Pioneer SGY-HR500 User manual

ENEN
FR
User’s Manual
Manuel de l'utilisateur
SGY-HR500
Heart Rate Sensor
For information on the Speed & Cadence sensor, refer to the User's Manual of
the Speed & Cadence Sensor SGY-CS500.
Pour de plus amples informations concernant le capteur de vitesse &
cadence, reportez-vous au manuel de l’utilisateur SGY-CS500.

2
EN
Table of Contents
Features
Heart Rate Data Acquisition
This device measures and transmits heart rate data for display on compatible
ANT+ cyclocomputers.
This product is ANT+™ certied.
Visit http://www.thisisant.com/directory/ for a list of compatible
products and apps.
Features................................................................................................................... 2
Important Safety Information................................................................................... 3
Before Use (Important)...........................................................................................10
Product Conguration.............................................................................................13
Putting the Sensor on Your Body ...........................................................................14
Installing and Removing the Battery ......................................................................16
Troubleshooting ......................................................................................................18
Care, Maintenance, and Storage ...........................................................................19
Specications ........................................................................................................ 20

3
EN
Important Safety Information
Pioneer Heart Rate Sensor is not a medical device.
Important Information About This Device
This device helps provide feedback about cycling. It is intended solely for
recreational purposes. THE LIMITED WARRANTY PROVIDED WITH THIS
DEVICE CONSTITUTES THE EXCLUSIVE WARRANTIES FOR THE PRODUCT
AND THE USER’S EXCLUSIVE REMEDIES. TO THE MAXIMUM EXTENT
ALLOWED BY APPLICABLE LAW, ALL OTHER WARRANTIES, WHETHER
EXPRESS, IMPLIED, OR STATUTORY, INCLUDING WITHOUT LIMITATION ANY
WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR
PURPOSE, ARE HEREBY DISCLAIMED. IN NO EVENT WILL PIONEER,
ITS AFFILIATES, OR THEIR RESPECTIVE EMPLOYEES, DIRECTORS, OR
OFFICERS, BE LIABLE FOR ANY INDIRECT, INCIDENTAL, CONSEQUENTIAL,
SPECIAL, PUNITIVE OR EXEMPLARY DAMAGES IN CONNECTION WITH
THIS DEVICE, REGARDLESS OF THE THEORY OF LIABILITY AND EVEN
IF SUCH DAMAGES ARE FORESEEABLE. BECAUSE SOME STATES OR
JURISDICTIONS MAY NOT ALLOW LIMITATIONS ON THE DURATION
OF IMPLIED WARRANTIES, OR LIMITATIONS ON OR EXCLUSIONS OF
CONSEQUENTIAL OR INCIDENTAL DAMAGES, SOME OF THE ABOVE
LIMITATIONS MAY NOT APPLY TO A USER DEPENDING ON HER, HIS, OR ITS
STATE OF RESIDENCE.

4
EN
Important Safety Information
WARNING
DO NOT USE THIS PRODUCT IF•
YOU ARE USING A PACEMAKER.
BEFORE BEGINNING OR•
MODIFYING ANY EXERCISE
ACTIVITY, ALWAYS CONSULT
YOUR PHYSICIAN FIRST. IF
YOU ARE USING ANY TYPE OF
IMPLANTED DEVICE EXCEPT
FOR A PACEMAKER, CONSULT
YOUR PHYSICIAN BEFORE USING
A HEART RATE SENSOR.
THIS PRODUCT IS NOT A•
MEDICAL DEVICE, AND COULD
EXPERIENCE INTERFERENCE
FROM EXTERNAL ELECTRICAL
SOURCES.
HEART RATE DATA IS FOR•
REFERENCE ONLY, AND
PIONEER IS NOT RESPONSIBLE
FOR ITS ACCURACY.
WARNING
Follow these guidelines as well to
ensure safe Cycling:
Always use your best judgement, •
and ride in a safe manner. Do not
become distracted by this device
while riding, and always be fully
aware of your surroundings.
If a rash occurs on the skin, please•
stop use immediately.
Metal snap fasteners may cause an•
allergic reaction.
Please replace the strap if it•
becomes damaged, loose, or
has too much slack since it is
consumables.
Only use provided straps.•
Secure your bicycle in a safe place•
before replacing batteries as the
bicycle could fall causing injury.
Upon replacing the battery, install •
the battery cover securely to ensure
water resistance and prevent
potential injury if the cover falls off.

5
EN
Important Safety Information
Do not leave small parts such as•
the battery or screws in an area that
infants and small children can reach
to prevent accidental swallowing. If
you think this may have happened,
call 911 for a medical emergency.
Do not leave this device in places•
that are exposed to direct sunlight,
high temperature, high humidity,
or a lot of dust as it may cause the
device to malfunction.
Never dismantle, refurbish, or repair•
this device or any attached parts as
it could cause electrical shock or the
device to malfunction.
Do not use this device if any unusual•
conditions exist such as penetration
by a foreign object, water
submersion, smoke is detected, or
an unusual odor is detected.
Stop using this device immediately
and have it repaired.
This device communicates using •
ANT+ radio communication. Do
not use in areas that forbid the
use of electronic devices such as
hospitals or airplanes as unintended
interference from this device could
cause serious accidents.
CAUTION
Do not wipe this device with•
detergents, chemical duster, or
volatile compounds such as benzine
or thinner as they may cause the
device to malfunction.
Avoid overly violent impacts on•
this device as it may cause it to
malfunction.
Do not touch or deform the battery•
contacts. This could cause a faulty
connection or short circuit.

6
EN
Important Safety Information
WARNING
Batteries (batteries installed) must not
be exposed to excessive heat such as
sunshine, re or the like.
“Perchlorate Material - special handling
may apply.
See
www.dtsc.ca.gov/hazardouswaste/
perchlorate.
(Applicable to California, U.S.A.)”
WARNING
STORE SMALL PARTS OUT OF
REACH OF CHILDREN AND INFANTS.
IF ACCIDENTALLY SWALLOWED,
CONTACT A DOCTOR IMMEDIATELY.
Radio wave caution
This unit uses a 2.4 GHz radio wave•
frequency, which is a band used by
other wireless systems (microwave
ovens and cordless phones, etc.).
In the event noise appears on
your television image, there is
the possibility this unit (including
products supported by this unit)
are causing signal interference
with the antenna input connector
of your television, video, satellite
tuner, etc. In this event, increase the
distance between the antenna input
connector and this unit (including
products supported by this unit).

7
EN
Important Safety Information
[For American Users]
IMPORTANT NOTICE
KEEP WARRANTY CARD IN A SAFE PLACE FOR FUTURE REFERENCE.
This transmitter must not be co-located or operated in conjunction with any other
antenna or transmitter.
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This Equipment may not cause harmful interference,
and (2) this device must accept any interference received, including interference
that may cause undesired operation.
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment and meets the FCC radio frequency (RF) Exposure
Guidelines in Supplement C to OET65. This equipment has very low levels of RF
energy that are deemed to comply without testing of specic absorption ratio (SAR).
Information to User
Alterations or modications carried out without appropriate authorization may
invalidate the user’s right to operate the equipment.
WARNING: This product contains chemicals known to the State of California and
other governmental entities to cause cancer and birth defects or other reproductive
harm.
Wash hands after handling.

8
EN
Important Safety Information
NOTE:
This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.–
Increase the separation between the equipment and receiver.–
Connect the equipment into an outlet on a circuit different from that to which the–
receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.–

9
EN
Important Safety Information
[For Canadian Users]
This device complies with Industry Canada licence-exempt RSS standard(s).
Operation is subject to the following two conditions: (1) this device may not
cause interference, and (2) this device must accept any interference, including
interference that may cause undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux
appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions
suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de
l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage
est susceptible d'en compromettre le fonctionnement.
This equipment complies with IC radiation exposure limits set forth for an
uncontrolled environment and meets RSS-102 of the IC radio frequency (RF)
Exposure rules. This equipment has very low levels of RF energy that are deemed
to comply without testing of specic absorption ratio (SAR).
Cet équipement est conforme aux limites d’exposition aux rayonnements
énoncées pour un environnement non contrôlé et respecte les règles d’exposition
aux fréquences radioélectriques (RF) CNR-102 de l’IC. Cet équipement émet
une énergie RF très faible qui est considérée conforme sans évaluation du débit
d’absorption spécique (DAS).
The ANT+ antenna cannot be removed (or replaced) by user.
L'antenne ANT+ ne peut pas être supprimé (ou remplacé) par l'utilisateur.
Operating Environment
Operating environment temperature and humidity:
0 °C to +50 °C (+32 °F to +122 °F); less than 85 %RH
Do not install this unit in a poorly ventilated area, or in locations exposed to high
humidity or direct sunlight (or strong articial light)

10
EN
Before Use (Important)
Safety Precautions
DANGER
About this Device
Do not throw this device, strike it•
with a hammer or other object, or
pierce this device in any way.
Do not use or leave this device in•
places where it will be exposed to
extremely high temperatures, such
as near a stove or re.
Always keep this device out of the•
reach of infants and small children.
WARNING
About this Device
Do not use this device if it emits an•
unusual odor, heats up, changes
color or shape, or if any other
abnormalities occur during use.
Do not place this device in a•
microwave oven or expose it to high
pressure, since the device may
overheat, rupture, or ignite.
Keep the lithium battery out of the•
reach of children. Should the battery
be swallowed, immediately consult a
doctor.

11
EN
Before Use (Important)
CAUTION
Do not recharge, disassemble, heat •
or dispose of the battery in re.
Use a CR2032 (3 V) lithium battery•
only. Never use other types of
batteries with this unit.
Do not handle the battery with•
metallic tools.
Do not store the battery with metallic•
materials.
When disposing of used batteries, •
please comply with governmental
regulations or environmental public
institutions rules that apply in your
country or area.
Always check carefully that you are•
loading battery with its (+) and (-)
poles facing in the proper directions.
CAUTION
About Water-resistance
Observe the following precautions
in regard to this device’s water-
resistant.
Do not expose to rain for long •
periods of time.
Do not pour or place in warm•
water or water containing soap or
detergent.
Do not use at or near the beach.•
This could cause rust. If exposed
to seawater, thoroughly wipe off
the moisture immediately with a dry
cloth.
If the rubber packing becomes •
soiled, wipe it clean with a dry, clean
cloth.
Do not open the battery cover•
in humid environments in which
this device could get exposed to
water.

12
EN
Before Use (Important)
If this device is exposed to a large•
amount of water or moisture,
immediately wipe it down with a
dry cloth.
Only open or close the transmitter
cover after having completely wiped
off any moisture. Be sure your hands
are completely dry and you are in an
environment where the unit will not
get exposed to moisture again.
Over exposure or submersion in•
water may require servicing.
This device has been designed with
water resistance to 30 m.
Malfunctions due to water damage
caused by improper use are not
covered by the product warranty, even
if they occur within the warranty period.
Depending on conditions of use,•
the water-resistant features are
not necessarily guaranteed even
during the warranty period.
We recommend you have the battery
cover and the rubber gaskets in the
transmitters of the sensors replaced
periodically. (This is a paid service.)

13
EN
Product Conguration
This product contains the following parts.
Heart rate sensor (transmitter)
Front View Back View
Attaching snap fastener
Battery cover
Heart rate sensor (strap)
Outside
Inside
Hook
Clip for length adjustment
Attaching snap fastener
Electrode pad
Others
User’s Manual (this manual)•
Warranty Card•

14
EN
Putting the Sensor on Your Body
Do not use this product if you are using a pacemaker.
1. Wet the electrode pad with
water.
To reliably detect the heart rate signal,
wet the electrode pad with water.
2. Install the transmitter to the
strap.
Firmly attach the snap fasteners of the
transmitter and strap until they click.
To prevent the transmitter from•
falling off while you use it, attach it
securely.
Before riding, conrm that the snap •
fasteners are not loose. If they are
loose, replace them.
3. Adjust the length of the strap.
Undo the strap’s hook, and use the clip
to adjust the strap’s length.
lengthen
shorten
4. Wear the strap around your
chest.
Wrap the strap around your chest and
attach the hook to the strap.
Adjust the strap’s length with the clip
again.

15
EN
Putting the Sensor on Your Body
Do not use excessive force pulling or •
adjusting while wearing. Doing so may
break the strap and cause an injury.
Be careful not to bend the electrode•
pad. Doing so may cause it to
malfunction.
5. Place the electrode pad
against the chest.
Rotate the strap to adjust the position
of the electrode pad so it attaches
tightly to your chest.
Attach the strap rmly so it does not •
slip down when riding.
Conrming Connection to the
Cyclocomputer
After attaching the Heart rate sensor,
pair the sensor with your cyclocomputer.
Refer to your cyclocomputer’s ANT+
pairing instructions.
Pairing with the cyclocomputer may •
not be possible due to the inuence
of the 2.4 GHz frequency band. If
pairing fails, try again someplace
where there is no interference from
microwaves, radio waves, or wireless
equipment.

16
EN
1. Remove the battery cover of
the Heart rate sensor.
Turn the cover counterclockwise with a
tool such as a coin or screw driver.
2. Remove the old battery.
Installing and Removing the Battery
The battery is pre-installed to this product. If the battery is almost empty (see
page 18), replace the battery with new one.
3. Install the new battery
(CR2032) and close the
battery cover.
Insert the battery with its (+) side
facing up. Align the cover with the
mark and turn it clockwise to close it
securely.

17
EN
Installing and Removing the Battery
Be careful not to drop or lose the•
battery when installing it.
Do not use batteries other than•
CR2032.
Install the cover rmly to ensure •
water resistant performance.
Be careful not to lose the rubber•
gaskets when removing the battery
cover.
Rubber
gaskets
When disposing of used batteries, •
please comply with governmental
regulations or environmental public
institutions rules that apply in your
country or area.
Keep coin batteries out of reach of•
children.

18
EN
Troubleshooting
If you have problems with your device, check the following items.
If a solution to your problem cannot be found here, contact your dealer.
Heart rate information is not displayed on the cyclocomputer. /■
I cannot pair the sensor with the cyclocomputer.
Cause Solution
The battery is almost empty. Replace the battery with a new one (see page 16).
(+) or (-) side of the battery is
installed in the opposite side.
Install the battery in the proper side (see page 16).
The battery is not installed correctly. Install the battery again (see page 16).
The transmitter is off the strap. Install the transmitter rmly to the strap (see page 14).
Sensitivity of the sensor has become
low due to dirt on the snap fasteners
or electrode pad.
Wipe off dirt from the snap fasteners or electrode pad.
Sensitivity of the sensor has become
low due to rust of the snap fasteners.
Attach and remove the strap to and from the transmitter
several times. If the problem continues, replace the
strap with a new one.
The electrode pad of the strap is
damaged.
Replace the strap with a new one.
The heart rate signal is not detected
because the electrode pad is not
wet.
Wet the electrode pad with water (see page 14).
The strap becomes loose. / The hook etc. has broken.■
Cause Solution
- Replace the strap with a new one.

19
EN
Care, Maintenance, and Storage
After use, remove the transmitter from the strap and wipe off any sweat and dirt•
with a soft cloth and then dry it.
Do not use detergents.
After use, wipe off sweat and dirt from the snap fasteners of the transmitter and•
strap and dry them to prevent rust.
After use, hand-wash the strap in cold water and dry it naturally in the shade.•
Do not use detergents or bleach.
Do not clean the strap using a washing machine or expose it to direct sunlight
as it may shorten its life. Never put it in a dryer.
When hand-washing the strap, put the strap into a washing bag or mesh •
laundry bag to prevent the strap from getting tangled.
Do not bend the electrode pad while drying it. Doing so may cause it to •
malfunction.
Never put the transmitter in a washing machine or dryer. Doing so may cause it •
to malfunction.
Remove the transmitter from the strap when not in use. Keeping the transmitter •
attached may shorten its battery’s life.

20
EN
Specications
Weight: About 47 g (0.104 lbs)
Dimensions: Transmitter:
64 mm(W) x 35 mm (H) x 10 mm(D)
(2.52 in.(W) x 1.38 in.(H) x 0.39 in.(D))
Strap length:
680 to 1000 mm
(26.77 to 39.37 in.)
Water resistant: Water resistant to 30 m (98.4 ft).
(Heart rate readings cannot be acquired underwater.)
Communications method (sensors): ANT+ wireless
Battery: CR2032
Operation temperature: 0 to 50°C (32 to 122°F)
Estimated usable period: About 3 years (at one hour per day of use)
ANT+ is a Wireless Personal Network protocol with very low power•
requirements using 2.4GHz frequency band.
For more information, visit http://www.thisisant.com/
Specications and design are subject to change without notice.•
Illustrations used in this manual may be different from actual appearance.•
