DRM-1004X40 100-Disc CD-ROM/R Autochanger
(Reader Model)
SPECIFICATIONS
GENERAL
Number of Discs Up to 100 CD-ROM discs (2 removable 50-
disc magazines)
Configurations 1004X40: 4 read, 1004XR21: two read/ one
write
Interface SCSI-2
SCSI ID Individually set for each drive and for jukebox
robotics control.
Disc Exchange Time Less than 6 seconds (even during writer
operation)
Disc Load Time Less than 3 seconds
Regulatory Approval UL, CSA, TUV, CE, FCC, VCCI
RELIABILITY
Change Mechanism (MSBF):
Disc Change
Mail-Slot Open/Close 1,000,000 times 100,000 times
Reader Drive: MTBF 75,000 POH (Duty 20%)
Writer Drive: MTBF 50,000 POH (Duty 20%)
PHYSICAL CHARACTERISTICS
Dimensions (W x H x D) 10-3/8” x 19-1/16” x 23-1/8”
263 x 484 x 588 mm
Weight (Net) DRM-1004X40: 74 pounds 33.6 kg
DRM-1004XR21: 73 pounds 33.1 kg
Operating Voltage AC 100V/120V/230V
Power Consumption DRM-1004X40: 73W (when using 4 readers)
DRM-1004XR21: 64W (when using 2
readers/1 writer)
ENVIRONMENTAL CONDITIONALS
Operating Temperature 41°F to 95°F degrees
5°C to 35°C degrees
Operating Humidity 5 to 85%RH
Storage Temperature -40°F to 140°F degrees
-40°F to 60°C degrees
Storage Humidity 10 to 90% RH
