Pioneer CDJ-800MK2 User manual

ORDER NO.
PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2006
CDJ-800MK2
RRV3364
COMPACT DISC PLAYER
CDJ-800MK2
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
Model Type Power Requirement Remarks
CDJ-800MK2 KUCXJ AC 120 V
CDJ-800MK2 WYXJ5 AC 220 – 240 V
CDJ-800MK2 RLFXJ AC 110-120 V / 220-240 V
For details, refer to "Important symbols for good services" .
T-ZZR JUNE 2006 printed in Japan

CDJ-800MK2
2
1234
1234
C
D
F
A
B
E
SAFETY INFORMATION
This service manual is intended for qualified service technicians ; it is not meant for the casual do-it
-
yourselfer. Qualified technicians have the necessary test equipment and tools, and have been trained
to properly and safely repair complex products such as those covered by this manual.
Improperly performed repairs can adversely affect the safety and reliability of the product and may
void the warranty. If you are not qualified to perform the repair of this product properly and safely, you
should not risk trying to do so and refer the repair to a qualified service technician.
WARNING
This product contains lead in solder and certain electrical parts contain chemicals which are known to the state of California to
causecancer, birth defects or other reproductive harm.
Health & Safety Code Section 25249.6 – Proposition 65
NOTICE
(FOR CANADIAN MODEL ONLY)
Fuse symbols (fast operating fuse) and/or (slow operating fuse) on PCB indicate that replacement
parts must be of identical designation.
REMARQUE
(POUR MODÈLE CANADIEN SEULEMENT)
Les symboles de fusible (fusible de type rapide) et/ou (fusible de type lent) sur CCI indiquent que
les pièces de remplacement doivent avoir la même désignation.
ANY MEASUREMENTS NOT WITHIN THE LIMITS
OUTLINED ABOVE ARE INDICATIVE OF A POTENTIAL
SHOCK HAZARD AND MUST BE CORRECTED BEFORE
RETURNING THE APPLIANCE TO THE CUSTOMER.
2. PRODUCT SAFETY NOTICE
Many electrical and mechanical parts in the appliance
have special safety related characteristics. These are
often not evident from visual inspection nor the protection
afforded by them necessarily can be obtained by using
replacement components rated for voltage, wattage, etc.
Replacement parts which have these special safety
characteristics are identified in this Service Manual.
Electrical components having such features are identified
by marking with a on the schematics and on the parts list
in this Service Manual.
The use of a substitute replacement component which does
not have the same safety characteristics as the PIONEER
recommended replacement one, shown in the parts list in
this Service Manual, may create shock, fire, or other hazards.
Product Safety is continuously under review and new
instructions are issued from time to time. For the latest
information, always consult the current PIONEER Service
Manual. A subscription to, or additional copies of, PIONEER
Service Manual may be obtained at a nominal charge
from PIONEER.
1. SAFETY PRECAUTIONS
The following check should be performed for the
continued protection of the customer and
service technician.
LEAKAGE CURRENT CHECK
Measure leakage current to a known earth ground (waterpipe
, conduit, etc.) by connecting a leakage current tester
such as Simpson Model 229-2 or equivalent between the
earth ground and all exposed metal parts of the appliance
(input/output terminals, screwheads, metal overlays, control
shaft, etc.). Plug the AC line cord of the appliance directly
into a 120V AC 60Hz outlet and turn the AC power switch
on. Any current measured must not exceed 0.5mA.
(FOR USA MODEL ONLY)
Leakage
current
tester
Reading should
not be above
0.5mA
Device
under
test
Test all
exposed metal
surfaces
Also test with
plug reversed
(Using AC adapter
plug as required)
Earth
ground
AC Leakage Test

CDJ-800MK2 3
5678
5678
C
D
F
A
B
E
IMPORTANT
THIS PIONEER APPARATUS CONTAINS
LASER OF CLASS 1.
SERVICING OPERATION OF THE APPARATUS
SHOULD BE DONE BY A SPECIALLY
INSTRUCTED PERSON.
LASER DIODE CHARACTERISTICS
MAXIMUM OUTPUT POWER: 5 mW
WAVELENGTH: 780 – 785 nm
WARNING !
The AEL(accessible emission level) of the laser power output is less then CLASS 1
but the laser component is capable of emitting radiation exceeding the limit for
CLASS 1.
A specially instructed person should servicing operation of the apparatus.
Additional Laser Caution
∗ : Refer to page 86.
for RLFXJ
(DRW2308)
(DRW2248)
1. Laser Interlock Mechanism
The position of the switch (S1901) for detecting loading
completion is detected by the system microprocessor,
and the design prevents laser diode oscillation when
the switch is not in LPS1 terminal side (when the
mechanism is not clamped and LPS1 signal is
high level.)
Thus, the interlock will no longer function if the switch is
deliberately set to LPS1 terminal side. ( if LPS1 signal
is low level ).
In the test mode∗the interlock mechanism will not
function. Laser diode oscillation will continue, if pin 41
of TC94A15FG (IC101) on the MAIN Assy is
connected to GND, or else the terminals of Q101 are
shorted to each other (fault condition).
2. When the cover is opened, close viewing of the
objective lens with the naked eye will cause exposure
to a Class 1 laser beam.
CDJ-800MK2 WYXJ5 and KUCXJ : Types Only
Printed on the Bottom Plate
Bottom Plate
LABEL CHECK

CDJ-800MK2
4
1234
1234
C
D
F
A
B
E
[Important Check Points for Good Servicing]
In this manual, procedures that must be performed during repairs are marked with the below symbol.
Please be sure to confirm and follow these procedures.
1. Product safety
Please conform to product regulations (such as safety and radiation regulations), and maintain a safe servicing environment by
following the safety instructions described in this manual.
1Use specified parts for repair.
Use genuine parts. Be sure to use important parts for safety.
2Do not perform modifications without proper instructions.
Please follow the specified safety methods when modification(addition/change of parts) is required due to interferences such as
radio/TV interference and foreign noise.
3Make sure the soldering of repaired locations is properly performed.
When you solder while repairing, please be sure that there are no cold solder and other debris.
Soldering should be finished with the proper quantity. (Refer to the example)
4Make sure the screws are tightly fastened.
Please be sure that all screws are fastened, and that there are no loose screws.
5Make sure each connectors are correctly inserted.
Please be sure that all connectors are inserted, and that there are no imperfect insertion.
6Make sure the wiring cables are set to their original state.
Please replace the wiring and cables to the original state after repairs.
In addition, be sure that there are no pinched wires, etc.
7Make sure screws and soldering scraps do not remain inside the product.
Please check that neither solder debris nor screws remain inside the product.
8There should be no semi-broken wires, scratches, melting, etc. on the coating of the power cord.
Damaged power cords may lead to fire accidents, so please be sure that there are no damages.
If you find a damaged power cord, please exchange it with a suitable one.
9There should be no spark traces or similar marks on the power plug.
When spark traces or similar marks are found on the power supply plug, please check the connection and advise on secure
connections and suitable usage. Please exchange the power cord if necessary.
0Safe environment should be secured during servicing.
When you perform repairs, please pay attention to static electricity, furniture, household articles, etc. in order to prevent injuries.
Please pay attention to your surroundings and repair safely.
2. Adjustments
To keep the original performance of the products, optimum adjustments and confirmation of characteristics within specification.
Adjustments should be performed in accordance with the procedures/instructions described in this manual.
4. Cleaning
For parts that require cleaning, such as optical pickups, tape deck heads, lenses and mirrors used in projection monitors, proper
cleaning should be performed to restore their performances.
3. Lubricants, Glues, and Replacement parts
Use grease and adhesives that are equal to the specified substance.
Make sure the proper amount is applied.
5. Shipping mode and Shipping screws
To protect products from damages or failures during transit, the shipping mode should be set or the shipping screws should be
installed before shipment. Please be sure to follow this method especially if it is specified in this manual.

CDJ-800MK2 5
5678
5678
C
D
F
A
B
E
CONTENTS
SAFETY INFORMATION......................................................................................................................................2
1. SPECIFICATIONS .............................................................................................................................................6
2. EXPLODED VIEWS AND PARTS LIST.............................................................................................................8
2.1 PACKING ....................................................................................................................................................8
2.2 EXTERIOR SECTION ..............................................................................................................................10
2.3 CONTROL PANEL SECTION...................................................................................................................12
2.4 SLOT-IN MECHANISM SECTION ............................................................................................................14
3. BLOCK DIAGRAM AND SCHEMATIC DIAGRAM ..........................................................................................16
3.1 BLOCK DIAGRAM....................................................................................................................................16
3.2 BLOCK DIAGRAM (2) ..............................................................................................................................18
3.3 BLOCK DIAGRAM (Power).......................................................................................................................20
3.4 OVERALL WIRING DIAGRAM .................................................................................................................22
3.5 MAIN (1/3) and RLYB ASSYS ..................................................................................................................24
3.6 MAIN ASSY(2/3).......................................................................................................................................26
3.7 MAIN ASSY(3/3).......................................................................................................................................30
3.8 AC IN, TRNS, SECB and REGB ASSYS..................................................................................................32
3.9 DFLB, JACK and KSWB ASSYS ..............................................................................................................34
3.10 JFLB, SLDB, SLMB and JOGB ASSYS .................................................................................................36
3.11 WAVEFORMS.........................................................................................................................................38
3.12 VOLTAGES..............................................................................................................................................45
4. PCB CONNECTION DIAGRAM ......................................................................................................................49
4.1 MAIN ASSY ..............................................................................................................................................50
4.2 RLYB ASSY ..............................................................................................................................................54
4.3 SECB ASSY .............................................................................................................................................56
4.4 TRNS ASSY..............................................................................................................................................60
4.5 AC IN ASSYS ...........................................................................................................................................62
4.6 DFLB ASSY..............................................................................................................................................64
4.7 REGB and JACK ASSYS..........................................................................................................................68
4.8 KSWB ASSY.............................................................................................................................................70
4.9 JFLB ASSY...............................................................................................................................................72
4.10 SLDB ASSY............................................................................................................................................76
4.11 SLMB and JOGB ASSYS .......................................................................................................................78
5. PCB PARTS LIST ............................................................................................................................................80
6. ADJUSTMENT ................................................................................................................................................85
7. GENERAL INFORMATION .............................................................................................................................86
7.1 DIAGNOSIS..............................................................................................................................................86
7.1.1 SERVICE MODE................................................................................................................................86
7.1.2 RESET and CLOCK MAP ..................................................................................................................92
7.1.3 TROBLE SHOOTING .........................................................................................................................94
7.1.4 POWER ON SEQUENCE ................................................................................................................105
7.1.5 DISASSEMBLY ................................................................................................................................106
7.2 PARTS ....................................................................................................................................................114
7.2.1 IC......................................................................................................................................................114
8. PANEL FACILITIES .......................................................................................................................................140

CDJ-800MK2
6
1234
1234
C
D
F
A
B
E
1. SPECIFICATIONS
• WYXJ5 type
1. General
System.......................... Compact disc digital audio system
Power requirements .................... AC 220-240 V, 50/60 Hz
Power consumption ..................................................... 22 W
Operating temperature .................................. +5°C to +35°C
Operating humidity ............................................ 5 % to 85 %
(There should be no condensation of moisture.)
Weight ....................................................................... 4.0 kg
Dimensions ..................305 (W) x 344.1 (D) x 106.5 (H) mm
2. Audio section
Frequency response...................................... 4 Hz to 20 kHz
Signal-to-noise ratio ....................... 115 dB or more (JEITA)
Distortion ................................................... 0.006 % (JEITA)
3. Accessories
• Operating instructions ..................................................... 1
• Power cord ...................................................................... 1
• Audio cable ..................................................................... 1
• Control cable ................................................................... 1
• Forced eject pin (housed in a groove in the bottom panel)... 1
NOTE:
Specifications and design are subject to possible modification
with-out notice.
• KUCXJ type
1. General
System..............................Compact disc digital audio system
Power requirements.....................................AC 120 V, 60 Hz
Power consumption.......................................................20 W
Operating temperature.......... +5˚C to +35˚C (+41˚F to +95˚F)
Operating humidity...............................................5 % to 85 %
(There should be no condensation of moisture.)
Weight..............................................................4.0 kg (8.8 lb)
Dimensions..................... 305 (W) ×344.1 (D) ×106.5 (H)mm
12 (W) ×13 –9/16 (D) ×4 – 1/4 (H) in
2. Audio section
Frequency response........................................4 Hz to 20 kHz
Signal-to-noise ratio..........................115 dB or more (JEITA)
Distortion.................................................... .0.006 % (JEITA)
3. Accessories
• Operating instructions........................................................1
• Power cord........................................................................1
• Audio cable....................................................................... 1
• Control cable..................................................................... 1
• Forced eject pin (housed in a groove in the bottom panel)... 1
• Limited warranty................................................................1
NOTE:
Specifications and design are subject to possible modification
with-out notice.
• RLFXJ type
1. General
System........................... Compact disc digital audio system
Power requirements .... AC 110-120 V/220-240 V, 50/60 Hz
Power consumption ..................................................... 22 W
For Taiwan: 21 W
Operating temperature ..................................+5°C to +35°C
Operating humidity ........................................... 5 % to 85 %
(There should be no condensation of moisture.)
Weight ........................................................................4.0 kg
Dimensions .................. 305 (W) x 344.1 (D) x 106.5 (H) mm
2. Audio section
Frequency response...................................... 4 Hz to 20 kHz
Signal-to-noise ratio ....................... 115 dB or more (JEITA)
Distortion ................................................... 0.006 % (JEITA)
3. Accessories
• Operating instructions ..................................................... 1
• Power cord ...................................................................... 1
• Audio cable ..................................................................... 1
• Control cable ................................................................... 1
• Forced eject pin (housed in a groove in the bottom panel)... 1
NOTE:
Specifications and design are subject to possible modification
with-out notice.
Specifications
Voltage selector (RLFXJ type only)
• You can find the voltage selector switch on the bottom plate
of the unit.
The factory setting for the voltage selector is 220 – 240 V.
Please set it to the correct voltage for your country or region.
• For Taiwan, please set to 110 – 120 V before using.
Before changing the voltage, disconnect the AC power cord.
Use a medium size screwdriver to change the voltage
selector switch.
110-120V
220-240V

CDJ-800MK2 7
5678
5678
C
D
F
A
B
E
Audio Cable
(VDE1064) L=1.5m Forced Fject Pin
(housed in a groove in
the bottom panel)
(DEX1008)
Power Cord
(ADG7021 : KUCXJ)
(ADG7097 : RLFXJ)
(ADG1154 : WYXJ,RLFXJ)
Control Cord
(XDE3063) L=1 m
Accessories

CDJ-800MK2
8
1234
1234
C
D
F
A
B
E
2. EXPLODED VIEWS AND PARTS LIST
2.1 PACKING
Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
The mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
Screws adjacent to mark on product are used for disassembly.
For the applying amount of lubricants or glue, follow the instructions in this manual.
(In the case of no amount instructions, apply as you think it appropriate.)
NOTES:
5
8
7
6
9
11
12
KUCXJ type
only
WYXJ & RLFXJ
type only
KUCXJ & RLFXJ
types only
4
3
2
1
13
10
1
1
14

CDJ-800MK2 9
5678
5678
C
D
F
A
B
E
PACKING parts List
(2) CONTRAST TABLE
CDJ-800MK2/KUCXJ, /WYXJ5 and RLFXJ types are constructed the same except for the following:
Mark No. Description Part No.
> 1AC Power Cord See Contrast table(2)
2 Control Cord XDE3063
3Audio Cord VDE1064
4 Operating Instructions See Contrast table(2)
NSP 5 Polyethylene Bag AHG7117
6Pad B DHA1556
7Pad C DHA1557
8Pad D DHA1558
9 Sheet RHX1006
10 Push Rod DEX1008
11 Pad A DHA1555
12 Packing Case See Contrast table(2)
NSP 13 Warranty Card See Contrast table(2)
NSP 14 Label See Contrast table(2)
Mark No. Description Part No.
Mark No. Symbol and Description CDJ-800MK2/
KUCXJ
CDJ-800MK2/
WYXJ5
CDJ-800MK2/
RLFXJ
> 1AC Power Cord ADG7021 ADG1154 ADG1154
> 1AC Power Cord Not used Not used ADG7097
4 Operating Instructions (English)(KUCXJ) DRB1401 Not used Not used
4 Operating Instructions (WYXJ5)(English, Not used DRB1400 Not used
French, German, Italian, Dutch, Spanish)
4 Operating Instructions (RLFXJ) Not used Not used DRB1402
(English, Spanish, Chinese)
12 Packing Case DHG2595 DHG2594 DHG2596
NSP 13 Warranty Card ARY7043 Not used Not used
NSP 14 Label DRW2311 VRW1629 VRW1629

CDJ-800MK2
10
1234
1234
C
D
F
A
B
E
2.2 EXTERIOR SECTION
A
A
B
B
D
D
E
E
J
J
F
F
G
G
H
H
I
I
C
C
CONTACT SIDE
NON-CONTACT
SIDE
Refer to
"2.3 CONTROL PANEL SECTION".
Refer to
"2.4 SLOT-IN MECHANISM SECTION".
42
43
43
17
41
3
4
14
19
13
33
31
31
31x4
34
31
33 32
44
38
35
618
37
33
15 44
44
44
44
44
44
1
44
44
12
11
8
39 46
44
16
25
30
29
44
23
40
26
27
44
44
44
22
46x4
36
7
9-(b)
44
44 24
28
44
41
41
45
2
10
21
5
E
F
D
44
44 C
33x4
M
B
A
12
11
I
30

CDJ-800MK2 11
5678
5678
C
D
F
A
B
E
EXTERIOR SECTION parts List
(2) CONTRAST TABLE
CDJ-800MK2/KUCXJ, /WYXJ5 and RLFXJ types are constructed the same except for the following:
Mark No. Description Part No.
1 MAIN Assy DWG1622
>
2AC IN Assy See Contrast table(2)
>
3 TRNS Assy See Contrast table(2)
4 SECB Assy DWR1309
5 REGB Assy DWR1310
6 SLMB Assy DWS1388
7RLYB Assy DWX2602
8JACK Assy DWG1626
9•• • •
>
10 Fuse See Contrast table(2)
11 FFC (9p) DDD1311
12 FFC (32p) DDD1312
13 FFC (25p) DDD1313
14 FFC (17p) DDD1314
15 FFC (24p) DDD1315
NSP 16 Earth Lead DE010VF0
>
17 Power Transfomer See Contrast table(2)
18 Connector Assy PF03PP-B05
19 Connector Assy PF03PP-C12
20 • • • •
21 Power Knob DAC2073
NSP 22 Silicon Lubber D5 L DEB1456
23 Bottom Cushion S4 DEC2506
24 Heat Sink DNG1102
25 Earth Plate DNH2532
26 Bottom Plate See Contrast table(2)
27 Bottom Earth Plate DNH2694
28 Trans Plate DNH2733
NSP 29 Chassis See Contrast table(2)
30 Insulator Assembly DXA2069
31 Damper CNV6011
32 Earth Spring DBH1398
33 Float Spring (G5) DBH1494
34 Front Sheet DED1132
35 Mecha Plate DNH2642
36 PCB Holder DNK4524
37 Float Base 04 Assy DXB1838
38 Laser Caution See Contrast table(2)
NSP 39 Serial Label (UPC) See Contrast table(2)
40 Screw BBT30P060FCC
41 Screw BBZ30P060FTC
42 Screw BBZ30P100FTC
43 Screw BBZ40P060FTC
44 Screw BPZ30P080FTB
45 DM Screw (FTC) DBA1260
46 Screw IPZ30P100FTC
Mark No. Description Part No.
Mark No. Symbol and Description CDJ-800MK2/
KUCXJ
CDJ-800MK2/
WYXJ5
CDJ-800MK2/
RLFXJ
> 2AC IN ASSY DWR1430 DWR1429 DWR1432
> 3 TRANS ASSY DWR1371 DWR1371 DWR1428
> 10 Fuse (T1.6A) AEK7075 Not used Not used
> 10 Fuse (800MA) Not used REK1021 REK1021
> 17 Power Transfomer DTT1204 DTT1203 DTT1203
26 Bottom Plate DNK2689 DNK2689 DNK2691
29 Chassis DNK4518 DNK4517 DNK4519
38 Laser Caution DRW2308 DRW2308 DRW2248
NSP 39 Serial Label DRW2311 VRW1629 VRW1629

CDJ-800MK2
12
1234
1234
C
D
F
A
B
E
2.3 CONTROL PANEL SECTION
C
B
D
E
C
B
A
D
E
A
CONTACT SIDE
NON-CONTACT
SIDE
21
9
26
18
27
29
58
58
58
58
58
58
58
58
58 58
58 58
58
58 58
20
15
16
3
25
30x8
10x3
13x12
28x9
5656x3
17
17
17x3
8
10
13
13
13
13
10
24
11
19
55
58
58
7
6
22
14
23
12
4
2
50
37
38-(c)
38-(b)
45
35
40
41
46
51
47
52
31
53
43
39
36 32
48-2
33
38-(a)
44
39
42
34
48-1
49
1
56
54x2
5
57
61
K
L
G
J
H
6
58
58
60
60
*1
*1
Grease: GYA1001( ZLB-PN397B)
*1
59

CDJ-800MK2 13
5678
5678
C
D
F
A
B
E
CONTROL PANEL SECTION parts List
Mark No. Description Part No.
1 DFLB Assy DWG1623
2 KSWB Assy DWS1386
3 JFLB Assy DWG1624
4 SLDB Assy DWS1387
5 JOGB Assy DWG1625
6 FFC DDD1220
7 Connector Assy PF04PP-B07
8 Jog Panel (PMMA) DAH2182
9 Jog Plate DAH2438
10 SW spring 25 DBH1514
11 Gear spring 200 DBH1525
12 ARM Sprimg DBH1566
13 SW Cushion HH48/2 DEC2538
14 Encorder Plate DEC2889
15 Protector Sheet DEC2945
16 FL Sheet DEC2946
17 Ring Cushion L24/2.0 DEC2958
18 SW Ring DNK4070
19 Adjust Plate DNK4178
20 Jog Holder DNK4545
21 Jog B DNK4557
22 Gear ARM DNK4559
23 Gear DNK4560
24 Smoother DNK4561
25 Load Gear A DNK4562
26 Jog A DNK4586
27 Sheet SW DSX1065
28 Roller A Assy DXB1825
29 Jog Stay Assy DXB1876
30 Roller B Assy DXB1877
31 Rotary Knob C DAA1194
32 TEMPO Knob DAC2061
33 VINYL Knob DAC2063
34 LOOP Knob DAC2066
35 Auto Beat Loop Knob DAC2069
36 Quick Return Knob DAC2070
37 PLAY Knob DAC2286
38 Set Knob (Eject) DAC2287
39 CALL Knob DAC2289
40 RELOOP Knob DAC2291
41 Slide Knob DAC2292
42 TEXT/A.CUE Knob DAC2294
43 Folder Search Knob DAC2298
44 DEL/MEMO Knob DAC2299
45 Reverse Knob DAC2364
46 Slide Sheet (gray) DAH2374
47 Display Panel DAH2418
48 Earth Plate (CU) DBK1224
49 Vessel Sheet DEC2495
50 FFC Guard DEC2586
51 Reloop Guard DNK4057
52 Q R Guard DNK4058
53 Control Panel DNK4525
54 Screw BPZ20P060FTC
55 Screw BPZ20P100FTC
56 Screw (FE) DBA1265
57 Screw IPZ30P100FTC
58 Screw BPZ30P080FTB
59 Ecsane Tape (10x50 ) DEC2988
60 Cord Clamper RNH-184-0
61 Washer WA42D080D050
Mark No. Description Part No.

CDJ-800MK2
14
1234
1234
C
D
F
A
B
E
2.4 SLOT-IN MECHANISM SECTION
CONTACT SIDE
NON-CONTACT
SIDE
To
RLYB CN14
(Stepping Motor)
To MAIN CN102
(Spindle Motor)
To
RLYB CN12
(Pickup)
To
RLYB CN16
(Loading Motor)
Grease
GYA1001
(ZLB-PN397B)
Grease
GYA1001
(ZLB-PN397B)
Dyefree
GEM1036
(ZLX-ME413A)
Dyefree
GEM1036 (ZLX-ME413A)
Dyefree
GEM1036
(ZLX-ME413A)
Grease
GYA1001
(ZLB-PN397B)
4
2
5
3
6
1
11
10
20
21
18
19
25
25
25
27
25
Note:
The TM. Assy 03-S is supplied only in
assembly form, not as a single part.
15
16
12
8
9
23
13
7
17
22
24
14
26
28
30
30
29
31
Cleaning liquid : GEM1004
Cleaning paper : GED-008

CDJ-800MK2 15
5678
5678
C
D
F
A
B
E
SLOT-IN MECHANISM SECTION parts List
Mark No. Description Part No.
NSP 1 Slot-in Mecha SV Assy DXA2005
2 TM. Assy 03-S VXX3125
3 Loading Motor Assy-S DXX2510
NSP 4 Worm Gear DNK3910
NSP 5 DC Motor S (ROHS) DXM1230
6 Connector Assy PF02PY-B22
7 Clamp Spring DBH1374
8 Guide Spring DBH1375
9 SW Lever Spacer SV DEC2831
10 Loading Lever DNK3406
11 Main Cam DNK3407
12 Disc Guide DNK3478
13 Clamp Arm DNK3576
14 Eject Lever DNK3684
15 Lever AP DNK3835
16 Lever BP DNK3836
17 Loading Gear DNK3911
18 Drive Gear DNK3912
19 Loading Base SV DNK4369
20 SW Lever SV1 DNK4370
21 SW Lever SV2 DNK4371
22 Gear Holder SV DNK4372
23 Clamper 04 Assy DXB1859
24 Screw BPZ20P060FTC
25 Floating Rubber (SI) VEB1351
26 Float Base 04 Assy DXB1838
27 Spacer POR (T3) DEB1566
28 Vessel Cushion A DEC2852
29 Vessel Cushion B DEC2853
30 Vessel Cushion C DEC2854
31 Front Sheet DED1132

CDJ-800MK2
16
1234
1234
C
D
F
A
B
E
3. BLOCK DIAGRAM AND SCHEMATIC DIAGRAM
3.1 BLOCK DIAGRAM
RLYB ASSY
TM. ASSY 03-S (VXX3125)
PICKUP ASSY
STEPPING
MOTOR 04
SPINDLE
MOTOR 04
Loading MOTOR
ASSY-S
B
REGB ASSY
F
C
ACIN ASSY
For KUCXJ, WYXJ5
For RLFXJ
E
ACIN ASSY
E
MAIN ASSY
A
SLMB ASSY
M
COMPARATOR
S2
S1 J3
J2
BROWN
VIOLET
BLUE
M63018FP
NJM2885DL1
BA008C0WCP
BA008C0WCP
V+10B
V+7A
V+6B
V+3D
11 9
SECB ASSY
TRNS ASSY
D
SLOT-IN
MECHANISM SV
ASSY
J91
CN52
CN53
CN53
CN56
CN50
CN301
CN301
CN51
CN22
(DXX2510)

CDJ-800MK2 17
5678
5678
C
D
F
A
B
E
JFLB ASSY
K
DFLB ASSY
G
SLDB ASSY
J
KSWB ASSY
H
JOGB ASSY
L
MAIN ASSY
A
JACK ASSY
AUDIO OUT
I
MPU
DIGITAL OUT
JA801
DKB1053
IC801
OP AMP
JA802
PKB1033
IC702
IC701
IC300 IC303
DSPC56371AF180-K
PE8001A
IC304
BU4230G
8 Mbit 64 Mbit
KU
19
6
1
4
9
÷When ordering service parts, be sure to refer to "EXPLODED VIEWS and PARTS LIST" or
"PCB PARTS LIST".
÷The >mark found on some component parts indicates the importance of the safety factor
of the part. Therefore, when replacing, be sure to use parts of identical designation.
÷: The power supply is shown with the marked box.
SCF5249VM140-K
IC301
CN501
CN1502
CN502
CN503
CN500
CN1503
CN1601
CN602
CN600
CN601
CN802
CN701 CN801

CDJ-800MK2
18
1234
1234
C
D
F
A
B
E
3.2 BLOCK DIAGRAM (2)
M
M
M
DWG1622
• Blick diagra Map
DWX2602
DWS1388
DWR1310 DW
R
CDJ-800MK2 has two MPU, MPU (MAIN), DISPLAY-MPU (DFLB).
One controls CORE BLOCK, Another is Top panel about DISPLAY, LED, VOLUME,
S
RESET IC and X'TAL have on the MAIN ASSY too.
It has two MEMORY. One 64MB sized SDRAM, Another is 8MB sized FLASH MEMO
R
About POWER BLOCK, Please refer to POWER DELIVERY MAP.
DATA Cntrol
Transformer
V+10
UnReg
FLAC_J
V+6
UnReg
Vload
+32V
FLAC_D
+3.3V
+7V
ACIN ASSY
POWER BLOCK
TRNS ASSY
REGB ASSY
SLMB ASSY
RLYB ASSY
MAIN ASSY
CD DRIVE BLOCK
DRIVE ASSY
SE
C
AUDIO BLOCK
DWS1387-A/J
SLDB ASSY
Loading
KP 2PIN
IC102 DRIVER
POWER
SUPPLY
IC101
SERVO DSP
IC302
FPGA
(50000GATE) SDRAM
(64 Mbit)
IC301
MPU
(140MHz)
FLASH
(8 Mbit)
FFC 25PIN
IC701
AUDIO
DSP
I
C
R
1
KP 4PINFFC17PINKP 3PIN
FFC 32PIN
6PIN
IC91
IC92
SLED
TRAVERS
MECHA
Spindle
Pickup ASSY
SW
3PIN
B
FC
D
E
A
M

CDJ-800MK2 19
5678
5678
C
D
F
A
B
E
DWG1626
DWS1386
DWR1309 DWG1623
VYNIL
SLIDER
DWG1625
(
DFLB).
ISPLAY, LED, VOLUME, SW, JOG, etc.
8MB sized FLASH MEMORY.
Y
MAP.
DATA Cntrol
DWG1624 Rotation Detect
JOG
FL
Vol
SECB ASSY
JACK ASSY
I
O BLOCK
CORE BLOCK
KSWB ASSY
PANEl BLOCK
DFLB ASSY
DWS1387-A/J
SLDB ASSY
DWS1387
SLDB ASSY
JOGB ASSY
JFLB ASSY
IC301
MPU
(140MHz)
IC701
A
UDIO
DSP
FFC 9PIN
IC702 IC801 OPAMP
AUDIO OUT
(L/R)
Digital OUT
MUTE MUTE
ZERO
DETECT
RESET IC
RESET IC
IC501
DISPLAY
MPU
(MASK)
V501
DATA FL
16.934MHz
B to B 8PIN
R to R 13PIN
B to B 11PIN
FFC 17PIN
KP 4PIN
16.00MHz
LED
SW
SW
LED
AUDIO OUT LINE
DIGITAL OUT LINE
AUDIO MUTE LINE
CONTROL LINE
DRIVE CONTROL
DAC
SW
C
I
H
G
K
L
J

CDJ-800MK2
20
1234
1234
C
D
F
A
B
E
3.3 BLOCK DIAGRAM (Power)
M
M
M
Motor Drive
DWG1622
IC704 <0.3A
•Power Delivery Map
DWX2602
MUTE
IC307 <0.6A FPGA (SPARTAN3)FPGA (SPARTAN3)
Stby
IC703 <0.6A DSP
IC305 <0.5A CPU (AMADEUS)CPU (AMADEUS)
IC306 <0.5A FPGA (SPARTAN3)FPGA (SPARTAN3)
V+3D CUP 21 FPGA 60 DSP 5CUP 21 FPGA 60 DSP 5
SDRAM 22 FLASH 5SDRAM 22 FLASH 5
DWS1388 ServoDSP 83
IC100 <x.x0.6A LD 80
V+7M V+8A V+5P V+6B
DWR1310 DWR13
0
IC91 <
<1.0A C52
IC92
<1.0A IC57 <1.0A
ICP <200mA IC60
IC23,24IC23,24 <1A IC50
<3.5A<3.5A <800mA IC53
IC21,22IC21,22 <0.8A IC61
C506
<5.0A<5.0A <1.5A IC54
IC25IC25
<630mA<630mA <200mA Q53 <200mA
IC58 IC59
Regurator supporting Current Shutdown DATA Cntrol
15W POINT
Before REG-IC
GND
IC Protect
Pori SW
FUSE
MAX SPEC Screw (Chasis GND
)
A
Transformer
V+10
UnReg
+7A
+3.3D
Loading
FLAC_J
Spindle
TRAVERS
MECHA
SLED
V+6
UnReg
3.3S
+1.2D
1.25D
1.8D
2.5D
+5P
5A
Pickup ASSY
GNDMGNDM
GNDSGNDS
GNDDGNDD
GNDDGNDD
GNDA
Vload
+32V
GNDD
GNDAD
GNDD
GNDF
GNDD
GNDD
GNDD
GNDAD
DAC
GNDSGNDS
GNDDGNDD
GNDSGNDS
GNDMGNDM
GNDD
+8A
GNDMGNDM
FLAC_D
-7
GNDD
GNDF
3.3V
ICP
3.3V
ACIN ASSY
TRNS ASSY
REGB ASSY
SLMB ASSY
RLYB ASSY
MAIN ASSY
SECB
SLDB ASSY
ICP
<10 A
IC56
B
F
C
D
E
A
M
