Pioneer DEH-P6750MP User manual

Operation Manual
Multi-CD/DAB control High power CD/MP3/WMA
player with FM/AM tuner
DEH-P6750MP
English
Português (B)
Español

Thank you for buying this Pioneer product.
Please read through these operating instructions so you will know how to operate
your model properly. After you have finished reading the instructions, keep this man-
ual in a safe place for future reference.
Before You Start
About this unit 5
About this manual 5
Features 5
About WMA 5
Protecting your unit from theft 6
Removing the front panel 6
Attaching the front panel 6
About the demo mode 6
Reverse mode 7
Feature demo 7
Use and care of the remote control 7
Installing the battery 7
Using the remote control 7
About the operation mode 8
Whats What
ead unit 9
Remote control 10
Basic Operations
Turning the unit on 11
Selecting a source 11
Loading a disc 11
Adjusting the volume 12
Turning the unit off 12
Tuner
Listening to the radio 13
Introduction of advanced tuner
operation 14
Storing and recalling broadcast
frequencies 14
Tuning in strong signals 14
Storing the strongest broadcast
frequencies 15
Built-in D Player
Playing a CD 16
Introduction of advanced built-in CD player
operation 16
Repeating play 16
Playing tracks in a random order 17
Scanning tracks of a CD 17
Pausing CD playback 17
Using compression and BMX 18
Selecting the search method 18
Searching every 10 tracks in the current
disc 18
Using disc title functions 18
Entering disc titles 18
Displaying disc titles 19
Using CD TEXT functions 19
Displaying titles on CD TEXT
discs 20
Scrolling titles in the display 20
MP3/WMA/WAV Player
Playing MP3/WMA/WAV 21
Introduction of advanced built-in CD player
(MP3/WMA/WAV) operation 22
Repeating play 22
Playing tracks in a random order 22
Scanning folders and tracks 22
Pausing MP3/WMA/WAV playback 23
Selecting folders from the folder title list 23
Using compression and BMX 23
Selecting the search method 23
Searching every 10 tracks in the current
folder 24
Displaying text information on MP3/WMA/
WAV disc 24
When playing back an MP3/WMA
disc 24
When playing back a WAV disc 24
Scrolling text information in the display 25
Contents
En
2

Multi- D Player
Playing a CD 26
50-disc multi-CD player 26
Introduction of advanced multi-CD player
operation 27
Repeating play 27
Playing tracks in a random order 27
Scanning CDs and tracks 28
Pausing CD playback 28
Using ITS playlists 28
Creating a playlist with ITS
programming 28
Playback from your ITS playlist 29
Erasing a track from your ITS
playlist 29
Erasing a CD from your ITS
playlist 29
Using disc title functions 30
Entering disc titles 30
Displaying disc titles 31
Selecting discs from the disc title
list 31
Using CD TEXT functions 31
Displaying titles on CD TEXT
discs 31
Scrolling titles in the display 31
Using compression and bass emphasis 32
Audio Adjustments
Introduction of audio adjustments 33
Compensating for equalizer curves (EQ-
EX) 33
Using balance adjustment 33
Using the equalizer 34
Recalling equalizer curves 34
Adjusting equalizer curves 34
Fine-adjusting equalizer curve 35
Adjusting bass and treble 35
Adjusting bass and treble level 35
Selecting bass frequency 36
Selecting treble frequency 36
Adjusting loudness 36
Using subwoofer output 36
Adjusting subwoofer settings 37
Using nonfading output 37
Adjusting nonfading output level 37
Using the high pass filter 37
Adjusting source levels 38
Initial Settings
Adjusting initial settings 39
Setting the clock 39
Setting the FM tuning step 39
Setting the AM tuning step 40
Switching the warning tone 40
Switching the auxiliary setting 40
Switching the dimmer setting 40
Adjusting the brightness 40
Setting the rear output and subwoofer
controller 41
Switching the telephone muting/
attenuation 41
Switching the Ever Scroll 42
Other Functions
Using the operation mode 2 43
Tuner 43
Built-in CD Player 43
MP3/WMA/WAV and Multi-CD
player 43
DAB 43
Television 44
DVD player and Multi-DVD player 44
AUX 44
Turning the clock display on or off 44
Using the AUX source 44
Selecting AUX as the source 44
Setting the AUX title 45
En 3
English
Contents

Using different entertainment displays 45
Introduction of DAB operation 46
Operation 46
Changing the label 46
Operating announcements with the
function menu 46
Available PTY function 47
Using dynamic label 47
Introduction of DVD operation 48
Operation 48
Function menu switching 48
Using ITS playlist and disc title
functions 48
Additional Information
Understanding built-in CD player error
messages 49
CD player and care 49
CD-R/CD-RW discs 49
MP3, WMA and WAV files 50
MP3 additional information 51
WMA additional information 51
WAV additional information 51
About folders and MP3/WMA/WAV files 52
Terms 53
Specifications 55
Contents
En
4

About this unit
AUTION
!Do not allow this unit to come into contact
with liquids. Electrical shock could result.
Also, this unit damage, smoke, and overheat
could result from contact with liquids.
!Keep this manual handy as a reference for op-
erating procedures and precautions.
!Always keep the volume low enough so that
you can hear sounds from outside the vehicle.
!Protect this unit from moisture.
!If the battery is disconnected or discharged,
the preset memory will be erased and must be
reprogrammed.
!If this unit does not operate properly, contact
your dealer or nearest authorized Pioneer Ser-
vice Station.
About this manual
This unit features a number of sophisticated
functions ensuring superior reception and op-
eration. All the functions have been designed
for the easiest possible use, but many are not
self-explanatory. This operation manual will
help you benefit fully from this units potential
and to maximize your listening enjoyment.
We recommend that you familiarize yourself
with the functions and their operation by read-
ing through the manual before you begin
using this unit. It is especially important that
you read and observe WARNINGs and AU-
TIONs in this manual.
Features
CD playback
Music CD/CD-R/CD-RW playback is possible.
MP3 file playback
You can play back MP3 files recorded on CD-
ROM/CD-R/CD-RW (ISO9660 Level 1/Level 2
standard recordings).
!Supply of this product only conveys a li-
cense for private, non-commercial use and
does not convey a license nor imply any
right to use this product in any commercial
(i.e. revenue-generating) real time broad-
casting (terrestrial, satellite, cable and/or
any other media), broadcasting/streaming
via internet, intranets and/or other net-
works or in other electronic content distri-
bution systems, such as pay-audio or
audio-on-demand applications. An inde-
pendent license for such use is required.
For details, please visit
http://www.mp3licensing.com.
WMA file playback
You can play back WMA files recorded on CD-
ROM/CD-R/CD-RW (ISO9660 Level 1/Level 2
standard recordings).
WAV file playback
You can play back WAV files recorded on CD-
ROM/CD-R/CD-RW (Linear PCM (LPCM)/MS
ADPCM recordings).
About WMA
The Windows Media"logo printed on the box
indicates that this unit can play back WMA
data.
Before You Start
En 5
English
Section
01

WMA is short for Windows Media Audio and
refers to an audio compression technology
that is developed by Microsoft Corporation.
WMA data can be encoded by using Windows
Media Player version 7 or later.
Microsoft, Windows Media, and the Windows
logo are trademarks, or registered trademarks
of Microsoft Corporation in the United States
and/or other countries.
Notes
!With some applications used to encode WMA
files, this unit may not operate correctly.
!Depending on the version of Windows Media
Player used to encode WMA files, album
names and other text information may not be
correctly displayed.
Protecting your unit from
theft
The front panel can be detached from the
head unit and stored in the protective case
provided to discourage theft.
!If the front panel is not detached from the
head unit within five seconds of turning off
the ignition, a warning tone will sound.
!You can turn off the warning tone. See
Switching the warning tone on page 40.
Important
!Never use force or grip the display and the
buttons too tightly when removing or attach-
ing.
!Avoid subjecting the front panel to excessive
shocks.
!Keep the front panel out of direct sunlight and
high temperatures.
emoving the front panel
1 Press OPEN to open the front panel.
2 Grip the left side of the front panel and
pull it gently outward.
Take care not to grip it too tightly or to drop
the front panel and protect it from contact
with water or other fluids to prevent perma-
nent damage.
3 Put the front panel into the protective
case provided for safe keeping.
Attaching the front panel
%Replace the front panel by holding it
upright to the unit and clipping it securely
into the ounting hooks.
About the demo mode
This unit features two demonstration modes.
One is the reverse mode, the other is the fea-
ture demo mode.
!You cannot cancel a demo mode when the
front panel is open.
Before You Start
En
6
Section
01

Important
The red lead (ACC) of this unit should be con-
nected to a terminal coupled with ignition switch
on/off operations. If this is not done, the vehicle
battery may be drained.
everse mode
If you do not perform an operation within
about 30 seconds, screen indications start to
reverse, and then continue reversing every 10
seconds. Pressing button 5when power to
this unit is turned off while the ignition switch
is set to ACC or ON cancels the reverse mode.
Press button 5again to start the reverse
mode.
Feature demo
The feature demo automatically starts when
power to this unit is turned off while the igni-
tion switch is set to ACC or ON. Pressing but-
ton 6during feature demo operation cancels
the feature demo mode. Press button 6again
to start the feature mode. Remember that if
the feature demo continues operating when
the car engine is turned off, it may drain bat-
tery power.
Use and care of the remote
control
Installing the battery
Slide the tray out on the back of the remote
control and insert the battery with the plus (+)
and minus () poles pointing in the proper di-
rection.
WARNING
Keep the battery out of the reach of children.
Should the battery be swallowed, immediately
consult a doctor.
AUTION
!Use only one R2025 (3 V) lithium battery.
!Remove the battery if the remote control is not
used for a month or longer.
!Do not recharge, disassemble, heat or dispose
of the battery in fire.
!Do not handle the battery with metallic tools.
!Do not store the battery with metallic materi-
als.
!In the event of battery leakage, wipe the re-
mote control completely clean and install a
new battery.
!When disposing of used batteries, please
comply with governmental regulations or en-
vironmental public institutionsrules that
apply in your country/area.
Using the remote control
Point the remote control in the direction of the
front panel to operate.
Before You Start
En 7
English
Section
01

!The remote control may not function prop-
erly in direct sunlight.
Important
!Do not store the remote control in high tem-
peratures or direct sunlight.
!Do not let the remote control fall onto the
floor, where it may become jammed under the
brake or accelerator pedal.
About the operation mode
This unit features two operation modes, opera-
tion mode 1 and 2. Operation mode 1 enables
you to operate all the functions of this unit.
Operation mode 2 enables you to operate the
basic functions for each source easily. This
manual explains operation mode 1. Please
refer to Using the operation mode 2 on page 43
for operation mode 2.
Before You Start
En
8
Section
01

Head unit
1CLOCK button
Press to change to the clock display.
2PAUSE button
Press to turn pause on or off.
3DISPLAY button
Press to select different displays.
4FUNCTION button
Press to select functions.
5AUDIO button
Press to select various sound quality con-
trols.
6ENTERTAINMENT button
Press to change to the entertainment dis-
play.
7OPEN button
Press to open the front panel.
8a/b/c/dbuttons
Press to do manual seek tuning, fast for-
ward, reverse and track search controls.
Also used for controlling functions.
9SW button
Press to directly select subwoofer setting
menu. See Using subwoofer output on page
36. Press and hold to select EQ-EX setting
menu. See Compensating for equali er
curves (EQ-EX) on page 33.
aBAND button
Press to select among three FM bands and
one AM band and to cancel the control
mode of functions.
b16 buttons
Press for preset tuning and disc number
search when using a multi-CD player.
cSOURCE button
This unit is turned on by selecting a source.
Press to cycle through all the available
sources.
dEQ button
Press to select various equalizer curves.
eVOLUME
When you press VOLUME, it extends out-
ward so that it becomes easier to turn. To re-
tract VOLUME, press it again. Rotate it to
increase or decrease the volume.
123 4
5
67
8
9abcd
e
Whats What
En 9
English
Section
02

emote control
Operation is the same as when using the but-
tons on the head unit. See the explanation of
the head unit about the operation of each but-
ton with the exception of ATT, which is ex-
plained below.
fVOLUME buttons
Press to increase or decrease the volume.
gATT button
Press to quickly lower the volume level, by
about 90%. Press once more to return to the
original volume level.
hTUNER button
Press to select the tuner as the source.
iPAUSE button
Press to turn pause on or off.
jCD button
Press to select the built-in or multi-CD
player as the source.
5
4
h
j
i
i
i
a
g
8
f
Whats What
En
10
Section
02

Turning the unit on
%Press SOURCE to turn the unit on.
When you select a source the unit is turned
on.
Selecting a source
You can select a source you want to listen to.
To switch to the built-in CD player, load a disc
in the unit (refer to page 16).
%When using the head unit, press
SOURCE to select a source.
Press SOURCE repeatedly to switch between
the following sources:
DAB (Digital Audio Broadcasting)Tuner
TelevisionDVD player/Multi-DVD player
Built-in D playerMulti- D player
External unit 1External unit 2AUX
%When using the re ote control, press
TUNER or CD to select a source.
Press each button repeatedly to switch be-
tween the following sources:
TUNER:DAB (Digital Audio Broadcasting)
TunerTelevisionSources off
CD:DVD player/Multi-DVD playerBuilt-
in D playerMulti- D playerSources
off
Notes
!In the following cases, the sound source will
not change:
When there is no unit corresponding to the
selected source connected to this unit.
When there is no disc in the unit.
When there is no disc in the DVD player.
When there is no magazine in the multi-
CD player.
When there is no magazine in the multi-
DVD player.
When the AUX (auxiliary input) is set to off
(refer to page 40).
!External unit refers to a Pioneer product (such
as one available in the future) that, although
incompatible as a source, enables control of
basic functions by this unit. Two external units
can be controlled by this unit. When two exter-
nal units are connected, the allocation of
them to external unit 1 or external unit 2 is
automatically set by this unit.
!When this units blue/white lead is connected
to the vehicles auto-antenna relay control
terminal, the vehicles antenna extends when
this units source is turned on. To retract the
antenna, turn the source off.
Loading a disc
1 Press OPEN to open the front panel.
CD loading slot appears.
#After a CD has been inserted, press SOURCE
to select the built-in CD player.
2 Insert a CD into the CD loading slot.
Playback will automatically start.
CD loading slot
EJECT button
#You can eject a CD by pressing EJECT.
#To avoid a malfunction, make sure that no
metal object comes into contact with the term-
inals when the front panel is open.
Basic Operations
En 11
English
Section
03

Notes
!The built-in CD player plays one, standard, 12-
cm or 8-cm (single) CD at a time. Do not use
an adapter when playing 8-cm CDs.
!Do not insert anything other than a CD into
the CD loading slot.
!There is sometimes a delay between starting
up CD playback and the sound being issued.
When being read in, For at Read is dis-
played.
!If you cannot insert a disc completely or if
after you insert a disc the disc does not play,
check that the label side of the disc is up.
Press EJECT to eject the disc, and check the
disc for damage before inserting it again.
!If an error message such as ERROR-11 is dis-
played, refer to Understanding built-in CD
player error messages on page 49.
!You can eject the CD by pressing and holding
EJECT with opening the front panel when the
CD loading or ejecting cannot operate proper-
ly.
Adjusting the volume
%Use VOLUME to adjust the sound level.
With the head unit, rotate VOLUME to in-
crease or decrease the volume.
With the remote control, press VOLUME to in-
crease or decrease the volume.
Turning the unit off
%Press SOURCE and hold until the unit
turns off.
Basic Operations
En
12
Section
03

Listening to the radio
5
21 43
These are the basic steps necessary to operate
the radio. More advanced tuner operation is
explained starting on the next page.
Important
If you are using this unit in North, Central or
South America, reset the AM tuning step (see
Setting the AM tuning step on page 40).
1Stereo (ST) indicator
Shows that the frequency selected is being
broadcast in stereo.
2LOC indicator
Shows when local seek tuning is on.
3Preset nu ber indicator
Shows which preset has been selected.
4Band indicator
Shows which band the radio is tuned to, AM
or FM.
5Frequency indicator
Shows to which frequency the tuner is
tuned.
1 Press SOURCE to select the tuner.
Press SOURCE until you see Tuner displayed.
2 Press BAND to select a band.
Press BAND until the desired band is dis-
played, FM1,FM2,FM3 for FM or AM.
3 To perfor anual tuning, briefly press
cor d.
The frequencies move up or down step by
step.
4 To perfor seek tuning, press and hold
cor dfor about one second and release.
The tuner will scan the frequencies until a
broadcast strong enough for good reception is
found.
#You can cancel seek tuning by briefly pressing
either cor d.
#If you press and hold cor dyou can skip sta-
tions. Seek tuning starts as soon as you release
the button.
Tuner
En 13
English
Section
04

Introduction of advanced
tuner operation
1
1Function display
Shows the function status.
%Press FUNCTION to display the function
na es.
Press FUNCTION repeatedly to switch be-
tween the following functions:
BSM (best stations memory)Local (local
seek tuning)
#To return to the frequency display, press
BAND.
Note
If you do not operate the function within about 30
seconds, the display is automatically returned to
the frequency display.
Storing and recalling
broadcast frequencies
If you press any of the preset tuning buttons
16you can easily store up to six broadcast
frequencies for later recall with the touch of a
button.
%When you find a frequency that you
want to store in e ory press one of pre-
set tuning buttons 16 and hold until the
preset nu ber stops flashing.
The number you have pressed will flash in the
preset number indicator and then remain lit.
The selected radio station frequency has been
stored in memory.
The next time you press the same preset tun-
ing button the radio station frequency is re-
called from memory.
Notes
!Up to 18 FM stations, six for each of the three
FM bands, and six AM stations can be stored
in memory.
!You can also use aand bto recall radio sta-
tion frequencies assigned to preset tuning
buttons 16.
Tuning in strong signals
Local seek tuning lets you tune in only those
radio stations with sufficiently strong signals
for good reception.
1 Press FUNCTION to select Local.
Press FUNCTION until Local appears in the
display.
2 Press ato turn local seek tuning on.
Local seek sensitivity (e.g., Local 2) appears in
the display.
3 Press cor dto set the sensitivity.
There are four levels of sensitivity for FM and
two levels for AM:
FM: Local 1Local 2Local 3Local 4
AM: Local 1Local 2
The Local 4 setting allows reception of only
the strongest stations, while lower settings let
you receive progressively weaker stations.
4 When you want to return to nor al
seek tuning, press bto turn local seek tun-
ing off.
Local :OFF appears in the display.
Tuner
En
14
Section
04

Storing the strongest
broadcast frequencies
BSM (best stations memory) lets you automa-
tically store the six strongest broadcast fre-
quencies under preset tuning buttons 16and
once stored there you can tune in to those fre-
quencies with the touch of a button.
1 Press FUNCTION to select BSM.
Press FUNCTION until BSM appears in the
display.
2 Press ato turn BSM on.
BSM begins to flash. While BSM is flashing
the six strongest broadcast frequencies will be
stored under preset tuning buttons 16in the
order of their signal strength. When finished,
BSM stops flashing.
#To cancel the storage process, press b.
Note
Storing broadcast frequencies with BSM may re-
place broadcast frequencies you have saved
using buttons 16.
Tuner
En 15
English
Section
04

Playing a CD
2
1
These are the basic steps necessary to play a
CD with your built-in CD player. More ad-
vanced CD operation is explained starting on
this page.
1Track nu ber indicator
Shows the track currently playing.
2Play ti e indicator
Shows the elapsed playing time of the cur-
rent track.
1 Press SOURCE to select the built-in CD
player.
Press SOURCE until you see Co pact Disc
displayed.
#If no disc is loaded in the unit, you cannot se-
lect Co pact Disc (built-in CD player). Insert a
disc in the unit. (Refer to page 11.)
2 To perfor fast forward or reverse,
press and hold cor d.
#If you select ROUGH SEARCH, pressing and
holding cor denables you to search every 10
tracks in the current disc. (Refer to Selecting the
search method on page 18.)
3 To skip back or forward to another
track, press cor d.
Pressing dskips to the start of the next track.
Pressing conce skips to the start of the cur-
rent track. Pressing again will skip to the pre-
vious track.
Introduction of advanced
built-in CD player operation
1
1Function display
Shows the function status.
%Press FUNCTION to display the function
na es.
Press FUNCTION repeatedly to switch be-
tween the following functions:
Repeat (repeat play)Rando (random play)
Scan (scan play)Pause (pause)
Co p./BMX (compression and BMX)
FF/REV (search method)
#To return to the playback display, press BAND.
Note
If you do not operate the function within about 30
seconds, the display is automatically returned to
the playback display.
epeating play
Repeat play lets you hear the same track over
again.
1 Press FUNCTION to select Repeat.
Press FUNCTION until Repeat appears in the
display.
2 Press cor dto select the repeat range.
Press cor duntil the desired repeat range ap-
pears in the display.
!DISC Repeat the current disc
Built-in CD Player
En
16
Section
05

!TRACK Repeat just the current track
Note
If you perform track search or fast forward/re-
verse during TRACK, the repeat play range
changes to DISC.
Playing tracks in a random
order
Random play lets you play back tracks on the
CD in a random order.
1 Press FUNCTION to select Rando .
Press FUNCTION until Rando appears in
the display.
2 Press ato turn rando play on.
Rando :ON appears in the display. Tracks
will play in a random order.
3 Press bto turn rando play off.
Rando :OFF appears in the display. Tracks
will continue to play in order.
Scanning tracks of a CD
Scan play lets you hear the first 10 seconds of
each track on the CD.
1 Press FUNCTION to select Scan.
Press FUNCTION until Scan appears in the
display.
2 Press ato turn scan play on.
Scan :ON appears in the display. The first 10
seconds of each track is played.
3 When you find the desired track press
bto turn scan play off.
Scan :OFF appears in the display. The track
will continue to play.
#If the display has automatically returned to
the playback display, select Scan again by press-
ing FUNCTION.
Note
After scanning of a CD is finished, normal play-
back of the tracks will begin again.
Pausing CD playback
Pause lets you temporarily stop playback of
the CD.
1 Press FUNCTION to select Pause.
Press FUNCTION until Pause appears in the
display.
2 Press ato turn pause on.
Pause :ON appears in the display. Play of the
current track pauses.
3 Press bto turn pause off.
Pause :OFF appears in the display. Play will re-
sume at the same point that you turned pause
on.
Built-in CD Player
En 17
English
Section
05

Using compression and BMX
Using the COMP (compression) and BMX
functions let you adjust the sound playback
quality of this player. Each of the functions
have a two-step adjustment. The COMP func-
tion balances the output of louder and softer
sounds at higher volumes. BMX controls
sound reverberations to give playback a fuller
sound. Listen to each of the effects as you se-
lect through them and use the one that best
enhances the playback of the track or CD that
you are listening to.
1 Press FUNCTION to select Co p.
Press FUNCTION until Co p. appears in the
display.
2 Press aor bto select your favorite set-
ting.
Press aor brepeatedly to switch between the
following settings:
Co p./BMX OFFCo p. 1Co p. 2
Co p./BMX OFFBMX 1BMX 2
Selecting the search method
You can switch the search method between
fast forward/reverse and searching every 10
tracks.
1 Press FUNCTION to select FF/REV.
Press FUNCTION until FF/REV appears in the
display.
#If the search method ROUGH SEARCH has
been previously selected, ROUGH SEARCH will
be displayed.
2 Press cor dto select the search eth-
od.
Press cor duntil the desired search method
appears in the display.
!FF/REV Fast forward and reverse
!ROUGH SEARCH Searching every 10
tracks
Searching every 10 tracks in
the current disc
If a disc contains over 10 tracks, you can
search every 10 tracks. When a disc contains
a lot of tracks, you can roughly search for the
track you want to play.
1 Select the search ethod
ROUGH SEARCH.
2 Press and hold cor dto search every
10 tracks on a disc.
#If a disc contains less than 10 tracks, pressing
and holding drecalls the last track of the disc.
Also, if the remaining number of tracks after
searching every 10 tracks is less than 10, press-
ing and holding drecalls the last track of the
disc.
#If a disc contains less than 10 tracks, pressing
and holding crecalls the first track of the disc.
Also, if the remaining number of tracks after
searching every 10 tracks is less than 10, press-
ing and holding crecalls the first track of the
disc.
Using disc title functions
You can input CD titles and display the title.
The next time you insert a CD for which you
have entered a title, the title of that CD will be
displayed.
Entering disc titles
Use the disc title input feature to store up to
48 CD titles in the unit. Each title can be up to
10 characters long.
1 Play the CD that you want to enter a
title for.
Built-in CD Player
En
18
Section
05

2 Press FUNCTION and hold until TITLE
appears in the display.
#When playing a CD TEXT disc, you cannot
switch to TITLE. The disc title will have already
been recorded on a CD TEXT disc.
3 Press button 1 to select the desired
character type.
Press button 1repeatedly to switch between
the following character types:
Alphabet (upper case)Alphabet (lower case)
European letters, such as those with ac-
cents (e.g., á, à, ä, ç)
#You can select to input numbers by pressing
button 2.
4 Press aor bto select a letter of the al-
phabet.
Each press of awill display a letter of the al-
phabet in A B C ... X Y Z, numbers and sym-
bols in 1 2 3 ... @ # < order. Each press of b
will display a letter in the reverse order, such
as Z Y X ... C B A.
5 Press dto ove the cursor to the next
character position.
When the letter you want is displayed, press d
to move the cursor to the next position and
then select the next letter. Press cto move
backwards in the display.
6 Move the cursor to the last position by
pressing dafter entering the title.
When you press done more time, the entered
title is stored in memory.
7 Press BAND to return to the playback
display.
Notes
!Titles remain in memory, even after the disc
has been removed from the unit, and are re-
called when the disc is reinserted.
!After data for 48 discs has been stored in
memory, data for a new disc will overwrite the
oldest one.
!If you connect a multi-CD player, you can
input disc titles for up to 100 discs.
Displaying disc titles
You can display the title of any disc that has
had a disc title entered.
%Press DISPLAY.
Press DISPLAY repeatedly to switch between
the following settings:
Play timeDisc Title (disc title)DAB infor-
mation (DAB information and play time)
When you select Disc Title, the title of the cur-
rently playing disc is shown in the display.
#When a CD with a disc title is inserted, the
disc title automatically begins to scroll through
the display.
#If no title has been entered for the currently
playing disc, No Disc Title is displayed.
#You can only switch to DAB information when
a DAB tuner (GEX-P700DAB) is connected.
Using CD TEXT functions
Some discs have certain information encoded
on the disc during manufacture. These discs
may contain such information as the CD title,
track title, artists name and playback time
and are called CD TEXT discs. Only these spe-
cially encoded CD TEXT discs support the
functions listed below.
Built-in CD Player
En 19
English
Section
05

Displaying titles on CD TEXT discs
%Press DISPLAY.
Press DISPLAY repeatedly to switch between
the following settings:
Play timeDisc Title (disc title)
DiscArtist Na e (disc artist name)
Track Title (track title)TrackArtist Na e
(track artist name)DAB information (DAB
information and play time)
#If specific information has not been recorded
on a CD TEXT disc, No XXXX will be displayed
(e.g., No Track Artist Na e).
#You can only switch to DAB information when
a DAB tuner (GEX-P700DAB) is connected.
Scrolling titles in the display
This unit can display the first 16 letters of
Disc Title,DiscArtist Na e,Track Title and
TrackArtist Na e. When the text information
is longer than 16 letters, you can scroll the dis-
play as follows.
%Press DISPLAY and hold until the title
begins to scroll through the display.
The titles scroll.
Note
When Ever Scroll is set to ON at the initial setting,
CD text information scrolls continuously in the
display. If you want to display the first 16 charac-
ters of text information temporarily and scroll
from the beginning, press and hold DISPLAY.
About Ever Scroll, refer to Switching the Ever
Scroll on page 42.
Built-in CD Player
En
20
Section
05
