THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
Model Type Power Requirement Remarks
PRO-507PU KUCXC AC120 V
PRO-507PU
PLASMA DISPLAY
¶This service manual should be used together with the following manual(s):
Model No. Order No. Remarks
PDP-5071PU/KUCXC ARP3354 SAFETY INFORMATION, EXPLODED VIEWS AND PARTS LIST, BLOCK DIAGRAM,
PCB PARTS LIST,ADJUSTMENT, IC INFORMATION etc.
ARP3355 SCHEMATIC DIAGRAM and PCB CONNECTION DIAGRAM
CONTENTS
1. CONTRAST OF MISCELLANEOUS PARTS ..............................2
2. BLOCK DIAGRAM AND SCHEMATIC DIAGRAM ...................10
2.1 OVERALL WIRING DIAGRAM............................................10
2.2 HNM BLOCK DIAGRAM .....................................................12
2.3 CONNECTOR PIN DESCRIPTION ....................................13
2.4 HN MODULE ASSY (1/6) ....................................................14
2.5 HN MODULE ASSY (2/6) ....................................................18
2.6 HN MODULE ASSY (3/6) ....................................................20
2.7 HN MODULE ASSY (4/6) ....................................................22
2.8 HN MODULE ASSY (5/6) ....................................................24
2.9 HN MODULE ASSY (6/6) ....................................................26
3. PCB CONNECTION DIAGRAM................................................ 28
3.1 HN MODULE ASSY ............................................................28
4. TROUBLESHOOTING ..............................................................30
5. IC INFORMATION..................................................................... 33

2
A
B
C
D
1234
1234
PRO-507PU
1. CONTRAST OF MISCELLANEOUS PARTS
Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
The mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
Screws adjacent to mark on product are used for disassembly.
Reference Nos. indicate the pages and Nos. in the service manual for the base model.
NOTES:
When ordering resistors, first convert resistance values into code form as shown in the following examples.
Ex.1 When there are 2 effective digits (any digit apart from 0), such as 560 ohm and 47k ohm (tolerance is shown by J=5%,
and K=10%).
Ex.2 When there are 3 effective digits (such as in high precision metal film resistors).
561
473
R50
1R0
5621
560
47k
0.5
1
RD1/4PU J
RD1/4PU J
RN2H K
RS1P K
56 x 10
1
47 x10
3
R50
1R0
561
473
5.62k RN1/4PC F562 x 10
1
5621
• Parts of the packing section are all mentioned in this manual.
1.1 PACKING SECTION
Speed clamp x3
Bead band x3
Noise filter
for antenna cable
Binder for noise filter
5
7
24
9, 11, 14
28
19
20
13
10
12
21
15
1
16
43
23
17
22
18
6

3
A
B
C
D
5678
5678
PRO-507PU
•PACKING Parts List
Mark No. Description Part No.
>1 Power Cord (2 m) ADG1215
2 G-LINK Cable (3 m) VDX1010
3 Remote Control Unit AXD1531
4 Battery Cover AZN2681
NSP 5 Alkaline Dry Cell Battery (LR6, AA) VEM1023
6 Filter CTX1054
7 Binder Assy AEC1908
8 Cleaning Cloth AED1285
9 Operating Instructions (English) ARB1573
10 Caution Card ARM1239
11 Cleaning Caution (U) ARM1303
12 Accessory Caution ARM1304
NSP 13 Warranty Card ARY1123
NSP 14 Card (Register) ARY1156
15 Polyethlene Bag AHG1394
16 Vinyl Bag AHG1347
17 Pad (507EL. T-L) AHA2576
18 Pad (507EL. T-R) AHA2577
19 Pad (507EL. B-L) AHA2578
20 Pad (507EL. B-R) AHA2579
21 Under Carton (507EL) AHD3491
22 Upper Carton (507EL) AHD3492
23 Packing Sheet AHG1352
24 Polyethylene Bag S AHG1395

4
A
B
C
D
1234
1234
PRO-507PU
PRO-507PU/KUCXC and PDP-5071PU/KUCXC are constructed the same except for the following :
PCB ASSEMBLIES
P23 - 1 1..MAIN Assy AWV2312 AWV2309
NSP 1..IO Assy AWV2313 AWV2310
P23 - 2 2..TANSHI ASSY AWW1156 AWW1153
P23 - 3 2..POD ASSY AWW1154 AWW1158
P13 - 2 2..SIDE ASSY AWW1157 AWW1155
1..HN MODULE Assy Not used AWV2311 Refer to “Replacement of AWV2311:
HOME NETWORK MODULE Assy”
MULTI BASE SECTION
P23 - 37 Terminal Panel A (U/B) ANC2394 ANC2396
P23 - 38 POD StayA ANG2933 Not used
P23 - 38 POD Stay B Not used ANG2934
DLNA Stay Not used ANG2932 No.1
Wire Saddle Not used AEC1751 No.2
Loking Wire Spacer Not used AEC2098 No.3
4P Housing Wire (J124) Not used ADX3417 No.4
3P Housing Wire (J125) Not used ADX3484 No.5
Flexible Cable (J216) Not used ADD1474 No.6
REAR SECTION
P13 - 17 NSP Name Label AAL2766 AAL2812
P13 - 22 Terminal Label A(U/B) AAX3325 Not used
P13 - 22 Terminal Label A(U/E) Not used AAX3331
P13 - 23 Terminal Label C (U/B) AAX3330 Not used
P13 - 23 Terminal Label C (U/E) Not used AAX3335
P13 - 24 Terminal Label B50 (U/B) AAX3414 Not used
P13 - 24 Terminal Label B50 (U/E) Not used AAX3416
P13 - 29 Function Button Sheet (U) AAK2895 Not used
P13 - 29 Function Button Sheet (U/E) Not used AAK2903
P13 - 30 Input Cover Label U AAX3363 Not used
P13 - 30 Input Cover Label U/E Not used AAX3404
FRONT SECTION
P15 - 3 Front Case Assy (507PU) AMB2917 AMB2918
P15 - 5 Pioneer Name Plate AAM1098 Not used
P15 - 5 Elite Badge Not used AAM1102
PDP SERVICE ASSY
P25 1..PDP SERVICE Assy AWU1212 AWU1227
P25 - 1 NSP 2..P. Chassis (507)Assy AWU1148 Not used
P25 - 1 NSP 2..P. Chassis (507E)Assy Not used AWU1187
P25 - 8 2..Clamp Base ANG3030 Not used
P25 - 10 NSP 2..PCB Spacer AEC1126 Not used
P25 - 13 2..Wire Saddle AEC1751 Not used
P25 - 16 2..PCB Support AEC1958 Not used
P25 - 17 2..Harness Lifter 28 AEC1982 Not used
P25 - 22 2..DC SheetA AMR3612 Not used
P25 - 23 2..Address Sheet E AMR3621 Not used
P25 - 24 2..Address Sheet D AMR3631 Not used
P25 - 25 2..Gasket E ANK1874 Not used
P25 - 37 2..Polyethylene Bag AHG1337 Not used
TABLE TOP STAND
P26 - 1 NSP Stand Pipe Assy AXY1141 Not used
P26 - 2 NSP Base Cover Assy AXY1142 Not used
P26 - 3 Bolt (HEX) ABA1358 Not used
P26 - 4 Bolt (HEX) ABA1359 Not used
P26 - 5 Screw ABA1360 Not used
CONTRAST TABLE
Part No.
PDP-5071PU
KUCXC
Ref. No. Symbol and Description Remarks
Mark PRO-507PU
KUCXC
1.2 EXTERIOR SECTION
Note : For PCB ASSEMBLIES, Refer to “ CONTRAST OF PCB ASSEMBLIES ”.
: The numbers in the remarks column correspond to the numbers on the “ EXPLODED VIEWS ”.

5
A
B
C
D
5678
5678
PRO-507PU
EXPLODED VIEWS
No.5No.5No.4No.4
No.5No.5
Note: see next pageNote: see next page
No.5No.5No.1No.1
No.5No.5No.2No.2
No.5No.5No.3No.3
No.5No.5No.6No.6
POD Stay BPOD Stay B
PMB30P080FNIPMB30P080FNI AMZ30P060FTBAMZ30P060FTB
AMZ30P060FTBAMZ30P060FTB BMZ30P060FTBBMZ30P060FTB
BMZ30P060FTBBMZ30P060FTB
No.5No.5No.4
No.5
Note: see next page
No.5No.5No.1
No.5No.5No.2
No.5No.5No.3
No.5No.5No.6
POD Stay B
PMB30P080FNI AMZ30P060FTB
AMZ30P060FTB BMZ30P060FTB
BMZ30P060FTB

6
A
B
C
D
1234
1234
PRO-507PU
Replacement of AWV2311: HOME NETWORK MODULE ass'y
There are two types of HOME NETWORK MODULE ass'y in interface with MAIN ass'y,
and only AWV2311-B/J is available as a service parts ass'y.
AWV2311- A/J AWV2311- B/J
J7601: ADX3483 yes no
CN7802: KM200NA3L no yes
Connection with MAIN ass'y Figure A Figure B
When AWV2311-A /J is used in the product, order ADX3484 in addition,
and connect it with MAIN ass'y as shown in Figure B.
Or perform the following steps as shown in Figure A.
1. Take off ADX3483 from the defective ass'y
2. Solder it to the same point (4th pin in IC7803) on a service parts ass'y
3. Fix the wire by bond-lock, and then connect it with MAIN ass'y
When AWV2311-B /J is used in the product,
replace the defective ass'y with a service parts ass'y as shown in Figure B.
Figure A: AWV2311-A /J
Figure B: AWV2311-B /J
Fix the wire by bond-lock.
Fix the wire by bond-lock.
4th pin in IC7803
4th pin in IC7803
ADX3484
ADX3484
CN7802
CN7802
M17
M17
M17
M17
ADX3483
ADX3483
ADX3485
ADX3485
Fix the wire by bond-lock.
4th pin in IC7803
ADX3484
CN7802
M17
M17 ADX3483
ADX3485

7
A
B
C
D
5678
5678
PRO-507PU
CONTRAST OF PCB ASSEMBLIES
•MAIN ASSY
AWV2309 and AWV2312 are constructed the same except for the following :
Mark Symbol and Description Part No.
AWV2312 AWV2309 Remarks
[DT AV BLOCK]
IC7105 R5520H001B Not used
IC7108 Not used TC7WH157FU
Q7102 Not used 2SC4116
C7135 ACH1421 Not used
C7136, C7138 CKSSYB104K10 Not used
C7178 Not used CKSSYB104K10
F7105 Not used VTF1084
L7103, L7104 BTX1042 Not used
L7106 ATH1160 Not used
R7173 Not used RS1/16SS103J
R7112 RS1/16SS0R0J Not used
R7163 RS1/16SS0R0J Not used
CN7101 AKM1276 Not used
[POWER 0 BLOCK]
Q4102 Not used UPA1917TE
Q4103 Not used 2SC4116
C4134 Not used CKSSYB104K10
R4113 Not used RS1/16SS102J
R4114 Not used RS1/16SS223J
R4115 Not used RS1/16SS104J
R4169 Not used RS1/10S0R0J
[BOARD IF BLOCK]
R4031 RS1/16SS0R0J Not used
R4011 Not used RS1/16S0R0J
R4032 Not used RS1/16SS0R0J
CN4011 Not used AKM1274
CN4016 Not used AKM1275
CN4017 Not used AKM1235
[AV SW BLOCK]
C4703 Not used CKSRYB105K10
C4755, C4756 Not used CCG1205
R4713 Not used RS1/16SS101J
R4821 Not used RS1/16SS104J
R4827, R4829 Not used RS1/16SS202J
R4830 RS1/16SS473J RS1/16SS104J
R4833 Not used RS1/16SS104J
R4836 RS1/16SS473J RS1/16SS104J
[RGB SW BLOCK]
C4945, C4946, C4947 Not used CKSRYB105K10
R4901, R4902, R4904 Not used RS1/16SS220J
[MAIN UCOM BLOCK]
R8454 RS1/16SS103J Not used
R8470 RS1/16SS103J Not used
R8469, R8453 Not used RS1/16SS103J
Note: For Schematic Diagram and PCB Connection Diagram. Refer to “Service Manual: Order No. ARP3355”

8
A
B
C
D
1234
1234
PRO-507PU
SEMICONDUCTORS
IC7703 AGC1027
[8620 BLOCK(U)]
SEMICONDUCTORS
IC7601 EM8620L-LFC
MISCELLANEOUS
F 7601,7602 ATX1066
X 7601 ASS1208
RESISTORS
R 7646,7647 RS1/16SS1400F
R 7649-7651 RAB4CQ330J
R 7652-7654 RAB4CQ103J
Other Resistors RS1/16SS###J
•HN MODULE ASSY (AWV2311)
Note: For Schematic Diagram and PCB Connection Diagram. Refer to “2.4 - 2.9 Schematic Diagram and 3. PCB Connection Diagram”
•TANSHI ASSY
AWW1153 and AWW1156 are constructed the same except for the following :
Mark Symbol and Description Part No.
AWW1156 AWW1153 Remarks
R8842, R8910 RS1/16SS0R0J Not used
R8843 Not used RS1/16SS0R0J
JA8801 AKB1338 AKB1343
JA8803, JA8805 AKB1331 AKB1341
JA8807 AKB1334 AKB1344
JA8808, JA8809 AKB1332 AKB1342
JA8810 Not used AKN7008
•POD ASSY
Mark Symbol and Description Part No.
AWW1154 AWW1158 Remarks
R9200 RS1/16SS0R0J Not used
R9201 Not used RS1/16SS0R0J
AWW1158 and AWW1154 are constructed the same except for the following :
•SIDE ASSY
Mark Symbol and Description Part No.
AWW1157 AWW1155 Remarks
R9141 RS1/16SS0R0J Not used
R9142 Not used RS1/16SS0R0J
JA9101 AKB1303 AKB1304
JA9102 AKB1305 AKB1306
AWW1155 and AWW1157 are constructed the same except for the following :
Note: For Schematic Diagram and PCB Connection Diagram. Refer to “Service Manual: Order No. ARP3355”
Note: For Schematic Diagram and PCB Connection Diagram. Refer to “Service Manual: Order No. ARP3355”
Note: For Schematic Diagram and PCB Connection Diagram. Refer to “Service Manual: Order No. ARP3355”
Mark No. Description Part No. Mark No. Description Part No.
CAPACITORS
C 7601-7609 DCH1201
C 7610,7611 CCSSCH7R0D50
C 7612,7613,7615-7639 CKSSYF104Z16
[8620 DDR BLOCK(U)]
SEMICONDUCTORS
IC7701,7702 EDD2516AKTA-6B
MISCELLANEOUS
F 7701 ATL7002
RESISTORS
R 7709,7710 RS1/16SS1001F
R 7711-7718 RAB4CQ560J
Other Resistors RS1/16SS###J

9
A
B
C
D
5678
5678
PRO-507PU
CAPACITORS
C 7701-7717 CKSSYF104Z16
C 7722-7726 DCH1201
[ETHERNET BLOCK(U)]
MISCELLANEOUS
7752,7753 VNE1949
SEMICONDUCTORS
IC7751 TC74LCX125FTS1
IC7753 BR93L46RFJ-W
IC7754 RTL8100CL-LF
Q 7751 2SB1197K
MISCELLANEOUS
F 7751-7753 ATL7002
JA7752 AKP1307
X 7751 ASS1209
RESISTORS
R 7753 RS1/16SS5601F
R 7754,7755,7757,7758 RS1/16SS49R9F
Other Resistors RS1/16SS###J
CAPACITORS
C 7751 BCG1059
C 7752,7753,7756,7757 CKSSYB103K25
C 7754,7755 CCSSCH100D50
C 7758-7762,7764-7779 CKSSYF104Z16
[HNM USB BLOCK(U)]
SEMICONDUCTORS
IC7801 VT6212L-G
IC7803 R5520H001B
MISCELLANEOUS
L 7801 ATH7015
F 7801-7806 ATL7002
X 7801 ASS1210
CN7801 KM200NA5L
CN7802 KM200NA3L
RESISTORS
R 7803 RS1/16SS5111F
R 7806 RS1/16SS1021F
Other Resistors RS1/16SS###J
CAPACITORS
C 7801-7803 DCH1201
C 7805 CCSRCH102J50
C 7806,7807 CCSSCH200J50
C 7808 CEHVKW221M10
C 7809-7823 CKSSYF104Z16
C 7824 CEHVKW100M16
[HNM IO BLOCK(U)]
SEMICONDUCTORS
IC7851 PST596IN
IC7852 TC74LCX04FTS1
IC7853 NJM2746V
IC7854 TC7S00F
IC7855 CY2305SC-1H
IC7856 WM8728SEDS
IC7857 TC74LCX125FTS1
Q 7852-7854 2SA1586
Mark No. Description Part No. Mark No. Description Part No.
MISCELLANEOUS
L 7852-7854 LCTAWR47J2520
F 7852-7858 ATX1066
X 7851 ASS1211
CN7851 CKS3888
RESISTORS
R 7851 RS1/16SS37R4F
R 7859,7861,7875 RS1/16SS75R0F
R 7876,7886 RS1/16SS1501F
R 7877,7887 RS1/16SS6801F
R 7879,7888 RS1/16SS3301F
R 7880,7893 RS1/16SS5101F
R 7895-7897 RS1/16SS75R0F
Other Resistors RS1/16SS###J
CAPACITORS
C 7851-7858,7861,7862 CKSSYF104Z16
C 7859,7860,7881,7883 DCH1201
C 7865 CKSSYF104Z16
C 7869,7870,7873 CCSSCH470J50
C 7871,7872,7874,7876 CCSSCH220J50
C 7875 CKSSYB103K25
C 7877 CCSSCH220J50
C 7880,7884 CCSRCH102J50
C 7882,7886 CCSRCH821J50
C 7885,7887 DCH1201
C 7888-7890 CCSSCH100D50
[HNM POWER BLOCK(U)]
SEMICONDUCTORS
IC7901 LM2664M6X
IC7902 NJM2846DL3-25
IC7903,7904 LTC3412EFE
D 7901,7902 RB051L-40
MISCELLANEOUS
L 7901 ATH1206
L 7902 ATH1207
F 7901 ATX1059
F 7902 ATL7002
CN7901 AKM1290
RESISTORS
R 7903,7909 RS1/16SS3093F
R 7904,7910 RS1/16SS1103D
R 7905,7911 RS1/16SS7502D
R 7906 RS1/16SS5763F
R 7912 RS1/16SS9312F
Other Resistors RS1/16SS###J
CAPACITORS
C 7901 CKSRYB334K10
C 7902 CKSQYF475Z10
C 7903,7906 BCG1059
C 7904 CCSRCH471J50
C 7905,7907,7908 CCSRCH102J50
C 7909 CEHVKW101M6R3
C 7910,7914,7917,7920 CKSSYF104Z16
C 7911,7918 CCSSCH101J50
C 7912,7919 BCG1050
C 7913,7915,7916 DCH1201

10
A
B
C
D
1234
1234
PRO-507PU
2. BLOCK DIAGRAM AND SCHEMATIC DIAGRAM
2.1 OVERALL WIRING DIAGRAM
AWV2310- (ELITE)
AWW1153 (ELITE)
AWV2310-
AWW1155
AWV2313- (REGULAR)
AWW1156
(REGULAR)
AWV2313-
AWW1157

11
A
B
C
D
5678
5678
PRO-507PU
(ELITE)
AWV2310-
AWW1158
for AWV2311-B
for AWV2311-A
(REGULAR)
AWV2313-
AWW1154

12
A
B
C
D
1234
1234
PRO-507PU
2.2 HNM BLOCK DIAGRAM
•HNM Ass'y Block Diagram
Connector to outside of the ass'y Host controll signal Other digital signal
Power supply block
Ethernet block
DDR block
USB block
8620 block
I/O block
PCI clock
block
IC xxxx
IC7701
EDD2516AKTA-6B
[DDR-SDRAM (256Mbit)]
IC7703
AGC1027-A-PI
(S29GL128N90TFIR2)
[Flash Memory (128Mbit)]
IC7702
EDD2516AKTA-6B
[DDR-SDRAM (256Mbit)]
Connector to Main Ass'y
+5V for USB Bus-power
+5V for Power supply
Memory bus
Peripheral bus
PCI bus
PCI clock
X7851
ASS1211-
[33MHz OSC]
IC7855
CY2305SC-1H
[Clock Buffer]
L7801
ATH7015-
[C. mode filter]
IC7803
R5520H001B
[USB High-side
Switch]
to USB Receptacle Connector
USB Differencial
signal
+5V
IC7753
BR93L46RFJ-W
[EEPROM (1kbit)]
IC7751
TC74LCX125
[3-state Buffer]
TxRx
Tx / Rx
IC7857
TC74LCX125
[3-state Buffer]
Reset Reset
Reset
Reset
IC7851
PST596IN
[Reset IC]
IC7852
TC7S00F
[NAND] IC7852
TC74LCX04
[Inverter]
Reset
+3.3V +2.5V -5.0V+1.2V+5.0V
IC7902
NJM2846DL3-25
[Regulator IC]
IC7903
LTC3412EFE
[SW Reg. IC]
IC7904
LTC3412EFE
[SW Reg. IC]
RJ-45 Ethernet Connector
IC7801
VT6212L-G
[USB Controller]
IC7754
RTL8100CL-LF
[Ethernet Controller]
IC7601
EM8620L-LFC
[Digital Media Processor]
27MHz
X'tal
24MHz
X'tal
25MHz
X'tal
* Or, a wire is soldered
directly to IC7803.
IC7901
LM2664M6X
[Converter IC]
CN7901
CN7851
*CN7802
CN7801 JA7752
AKP1307-
CN (JA) xxxx
xx MHz
X'tal
Classification of each component
IC, memory, regulator and so on
X'tal or oscillator Power supply
Differential signal Bus signal

13
A
B
C
D
5678
5678
PRO-507PU
2.3 CONNECTOR PIN DESCRIPTION
HNM Ass'y MTB MAIN Ass'y
[HN1] CN7851 [M14] CN4017
pin pin name I/O description voltage (V) pin
1 TXD_DLNA I UART signal with Main ass'y, Main => HNM +3.3 / 0 1
2 RXD_DLNA O UART signal with Main ass'y, HNM => Main +3.3 / 0 2
3 RST_DLNA I Reset signal for HNM ass'y, Active low +3.3 / 0 3
• •
20 20
HNM Ass'y MTB MAIN Ass'y
[HN2] CN7901 [M15] CN4016
pin pin name I/O description voltage (V) pin
1 +5V I+5V power supply +5.0 1
2 N.C. - No use in this model - 2
3 GND - 0 3
4 GND - 0 4
HNM Ass'y USB cable
[HN3] CN7801
pin pin name I/O description voltage (V)
1 +5V O+5V for USB bus-power +5.0
2D- I/O USB differential signal minus +3.3 / 0
3D+ I/O USB differential signal plus +3.3 / 0
4 GND - 0
5 Sheild - 0
HNM Ass'y MTB MAIN Ass'y
[HN7] CN7802* CN4011
pin pin name I/O description voltage (V) pin
1 N.C. - No connection in this ass'y - 1
2 +5.1V I +5V for USB bus-power +5.1 2
3 N.C. - - 3
* CN7802 connector exists only in AWV2311-B.
For AWV2311-A, a wire is directl
y
soldered to 4th pin of IC7803.
•Voltage at each connecter.

14
A
B
C
D
1234
1234
PRO-507PU
2.4 HN MODULE ASSY (1/6)
•8620 BLOCK
HN MODULE ASSY (1/6)
1/2
2/2
1/2
Large size
SCH diagram

15
A
B
C
D
5678
5678
PRO-507PU

16
A
B
C
D
1234
1234
PRO-507PU
•8620 BLOCK
HN MODULE ASSY
(1/6)
1/2
2/2
2/2
Large size
SCH diagram

17
A
B
C
D
5678
5678
PRO-507PU

18
A
B
C
D
1234
1234
PRO-507PU
2.5 HN MODULE ASSY (2/6)
•86220 DDR BLOCK
HN MODULE ASSY (2/6)

19
A
B
C
D
5678
5678
PRO-507PU

20
A
B
C
D
1234
1234
PRO-507PU
2.6 HN MODULE ASSY (3/6)
•ETHERNET BLOCK
HN MODULE ASSY (3/6)
