Pioneer CT-S450S User manual

ORDER NO.
PIONEER ELECTRONIC CORPORATION 4-1, Meguro 1-Chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS SERVICE, INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER ELECTRONIC (EUROPE) N.V. Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 501 Orchard Road, #10-00 Wheelock Place, Singapore 238880
PIONEER ELECTRONIC CORPORATION 1998
STEREO CASSETTE DECK
RRV2040
T–DZE OCT. 1998 Printed in Japan
CT-S450S
1. CONTRAST OF MISCELLANEOUS PARTS .....2
2. SCHEMATIC DIAGRAM.....................................4
3. PCB CONNECTION DIAGRAM .........................5
CONTENTS
¶Refer to the service manual RRV1497 for CT-S450S/HYXJ.
Remarks
Type Model
CT-S450S Power Requirement
HYXJ7 AC220–230V
HYXJ/GR7 AC220–230V
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).

CT-S450S
2
NSP MOTHER UNIT RWM1895 RWM2052 RWM2052
P2–1 MAIN UNIT RWZ3845 RWZ4314 RWZ4314
P2–2 DOLBY S UNIT RWX1109 RWX1109 RWX1109
P2–3 OPSW UNIT RWZ3846 RWZ4316 RWZ4316 ∗1
P2–6 FL UNIT RWZ3847 RWZ4315 RWZ4315
P2–4 TR 1 UNIT RWZ3848 RWZ4317 RWZ4317
P2–5 NSP TR 2 UNIT RNZ3037 RNZ3312 RNZ3312
POWER SW UNIT Not used RWX1151 RWX1151 ∗2 No. 1, ∗3
P2–10 Power Cord with HE Plug PDG1043 PDG1058 PDG1058
P2–16 NSP Main Chassis RNB1100 RNB1140 RNB1140
P2–25 Power Knob RAC1809 Not used Not used
P2–28 Name Plate RAM1007 PAM1791 PAM1791
P2–34 Front Panel RAH2717 RAH2871 RAH2871
P2–35 Rear Panel RNA2035 RNA2213 RNA2213
P2–50 Screw BBZ30P080FMC BBZ30P080FZK BBZ30P080FZK
P2–58 Operating Instructions RRE1135 RRE1167 RRE1167
(English/German)
Operating Instructions RRD1183 RRD1203 Not used
(French/Italian/Dutch/Swedish/
Spanish/Portuguese)
P2–61 Packing Case RHG1813 RHG1879 RHG1879
P2–66 Acetate Tape REH1028 Not used Not used
NSP Warranty Card ARY7009 ARY7022 ARY7022 for packing
Screw Not used PMA30P060FMC PMA30P060FMC ∗2 No. 2
Power Button Not used RAC1775 RAC1775 ∗2 No. 3
Disc Guard Not used REC1305 REC1305 ∗2 No. 4
LED Holder Not used RNK2321 RNK2321 ∗2 No. 5
1. CONTRAST OF MISCELLANEOUS PARTS
CONTRAST TABLE
Part No. Remarks
CT-S450S CT-S450S CT-S450S
HYXJ HYXJ7 HYXJ/GR7
CT-S450S/HYXJ7, HYXJ/GR7 and CT-S450S/HYXJ are constructed the same except for the following:
Ref.
No. Mark Symbol and Description
*1: Although RWZ4316 and RWZ3846 are different in part number, they have same service parts.
*2: The numbers in the remarks column correspond to the numbers on the " EXPLODED VIEWS ".
*3: Refer to " PCB PARTS LIST ", " 2. SCHEMATIC DIAGRAM" and " 3. PCB CONNECTION DIAGRAM".
NOTES : ÷Parts marked by “ NSP ” are generally unavailable because they are not in our Master Spare Parts List.
÷The mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
÷When ordering resistors, first convert resistance values into code form as shown in the following examples.
Ex. 1 When there are 2 effective digits (any digit apart from 0), such as 560 ohm and 47k ohm (tolerance is shown by
J = 5%, and K = 10%).
560 Ω=56 ×101 =561................................................... RD1/4PU 561J
47k Ω=47 ×10 3=473 .................................................. RD1/4PU 473J
0.5 Ω=R50 ...................................................................... RN2H Â50K
1 Ω=1R0 ......................................................................... RS1P 1Â0K
Ex. 2 When there are 3 effective digits (such as in high precision metal film resistors).
5.62k Ω=562 ×10 1=5621 ........................................... RN1/4PC 5621F
÷Reference Nos. indicate the pages and Nos. in the service manual for the base model.

CT-S450S
3
1
3
5
4
2
BBZ30P060FMC
FL UNIT
EXPLODED VIEWS
CONTRAST OF PCB ASSEMBLIES
IC223 XRA10393F–TFB BA10393F–FTB
IC501 PD4508A PE5049A
IC1701 TC4050BP MC14050BCP
Q1159, Q1161 FMG1 FMG1A
D431 1SS252 1SS254
C103, C104, C210, C214–C216, C261, CEAS101M10 CEAT101M10
C262, C721, C722
C111, C112, C201, C202, C408, C617, CEAS100M50 CEAT100M50
C707, C708, C1016
C131, C132, C209, C259, C260, C361, CEAS470M16 CEAT470M16
C362, C402, C403, C409, C513, C520,
C1603, C1604
C205, C206, C211, C219, C355, C356, CEAS4R7M50 CEAT4R7M50
C917, C918
C213, C321, C322, C358, C555 CEAS1R0M50 CEAT1R0M50
C401 CQPA822J2A CQMA822J50
C614 CEASR10M50 CEATR10M50
C1001, C1004 CEAS101M50 CEAT101M50
C1009, C1012 CEAS331M10 CEAT331M10
C1010 CEAS102M10 CEAT102M10
C1018 CEAS220M16 CEAT220M25
VR101, VR102 RCP1020 VCP1154
VR321, VR322, VR551–VR553, VR601, RCP1046 VCP1158
VR602
VR852 RCP1044 VCP1151
NSP J3001 XDF–536 Not used
J3001 Not used DB015NT0
MAIN UNIT
RWZ4314 and RWZ3845 are constructed the same except for the following:
Mark Remarks
Symbol and Description Part No.
RWZ3845 RWZ4314

CT-S450S
4
TR 1 UNIT (RWZ4317)
TR 2 UNIT (RNZ3312)
POWER SW UNIT
(RWX1151)
POWER TRANSFORMER
RTT1254
AC POWER CORD
PDG1058
10000pF/
AC250V
4.1 MAIN, OPSW, FL AND TR1 UNIT
SCH-1 SCH-1
PDF1004
PDF1035 LIVE
NEUTRAL
PCB PARTS LIST
POWER SW UNIT
SWITCHES AND RELAYS
S1201 RSA–063
CAPACITOR
C1201 (10000 pF/AC250V) ACG7020
Mark No. Description Part No.
D1520 SLR–342UCT31 SLR–342VCT31
S1505 (POWER SW) RSG1030 Not used
FL UNIT
RWZ4315 and RWZ3847 are constructed the same except for the following:
Mark Remarks
Symbol and Description Part No.
RWZ3847 RWZ4315
C1031 (10000 pF/AC250V) ACG7020 Not used
Earth Lead Unit XDF–510 DE007WF0
Capacitor Cover REC–150 Not used
TR1 UNIT
RWZ4317 and RWZ3848 are constructed the same except for the following:
Mark Remarks
Symbol and Description Part No.
RWZ3848 RWZ4317
2. SCHEMATIC DIAGRAM
Note: When ordering service parts, be sure to refer to
"EXPLODED VIEWS AND PARTS LIST" or "PCB
PARTS LIST".
OTHERS
1201 TERMINAL RKC–061
PCB BINDER VEF1040
Mark No. Description Part No.

CT-S450S
5
A
B
C
D
1234
1234
NOTE FOR PCB DIAGRAMS:
1. Part numbers in PCB diagrams match those in the schematic
diagrams.
2. A comparison between the main parts of PCB and schematic
diagrams is shown below.
Symbol in PCB
Diagrams Symbol in Schematic Diagrams Part Name
Transistor
Transistor
with resistor
Field effect
transistor
BCE
BCE
BCE
DGS
BCE
BCEBCE
DGSDGS
Symbol in PCB
Diagrams Symbol in Schematic Diagrams Part Name
3. The parts mounted on this PCB include all necessary parts
for several destination.
For further information for respective destinations, be sure
to check with the schematic diagram.
4. Viewpoint of PCB diagrams
Resistor array
3-terminal
regulator
CapacitorConnector
P. C. Board Chip Part
SIDE B
SIDE A
To MAIN UNIT
J1001
PDF1035 PDF1004
POWER TRANSFORMER
AC POWER CORD
TR 1 UNIT
POWER SW UNIT
(RNP1731–B)
(RNP1729–A)
3. PCB CONNECTION DIAGRAM
3.1 POWER SW UNIT and TR 1 UNIT
SIDE A
SIDE A

CT-S450S
6
A
B
C
D
1234
1234
To FL UNIT
J902
To FL UNIT
J903
To OPSW UNIT
J1401
To MECHANISM UNIT (3/3)
To MECHANISM UNIT (2/3)
(E. HEAD)
To FL UNIT
J901
To TR 1 UNIT
J1001
MAIN UNIT
Q1001
Q1005
Q1006
Q1007
IC501
IC1701
Q1701
IC1004
IC1005
IC1003 Q403
Q602
Q603
IC601
VR601
VR451
VR602
VR852
Q422
Q432
Q431
Q421
Q852
Q854
Q501
3.2 MAIN UNIT

CT-S450S
7
A
B
C
D
5678
5678
To MECHANISM UNIT
(1/3) (R/P. HEAD)
To DOLBY S UNIT
CN1001
To DOLBY S UNIT
CN1002
(RNP1729–A)
VR451
VR322
Q1603
Q210
|
Q212
Q402
Q401
Q161
|
Q165
Q167
Q168
Q353
Q354
Q355
|
Q357
Q762
Q332
Q351
Q352
Q358
Q255
|
Q260
Q253
Q254
IC251
Q213
IC505
Q701
Q702
Q1604
Q105
Q106
Q858
Q901
Q902
Q853
Q855
|
Q857
Q502
Q511
Q512
IC502
VR551
VR101
VR102
VR552
VR553
VR2003

CT-S450S
8
A
B
C
D
1234
1234
MAIN UNIT
IC1601
Q1159
Q551
Q552
IC554
IC2002
IC223
IC701
IC101
Q1165
Q1151
Q1153
Q1155
Q1157
SIDE B

CT-S450S
9
A
B
C
D
5678
5678
(RNP1729–A)
Q841
Q844
Q1010
Q843
Q842
SIDE B

CT-S450S
10
A
B
C
D
1234
1234
To MAIN UNIT
CN902
To MAIN UNIT
CN1401
To MAIN UNIT
CN901
To MAIN UNIT
CN903
FL UNIT
OPSW UNIT
(RNP1729–A)
(RNP1729–A)
IC1501
Q1501
Q1401
SIDE A
SIDE A
3.3 FL UNIT and OPSW UNIT
