Pioneer DVH-P7000R User manual

English Español Deutsch
Multi-CD/DAB control High power DVD/VCD/CD
player with RDS tuner
Reproductor de DVD/VCD/CD de alta potencia con
control de múltiples CD/DAB con sintonizador RDS
Operation Manual
DVH-P7000R
Manual de Operación
Downloaded from Caradio-Manual.com Manuals

Be sure to read this
DVD disc region numbers 7
• Region number 7
Disc operation 8
Compatible with DVD, Video CD and CD
Formats 89
Before You Start
About this unit 6
About this manual 6
Precautions 6
In case of trouble 6
DVD disc region numbers 7
• Region number 7
Video system of a connected component 7
To ensure safe driving 7
• When using a display connected to
DVD REAR MONITOR OUTPUT 8
Condition memory 8
What the marks on DVDs indicate 8
• Disc operation 8
Disc organization 9
• DVD 9
• Video CD and CD 9
Main features 10
Protecting your unit from theft 11
• Removing the front panel 11
• Attaching the front panel 11
Switching the remote control operation
mode switch 12
About the demo mode 12
• Reverse mode 12
• Feature demo 12
What’s what 13
• Head unit 13
• Remote control 14
Use and care of the remote control 16
• Installing the battery 16
• Using the remote control 16
Power ON/OFF
Turning the unit on 17
• When the remote control is
set to DVH mode 17
• When the remote control is
set to DVD mode 17
Selecting a source 17
• When the remote control is
set to DVH mode 17
Turning the unit off 18
• When the remote control is
set to DVH mode 18
• When the remote control is
set to DVD mode 18
Tuner
Listening to the radio 19
Introduction of advanced tuner
operation 20
Storing and recalling broadcast
frequencies 20
Tuning in strong signals 21
Storing the strongest broadcast
frequencies 21
RDS
Introduction of RDS operation 22
Switching the RDS display 23
Thank you for buying this Pioneer product.
Please read through these operating instructions so you will know how to oper-
ate your model properly. After you have finished reading the instructions, put them
away in a safe place for future reference.
Contents
En
2
00
Section
Downloaded from Caradio-Manual.com Manuals

Selecting alternative frequencies 23
• Using PI Seek 24
• Using Auto PI Seek for preset
stations 24
• Limiting stations to regional
programming 24
Receiving traffic announcements 25
• Responding to the TP alarm 25
Using PTY functions 26
• Searching for an RDS station by PTY
information 26
• Using news program interruption 26
• Receiving PTY alarm broadcasts 26
Using radio text 27
• Displaying radio text 27
• Storing and recalling radio text 27
PTY list 28
Playing DVDs on the built-in player
Playing a DVD 29
• OEL display 29
• Information display 29
Basic operation of DVD 30
Specifying title (DVD mode) 31
Specifying chapter (DVD mode) 31
Stopping playback 32
Frame-by-frame playback 32
Still playback 32
Slow motion playback 32
Changing audio language during
playback (Multi-audio) 32
Changing the subtitle language during
playback (Multi-subtitle) 33
Changing the viewing angle during
playback (Multi-angle) 33
• About scenes that let you change the
viewing angle 34
Operating from the information display 1
(DVH&DVD mode) 34
• Searching for a desired scene,
starting playback from a
specified time 35
• Selecting audio, subtitle and angle 36
Operating from the information display 2
(DVH&DVD mode) 37
• Selecting repeat range 37
• Selecting audio output 37
Operating from the function display
(DVH mode) 38
• Repeating play 38
• Pausing playback 38
Playing Video CDs on the built-in player
Playing a Video CD 39
• OEL display 39
• Information display 39
Basic operation of Video CD 40
Stopping playback 41
Specifying track (DVD mode) 41
Still playback 42
Operating from the information display
(DVH&DVD mode) 43
• Searching for a desired scene,
starting playback from a
specified time 43
• Selecting repeat range 44
• Selecting audio output 44
Operating from the function display
(DVH mode) 45
• Repeating play 45
• Pausing playback 45
Contents
En 3
English Español Deutsch Français Italiano Nederlands
00
Section
Downloaded from Caradio-Manual.com Manuals

Playing CDs on the Built-in Player
Playing a CD 46
• OEL display 46
• Information display 46
Basic operation of CD 47
Operating from the information display
(DVH&DVD mode) 48
• Searching for a desired track 48
• Selecting repeat range 49
• Setting random play 49
• Setting scan play 49
• Pausing playback 49
Operating from the function display
(DVH mode) 50
• Repeating play 50
• Playing tracks in a random order 51
• Scanning tracks of a CD 51
• Pausing CD playback 51
Multi-CD Player
Playing a CD 52
Pausing playback 53
50-disc multi-CD player 53
Introduction of advanced multi-CD player
operation 53
Repeating play 54
Playing tracks in a random order 54
Scanning CDs and tracks 55
Pausing CD playback 55
Using ITS playlists 56
• Creating a playlist with ITS
programming 56
• Playback from your ITS playlist 57
• Erasing a track from your ITS
playlist 57
• Erasing a CD from your ITS playlist 58
Using disc title functions 58
• Entering disc titles 58
• Displaying disc titles 59
• Selecting discs from the disc
title list 59
Using CD TEXT functions 60
• Displaying titles on CD TEXT discs 60
• Scrolling titles in the display 60
Using compression and bass emphasis 60
Audio Adjustments
Introduction of audio adjustments 61
Setting the sound focus equalizer 62
Using balance adjustment 62
Using the equalizer 63
• Recalling equalizer curves 63
• Adjusting equalizer curves 63
• Fine adjusting equalizer curve 64
Adjusting bass 64
Adjusting treble 65
Adjusting loudness 65
Using subwoofer output 66
• Adjusting subwoofer settings 66
Using non fading output 67
• Adjusting non fading output level 67
Using the high pass filter 67
Adjusting source levels 68
Initial Settings for DVD player
Calling up the SET UP MENU 69
• Returning to the previous display 69
Setting the subtitle (SUBTITLE LANG.) 70
• Setting subtitles and assist subtitles
ON/OFF 70
• Assist subtitles 70
• Setting the subtitle language 70
• When you select OTHERS 71
Contents
En
4
00
Section
Downloaded from Caradio-Manual.com Manuals

Setting the audio language
(AUDIO LANG.) 71
Setting the menu language
(MENU LANG.) 72
Setting the parental lock (PARENTAL) 72
• Setting the code number and level 72
• Changing the level 73
• When playing DVDs enabling parental
lock 73
Setting aspect ratio (TV ASPECT) 74
Setting angle mark display (ANGLE) 74
Setting for digital output
(DIGITAL OUTPUT) 75
Setting digital and analog audio output
(OUTPUT SELECTION) 76
Setting remote control code type 77
If you forget your code number 77
Initial Settings
Adjusting initial settings 78
Setting the time 79
Setting the FM tuning step 79
Setting the DAB Priority Function 80
• When it is on 80
• When it is off 80
Switching Auto PI Seek 80
Switching the warning tone 80
Switching the auxiliary setting 81
Switching the dimmer setting 81
Selecting the brightness 81
Selecting the illumination color 81
Setting the rear output and
subwoofer controller 82
Switching the telephone muting/
attenuation 83
Switching the automatic disc playback 83
Other Functions
Using different entertainment displays 84
Using the AUX source 84
• Selecting AUX as the source 84
• Setting the AUX title 84
Using the telephone
muting/attenuation 85
• Telephone muting/attenuation
function 85
Displaying built-in player information 85
Introduction of DAB operation 86
• Operation 86
• Changing the label 86
• Operating announcements using the
function menu 87
• Available PTY function 87
• Searching the PTY 87
• Using dynamic label 87
• Displaying dynamic label 87
• Storing and recalling
dynamic label 88
Additional Information
Compatible with DVD, Video CD and CD
formats 89
Care of discs 91
Language code chart for DVD 92
Troubleshooting 93
• Common problems 93
• Problems during DVD playback 95
• Problems during Video CD playback 96
Error messages 97
• Error messages on the OEL display 97
• Error messages on the display 97
Terms of DVD/Video CD 98
Specifications 100
Contents
En 5
English Español Deutsch Français Italiano Nederlands
00
Section
Downloaded from Caradio-Manual.com Manuals

Before You Start
En
6
01
Section
About this unit
The tuner frequencies on this unit are allocated
for use in Western Europe, Asia, the Middle
East, Africa and Oceania. Use in other areas
may result in improper reception. The RDS
function operates only in areas with FM stations
broadcasting RDS signals.
About this manual
This unit features a number of sophisticated
functions ensuring superior reception and oper-
ation. All the functions have been designed for
the easiest possible use, but many are not self-
explanatory. This operation manual will help you
benefit fully from this unit’s potential and to
maximize your listening enjoyment.
We recommend that you familiarize yourself
with the functions and their operation by read-
ing through the manual before you begin using
this unit. It is especially important that you read
and observe precautions on this page and in
other sections.
This manual mainly explains remote control
operation. However, in addition to those func-
tions related with DVD/Video CD/CD operation
that can only be operated by the remote control,
there are also functions that can be operated
similarly by the head unit and functions that
can only be operated by the buttons provided for
the head unit.
Precautions
• This product contains a laser diode of higher
class than 1. To ensure continued safety, do
not remove any covers or attempt to gain
access to the inside of the product.
Refer all servicing to qualified personnel.
The following caution label appears on your
unit.
Location: bottom of the product
On the top of the product
• The Pioneer CarStereo-Pass is for use only in
Germany.
• Keep this manual handy as a reference for
operating procedures and precautions.
• Always keep the volume low enough so you
can hear sounds outside of the car.
• Protect this product from moisture.
• If the battery is disconnected or discharged,
the preset memory will be erased and must be
reprogrammed.
In case of trouble
Should this product fail to operate properly,
contact your dealer or nearest authorized
Pioneer Service Station.
CAUTION :
VORSICHT :
ADVARSEL :
VARNING :
VARO! :
VISIBLE AND INVISIBLE LASER RADIATION WHEN OPEN.
AVOID EXPOSURE TO BEAM.
SICHTBARE UND UNSICHTBARE LASERSTRAHLUNG, WENN
ABDECKUNG GEÖFFNET NICHT DEM STRAHL AUSSETZEN!
SYNLIG OG USYNLIG LASERSTRÅLING VED ÅBNING UNDGÅ
UDSÆTTELSE FOR STRÀLING.
SYNLIG OCH OSYNLIG LASERSTRÅLNING NÄR DENNA DEL ÄR
ÖPPNAD BETRAKTA EJ STRÅLEN.
AVATTAESSA ALTISTUT NÄKYVÄ JA NÄKYMÄTTÖMÄLLE
LASERSATEIL YLLE. ÄLÄ KATSO SÄTEESEN. VRW1860
CLASS 1
LASER PRODUCT
This product complies with the EMC
Directives (89/336/EEC, 92/31/EEC) and
CE Marking Directive (93/68/EEC).
Downloaded from Caradio-Manual.com Manuals

Before You Start
En 7
English Español Deutsch Français Italiano Nederlands
01
Section
DVD disc region numbers
DVDs that have incompatible region numbers
cannot be played on this player. The region num-
ber of the player can be found on the bottom of
this product.
The illustration below shows the regions and
corresponding region numbers.
Region number
DVD players and DVD discs feature region num-
bers indicating the area in which they were
purchased. Playback of a DVD is not possible
unless it features the same region number as
the DVD player. This product’s region number is
displayed on the bottom of this product.
Video system of a connected
component
This product is NTSC/PAL system compatible.
When connecting other components to this
product, be sure components are compatible
with the same video systems. If it is not, images
will not be correctly reproduced.
To ensure safe driving
WARNING
• To avoid the risk of accident and the potential
violation of applicable laws, this product is not
for use with a video screen that is visible to
the driver.
• In some countries or states the viewing of
images on a display inside a vehicle even by
persons other than the driver may be illegal.
Where such regulations apply, they must be
obeyed.
This product detects whether your car’s parking
brake is engaged or not, and prevents you from
watching a DVD or Video CD on the display
connected to Front Video Output while driving.
When you attempt to watch a DVD/Video CD,
the screen will turn to black.
When you park your car in a safe place and
apply the parking brake, the picture appears on
the screen.
Downloaded from Caradio-Manual.com Manuals
9
Disc organization
DVD
On DVD-Video discs, the contents are divided
into titles which are in turn divided into chap-
ters.
With video material, a single work (movie etc.)
usually corresponds to a single title, with differ-
ent scenes corresponding to separate chapters.
With karaoke discs, one song corresponds to
one title.
However, some discs are not organized like this,
so bear this in mind when using the search
function.
Video CD and CD
On CDs and Video CDs, the contents are divided
into tracks. One track usually corresponds to
one song. On some discs, tracks may also fea-
ture an index.
With Video CDs featuring PBC (Playback
Control), you can use a menu to perform play-
back operations. It may not be possible to use
functions such as repeat and search.
English Español Deutsch Français Italiano Nederlands
01
Section
Downloaded from Caradio-Manual.com Manuals

Before You Start
When using a display connected to
DVD REAR MONITOR OUTPUT
This product’s DVD REAR MONITOR OUTPUT is
for connection of a display to enable passengers
in the rear seats to watch the DVD or Video CD.
WARNING
• NEVER install the display in a location that
enables the Driver to watch the DVD or Video
CD while Driving.
Condition memory
This function memorizes audio language, subti-
tle language, angle number, audio output (L, R)
and aspect ratio made during disc playback for
up to 30 discs. Without any special operations,
the final setting details during playback of a disc
are memorized. The next time a disc is played,
the previous settings are automatically applied.
Notes
• With some discs, audio language and subtitle
language are automatically specified, in
which case condition memory does not func-
tion.
• When the number of discs exceeds 30, set-
tings for the latest disc replace those for the
least recent disc.
What the marks on DVDs
Indicate
The marks below can be found on DVD disc
labels and packages. They indicate the type of
images and audio recorded on the disc, and the
functions you can use.
Mark Meaning
Indicates the number of audio systems.
Indicates the number of subtitle
languages.
Indicates the number of viewing angles.
Indicates the picture size (aspect ratio:
screen width-to-height ratio) type.
Indicates the number of the region
where playback is possible.
Disc operation
With some DVDs, depending on the intentions
of the disc’s producer, certain operations may
be prohibited. Also, with discs enabling menu
operation and two-way operation during play-
back, the way titles and chapters are organized
may prevent certain operations such as repeat
play.
Notes
• If this happens with this product, the prohib-
ited mark “ ” is displayed.
• The prohibited mark “ ” may not appear on
some discs.
ALL
2
16 : 9 LB
3
2
2
En
8
01
Section
Downloaded from Caradio-Manual.com Manuals

Before You Start
En 7
English Español Deutsch Français Italiano Nederlands
01
Section
DVD disc region numbers
DVDs that have incompatible region numbers
cannot be played on this player. The region num-
ber of the player can be found on the bottom of
this product.
The illustration below shows the regions and
corresponding region numbers.
Region number
DVD players and DVD discs feature region num-
bers indicating the area in which they were
purchased. Playback of a DVD is not possible
unless it features the same region number as
the DVD player. This product’s region number is
displayed on the bottom of this product.
Video system of a connected
component
This product is NTSC/PAL system compatible.
When connecting other components to this
product, be sure components are compatible
with the same video systems. If it is not, images
will not be correctly reproduced.
To ensure safe driving
WARNING
• To avoid the risk of accident and the potential
violation of applicable laws, this product is not
for use with a video screen that is visible to
the driver.
• In some countries or states the viewing of
images on a display inside a vehicle even by
persons other than the driver may be illegal.
Where such regulations apply, they must be
obeyed.
This product detects whether your car’s parking
brake is engaged or not, and prevents you from
watching a DVD or Video CD on the display
connected to Front Video Output while driving.
When you attempt to watch a DVD/Video CD,
the screen will turn to black.
When you park your car in a safe place and
apply the parking brake, the picture appears on
the screen.
Downloaded from Caradio-Manual.com Manuals
9
Disc organization
DVD
On DVD-Video discs, the contents are divided
into titles which are in turn divided into chap-
ters.
With video material, a single work (movie etc.)
usually corresponds to a single title, with differ-
ent scenes corresponding to separate chapters.
With karaoke discs, one song corresponds to
one title.
However, some discs are not organized like this,
so bear this in mind when using the search
function.
Video CD and CD
On CDs and Video CDs, the contents are divided
into tracks. One track usually corresponds to
one song. On some discs, tracks may also fea-
ture an index.
With Video CDs featuring PBC (Playback
Control), you can use a menu to perform play-
back operations. It may not be possible to use
functions such as repeat and search.
Track 1 Track 2
Video CD
Track 3 Track 4
Track 1 Track 2
CD
Track 3 Track 4 Track 5
Title 1
Chapter 1 Chapter 2 Chapter 1 Chapter 2
Title 2
DVD
English Español Deutsch Français Italiano Nederlands
01
Section
Downloaded from Caradio-Manual.com Manuals

Before You Start
Main features
You can play back DVDs, Video CDs (PBC com-
patibility) and CDs.
Repeat Play
You can enjoy different kinds of repeat play.
Still image & frame-by-flame playback
You can view still images or playback of one
frame at a time.
Slow motion playback
Slow motion playback is possible.
Multi-Aspect
Switching between Wide screen, Letter box
and Panscan display is possible.
Multi-Audio
You can switch between multiple audio
systems recorded on a DVD as desired.
Multi-Subtitle
You can switch between multiple subtitle
languages recorded on a DVD as desired.
Multi-Angle
You can switch between multiple viewing
angles of a scene recorded on a DVD as
desired.
Video CDs featuring PBC Compatibility
You can play back Video CDs featuring PBC
(Playback Control).
Parental Lock
You can use this to prevent your children
viewing violent or adult oriented scenes.
Dolby* Digital/DTS** Compatibility (When
combining this product with a Pioneer
Multi-channel processor such as DEQ-
P7000)
When using this product with a Pioneer
Multi-channel processor, you can enjoy the
atmosphere and excitement provided by
DVD movie and music software featuring 5.1
channel recordings.
* Manufactured under license from Dolby
Laboratories. “Dolby” and the double-D symbol
are trademarks of Dolby Laboratories.
** “DTS” is a registered trademark of Digital
Theater Systems, Inc.
Notes
• This product incorporates copyright protec-
tion technology that is protected by method
claims of certain U.S. patents and other intel-
lectual property rights owned by Macrovision
Corporation and other rights owners.
• Use of this copyright protection technology
must be authorized by Macrovision
Corporation, and is intended for home and
other limited viewing uses only unless other-
wise authorized by Macrovision Corporation.
Reverse engineering or disassembly is prohib-
ited.
En
10
01
Section
Downloaded from Caradio-Manual.com Manuals

Before You Start
En 7
English Español Deutsch Français Italiano Nederlands
01
Section
DVD disc region numbers
DVDs that have incompatible region numbers
cannot be played on this player. The region num-
ber of the player can be found on the bottom of
this product.
The illustration below shows the regions and
corresponding region numbers.
Region number
DVD players and DVD discs feature region num-
bers indicating the area in which they were
purchased. Playback of a DVD is not possible
unless it features the same region number as
the DVD player. This product’s region number is
displayed on the bottom of this product.
Video system of a connected
component
This product is NTSC/PAL system compatible.
When connecting other components to this
product, be sure components are compatible
with the same video systems. If it is not, images
will not be correctly reproduced.
To ensure safe driving
WARNING
• To avoid the risk of accident and the potential
violation of applicable laws, this product is not
for use with a video screen that is visible to
the driver.
• In some countries or states the viewing of
images on a display inside a vehicle even by
persons other than the driver may be illegal.
Where such regulations apply, they must be
obeyed.
This product detects whether your car’s parking
brake is engaged or not, and prevents you from
watching a DVD or Video CD on the display
connected to Front Video Output while driving.
When you attempt to watch a DVD/Video CD,
the screen will turn to black.
When you park your car in a safe place and
apply the parking brake, the picture appears on
the screen.
Downloaded from Caradio-Manual.com Manuals
9
Disc organization
DVD
On DVD-Video discs, the contents are divided
into titles which are in turn divided into chap-
ters.
With video material, a single work (movie etc.)
usually corresponds to a single title, with differ-
ent scenes corresponding to separate chapters.
With karaoke discs, one song corresponds to
one title.
However, some discs are not organized like this,
so bear this in mind when using the search
function.
Video CD and CD
On CDs and Video CDs, the contents are divided
into tracks. One track usually corresponds to
one song. On some discs, tracks may also fea-
ture an index.
With Video CDs featuring PBC (Playback
Control), you can use a menu to perform play-
back operations. It may not be possible to use
functions such as repeat and search.
English Español Deutsch Français Italiano Nederlands
01
Section
Downloaded from Caradio-Manual.com Manuals

Before You Start
Switching the remote control
operation mode switch
There are two remote control operation modes
on the supplied remote control.
If you want to operate this product by remote
control, turn the mode switch to DVH mode. In
this case, both the head unit’s buttons and
remote control can control this unit.
If you want to operate the DVD playback on the
rear display, turn the mode switch to DVD
mode. In this case, the remote control can con-
trol the DVD playback of the rear display inde-
pendently. (If both the front and rear displays
are playing DVD as the source at the same time,
operation is the same for the front and rear
displays.)
If the rear display is connected to this product
and the remote control operation mode is set to
DVD mode, the rear display can playback DVD
even though the source which is selected by the
head unit is not DVD.
Note
• If the remote control operation mode is set to
DVD mode, only the DVD (built-in player) can
be operated by the remote control.
About the demo mode
This product features two demonstration
modes. One is the reverse mode, the other is the
feature demo mode.
Reverse mode
If you do not perform an operation within about
30 seconds, screen indications start to reverse,
and then continue reversing every 10 seconds.
Pressing 5 numbered button when power to this
product is switched off while the ignition switch
is set to ACC or ON cancels the reverse mode.
Pressing 5 numbered button again to start the
reverse mode.
Feature demo
The feature demo automatically starts when
power to this product is switched off while the
ignition switch is set to ACC or ON. Pressing 6
numbered button during feature demo opera-
tion cancels the feature demo mode. Pressing 6
numbered button again to start the feature
mode. Remember that if the feature demo con-
tinues operating when the car engine is
switched off, it may drain battery power.
Notes
• You cannot cancel a demo mode when the
front panel is open.
• The red lead (ACC) of this unit should be con-
nected to a terminal coupled with ignition
switch on/off operations. If this is not done,
the vehicle battery may be drained.
En
12
01
Section
Downloaded from Caradio-Manual.com Manuals

Before You Start
En 7
English Español Deutsch Français Italiano Nederlands
01
Section
DVD disc region numbers
DVDs that have incompatible region numbers
cannot be played on this player. The region num-
ber of the player can be found on the bottom of
this product.
The illustration below shows the regions and
corresponding region numbers.
Region number
DVD players and DVD discs feature region num-
bers indicating the area in which they were
purchased. Playback of a DVD is not possible
unless it features the same region number as
the DVD player. This product’s region number is
displayed on the bottom of this product.
Video system of a connected
component
This product is NTSC/PAL system compatible.
When connecting other components to this
product, be sure components are compatible
with the same video systems. If it is not, images
will not be correctly reproduced.
To ensure safe driving
WARNING
• To avoid the risk of accident and the potential
violation of applicable laws, this product is not
for use with a video screen that is visible to
the driver.
• In some countries or states the viewing of
images on a display inside a vehicle even by
persons other than the driver may be illegal.
Where such regulations apply, they must be
obeyed.
This product detects whether your car’s parking
brake is engaged or not, and prevents you from
watching a DVD or Video CD on the display
connected to Front Video Output while driving.
When you attempt to watch a DVD/Video CD,
the screen will turn to black.
When you park your car in a safe place and
apply the parking brake, the picture appears on
the screen.
Downloaded from Caradio-Manual.com Manuals
9
Disc organization
DVD
On DVD-Video discs, the contents are divided
into titles which are in turn divided into chap-
ters.
With video material, a single work (movie etc.)
usually corresponds to a single title, with differ-
ent scenes corresponding to separate chapters.
With karaoke discs, one song corresponds to
one title.
However, some discs are not organized like this,
so bear this in mind when using the search
function.
Video CD and CD
On CDs and Video CDs, the contents are divided
into tracks. One track usually corresponds to
one song. On some discs, tracks may also fea-
ture an index.
With Video CDs featuring PBC (Playback
Control), you can use a menu to perform play-
back operations. It may not be possible to use
functions such as repeat and search.
English Español Deutsch Français Italiano Nederlands
01
Section
Downloaded from Caradio-Manual.com Manuals

Before You Start
Remote control
1Remote control selection switch
Switch to change the setting of the remote
control (refer to page 77).
2VOLUME (+/–) button
Press to increase or decrease the volume.
3TOP MENU button
Press to return to the top menu while the
built-in player is playing as the source.
4MENU button
Press to display the menu while the built-in
player is playing as the source.
5RETURN button
Press to return to the playback display when
the menu is displayed while the built-in
player is playing as the source.
6AUDIO button
Press to change the audio language during
playback when the built-in player is playing
as the source.
7DISPLAY button
Press to display the information display 1 or
2 while the built-in player is playing as the
source.
8SUBTITLE button
Press to change the subtitle language during
playback when the built-in player is playing
as the source.
En
14
01
Section
1
2
r
t
y
u
i
o
;
a
s
e
w
q
p
9
8
7
6
5
4
3
d
f
Downloaded from Caradio-Manual.com Manuals

Before You Start
En 7
English Español Deutsch Français Italiano Nederlands
01
Section
DVD disc region numbers
DVDs that have incompatible region numbers
cannot be played on this player. The region num-
ber of the player can be found on the bottom of
this product.
The illustration below shows the regions and
corresponding region numbers.
Region number
DVD players and DVD discs feature region num-
bers indicating the area in which they were
purchased. Playback of a DVD is not possible
unless it features the same region number as
the DVD player. This product’s region number is
displayed on the bottom of this product.
Video system of a connected
component
This product is NTSC/PAL system compatible.
When connecting other components to this
product, be sure components are compatible
with the same video systems. If it is not, images
will not be correctly reproduced.
To ensure safe driving
WARNING
• To avoid the risk of accident and the potential
violation of applicable laws, this product is not
for use with a video screen that is visible to
the driver.
• In some countries or states the viewing of
images on a display inside a vehicle even by
persons other than the driver may be illegal.
Where such regulations apply, they must be
obeyed.
This product detects whether your car’s parking
brake is engaged or not, and prevents you from
watching a DVD or Video CD on the display
connected to Front Video Output while driving.
When you attempt to watch a DVD/Video CD,
the screen will turn to black.
When you park your car in a safe place and
apply the parking brake, the picture appears on
the screen.
Downloaded from Caradio-Manual.com Manuals
9
Disc organization
DVD
On DVD-Video discs, the contents are divided
into titles which are in turn divided into chap-
ters.
With video material, a single work (movie etc.)
usually corresponds to a single title, with differ-
ent scenes corresponding to separate chapters.
With karaoke discs, one song corresponds to
one title.
However, some discs are not organized like this,
so bear this in mind when using the search
function.
Video CD and CD
On CDs and Video CDs, the contents are divided
into tracks. One track usually corresponds to
one song. On some discs, tracks may also fea-
ture an index.
With Video CDs featuring PBC (Playback
Control), you can use a menu to perform play-
back operations. It may not be possible to use
functions such as repeat and search.
English Español Deutsch Français Italiano Nederlands
01
Section
Downloaded from Caradio-Manual.com Manuals

Before You Start
Use and care of the remote con-
trol
Installing the battery
Slide the tray out on the back of the remote
control and insert the battery with the plus (+)
and minus (–) poles pointing in the proper direc-
tion.
Note
• When using for the first time, pull out the film
protruding from the tray.
WARNING
• Keep the battery out of the reach of children.
Should the battery be swallowed, immediately
consult a doctor.
CAUTION
• Use only one CR2025 (3V) lithium battery.
• Remove the battery if the remote control is not
to be used for a month or longer.
• Do not recharge, disassemble, heat or dis-
pose of battery in fire.
• Do not handle the battery with metallic tools.
• Do not store the battery with metallic materi-
als.
• In the event of battery leakage, wipe the
remote control completely clean and install a
new battery.
• When disposing of used batteries, please
comply with governmental regulations or
environmental public institution’s rules that
apply in your country/area.
• Always check carefully that you are loading
the battery with its plus (+) and minus (–)
poles facing in the proper directions.
Using the remote control
Point the remote control in the direction of the
front panel to operate.
Important
• Do not store the remote control in high tem-
peratures or direct sunlight.
• The remote control may not function properly
in direct sunlight.
• Do not let the remote control fall onto the
floor, where it may become jammed under the
brake or accelerator pedals.
En
16
01
Section
Downloaded from Caradio-Manual.com Manuals

Power ON/OFF
En 17
Turning the unit on
When the remote control is set to
DVH mode
Press SOURCE to turn the unit on.
When you select a source the unit is turned on.
• Pressing SOURCE on the head unit also per-
forms the same operation.
When the remote control is set to
DVD mode
Press POWER to turn the DVD playback on.
Notes
• Even if the source selected with this product
is not DVD, if you switch power to this product
on with POWER, you can watch the DVD pic-
ture from this unit on the rear display.
• Regardless of whether this product is
switched on or off, you can watch the DVD
video on the rear display.
Selecting a source
You can select the source you want to listen to.
If AUTO PLAY (refer to page 83) is set to on, load
a disc into the disc loading slot to switch to the
built-in player.
When the remote control is set to
DVH mode
Press SOURCE to select a source.
Press SOURCE repeatedly to switch between
the following sources:
TV—Tuner—DAB (Digital Audio
Broadcasting)—DVD (Built-in player)—Multi-CD
player—External unit 1—External unit 2 —AUX
• Pressing SOURCE on the head unit also per-
forms the same operation.
English Español Deutsch Français Italiano Nederlands
02
Section
Downloaded from Caradio-Manual.com Manuals

Power ON/OFF
Notes
• In the following cases, the sound source will
not change:
— When a product corresponding to each
source is not connected to this product.
— When no disc is set in this product.
— When no magazine is set in the multi-CD
player.
— When the AUX (auxiliary input) is set to off
(refer to page 81).
• External unit refers to a Pioneer product (such
as one available in the future) that, although
incompatible as a source, enables control of
basic functions by this product. Two external
units can be controlled by this product. When
two external units are connected, the alloca-
tion of them to external unit 1 or external unit
2 is automatically set by this product.
• When this unit’s blue/white lead is connected
to the car’s auto-antenna relay control termi-
nal, the car’s antenna extends when this
unit’s source is switched on. To retract the
antenna, switch the source off.
Turning the unit off
When the remote control is set to
DVH mode
Press SOURCE and hold for about one second
to turn the unit off.
• Pressing and holding SOURCE on the head
unit also performs the same operation.
When the remote control is set to
DVD mode
Press POWER to turn the DVD playback off.
REAR will disappear from the OEL display.
Notes
• If the DVD playback is set to off, REAR will
disappear from the OEL display.
• When you have selected DVD (built-in player)
on the head unit, pressing POWER on the
remote control stops the DVD playback. In
this case, Power Off will be displayed on the
OEL display.
CAUTION
• When you have turned the DVD playback on
by pressing POWER, you cannot turn this
product off even if you press and hold
SOURCE. (REAR on the OEL display will be
flashing.) In this case, press POWER to turn
REAR off. When REAR has disappeared from
the OEL display, you can confirm that this
product is off.
En
18
02
Section
Downloaded from Caradio-Manual.com Manuals

Tuner
En 19
Listening to the radio
These are the basic steps necessary to operate
the radio. More advanced tuner operation is
explained starting on page 20.
This product’s AF (alternative frequencies
search) function can be switched on and off. AF
should be off for normal tuning operation (refer
to page 23).
1STEREO (ST) indicator
Shows that the frequency selected is being
broadcast in stereo.
2BAND indicator
Shows which band the radio is tuned to, MW,
LW or FM.
3PRESET NUMBER indicator
Shows what preset has been selected.
4FREQUENCY indicator
Shows to which frequency the tuner is
tuned.
1 Press SOURCE to select the tuner.
Press SOURCE until you see Tuner displayed.
• Pressing SOURCE on the head unit also per-
forms the same operation.
2 Use VOLUME to adjust the sound level.
Press VOLUME to increase or decrease the vol-
ume.
• Rotating VOLUME on the head unit also
increases or decreases the volume.
3 Press BAND/ESC to select a band.
Press BAND/ESC until the desired band is dis-
played, FM1, FM2, FM3 for FM or MW/LW.
• Pressing BAND/ESC on the head unit also
performs the same operation.
4 To perform manual tuning, press 1or
¡with quick presses.
The frequencies move up or down step by step.
• Pressing 2or 3on the head unit also per-
forms the same operation.
5 To perform seek tuning, press and hold 1
or ¡for about one second and release.
The tuner will scan the frequencies until a
broadcast strong enough for good reception is
found.
• You can cancel seek tuning by pressing either
1or ¡with a quick press.
• If you press and hold 1or ¡you can skip
broadcasting stations. Seek tuning starts as
soon as you release the buttons.
• Pressing 2or 3on the head unit also per-
forms the same operation.
Note
• When the frequency selected is being broad-
cast in stereo the STEREO (ST) indicator will
light.
123
4
English Español Deutsch Français Italiano Nederlands
03
Section
Downloaded from Caradio-Manual.com Manuals
21
Tuning in strong signals
Local seek tuning lets you tune in only those
radio stations with sufficiently strong signals for
good reception.
1 Press Fto select LOCAL.
Press F until Local appears in the display.
• Pressing FUNCTION on the head unit also
performs the same operation.
2 Press Eto turn local seek tuning on.
Local seek sensitivity (e.g., Local 2) appears in
the display.
• Pressing 5on the head unit also performs
the same operation.
3 Press 1or ¡to set the sensitivity.
There are four levels of sensitivity for FM and
two levels for MW/LW:
FM: Local 1—Local 2—Local 3—Local 4
MW/LW: Local 1—Local 2
The Local 4 setting allows reception of only the
strongest stations, while lower settings let you
receive progressively weaker stations.
• Pressing 2or 3on the head unit also per-
forms the same operation.
4 When you want to return to normal seek
tuning, press eto turn local seek tuning off.
Local :OFF appears in the display.
• Pressing ∞on the head unit also performs
the same operation.
Storing the strongest broadcast
frequencies
BSM (best stations memory) lets you automati-
cally store the six strongest broadcast frequen-
cies under NUMBER (1-6) buttons (PRESET
TUNING on the head unit) and once stored
there you can tune in to those frequencies with
the touch of a button.
1 Press Fto select BSM.
Press Funtil BSM appears in the display.
• Pressing FUNCTION on the head unit also
performs the same operation.
2 Press Eto turn BSM on.
BSM begins to flash. While BSM is flashing the
six strongest broadcast frequencies will be
stored under NUMBER (1-6) buttons (PRESET
TUNING on the head unit) in order of their sig-
nal strength. When finished, BSM stops flash-
ing.
• To cancel the storage process, press e.
• Pressing 5or ∞on the head unit also per-
forms the same operation.
Note
• Storing broadcast frequencies that with BSM
may replace the broadcast frequencies that
you have saved using NUMBER (1-6) buttons
(PRESET TUNING on the head unit).
English Español Deutsch Français Italiano Nederlands
03
Section

Tuner
Introduction of advanced tuner
operation
1FUNCTION display
Shows the function status.
Press F to display the function names.
Press F repeatedly to switch between the follow-
ing functions:
BSM (best stations memory)—REG (regional)—
LOCAL (local seek tuning)—PTY (program type
selection)—TA (traffic announcement
standby)—AF (alternative frequencies search)—
NEWS (news program interruption)
• Pressing FUNCTION on the head unit also
performs the same operation.
• To return to the frequency display, press
BAND/ESC.
• If MW/LW band is selected, you can only
select BSM or LOCAL.
Note
• If you do not operate the function within about
30 seconds, the display is automatically
returned to the frequency display.
Storing and recalling broadcast
frequencies
If you press any of the NUMBER (1-6) buttons
you can easily store up to six broadcast frequen-
cies for later recall with the touch of a button.
When you find a frequency that you want to
store in memory press a NUMBER button and
hold until the preset number stops flashing.
The number you have pressed will flash in the
PRESET NUMBER indicator and then remain lit.
The selected radio station frequency has been
stored in memory.
The next time you press the same NUMBER (1-6)
buttons the radio station frequency is recalled
from memory.
• Pressing PRESET TUNING on the head unit
also performs the same operation.
Notes
• Up to 18 FM stations, 6 for each of the three
FM bands, and 6 MW/LW stations can be
stored in memory.
• You can also use eand E(5and ∞on the
head unit) to recall radio station frequencies
assigned to NUMBER (1-6) buttons (PRESET
TUNING on the head unit).
1
En
20
03
Section
Downloaded from Caradio-Manual.com Manuals
