9
RS-232C Adjustment
Command
434CMX
505CMX
Command
425CMX
Command
427CMX
507CMX
Function
Number direct Last
memory Comment
Effective Minimum Maximum
CLSS05 ++
Sets color system to 4.43NTSC.
CLSS06 ++
Sets color system to PAL M.
CLSS07 ++
Sets color system to PAL N.
SIGNAL FORMAT
SFT ++
Displays the present set value of the SIGNAL FORMAT.
SFTS01 ++
Sets SIGNAL FORMAT to Type1. Note 1
SFTS02 ++
Sets SIGNAL FORMAT to Type2. Note 1
SFTS03 ++
Sets SIGNAL FORMAT to Type3. Note 1
SFTS04 ++
Sets SIGNAL FORMAT to Type4. Note 1
–SFTS05 +Sets SIGNAL FORMAT to Type5.
–SFTS06 +Sets SIGNAL FORMAT to Type6.
–SFTS07 +Sets SIGNAL FORMAT to Type7.
–SFTS08 +Sets SIGNAL FORMAT to Type8.
–+SFTS09 Sets SIGNAL FORMAT to Type9. New
–+SFTS20 Sets SIGNAL FORMAT to Type10. New
–SFTS10 +Sets SIGNAL FORMAT to AUTO.
DVI
EDIS01 DSGS01 +Sets the DVI connection signal to PC. Note 2
EDIS02 DSGS02 +Sets the DVI connection signal to STB/DVD. Note 2
–DBLS01 +Sets the DVI BLACK LEVEL to LOW.
–DBLS02 +Sets the DVI BLACK LEVEL to HIGH.
Note 1: The operation differs between the PDP-434CMX/PDP-505CMX and PDP-425CMX/PDP-507CMX/PDP-427CMX
Note 2: EDIS01/02 only operates on the PDP-505CMX
7“MENU”–“OPTION”related commands
Command
434CMX
505CMX
Command
425CMX
Command
427CMX
507CMX
Function Number direct Last
memory Comment
Effective Minimum Maximum
ENERGY SAVE
ESV ++
Displays the present set value of ENERGY SAVE.
ESVS00 ++
Sets ENERGY SAVE to STANDARD (STANDARD1).
Sets STANDARD1
only on the 507CMX
ESVS01 ++
Sets ENERGY SAVE to save energy.
ESVS02 ++
Sets ENERGY SAVE to fixed brightness.
ESVS03 ++
Sets ENERGY SAVE to mode 3 (long service life).
ESVS04 ++
Sets ENERGY SAVE to AUTO.
–+ESVS05 Sets ENERGY SAVE to MUTE. New
–+ESVS06 Sets ENERGY SAVE to standard 2.
New, and effective
only on the 507CMX
TIMER
– TSMS00 +Turns summer time to OFF.
– TSMS01 +Turns summer time to ON.
– TPH +Sets the hour of the present time. 000 023
000 – 023: Set by
24-hour clock time
– TPM +Sets the minute of the present time. 000 059 000 – 059: Set
for 60 minutes
– TPW +Sets the day of week of the present time. 001 007 001: Monday –
007; Saturday
– TPTS00 +Sets PROGRAM TIMER/REPEAT TIMER to OFF.
– TPTS01 +Sets PROGRAM TIMER to ON.
–+TPTS02 Sets REPEAT TIMER to ON. New
ORBITER
OMN ORBS00 +Sets the ORBITER to OFF.
OMY ORBS01 +Sets the ORBITER to ON (AUTO1).
– ORBS02 +Sets the ORBITER to ON (AUTO2).
– ORBS03 +Sets the ORBITER to ON (AUTO3).
SOFT FOCUS
– SOFS00 +Sets SOFT FOCUS to OFF.
– SOFS01 +Sets SOFT FOCUS to 1.
– SOFS02 +Sets SOFT FOCUS to 2.
– SOFS03 +Sets SOFT FOCUS to 3.
– SOFS04 +Sets SOFT FOCUS to 4.
SUB SCREEN FREEZE
– SSTS00 +Sets SUB SCREEN FREEZE to OFF.
– SSTS01 +Sets SUB SCREEN FREEZE to SIDE BY SIDE.
– SSTS02 +Sets SUB SCREEN FREEZE to PinP.
