
3.3 JIGS LIST .................................................................................................................................................10
3.4 CLEANING ...............................................................................................................................................10
3.5 FACTORY SETTINGS.............................................................................................................................. 11
4. BLOCK DIAGRAM ..........................................................................................................................................12
4.1 BLOCK DIAGRAM....................................................................................................................................12
4.2 POWER BLOCK DIAGRAM .....................................................................................................................13
5. DIAGNOSIS ....................................................................................................................................................14
5.1 OPERATIONAL FLOWCHART.................................................................................................................14
5.2 ERROR CODE LIST.................................................................................................................................15
5.3 CONNECTOR FUNCTION DESCRIPTION .............................................................................................16
6. SERVICE MODE.............................................................................................................................................17
6.1 SOFTWARE VERSION INFORMATION DISPLAY ..................................................................................17
6.2 SOFTWARE VERSION UP METHOD......................................................................................................18
7. DISASSEMBLY ...............................................................................................................................................23
8. EACH SETTING AND ADJUSTMENT............................................................................................................27
9. EXPLODED VIEWS AND PARTS LIST ..........................................................................................................28
9.1 PACKING..................................................................................................................................................28
9.2 EXTERIOR (1) ..........................................................................................................................................30
9.3 EXTERIOR (2) ..........................................................................................................................................32
10. SCHEMATIC DIAGRAM................................................................................................................................34
10.1 MB UNIT (1/2) (GUIDE PAGE) ...............................................................................................................34
10.2 MB UNIT (2/2) (GUIDE PAGE) ...............................................................................................................40
10.3 SB SMT UNIT (POWER PART) (GUIDE PAGE) ....................................................................................46
10.4 SB SMT UNIT (MAIN PART) (GUIDE PAGE).........................................................................................52
10.5 KB PCB and AUX PCB (GUIDE PAGE) .................................................................................................58
10.6 CB PCB and LB PCB..............................................................................................................................64
11. PCB CONNECTION DIAGRAM ....................................................................................................................66
11.1 MB UNIT .................................................................................................................................................66
11.2 SB SMT UNIT .........................................................................................................................................70
11.3 KB PCB...................................................................................................................................................72
11.4 AUX PCB ................................................................................................................................................74
11.5 CB PCB...................................................................................................................................................75
11.6 LB PCB ...................................................................................................................................................76
12. ELECTRICAL PARTS LIST...........................................................................................................................77

DVH-840AVBT/XEUW5
4
1234
1234
C
D
F
A
B
E
1. SERVICE PRECAUTIONS
1.1 SERVICE PRECAUTIONS
1.2 NOTES ON SOLDERING
1. You should conform to the regulations govering the product (safety, radio and noise, and other regulations),
and should keep the safety during servicing by following the safety instructions described in this manual.
2. Be careful about an internal sharp edge.
3. Be careful in handling ICs. Some ICs such as MOS type are so fragile that they can be damaged by
electrostatic induction.
4. Be careful in handing made from metal parts. There might be burr at the edge of it.
5. Two kinds of resetting are available
1Turn over the Detach Panel and press RESET Button at Central Part.
Without entire initialization.
Microcomputer restarting (emergency resetting at function trouble) .
With the reset of the pioneer.
2Perform [Default Setting] initialization in Setting
Perform product initialization except a part of items.
Please carry it out when updating software.
6. Any component parts in the CD Mechanism Unit of this model can not be supplied.
If you need to replace any parts in the CD Mechanism Unit, replace whole of CD Mechanism Unit.
For environmental protection, lead-free solder is used on the printed circuit boards mounted in this unit.
Be sure to use lead-free solder and a soldering iron that can meet specifications for use with lead-free solders for repairs
accompanied by reworking of soldering.
Compared with conventional eutectic solders, lead-free solders have higher melting points, by approximately 40 C.
Therefore, for lead-free soldering, the tip temperature of a soldering iron must be set to around 373 C in general, although
the temperature depends on the heat capacity of the PC board on which reworking is required and the weight of the tip of
the soldering iron.
Compared with eutectic solders, lead-free solders have higher bond strengths but slower wetting times and higher melting
temperatures (hard to melt/easy to harden).
The following lead-free solders are available as service parts:
Parts numbers of lead-free solder:
GYP1006 1.0 in dia.
GYP1007 0.6 in dia.
GYP1008 0.3 in dia.

DVH-840AVBT/XEUW5 5
5 678
5678
C
D
F
A
B
E
2. SPECIFICATIONS
2.1 SPECIFICATIONS
General
• DVH-840AVBT/XEUW5
Rated power source: ............................... 14.4 V DC (allowable voltage range: 10.8 V to 15.1
V DC)
Preout maximum output level:................. 4.0 V
Maximum current consumption:
Backup current: .......................................
............. 10.0 A
5 mA or less
Dimensions (W × H × D):
Chassis............................................ 178 mm × 50 mm × 165 mm
Nose ................................................ 188 mm × 58 mm × 22 mm
Weight: .................................................... 1.3 kg
Display
Screen size/aspect ratio: ......................... 3.5 inch wide/16:9 (effective display area: 76.32 mm
× 42.82 mm)
Pixels:...................................................... 320 × (RGB) × 234
Display method: ..................................... TFT active matrix
Durable temperature range (power off) ... –20 °C to + 60 °C
DVD Player
System..................................................... DVD video, Video CD, CD,WMA, MP3, DivX, JPEG
system
Usable discs ............................................ DVD video, Video CD, CD, CD-R/RW, DVD±R/RW/
R DL
Region number........................................ 5 for Russia
Frequency response................................ 20 Hz to 20 kHz (with DVD, at sampling frequency
96 kHz)
Signal-to-noise ratio................................. 75 dB (1 kHz) (IEC-A network) (RCA level)
Output level:
Video ............................................... 1.0 Vp-p/75 (±0.2 V)
Number of channels ................................ 2 (stereo)
MP3 decoding format .............................. MPEG-1 & 2 Audio Layer 3
WMA decoding format............................. Ver. 7, 7.1, 8, 9, 10, 11 (2ch audio) (Windows Media
Player)
DivX decoding format .............................. Home Theater Ver. 3, 4, 5.2, 6 (.avi, .divx)
DVD video output .................................... NTSC
Audio
Maximum power output: .......................... 50 W × 4
Continuous power output ... .................... 22W × 4 (50 Hz to 15 000 Hz, 5%THD, 4 load,
both channels driven)
Load impedance:..................................... 4 (4 to 8 (2 for 1 ch) allowable)
Preout maximum output level.................. 4.0 V
Equalizer (8-Band Graphic Equalizer):
Frequency ......................................... 40/80/200/400/1k/2.5k/8k/10 kHz
Gain................................................... ±12 dB

DVH-840AVBT/XEUW5
6
1234
1234
C
D
F
A
B
E
USB
.................... USB 1.1, USB 2.0 full speed
Maximum current supply ......................... 1000mA
File system: ............................................. FAT16, FAT32
FM tuner
Frequency range: .................................... 87.5 MHz to 108.0 MHz)
Usable sensitivity..................................... 10 dBµ (S/N: 30 dB)
AM tuner
Frequency range: .................................... 531 kHz to 1 602 kHz (9 kHz)
........................................................ 530 kHz to 1 640 kHz (10 kHz)
Usable sensitivity:.................................... 30 dBµ (S/N: 20 dB)
Bluetooth 2.0 certified
Bluetooth
Version ....................................................
Output power........................................... +4dBm Maximum(Power class 2)
USB standard specification:
Gain................................................. ±12 dB
HPF:
Frequency....................................... 50 Hz/63 Hz/80 Hz/100 Hz/125 Hz
Slope............................................... –12 dB/oct
Subwoofer (mono):
Frequency....................................... 50 Hz/63 Hz/80 Hz/100 Hz/125 Hz
Slope............................................... –18 dB/oct
Gain................................................. +6 dB to –24 dB
Phase.............................................. Normal/Reverse
Bass boost:
Gain................................................. +12 dB to 0 dB

DVH-840AVBT/XEUW5 7
5 678
5678
C
D
F
A
B
E
General
Rated power source: ............................... 14.4 V DC (allowable voltage range: 10.8 V to 15.1
V DC)
Preout maximum output level:................. 4.0 V
Maximum current consumption:
Backup current: .......................................
............. 10.0 A
5 mA or less
Dimensions (W × H × D):
Chassis............................................ 178 mm × 50 mm × 165 mm
Nose ................................................ 188 mm × 58 mm × 22 mm
Weight: .................................................... 1.3 kg
Display
Screen size/aspect ratio: ......................... 3.5 inch wide/16:9 (effective display area: 76.32 mm
× 42.82 mm)
Pixels:...................................................... 320 × (RGB) × 234
Display method: ..................................... TFT active matrix
Durable temperature range (power off) ... –20 °C to + 60 °C
DVD Player
System..................................................... DVD video, Video CD, CD,WMA, MP3, DivX, JPEG
system
Usable discs ............................................ DVD video, Video CD, CD, CD-R/RW, DVD±R/RW/
R DL
Region number........................................ 4 for Brazil
Frequency response................................ 20 Hz to 20 kHz (with DVD, at sampling frequency
96 kHz)
Signal-to-noise ratio................................. 75 dB (1 kHz) (IEC-A network) (RCA level)
Output level:
Video ............................................... 1.0 Vp-p/75 (±0.2 V)
Number of channels ................................ 2 (stereo)
MP3 decoding format .............................. MPEG-1 & 2 Audio Layer 3
WMA decoding format............................. Ver. 7, 7.1, 8, 9, 10, 11 (2ch audio) (Windows Media
Player)
DivX decoding format .............................. Home Theater Ver. 3, 4, 5.2, 6 (.avi, .divx)
DVD video output .................................... NTSC
Audio
Continuous power output ... .................... 23 W × 4 (50 Hz to 15 000 Hz, 5%THD, 4 load,
both channels driven)
Load impedance:..................................... 4 (4 to 8 (2 for 1 ch) allowable)
Preout maximum output level.................. 4.0 V
Equalizer (3-Band Graphic Equalizer):
Frequency ....................................... 80/1k/10 kHz
Gain................................................. -14 to +14 dB
• DVH-8480AVBT/XFBR

DVH-840AVBT/XEUW5
8
1234
1234
C
D
F
A
B
E
2.2 DISC/CONTENT FORMAT
Subwoofer (mono):
Frequency ....................................... 80 Hz/120 Hz/160 Hz
Gain................................................. -79 dB to 0 dB
USB
.................... USB 1.1, USB 2.0 full speed
Maximum current supply ......................... 1000mA
File system: ............................................. FAT16, FAT32
FM tuner
Frequency range: .................................... 87.5 MHz to 108.0 MHz)
Usable sensitivity..................................... 10 dBµ (S/N: 30 dB)
AM tuner
Frequency range: .................................... 531 kHz to 1 602 kHz (9 kHz)
........................................................ 530 kHz to 1 640 kHz (10 kHz)
Usable sensitivity:.................................... 30 dBµ (S/N: 20 dB)
Bluetooth 2.0 certified
Bluetooth
Version ....................................................
Output power
Specifications and the design are subject to modifications without notice.
........................................... +4dBm Maximum(Power class 2)
Note:
USB standard specification:
The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc.
and any use of such marks by Pioneer Corporation is under license.
Other trademarks and trade names are those of their respective owners.

DVH-840AVBT/XEUW5 9
5 678
5678
C
D
F
A
B
E
3. BASIC ITEMS FOR SERVICE
3.1 CHECK POINTS AFTER SERVICING
To keep the product quality after servicing, please confirm following check points.
No. Procedures Item to be confirmed
1 Confirm whether the customer complain has
been solved.
If the customer complain occurs with the
specific media, use it for the operation check.
The customer complain must not be
reappeared.
Display, video, audio and operations must be
normal.
2 DVD Play back a DVD.
(Menu operation; Title/chapter search)
Display, video, audio and operations must be
normal.
3 CD Play back a CD.
(Track search)
Display, audio and operations must be
normal.
4 FM/AM tuner Check FM/AM tuner action.
(Seek, Preset)
Switch band to check both FM and AM.
Display, audio and operations must be
normal.
5 Check whether no disc is inside the product. The media used for the operating check must
be ejected.
6 Appearance check No scratches or dirt on its appearance after
receiving it for service.
For check items concerning image and voice, please refer to the followings:
Check items concerning image Check items concerning voice
Block-noise Distortion
Crosscut noise Noise
Dot noise Low volume
Distorted image (Image skip) High volume
Low brightness Changes in level
Too bright Pause of sound
Color fading
Partial discoloration

DVH-840AVBT/XEUW5
10
1234
1234
C
D
F
A
B
E
3.2 PCB LOCATIONS
3.3 JIGS LIST
3.4 CLEANING
C
SB SMT UNIT
MB UNIT
FLB PCB
KB PCB
A
CB PCB
E
AUX PCB
D
B
A:DVH-840AVBT/XEUW5
B:DVH-8480AVBT/XFBR
Unit Number : 843DM7376HRMB003-FY(A)
: CYW1008(B)
Unit Name : MB Unit
Unit Number : 842DM7376HRSB003-FY(A)
: 882DM7376HBSB003-FY(B)
Unit Name : SB SMT Unit
KB Ass'y
Consists of
KB PCB
AUX PCB
Unit Number :
Unit Name : KB Assy
CB/LB Ass'y
Consists of
CB PCB
LB PCB
Unit Number :
Unit Name : CB/LB Assy
-Jigs List
Name
21P FFC
Jig No.
GGD1627
Remarks
Mother Unit (MB) - DVD Decode Unit (SB)
Before shipping out the product, be sure to clean the following portions by using the prescribed cleaning tools:
Portions to be cleaned Cleaning tools
DVD pickup lenses Cleaning liquid : GEM1004
Cleaning paper : GED-008

DVH-840AVBT/XEUW5 11
5 678
5678
C
D
F
A
B
E
3.5 FACTORY SETTINGS
-When the Repair is Complete
When the repair is complete, make the DVD mechanism ready for transportation
implementing the following procedures:
1. Attach the two Transportation Screws.
Now you can transport it.(See the figure below)
Transportation
Screws

DVH-840AVBT/XEUW5
12
1234
1234
C
D
F
A
B
E
4. BLOCK DIAGRAM
4.1 BLOCK DIAGRAM
PICK UP Servo system
Zoran ZR36966H
MCU
NEC uPD78F0547
Panel keys
LCD Driver
T118FS
PW035XS4 3.5“16:9 TFT
Display
Preamp
NJM2792
(4V x 4Ch)
LINE OUT
L/R
L/R
Motor Driver
D5869S
Power
Amplifier
PAL007E
TUNER
TEF6606T
TUNER
Audio
Processor
TDA7419
REMOTE
IR
USB
Power Supply
A/D
SPI
I
2
C
I
2
C
Video
Preamp
NJM2267 Video out
Video
Switch
D310
I
2
C
Camera in
Front AV-IN
L/R
Front
Rear/Sub
DC 14.4V
IPOD
Appreciate
341S2162
BT Audio
Operational
AMP
TPA6112A2
BT NF2301
MODULE
UART
L/R
I
2
C
SD RAM
M12L64164A
EN25T16
FLASH
I
2
C
Y/C
CVBS/Y/C
AUX PCB
D
MB UNIT
A
SB SMT UNIT
B
KB PCB
C

DVH-840AVBT/XEUW5 13
5 678
5678
C
D
F
A
B
E
4.2 POWER BLOCK DIAGRAM
BATT
+14.4V
Power AMP IC
PAL007E
MCU
UPD78F0547
AGK
60mA
MCU5V
MUTE
20 mA
B+
AMP/ANT control
Video Processor NJM2267M
LOD 9V 1A
LSP9801
ADJ
Audio EQ Processor TDA7419
SA1117
3V3
MAX:500mA
D5869S
(Motor
driver)
MAX:390mA
SA1117
1V8
SB Unit
KB Unit
SA1117-3V3 TFT Driver
T118FS MAX:120mA
MAX:30mA
MAX:200mA
USB Power
AP1507-ADJ
Key illumination
DVD DSP
Zoran
ZR36966H
15mA
SA1117- 1V8
B+
1A
LM2950-5V MAX:100mA
LOD 9V 1A
LSP9801
ADJ MAX:2A
AP1507-ADJ
MAX:3A
SA1117-3V3 MAX:800mA
SA1117 1V8 MAX:800mA
AM FM PLL TUNER TEF6606T 150mA
Current
Term 1.5A
AP2191D
MAX:1.5A
AP1507-ADJ
Current Term 5V
1.5A
AP2191D
SA1117-
3V3
BT Module
NF2301
MAX:150mA
Video signal switcher BA7613F 20mA
Audio Preamp NJM2792
47 mA
Operational AMP NJU3414
Current Term
5V 1.5A
AP2191D
Audio DAC
CS4344
SD RAM
M12L64164A
EN25T16
FLASH
Authentication
341S2162-TBB
9V
5V
BT Audio
Operational AMP
TPA6112A2
9V

DVH-840AVBT/XEUW5
14
1234
1234
C
D
F
A
B
E
5. DIAGNOSIS
5.1 OPERATIONAL FLOWCHART
if Acc on
if Press power on key
Acc = 12 V
Starts
communication
with Grille
microcomputer.
Source keys
operative
Source ON
Completes power-on operation.
(After that, proceed to each source operation)
Power ON
Battery = 12 V
DVD Power = 5 V
Vcc = 5 V
TFT Power
On and TFT
Init
Entery select
mode
operative

DVH-840AVBT/XEUW5 15
5 678
5678
C
D
F
A
B
E
5.2 ERROR CODE LIST
Message Cause Action
Loading Disc is being read Please wait, it may take several minutes
for some disc or storage device.
No Disc
Disc is dirty Clean disc with soft cloth
Disc is upside down Insert disc with label side up
Disc not present in loading
compartment Insert disc
Bad Disc
Disc is dirty Clean disc with soft cloth
Disc is upside down Insert disc with label side up
Unknown disc Disc format is not compatible
with this unit Change another disc.
Region Error DVD is not compatible with
region code of unit
Use discs with corresponding regional
code.
Error Illegal mechanism operation Press EJECT key for 5 seconds to reset
loading mechanism

DVH-840AVBT/XEUW5
16
1234
1234
C
D
F
A
B
E
5.3 CONNECTOR FUNCTION DESCRIPTION
1: FR-
2: FL+
3: FR+
4: FL-
5: RR+
6: ILLU_IN
7: RR-
8: ANT
9: T_MUTE
10: +B
9
10
11
12
13
14
15
16
1
2
3
4
5
6
7
8
17
18
19
20
11: RL+
12: GND
13: RL-
14: LO-FL
15: ACCIN
16: LO-FR
17: GND
18: GND
19: LO/SUB-RR
20: LO/SUB-RL
Fuse 10A
(Light Green/ White)
(Pink)
Radio Antenna SWC (Steering Wheel Control) Reverse (Active high level input) Parking SW (Active low level input)
Microphone
(Black)
BT Antenna Video-out
(Y ellow) (Y ellow)
Camera-in

DVH-840AVBT/XEUW5 17
5 678
5678
C
D
F
A
B
E
6. SERVICE MODE
6.1 SOFTWARE VERSION INFORMATION DISPLAY
MODEL: DVH-8480AVBT r Model number (UW5 model : DVH-840AVBT)
MPEG CHIP: ZORAN36966H
MPEG VERSION: V0.24_20111012 r Version of MPEG software : V0.24
PCB:V1.0
Disc Region: 4 r Region Code of DVD : 4
MCU DATE: 09.20.11
MCU VERSION: 01.04 r Version of MPU software : V1.04
BT Firmware: V00.46.R00.25 r Version of BT software : V0.46.R0.25
Example of a display(AVH-8480AVBT)

DVH-840AVBT/XEUW5
18
1234
1234
C
D
F
A
B
E
6.2 SOFTWARE VERSION UP METHOD
Save six (6) sorts of file for Version Up (build.img, UPD_MPEG.VER, update.img, UPD_MCU.VER, UPD_BT.VER and
NFOREBT.dfu) on an USB.
Turn the product power to be ON and insert the above mentioned USB.
1. MPEG software update
2. MCU software update
3. BT software update (Only a model with BT functional)
4. Reset, "do default setting" in the setting menu.
5. Check Version
Insertion of USB will display the following Update screen.
UW model
Method of individual upgrading
Prepare files shown below according to the purpose for upgrading the software. (It is not necessary to prepare all files)
Item to upgrade Use software
MPEG build.img , UPD_MPEG.VER
MCU update.img , UPD_MCU.VER
BT NFOREBT.dfu , UPD_BT.VER
Upgrade the software in the order of MPEG, MCU, and BT.
Please be sure to perform Default Settings in the Setting after performing Version Up.
If you do not perform the Version Up, the initialization of MPEG software will not be executed.
In addition, the Main Body Reset SW located at the rear surface of Detach Panel is only for the Restart RESET
of MCU and it does not mean to perform all of the initializations.
(Language Setting: Russian for UW5 model)
BR model
(Language Setting: Portuguese(B) for BR model)

DVH-840AVBT/XEUW5 19
5 678
5678
C
D
F
A
B
E
1. MPEG update instruction
1. Copy the MPEG update files(upd_mpeg.ver, build.img) to USB device, and insert it to USB Port,
when the system detect the update file exists, it will pop up a menu like Fig.1 as below:
UW5 model BR model
UW5 model BR model
2. If you don’t want to upgrade ,you can press “Cancel” button through Left or Right key of remote control or panel,
otherwise you can move the curse to button “MPEG”, and after pressing Enter key, there will pop other prompt
menu like Fig.2, as below:
3. During the process of upgrade, do not remove the USB device or shut off the power supply, otherwise the system
will breakdown, and never recover any more, if the system restart and pop up Fig.1 for the second time, it means
MPEG upgrade process finished, you can remove the USB device, the whole upgrade process will last about 1 minute;
Fig.1-1 Fig.1-1
Fig.2-1 Fig.2-1

DVH-840AVBT/XEUW5
20
1234
1234
C
D
F
A
B
E
2. If you don’t want to upgrade, you can press “Cancel” button through Left or Right key of remote control or panel,
otherwise you can move the curse to button “MCU”, and after pressing Enter key, there will pop other prompt menu
like Fig.4, the system start to erase the MCU flash, as below:
UW5 model BR model
UW5 model BR model
3. After erasing process finish, system start to upgrade process, and you will find the upgrade process,
just like Fig.5 as below:
4. During the process of upgrade, it’s allowed the user to remove the USB device, because system had copied the
update files to SDRAM, this is different from MPEG upgrade, after the process reach 100%, which means MCU
upgrade finished, and the system will power off automatically, you need to press the power key to restart the system,
the whole upgrade process will take around 2.5 Minutes
UW5 model BR model
2. MCU update instruction
1. Copy the MCU update files(UPD_MCU.VER, update.img) to USB device, and insert it to USB port,
when the system detect the update file exists, it will pop up a menu like Fig.3, as below:
Fig.3-1 Fig.3-1
Fig.4-1 Fig.4-1
Fig.5-1 Fig.5-1
