Pioneer KEH-P1010R User manual

ENGLISH ESPAÑOL DEUTSCH FRANÇAIS ITALIANO NEDERLANDS
Multi-CD control High power cassette player with
RDS tuner
Operation Manual
KEH-P1013R
KEH-P1010R

1
Contents
Key Finder .................................................... 2
-Head Unit
Before Using This Product ...................... 3
About This Product .......................................... 3
About This Manual ............................................ 3
Precaution .......................................................... 3
In Case of Trouble ............................................ 3
Basic Operation ........................................ 4
To Listen to Music ............................................ 4
Basic Operation of Tuner .................................. 5
-Manual and Seek Tuning
-Band
-Preset Tuning
Basic Operation of Cassette Player .................. 6
-Fast Forward/Rewind
-Cassette Loading Slot
-Direction Change
-Eject
Basic Operation of Multi-CD Player ................ 7
-Track Search and Fast Forward/Reverse
-Switching the Display
-Disc Number Search
(for 6-Disc, 12-Disc types)
Tuner Operation ........................................ 8
-Local Seek Tuning
-Best Stations Memory (BSM)
Using RDS Functions ................................ 9
What is RDS? .................................................... 9
Program Service Name Display ........................ 9
AF Function .................................................... 10
-Activating/Deactivating the AF Function
PI Seek Function ............................................ 11
-PI Seek
-Auto PI Seek (for preset station)
Regional Function .......................................... 11
-Activating/Deactivating the REG Function
TA Function .................................................... 12
-Activating/Deactivating the TA Function
-Canceling Traffic Announcements
-Adjusting the TA Volume
-TP Alarm Function
PTY Function .................................................. 14
-PTY Search Setting Function
-PTY Search Function
-PTY Alarm
-Canceling Emergency Announcements
Using the Cassette Player ...................... 17
-Radio Intercept
Using Multi-CD Players .......................... 18
-Repeat Play
-Pause
Audio Adjustment .................................... 19
Selecting the Equalizer Curve ........................ 19
Entering the Audio Menu ................................ 19
Audio Menu Functions .................................... 20
-Balance Adjustment (FAD)
-Equalizer Curve Adjustment (EQ-L/M/H)
-Loudness Adjustment (LOUD)
-Front Image Enhancer Function (FIE)
-Source Level Adjustment (SLA)
Detaching and Replacing
the Front Panel .................................. 24
Theft Protection .............................................. 24
-Detaching the Front Panel
-Replacing the Front Panel
Initial Setting ............................................ 25
Entering the Initial Setting Menu .................... 25
Initial Setting Menu Functions ........................ 26
-Changing the FM Tuning Step (STEP)
-Switching the Auto PI Seek (A-PI)
Cassette Player and Care ...................... 27
Precaution ........................................................ 27
-About the Cassette Player
-About Cassette Tapes
Cleaning the Head .......................................... 27
Specifications .......................................... 28

Key Finder
Head Unit
2/3buttons
SOURCE button
+/– buttons
AUDIO button Detach button
Buttons 1–6
Cassette door
EJECT button
LOCAL/BSM button
PTY button
TA/AF button
BAND button
DISPLAY button
EQ button
1/¡buttons
2
ENGLISH ESPAÑOL DEUTSCH FRANÇAIS ITALIANO NEDERLANDS

3
Before Using This Product
About This Product
The tuner frequencies on this product are allocated for use in Western Europe, Asia, the
Middle East, Africa and Oceania. Use in other areas may result in improper reception. The
RDS function operates only in areas with FM stations broadcasting RDS signals.
About This Manual
This product features a number of sophisticated functions ensuring superior reception and
operation. All are designed for the easiest possible use, but many are not self-explanatory.
This operation manual is intended to help you benefit fully from their potential and to
maximize your listening enjoyment.
We recommend that you familiarize yourself with the functions and their operation by
reading through the manual before you begin using this product. It is especially important
that you read and observe the “Precaution” on this page and in other sections.
Precaution
• The Pioneer CarStereo-Pass is for use only in Germany.
• Keep this manual handy as a reference for operating procedures and precautions.
• Always keep the volume low enough for outside sounds to be audible.
• Protect this product from moisture.
• If the battery is disconnected, the preset memory will be erased and must be repro-
grammed.
In Case of Trouble
Should this product fail to operate properly, contact your dealer or nearest authorized
Pioneer Service Station.
• This product complies with the EMC Directives (89/336/EEC, 92/31/EEC)
and CE Marking Directive (93/68/EEC).

Basic Operation
4
ENGLISH ESPAÑOL DEUTSCH FRANÇAIS ITALIANO NEDERLANDS
To Listen to Music
The following explains the initial operations required before you can listen to music.
Note:
• Loading a cassette in this product. (Refer to page 6.)
1. Select the desired source (e.g. Tuner).
Each press of the SOURCE button selects the desired source in the following order:
Tuner =Cassette player =Multi-CD player =External Unit
Note:
• External Unit refers to a Pioneer product (such as one available in the future) that, although incom-
patible as a source, enables control of basic functions by this product. Only one External Unit can
be controlled by this product.
• In the following cases, the sound source will not change:
* When a product corresponding to each source is not connected to this product.
* When no tape is set in this product.
* When no magazine is set in the Multi-CD player.
• When this product’s blue/white lead is connected to the car’s Auto-antenna relay control terminal,
the car’s Auto-antenna extends when this product’s source is switched ON. To retract the antenna,
switch the source OFF.
2. Raise or lower the volume.
3. Turn the source OFF.
Hold for 1 second
Each press changes the Source ...

5
Basic Operation
Basic Operation of Tuner
This product’s AF function can be switched ON and OFF. AF should be switched OFF
for normal tuning operations. (Refer to page 10.)
Manual and Seek Tuning
• You can select the tuning method by changing the length
of time you press the 2/3button.
Manual Tuning (step by step) 0.5 seconds or less
Seek Tuning 0.5 seconds or more
Note:
• If you continue pressing the button for longer than 0.5 seconds, you can skip
broadcast stations. Seek Tuning starts as soon as you release the button.
• Stereo indicator “” lights when a stereo station is selected.
Preset Tuning
• You can memorize broadcast stations in buttons
1 through 6 for easy, one-touch station recall.
Preset station recall 2 seconds or less
Broadcast station preset memory 2 seconds or more
Note:
• Up to 12 FM stations (6 each in F1 (FM1) and F2 (FM2)) and
6 MW/LW stations can be stored in memory.
Band
F1 (FM1) =F2 (FM2)
=MW/LW
Preset Number Indicator
Band Indicator
Frequency Indicator

Basic Operation of Cassette Player
6
ENGLISH ESPAÑOL DEUTSCH FRANÇAIS ITALIANO NEDERLANDS
Fast Forward/Rewind
• To select Fast Forward, press the button for the same direction as
the direction indicator.
• To select Rewind, press the button for the opposite direction as the
direction indicator.
Note:
• To release Fast Forward/Rewind, lightly press the 1or ¡button located on the
opposite side of the one you pressed to Fast Forward or Rewind.
Eject
Note:
• The Tape function can be turned ON/OFF with
the cassette tape remaining in this product.
(Refer to page 4.)
Direction Indicator
Cassette Loading Slot
Direction Change
• To change the
direction, press
the 1and ¡
buttons at the
same time.

Basic Operation of Multi-CD Player
This product can control a Multi-CD player (sold separately).
7
Basic Operation
Track Search and Fast Forward/Reverse
• You can select between Track Search or Fast
Forward/Reverse by pressing the 2/3button
for a different length of time.
Track Search 0.5 seconds or less
Fast Forward/Reverse Continue pressing
Disc Number Search (for 6-Disc, 12-Disc types)
• You can select discs directly with the 1 to 6 buttons. Just press the number
corresponding to the disc you want to listen to.
Note:
• When a 12-Disc Multi-CD Player is connected and you want to select disc 7 to 12, press the 1 to 6
buttons for 2 seconds.
Note:
• The Multi-CD Player may perform a preparatory operation, such as verifying the presence of a
disc or reading disc information, when the power is turned ON or a new disc is selected for play-
back. “READY” is displayed.
• If the Multi-CD Player cannot operate properly, an error message such as “ERROR-14” is dis-
played. Refer to the Multi-CD Player owner’s manual.
• If there are no discs in the Multi-CD Player magazine, “NO DISC” is displayed.
• You can not operate the 50-Disc Type Multi-CD Player with this product.
Play Time Indicator
Switching the Display
Each press of the DISPLAY button changes the display in
the following order:
Playback mode (Play Time) =Disc and Track Number

Tuner Operation
8
ENGLISH ESPAÑOL DEUTSCH FRANÇAIS ITALIANO NEDERLANDS
Local Seek Tuning
This function selects only stations with especially strong signals.
Best Stations Memory (BSM)
The BSM function stores stations in memory automatically.
• To cancel the process, press the LOCAL/BSM button before memorization is
complete.
• Press the LOCAL/BSM button
for 2 seconds to switch BSM
ON.
The stations with the strongest signals
will be stored under buttons 1–6 and
in order of their signal strength.
“LOC”
• Switch the Local ON/OFF with
the LOCAL/BSM button.

What is RDS?
RDS (Radio Data System) is a system for transmitting data along with FM programs. This
data, which is inaudible, provides a variety of features such as: program service name,
program type display, traffic announcement standby, automatic tuning and program type
tuning, intended to aid radio listeners in tuning to a desired station.
Note:
• RDS service may not be provided by all stations.
• RDS functions, like AF (Alternative frequencies search) and TA (Traffic Announcement standby),
are only active when your radio is tuned to RDS stations.
Program Service Name Display
With this function, the names of networks/stations providing RDS services replace the
frequency on the display a few seconds after they are tuned in.
• When you want to know PTY Information or the frequency of the current
station, change the display.
Each press of the DISPLAY button selects the display in the following order:
Program Service Name =PTY Information =Frequency
Note:
• After switching displays, if you do not perform an operation within 8 seconds, the Program
Service Name is automatically displayed.
7PTY Information
PTY (Program Type ID code) information for the currently tuned station appears on the
display for 8 seconds. The information is correlated with the list in the section “PTY
Function” on page 14.
Note:
• If a PTY code of zero is received from a station, “NONE” will be displayed. This indicates that the
station has not defined its program contents.
• If the signal is too weak for this product to pick up the PTY code, “NO PTY” will be displayed.
7Frequency
The frequency of the current station appears on the display.
Each press changes the Display ...
9
Using RDS Functions

10
ENGLISH ESPAÑOL DEUTSCH FRANÇAIS ITALIANO NEDERLANDS
AF Function
The AF (Alternative Frequencies search) function is used to search for other frequencies in
the same network as the currently tuned station. It automatically retunes the receiver to
another frequency in the network which is broadcasting a stronger signal when there are
problems with reception of the currently tuned station or better reception is possible on
a different frequency.
Note:
• AF tunes the receiver only to RDS stations when you use Seek tuning or BSM Auto Memory with
the “AF ” indicator ON.
• When you recall a preset station, the tuner may update the preset station with a new frequency from
the station’s AF list. (This is only available when using presets on the FM1 band.) No preset num-
ber appears on the display if the RDS data for the station received differs from that for the original-
ly stored station.
• Sound may be temporarily interrupted by another program during an AF frequency search.
• When the tuner is tuned to a non-RDS station, the “AF ” indicator flashes.
• AF can be switched ON or OFF independently for each FM band.
Activating/Deactivating the AF Function
AF is set to ON by default.
• Turn AF to OFF.
To turn AF back ON, repeat the preceding operation.
“AF ” disappearsHold for 2 seconds

Using RDS Functions
11
PI Seek Function
The tuner searches for another frequency broadcasting the same programming. “PI SEEK”
appears on the display and the radio volume is muted during a PI Seek. The muting is dis-
continued after completion of the PI Seek, whether or not the PI seek has succeeded. If the
PI Seek is unsuccessful, the tuner returns to the previous frequency.
PI Seek
If the tuner fails to locate a suitable alternative frequency or if the broadcasting signal is
too weak for proper reception, the PI Seek will automatically start.
Auto PI Seek (for preset station)
When preset stations cannot be recalled, as when traveling long distances, this product can
be set to perform PI Seek also during preset recall.
The default setting for Auto PI Seek is OFF.
Note:
• Refer to “Initial Setting” for details on how to switch Auto PI Seek ON/OFF.
Regional Function
When AF is used to retune the tuner automatically, REG (regional) limits the selection to
stations broadcasting regional programs.
Note:
• Regional programming and regional networks are organized differently depending on the country
(i.e., they may change according to the hour, state or broadcast area).
• The preset number may disappear on the display if the tuner tunes in a regional station which dif-
fers from the originally set station.
• REG can be switched ON or OFF independently for each FM band.
Activating/Deactivating the REG Function
The REG function is set to ON by default.
• Turn REG to OFF.
To turn REG back ON, repeat the preceding operation.
Hold for 2 seconds

12
ENGLISH ESPAÑOL DEUTSCH FRANÇAIS ITALIANO NEDERLANDS
TA Function
The TA (Traffic Announcement standby) function lets you receive traffic announcements
automatically, no matter what source you are listening to. The TA function can be activat-
ed for either a TP station (a station that broadcasts traffic information) or an enhanced
other network’s TP station (a station carrying information which cross-references TP sta-
tions).
Activating/Deactivating the TA Function
1. Tune in a TP or enhanced other network’s TP station.
The “TP” indicator lights when the tuner is tuned to a TP station or an enhanced other net-
work’s TP station.
2. Activate the TA function.
The “TA” indicator lights, indicating that the tuner is waiting for traffic announcements.
Repeat the preceding operation when no traffic announcement is being received to deacti-
vate the TA function.
Note:
• The system switches back to the original source following traffic announcement reception.
• The TA function can be activated from sources other than tuner if the tuner was last set to the FM
band but not if it was last set to the MW/LW band.
• If the tuner was last set to FM, turning on the TA function lets you operate other tuning functions
while listening to sources other than tuner.
• Only TP or enhanced other network’s TP stations are tuned in during the Seek Tuning mode when
the “TA” indicator is ON.
• Only TP or enhanced other network’s TP stations are stored by BSM when the “TA” indicator is
ON.
“TP” “TA”

13
Using RDS Functions
Canceling Traffic Announcements
• Press the TA/AF button while a traffic announcement is being received to
cancel the announcement and return to the original source.
The announcement is canceled but the tuner remains in the TA mode until the TA/AF
button is pressed again.
Adjusting the TA Volume
When a traffic announcement begins, the volume adjusts automatically to a preset level to
enable you to hear the announcement clearly.
• Set the volume by adjusting it during reception of a traffic announcement.
The newly set volume is stored in memory and recalled for subsequent traffic
announcements.
TP Alarm Function
About 30 seconds after the “TP” indicator is extinguished due to a weak signal, a 5 second
beep sounds to remind you to select another TP or enhanced other network’s TP station.
• If you are listening to the tuner, tune in another TP station or enhanced
other network’s TP station.
In sources other than tuner, the tuner automatically seeks out the TP station with the
strongest signal in the current area 10 (or 30)* seconds after “TP” disappears from the dis-
play.
* Time taken before Seek begins.
TA function ON 10 seconds
TA, AF functions ON 30 seconds

14
ENGLISH ESPAÑOL DEUTSCH FRANÇAIS ITALIANO NEDERLANDS
PTY Function
The PTY function enables you to select stations by the type of programming they broadcast
(PTY Search). It also provides automatic tuning to emergency broadcasts (PTY Alarm).
Note:
• PTY code program types are as follows:
1. NEWS: News.
2. AFFAIRS: Current affairs.
3. INFO: General information and advice.
4. SPORT: Sports programs.
5. EDUCATE: Educational programs.
6. DRAMA: All radio plays and serials.
7. CULTURE: Programs concerned with any aspect of national or regional culture.
8. SCIENCE: Programs about nature, science and technology.
9. VARIED: Light entertainment programs.
10. POP MUS: Popular music.
11. ROCK MUS: Contemporary modern music.
12. EASY MUS: Easy listening music.
13. L. CLASS: Light classical music.
14. CLASSIC: Serious classical music.
15. OTH MUS: Other types of music, which can’t be categorized.
16. WEATHER: Weather reports/Meteorological information.
17. FINANCE: Stock market reports, commerce, trading etc.
18. CHILDREN: Children’s programs.
19. SOCIAL: Social affairs programs.
20. RELIGION: Religion affairs programs or services.
21. PHONE IN: Phone in based programs.
22. TOURING: Travel programs, not for announcements about traffic problem.
23. LEISURE: Programs about hobbies and recreational activities.
24. JAZZ: Jazz music based programs.
25. COUNTRY: Country music based programs.
26. NAT MUS: National music based programs.
27. OLDIES: Oldies music, ‘Golden age’ based programs.
28. FOLK MUS: Folk music based programs.
29. DOCUMENT: Documentary programs.

Using RDS Functions
PTY Search Setting Function
1. Enter the PTY Search setting mode.
The name of a program type appears on the display for 5 seconds.
Note:
• CURRENT sets desired PTY to the program type of the current station (only for RDS stations
broadcasting PTY information).
2. Select one of the PTYs.
3. When the desired programming type appears on the display, return to the
normal display.
Hold for 2 seconds
15

16
ENGLISH ESPAÑOL DEUTSCH FRANÇAIS ITALIANO NEDERLANDS
PTY Search Function
• Initiate a PTY search.
The tuner searches for a station broadcasting the desired PTY.
Note:
• The program of some stations may differ from that indicated by the transmitted PTY.
• If no station broadcasting the selected programming type is found, “NOTFOUND” is displayed for
about 2 seconds, and the tuner returns to the original station.
PTY Alarm
PTY Alarm is a special PTY code for announcements regarding emergencies such as nat-
ural disasters. When the tuner receives the radio alarm code, “ALARM” appears on the
display and the volume adjusts to the TA volume. When the station stops broadcasting the
emergency announcement, the system returns to the previous source.
Canceling Emergency Announcements
• Press the TA/AF button during emergency announcement reception to can-
cel the announcement and return to the previous source.

17
Using the Cassette Player
Radio Intercept
This function allows you to listen to the radio during tape fast-forwarding/rewinding.
“RI”
• Switch the Radio Intercept
ON/OFF with the button 6.

18
ENGLISH ESPAÑOL DEUTSCH FRANÇAIS ITALIANO NEDERLANDS
Using Multi-CD Players
Repeat Play
There are three repeat play ranges: One-track Repeat, Disc Repeat and Multi-CD player
Repeat. Default repeat play range is Multi-CD player Repeat.
Play range Display
Multi-CD player Repeat MCD
One-track Repeat TRK
Disc Repeat DSC
Note:
• If you select other discs during the repeat play, the repeat play range changes to Multi-CD player
Repeat.
• If you perform Track Search or Fast Forward/Reverse during One-track Repeat, the repeat play
range changes to Disc Repeat.
Pause
Pause pauses the currently playing track.
• Switch the Pause play ON/OFF
with the LOCAL/BSM button.
• Select the desired repeat play
range by pressing the
LOCAL/BSM button for
2 seconds.
Multi-CD player Repeat =One-track
Repeat =Disc Repeat

19
Audio Adjustment
Selecting the Equalizer Curve
You can switch between Equalizer curves.
• Press the EQ button to select the desired Equalizer curve.
POWERFUL (powerful) =NATURAL (natural) =VOCAL (vocal)
=CUSTOM (custom) =EQ FLAT (flat) =SPR-BASS (super bass)
Note:
• “CUSTOM” stores an equalizer curve you have made adjustments to. (Refer to “Equalizer Curve
Adjustment” on page 21.)
Entering the Audio Menu
With this Menu, you can adjust the sound quality.
Note:
• After entering the Audio Menu, if you do not perform an operation within about 30 seconds, the
Audio Menu is automatically canceled.
1. Select the desired mode in the Audio Menu.
2. Operate a mode.
3. Cancel the Audio Menu.
Each press changes the Mode ...
“EQ”
