Pioneer Elite PRO-730HDI User manual

ORDER NO.
PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2003
PRO-730HDI
ARP3183
HDTV PROJECTION MONITOR
PRO-730HDI
PRO-530HDI
THIS MANUAL IS APPLICABLETOTHE FOLLOWING MODEL(S) ANDTYPE(S).
This service manual should be used together with the following manual(s).
•Parts of the exploded views are all mentioned in this manual.
•The electrical parts are mentioned by contrast table in this manual.
(Refer to“3. Contrast of miscellaneous parts.”)
Model Type Power Requirement Remarks
PRO-730HDI KUXC/CA AC120V
PRO-530HDI KUXC/CA AC120V
Model No. Order No. Remarks
PRO-730HD, PRO530HD ARP3138 SAFETY INFORMATION, SPECIFICATIONS, EXPLODED VIEWS AND
PARTS LIST , BLOCK DIAGRAM AND SCHEMATIC DIAGRAM,
PCB CONNECTION DIAGRAM, PCB PARTS LIST
ARP3139 ADJUSTMENT, DIAGNOSIS, IC, EXPLANATION, PANEL FACILITIES etc.
For details, refer to "Important symbols for good services".
T-ZZY OCT. 2003 printed in Japan

PRO-730HDI
2
1234
1234
C
D
F
A
B
E
SAFETY INFORMATION
WARNING
This product contains lead in solder and certain electrical parts contain chemicals which are known to the state of California to
cause cancer, birth defects or other reproductive harm. Health & Safety Code Section 25249.6 - Proposition 65
NOTICE
(FOR CANADIAN MODEL ONLY)
Fuse symbols (fast operating fuse) and/or (slow operating fuse) on PCB indicate that replacement parts must
be of identical designation.
REMARQUE
(POUR MODÈLE CANADIEN SEULEMENT)
Les symboles de fusible (fusible de type rapide) et/ou (fusible de type lent) sur CCI indiquent que les pièces
de remplacement doivent avoir la même désignation.
This service manual is intended for qualified service technicians ; it is not meant for the casual do-it-
yourselfer. Qualified technicians have the necessary test equipment and tools, and have been trained
to properly and safely repair complex products such as those covered by this manual.
Improperly performed repairs can adversely affect the safety and reliability of the product and may
void the warranty. If you are not qualified to perform the repair of this product properly and safely, you
should not risk trying to do so and refer the repair to a qualified service technician.
1. SAFETY PRECAUTIONS
NOTICE : Comply with all cautions and safety related notes
located on or inside the cabinet and on the chassis or
picture tube.
The following precautions should be observed :
1. Do not install, remove, or handle the picture tube in any manner
unless shatterproof goggles are worn.
People not so equipped should be kept away while picture tubes
are handled.
Keep picture tube away from the while handling.
2. When service is required, even though the HDTV PROJECTION
MONITOR an isolation transformer should be inserted between
power line and the set in safety before any service is performed.
3. When replacing a chassis in the set, all the protective devices
must be put back in place, such as barriers, nonmetallic knobs,
adjustment and compartment covershields, isolation resistor-
capacitor, etc.
4. When service is required, observe the original lead dress. Extra
precaution should be taken to assure correct lead dress in the
high voltage circuitry area.
5. Always use the manufacture's replacement components.
Especially critical components as indicated on the circuit
diagram should not be replaced by other manufacture's.
Furthermore where a short circuit has occurred, replace those
components that indicate evidence of overheating.
6. Before returning a serviced set to the customer, the service
technician must thoroughly test the unit to be certain that it is
completely safe to operate without danger of electrical shock,
and be sure that no protective device built into the set by the
manufacture has become defective, or inadvertently defeated
during servicing.
Therefore, the following checks should be performed for the
continued protection of the customer and service technician.
Leakage Current Cold Check
With the AC plug removed from the 120V AC 60Hz source, place
a jumper across the two plug prongs. Turn the AC power switch
on. Using an insulation tester (DC 500V), connect one lead to the
jumpered AC plug and touch the other lead to each exposed metal
part (input/output terminals, screwheads, metal overlays, control
shafts, etc.), particularly any exposed metal part having a return
path to the chassis should have a minimum resistor reading of
0.3MΩand a maximum resistor reading of 5MΩ. Any resistor
value below or above this range indicates an abnormality which
requires corrective action. Exposed metal parts not having a return
path to the chassis will indicate an open circuit.

PRO-730HDI 3
5678
5678
C
D
F
A
B
E
Leakage
current
tester
Reading should
not be above
0.5 mA
Device
under
test
Test all
exposed metal
surfaces
Also test with
plug reversed
(Using AC adapter
plug as required)
Earth
ground
AC Leakage Test
Leakage Current Hot Check
Plug the AC line cord directly into a 120V AC 60Hz outlet (do not
use an isolation transformer for this check). Turn the AC power
switch on.
Using a "Leakage Current Tester (Simpson Model 229 equivalent)",
measure for current from all exposed metal parts of the cabinet
(input/output terminals, screwheads, metal overlays, control shaft,
etc.), particularly any exposed metal part having a return path to
the chassis, to a known earth ground (water pipe, conduit, etc.).
Any current measured must not exceed 0.5mA.
ANY MEASUREMENTS NOTWITHINTHE LIMITS
OUTLINED ABOVE ARE INDICATIVE OF A POTENTIAL
SHOCK HAZARD AND MUST BE CORRECTED BEFORE
RETURNINGTHE SETTOTHE CUSTOMER.
HighVoltage
This set is provided with a X-ray protection for clearly indicating
that voltage has increased in excess of a predetermined value.
Comply with all notes described in this Service Manual regarding
this hold down circuit when servicing, so that this X-ray protection
may correctly be operated.
Serviceman Warning
In the status of the black picture (video muting is being applied)
when no signal is input, high voltage of this set during operation is
less than 30.5kV. In case any component having some relation to
the high voltage is replaced, confirm that the high voltage is lower
than 30.5kV in the status of the black picture when no signal is
input.
To measure H. V. use a high impedance H. V. meter.
Connect (–) to earth and (+) to the FBT anode cable connector.
(Refer to section "7.1.2 DISASSEMBLY".)
X-radiation
TUBE : The primary source of X-radiation in this set is the picture
tube.
For continued X-radiation protection, the replacement tube must be
the same type as the original, PIONEER approved type.
The picture tube (CRT Service Assy R, G, B) used in this set holds
complete guarantee against X-ray radiation when the X-ray is
sealed (next page ).Accordingly, when the current in flowing to the
picture tube (CRT Service Assy R, G, B), be sure to perform it by
putting the tube into X-ray sealed applied state. Avoid absolutely to
flow the current to the picture tube (CRT Service Assy R, G, B)
itself. Moreover, when the voltage of the high voltage circuit
becomes abnormally a little higher, the picture tube radiates X-rays.
Accordingly, when servicing the high voltage circuit be sure to
replace as an assy with the POWER SUPPLY Assy in the manner
in which has been adjusted to perform normal operation.
Many electrical and mechanical parts in PIONEER set have special
safety related characteristics. These are often not evident from
visual inspection nor the protection afforded by them necessarily
can be obtained by using replacement components rated for higher
voltage, wattage, etc. Replacement parts which have these special
safety characteristics are identified in this Service Manual.
Electrical components having such features are identified by
marking with a >on the schematics and on the parts list in this
Service Manual.
The use of a substitute replacement component which dose not
have the same safety characteristics as the PIONEER
recommended replacement one, shown in the parts list in this
Service Manual, may create shock, fire, X-radiation, or other
hazards.
Product Safety is continuously under review and new instructions
are issued from time to time. For the latest information, always
consult the current PIONEER Service Manual. A subscription to, or
additional copies of, PIONEER Service Manual may be obtained at
a nominal charge from PIONEER.
1.2 PRODUCT SAFETY NOTICE

PRO-730HDI
4
1234
1234
C
D
F
A
B
E
3. CHARGED SECTION, HIGH VOLTAGE GENERATING POINT AND X-RAY
PROTECTION
The circuit in which the commercial AC power is used as it is
without passing through the power supply transformer.
If the charged section is touched, there is a risk of electric
shock. In addition, the measuring equipment can be
damaged if it is connected to the GND of the charged section
and the GND of the non-charged section while connecting
the set directly to the commercial AC power supply, In this
case, be sure to connect the set via an insulated transformer
and supply the current.
1. AC Power Cord
2. The primary side of the POWER SUPPLY Assy
3. POWER SW Assy
Charged section High Voltage generating point
X-ray protection
Charged section
(Power supply primary side)
The place where voltage of over 100V is generated.
1. Charged section
2. DEFLECTION Service Assy
(including FBT)......................(30.5kV, 1.2kV, 210V, 120V)
3. POWER SUPPLY Assy...........................................(120V)
4. R CRT DRIVEAssy....................................(10.5kV, 210V)
5. G CRT DRIVEAssy....................................(10.5kV, 210V)
6. B CRT DRIVEAssy....................................(10.5kV, 210V)
7. CRT Service Assy R.............................................(30.5kV)
8. CRT Service Assy G.............................................(30.5kV)
9. CRT Service Assy B.............................................(30.5kV)
10. Focus VR (VR1)...................................................(10.5kV)
11. Deflection Yokes (L1, L2 and L3)
..............Approx. (1100V at peak)
12. HV Distributor(Anode) .........................................(30.5kV)
• Regarding the parts which are relative to radiation of X-rays
(There is the danger to radiate X-ray from the individual
CRT Service Assy R, G, B), there are notifications of
caution in the individual schematic diagrams. Be sure to
read them for safety's sake.
• The component parts for X-ray protection are as follows:
When the current flows to the CRT Service Assy R, G, B,
be sure to perform it with these parts being attached.
Protection from the X-ray radiation is maintained in the
state in which these parts have been installed to the CRT
Service Assy R, G, B. Accordingly, never supply current
only to the CRT Service Assy R, G, B.
Moreover, the anode voltage of the CRT ServiceAssy R, G,
B should always be kept not higher than the predetermined
value (in the minimum brightness and picture state when
non signal input is less than 30.5kV). Be sure to drive the
CRT Service Assy R, G, B by using a completely functional
Deflection Service Assy (including FBT) which have been
adjusted completely in the combined state. (When the
voltage abnormally becomes high, the X-ray protection
circuit will operate.)
1. CRT ServiceAssy R, G, B (Do not dismantle CRT
assemblies under any circumstances).
2. Each Lens Assy
: Part is charged section.
: Part is the high voltage generating points other than the
charged section.
AC Power Cord
POWER SUPPLY
Assy
DEFLECTION
SERVICE Assy FBT
HV Distributor
POWER SW
Assy
Focus VR
(VR1)
Fig.1 Carged Section and High Voltage Generation Point
Each Lens Assy
CRT Service Assy R, G, B
Fig.2 Component parts for X-ray protection
B CRT
DRIVE Assy
CRT SERVICE
Assy B CRT SERVICE Assy G CRT SERVICE Assy R
G CRT
DRIVE Assy R CRT DRIVE Assy
Deflection
Yoke (L1) Deflection
Yoke (L2)
Deflection
Yoke (L3)

PRO-730HDI 5
5678
5678
C
D
F
A
B
E
[ Important symbols for good services ]
In this manual, the symbols shown-below indicate that adjustments, settings or cleaning should be made securely.
When you find the procedures bearing any of the symbols, be sure to fulfill them:
2. Adjustments
To keep the original performances of the product, optimum adjustments or specification confirmation is indispensable.
In accordance with the procedures or instructions described in this manual, adjustments should be performed.
3. Cleaning
For optical pickups, tape-deck heads, lenses and mirrors used in projection monitors, and other parts requiring cleaning,
proper cleaning should be performed to restore their performances.
5. Lubricants, glues, and replacement parts
Appropriately applying grease or glue can maintain the product performances. But improper lubrication or applying
glue may lead to failures or troubles in the product. By following the instructions in this manual, be sure to apply the
prescribed grease or glue to proper portions by the appropriate amount.For replacement parts or tools, the prescribed
ones should be used.
4. Shipping mode and shipping screws
To protect the product from damages or failures that may be caused during transit, the shipping mode should be set or
the shipping screws should be installed before shipping out in accordance with this manual, if necessary.
1. Product safety
You should conform to the regulations governing the product (safety, radio and noise, and other regulations), and
should keep the safety during servicing by following the safety instructions described in this manual.

PRO-730HDI
6
1234
1234
C
D
F
A
B
E
CONTENTS
SAFETY INFORMATION.....................................................................................................................................2
1. SPECIFICATIONS ............................................................................................................................................7
2. EXPLODED VIEWS AND PARTS LIST............................................................................................................8
2.1 PACKING ...................................................................................................................................................8
2.2 FRONT SECTION (1) ..............................................................................................................................10
2.3 FRONT SECTION (2) ..............................................................................................................................12
2.4 MIRROR SECTION..................................................................................................................................14
2.5 SCREEN SECTION.................................................................................................................................16
2.6 CRT SECTION.........................................................................................................................................18
2.7 REAR SECTION......................................................................................................................................20
2.8 CHASSIS SECTION ................................................................................................................................22
2.9 REAR PANEL SECTION..........................................................................................................................24
2.10 HDMI SECTION.....................................................................................................................................26
3. CONTRAST OF MISCELLANEOUS PARTS..................................................................................................27
4. BLOCK DIAGRAM AND SCHEMATIC DIAGRAM..........................................................................................28
4.1 BLOCK DIAGRAM...................................................................................................................................28
4.1.1 VIDEO BLOCK .................................................................................................................................. 28
4.1.2 CONTROL BLOCK............................................................................................................................30
4.1.3 AUDIO BLOCK .................................................................................................................................. 32
4.1.4 TUNER, SIGNAL and HDMI SERVICE ASSYS ................................................................................34
4.1.5 VIDEO UCOM and R,G,B CRT DRIVE ASSYS.................................................................................35
4.1.6 DEFLECTION SERVICE ASSY......................................................................................................... 36
4.1.7 DIGITAL CONV. and POWER SUPPLY ASSYS................................................................................37
4.2 OVERALL CONNECTION DIAGRAM...................................................................................................... 38
4.3 CONNECTOR PIN NAMES AND VOLTAGES..........................................................................................40
4.4 LED RLS ASSY .......................................................................................................................................41
4.5 HDMI SERVICE ASSY (1/2) .................................................................................................................... 42
4.6 HDMI SERVICE ASSY (2/2) .................................................................................................................... 44
4.7 VIDEO UCOM SERVICE ASSY (1/5) ......................................................................................................48
4.8 VIDEO UCOM SERVICE ASSY (2/5) ......................................................................................................50
4.9 VIDEO UCOM SERVICE ASSY (3/5) ......................................................................................................54
4.10 VIDEO UCOM SERVICE ASSY (4/5) ....................................................................................................58
4.11 VIDEO UCOM SERVICE ASSY (5/5) ....................................................................................................60
4.12 POWER SUPPLY ASSY (1/3)................................................................................................................62
4.13 POWER SUPPLY ASSY (2/3)................................................................................................................64
4.14 POWER SUPPLY ASSY (3/3)................................................................................................................66
5. PCB CONNECTION DIAGRAM .....................................................................................................................70
5.1 LED RLS ASSY .......................................................................................................................................71
5.2 HDMI SERVICE ASSY............................................................................................................................. 72
5.3 VIDEO UCOM SERVICE ASSY...............................................................................................................74
5.4 POWER SUPPLY and POWER SW ASSYS............................................................................................ 78
6. PCB PARTS LIST ...........................................................................................................................................84
7. ADJUSTMENT ............................................................................................................................................... 91
7.1 INTRODUCTION......................................................................................................................................91
7.2 JIGS AND MEASURING INSTRUMENTS...............................................................................................91
7.3 ADJUSTMENT LOCATION AND ITEMS .................................................................................................92
7.4 About flashing of LED ..............................................................................................................................94
7.5 About the ISF Modes ...............................................................................................................................95
7.6 FACTORY ADJ MODE.............................................................................................................................96
7.7 ADJUSTMENT.........................................................................................................................................98
8. GENERAL INFORMATION...........................................................................................................................116
8.1 DIAGNOSIS........................................................................................................................................... 116
8.1.1 DIAGNOSIS METHOD.................................................................................................................... 116
8.1.2 DISASSEMBLY................................................................................................................................120
8.1.3 WIRING DIAGRAM..........................................................................................................................124
8.1.4 ABOUT THE SERVICE (RS232C) PORT........................................................................................126
8.2 IC INFORMATION..................................................................................................................................127

PRO-730HDI 7
5678
5678
C
D
F
A
B
E
1. SPECIFICATIONS
Display and amplifier section
Reception system American TV standard NTSC system
Screen size ............................................64" (PRO-730HDI)
53" (PRO-530HDI)
CRT ................................................ 7" High focus CRT x 3
Brightness (White peak) 360 Foot-Lambert (PRO-730HDI)
450 Foot-Lambert (PRO-530HDI)
[White window signal input contrast Max.]
without protective screen
Horizontal resolution More than 1400 lines (PRO730HDI)
More than 1150 lines (PRO-530HDI)
[Input digital test pattern (1400 lines resolution)]
Input terminals ..............................................4 video inputs
4 S-VIDEO input jacks (Y/C separate INPUT)
2 COMPONENT VIDEO INPUT jacks (Y, PB, PR)
6 audio inputs
CENTER INPUT jack
Mini D-sub 15 pin INPUT jack (RGB)
BNC VIDEO INPUT jack
BNC COMPONENT VIDEO INPUT jack (Y, PB, PR)
2 HDMI INPUT jacks (Digital)
NOTE:
INPUT 1 video and component video input can be input to both
BNC and RCA type.
Output terminals ............................. MONITOR/TV, AUDIO
Input terminal signal ratings
Input signal
Video signal:
Composite and S-VIDEO (Y): 1.0 Vp-p (75 ohms load)
COMPONENT (Y): 1.0 Vp-p (75 ohms load)
(PB, PR): 0.7 Vp-p (75 ohms load)
*Mini D-sub 15 pin (RGB): 0.7 Vp-p (75 ohms load)
*Digital signal: 3.3V T.M.D.S, 50 ohms
Audio signal (including CENTER): 400mV rms
Input impedance ............................Video input: 75 ohms
Audio input (including CENTER): 22 kΩ
or more
Input signal polarity (Video) ........ Synchronized negative
Output terminal signal ratings
Output signal ..........Video signal: 1 Vp-p (75 ohms load)
Audio signal: 500 mV rms (100 % modulation)
Output impedance ..........................Video output: 75 ohms
Audio output: Less than 1 kilo-ohms
Effective output
Front both channels driven ............................10 W + 10 W
Built-in speaker system ......16 cm (6-5/16 in) full range x 2
* This jack cannot be used with a personal computer.
Tuner section
Circuit type ......................................Video signal detection:
PLL full synchronous detection
PLL digital synthesizer system
Audio multiplex: BTSC system
Reception channels..VHF; CH2~CH13, UHF; CH14~CH69
CATV (STANDARD, IRC or HRC)
CATV 1-125 CH
Antenna terminals ......Antenna terminal, 75 ohms UNBAL,
F-type connector (VHF, UHF MIXED)
Electrical section, miscellaneous
Power requirements .................................120 V AC, 60 Hz
Power consumption.......................... 250 W, 450 VA (CSA)
Standby power consumption........................................0.5W
External dimensions
PRO-730HDI ............1510 (W) x 1425 (H) x 709 (D) mm
59-7/16 (W) x 56-1/8 (H) x 27-15/16 (D) inch
PRO-530HDI ............1268 (W) x 1289 (H) x 640 (D) mm
49-15/16 (W) x 50-3/4 (H) x 25-3/16 (D) inch
Weight of main unit
PRO-730HDI .................................155 kg (341 lb 11 oz)
PRO-530HDI .................................. 123 kg (271 lb 3 oz)
Wireless remote control unit
Operation system ............. Infrared remote control system
Power source ....... Two DURACELL R"AA" MN1500 1.5 V
ALKALINE dry cell batteries
Dimensions ........................ 55 (W) x 26 (H) x 242 (D) mm
2-3/16 (W) x 1-1/32 (H) x 9-17/32 (H) inch
Weight ............................... 120 g (5 oz) (without batteries)
Accessories
Operating instructions .......................................................1
Warranty card ................................................................... 1
Remote control unit .......................................................... 1
DURACELLR"AA" MN1500 1.5V
Alkaline dry cell batteries ..................................................2
Side frame cover .............................................................. 2
Frame cover...................................................................... 2
Panel Frame Attaching screw (spare) .............................. 2
NOTE:
Specifications and design are subject to possible modifications
without notice due to improvements.

PRO-730HDI
8
1234
1234
C
D
F
A
B
E
2. EXPLODEDVIEWS AND PARTS LIST
2.1 PACKING
NOTES : Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
The >mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
Screws adjacent to ∞mark on the product are used for disassembly.
For the applying amount of lubricants or glue, follow the instructions in this manual.
(In the case of no amount instructions, apply as you think it appropriate.)
Parts marked by are important parts which relate in X-rays radiation.
If any of these parts need to be replaced, always replace with specified parts.
How to Attatch the Frame Cover
How to remove Frame Cover
13
14
18
27
16
15, 17
12
11 21
22
28
23
Frame Cover V Assy L
Frame Cover V
Assy L
Frame Cover V
Assy R
Frame Cover V Assy R
Frame Cover H
Frame Cover H
Flat-blade
Screw Driver
Cloth
Cloth
Frame Cover H
20
10
8
9
7
62
3
5 (PRO-730HDI Only)
4
4
1
26
19
24
29
25

PRO-730HDI 9
5678
5678
C
D
F
A
B
E
(
(1) PACKING parts List
(2) CONTRASTTABLE
PRO-730HDI/KUXC/CA and PRO-530HDI/KUXC/CA are constructed the same except for the following :
Mark No. Description Part No.
1 Under Carton See Contrast table (2)
2 Under Pad L See Contrast table (2)
3 Under Pad R See Contrast table (2)
NSP 4 Under Cushion A See Contrast table (2)
NSP 5 Under Cushion B See Contrast table (2)
6 Vinyl Sheet Under See Contrast table (2)
NSP 7 Packing Sheet Under See Contrast table (2)
NSP 8 Packing Sheet See Contrast table (2)
NSP 9 Vinyl Sheet See Contrast table (2)
10 CONV. Attention Card ARM1231
11 Panel Caution Card ARH1174
12 Upper Carton See Contrast table (2)
13 Upper Pad L See Contrast table (2)
14 Upper Pad R See Contrast table (2)
15 Frame Cover V Assy L See Contrast table (2)
16 Frame Cover H See Contrast table (2)
17 Frame Cover V Assy R See Contrast table (2)
NSP 18 Warranty Card EL ARY1122
19 Operating Instructions (English) ARB1557
20 Remote Control Unit AXD1485
21 Battery Cover AZA7424
NSP 22 Alkaline Dry Cell Battery AEX1018
(LR6, AA)
23 CU Packing Case AHC1050
NSP 24 Caution Card ARM1057
NSP 25 Wrapper Bag AHG1076
NSP 26 Literature Bag AHG1222
NSP 27 Polyethylene Bag AHG1285
28 Screw ABA1239
29 Screw ABA1226
Mark No. Description Part No.
Mark No. Symbol and Description PRO-730HDI/
KUXC/CA PRO-530HDI/ KUXC/CA
1 Under Carton (64W) AHD2995 Not used
1 Under Carton (53W) Not used AHD3048
2 Under Pad L AHA2224 AHA2255
3 Under Pad R AHA2225 AHA2256
NSP 4 Under Cushion A AHA2228 Not used
NSP 4 Under Cushion A (53W) Not used AHA2260
NSP 5 Under Cushion B AHA2229 Not used
6 Vinyl Sheet 64W Under AHG1289 Not used
6 Vinyl Sheet 60 Under Not used AHG1234
NSP 7 Packing Sheet 64W Under AHG1290 Not used
NSP 7 Packing Sheet 60L Not used AHG1235
NSP 8 Packing Sheet (60) AHG1230 Not used
NSP 8 Packing Sheet (50, 45) Not used AHG1120
NSP 9 Vinyl Sheet 64W Upper AHG1288 Not used
NSP 9 Vinyl Sheet XL Not used AHG1095
12 Upper Carton (64W) AHD3186 Not used
12 Upper Carton (53W) Not used AHD3184
13 Upper Pad L AHA2222 AHA2253
14 Upper Pad R AHA2223 AHA2254
15 Frame Cover V Assy L 64 AAP1664 Not used
15 Frame Cover V Assy L 53 Not used AAP1660
16 Frame Cover H (64W) AAP1593 Not used
16 Frame Cover H (53W) Not used AAP1614
17 Frame Cover V Assy R 64 AAP1665 Not used
17 Frame Cover V Assy R 53 Not used AAP1661

PRO-730HDI
10
1234
1234
C
D
F
A
B
E
2.2 FRONT SECTION (1)
18 7 6
5
9
2
4 3
Refer to
"2.6 CRT SECTION".
1
2
34 5
6
8
9
10
11
22
14
13
12
17
17 17 2320
2421
18
15
18
7
16
16 ×4
16 ×4
2
19

PRO-730HDI 11
5678
5678
C
D
F
A
B
E
(1) FRONT SECTION (1) parts List
(2) CONTRASTTABLE
PRO-730HDI/KUXC/CA and PRO-530HDI/KUXC/CA are constructed the same except for the following :
Mark No. Description Part No.
NSP 1 Cabinet See Contrast table (2)
2 Cone Speaker APV1021
3 HV Distributor AXW1050
4 5P HV Return Wire (J2) ADX2658
5 HV Cable (J9) ADY1064
> 6Focus Volume (VR1) ACX1097
NSP 7 VR Holder ANG1956
8 4P Housing Wire (J11) ADX2801
9 1P Lead Wire (J3) ADX2659
10 1P Lead Wire (J4) ADX2660
11 1P Lead Wire (J5) ADX2661
12 1P Lead Wire (J6) ADX2662
13 1P Lead Wire (J7) ADX2663
14 1P Lead Wire (J8) ADX2664
15 Nylon Binder AEC-093
16 Screw ABA1240
17 Screw ABZ30P120FZK
18 Screw BBZ30P080FZK
NSP 19 UL Caution Card AAX1238
NSP 20 Tray AMR3337
NSP 21 Solder Warning Label AAX2835
22 Wire Harness A (J12) ADX2817
23 Purse Lock AEC1540
NSP 24 Purse Lock S AEC1261
Mark No. Description Part No.
Mark No. Symbol and Description PRO-730HDI/
KUXC/CA PRO-530HDI/ KUXC/CA
NSP 1 Cabinet (64W) AMM3372 Not used
NSP 1 Cabinet (53W) Not used AMM3370

PRO-730HDI
12
1234
1234
C
D
F
A
B
E
2.3 FRONT SECTION (2)
(1)
Rear View
1
5
19 19
6
20
20
21
11 10
2121
22
22 30
22
22
23 2323
13
22 13
22
14 15
23 23 23
12
24 24
2424 24 16
17
18
27
27
29 2829 28 27
29 282928 27
27
27
2728 29 28 29
272928 2928
26
25 25 25 2517 17
24
(PRO-730HDI Only)
(PRO-730HDI Only)
(PRO-730HDI Only)
(PRO-730HDI
Only) (PRO-730HDI Only)
8
7
492
3
QEDG
• How to check the serial number:
Remove the grille and look at the front panel from below.
F

PRO-730HDI 13
5678
5678
C
D
F
A
B
E
(1) FRONT SECTION (2) parts List
(2) CONTRASTTABLE
PRO-730HDI/KUXC/CA and PRO-530HDI/KUXC/CA are constructed the same except for the following :
Mark No. Description Part No.
1POWER SW Assy AWZ6713
2FRONT INPUT Assy AWZ6715
3FRONT CONTROL Assy AWZ6718
4 LED RLS Assy AWZ6822
NSP 5 Switch Holder ANG2313
NSP 6 Serial Tag AAX1144
7Front Panel Assy AMB2792
8Power Knob AAD4105
NSP 9 Front Shield ANK1502
10 Axis Damper AXA1016
11 Door Assy AAN1472
12 Blind Plate AMM3222
13 Side Cover AMR3107
14 Side Panel Assy L See Contrast table (2)
15 Side Panel Assy R See Contrast table (2)
NSP 16 Bottom Rail See Contrast table (2)
17 Bottom Rail Holder ANG2289
18 Grille See Contrast table (2)
19 Screw AMZ30P060FZK
20 Screw ABZ40P080FZK
21 Screw APZ30P080FZK
22 Screw ABA1240
23 Screw ABA1249
24 Screw ABA1239
25 Screw ABA1263
26 ELITE Badge AAM1081
NSP 27 Catcher A ANZ-241
28 Screw ABA1271
29 Magic Tape AEC1394
30 Catcher F2M AEC1609
Mark No. Description Part No.
Mark No. Symbol and Description PRO-730HDI/
KUXC/CA PRO-530HDI/ KUXC/CA
14 Side Panel Assy 64L AMB2747 Not used
14 Side Panel Assy 53L Not used AMB2700
15 Side Panel Assy 64R AMB2795 Not used
15 Side Panel Assy 53R Not used AMB2793
NSP 16 Bottom Rail 64 AMM2945 Not used
NSP 16 Bottom Rail 53 Not used AMM3012
18 Grille (64W) AMM3225 Not used
18 Grille (53W) Not used AMM3223

PRO-730HDI
14
1234
1234
C
D
F
A
B
E
2.4 MIRROR SECTION
Rear View
10
10
10
10 10 10 10 10 107
5
6
12 12
44
3
2
1
2
12 12 12 12
11 11
910
10
10
810
Caution :
Be sure to remove the mirror inside the cabinet
before removing the mirror case.
If the mirror case is removed first, the mirror will
fall and likely become damaged.
A Torx driver is required to remove the No.11
screws.

PRO-730HDI 15
5678
5678
C
D
F
A
B
E
(1) MIRROR SECTION parts List
(2) CONTRASTTABLE
PRO-730HDI/KUXC/CA and PRO-530HDI/KUXC/CA are constructed the same except for the following :
Mark No. Description Part No.
1 Mirror See Contrast table (2)
2 Mirror Frame V See Contrast table (2)
3 Mirror Frame H See Contrast table (2)
4 Screen Cushion See Contrast table (2)
NSP 5 Mirror Upper Stay C ANG2006
NSP 6 Mirror Upper Stay L ANG2004
NSP 7 Mirror Upper Stay R ANG2005
NSP 8 Mirror Case Label AAX2448
9 Mirror Case (51) AME2296
10 Screw ABA1240
11 Screw PYC40T140FZB
12 Screw BYC35P160FZK
Mark No. Description Part No.
Mark No. Symbol and Description PRO-730HDI/
KUXC/CA PRO-530HDI/ KUXC/CA
1 Mirror 64W AMR3333 Not used
1 Mirror 53W Not used AMR3331
2 Mirror Frame V 64WB ANG2392 Not used
2 Mirror Frame V 53WB Not used ANG2524
3 Mirror Frame H 64WB ANG2391 Not used
3 Mirror Frame H 53WB Not used ANG2372
4 Screen Cushion 64 AEC1778 Not used
4 Screen Cushion 53 Not used AEC1831

PRO-730HDI
16
1234
1234
C
D
F
A
B
E
2.5 SCREEN SECTION
Rear View Front View
Top View
Cabinet
1/10
inch
When attaching the screen holder
to the cabinet, make the left side
basically level.
Screen Frame Assy
3
3
1
4
5
2
2
2
77
77
8
1616161616
16
16
16
16
16
1616
16
16
17
17
17
14
17
17
17 17 17 17 17 17
12 13 17 1717 17
17
17
14
17
17
15
12 13
15
15
15
11 17 17 1517 17 1517 17 151717 1417
9
9
10
10
6
6

PRO-730HDI 17
5678
5678
C
D
F
A
B
E
(1) SCREEN SECTION parts List
(2) CONTRASTTABLE
PRO-730HDI/KUXC/CAand PRO-530HDI/KUXC/CA are constructed the same except for the following :
Mark No. Description Part No.
1 Screen Holder TOP See Contrast table (2)
NSP 2 Upper Cabinet Metal ANG2000
NSP 3 Screen Side Fitting ANG1993
4Fresnel See Contrast table (2)
5 Lenticular Sheet See Contrast table (2)
6 Screw ABA1240
7 Screw ABA1189
8 AR Panel See Contrast table (2)
9Panel Frame H See Contrast table (2)
10 Panel Frame V See Contrast table (2)
11 Screen Frame Assy See Contrast table (2)
NSP 12 Under Screen Metal A ANG2003
NSP 13 Under Screen Metal B ANG2009
NSP 14 Upper Screen Metal A ANG2001
NSP 15 Upper Screen Metal B ANG2002
16 Screw ABA1226
17 Screw BYC40P160FMC
Mark No. Description Part No.
Mark No. Symbol and Description PRO-730HDI/
KUXC/CA PRO-530HDI/ KUXC/CA
1 Screen Holder TOP 64W ANG2530 Not used
1 Screen Holder TOP 53W Not used ANG2370
4Fresnel 64W AMR3330 Not used
4Fresnel 53W Not used AMR3328
5 Lenticular Sheet 64W AMR3390 Not used
5 Lenticular Sheet 53W Not used AMR3388
8 AR Panel (64W) AAK2791 Not used
8 AR Panel (53W) Not used AAK2789
9Panel Frame H (64W) AND1174 Not used
9Panel Frame H (53W) Not used AND1172
10 Panel Frame V (64W) AND1177 Not used
10 Panel Frame V (53W) Not used AND1175
11 Screen Frame Assy (64W) AAP1655 Not used
11 Screen Frame Assy (53W) Not used AAP1653

PRO-730HDI
18
1234
1234
C
D
F
A
B
E
2.6 CRT SECTION
ABC
C
B
A
Front Side
Rear Side
15
21
21
22
14 14
1
2
4
5
PRO-530HDI
Only
8
6
3
17
24
17
16
18
18 20
20
7
11
12
13
9
10
17 17
17 17
18
19
CRT Stand
(Accessory of Cabinet)
To Cabinet
21 21
21 21
23 23 23
22 22
24
RG
GB
27
27
28
28
24
25
26 26
MLK
F
27
Blue Green Red

PRO-730HDI 19
5678
5678
C
D
F
A
B
E
(1) CRT SECTION parts List
(2) CONTRASTTABLE
PRO-730HDI/KUXC/CA and PRO-530HDI/KUXC/CA are constructed the same except for the following :
Mark No. Description Part No.
1RCRT DRIVE Assy AWZ6709
2GCRT DRIVE Assy AWZ6710
3BCRT DRIVE Assy AWZ6711
4 REMOTE SENSOR Assy AWZ6717
5CRT SERVICE Assy R See Contrast table (2)
6CRT SERVICE Assy G AWY1444
7CRT SERVICE Assy B See Contrast table (2)
> 8DeflectionYoke (L1) ATL1144
> 9DeflectionYoke (L2) ATL1144
> 10 DeflectionYoke (L3) ATL1144
> 11 VM Coil (L4) ATL1146
> 12 VM Coil (L5) ATL1146
> 13 VM Coil (L6) ATL1146
14 Lens Assy See Contrast table (2)
15 Lens Assy See Contrast table (2)
>
16 1P Lead Wire (J15) ADX2505
17 Binder AEC-093
18 Cord Holder AEC1257
19 Bushing AEC1869
NSP 20 Lead Clamper M AEC1611
21 Screw ABA1168
22 Screw AMZ40P080FZK
23 Screw FBT40P120FZK
24 Screw BPZ30P080FZK
25 Screw BBZ30P080FZK
26 Screw ABZ30P120FZK
NSP 27 Purse Lock S AEC1261
28 Purse Lock AEC1540
Mark No. Description Part No.
Mark No. Symbol and Description PRO-730HDI/
KUXC/CA PRO-530HDI/ KUXC/CA
5CRT SERVICE Assy 64R AWY1448 Not used
5CRT SERVICE Assy 53R Not used AWY1443
7CRT SERVICE Assy 58B AWY1447 Not used
7CRT SERVICE Assy 53B Not used AWY1445
14 Lens Assy AMR3235 AMR3248
15 Lens Assy AMR3321 AMR3321

PRO-730HDI
20
1234
1234
C
D
F
A
B
E
2.7 REAR SECTION
Refer to
"2.10 HDMI SECTION".
8
12
13
6
5
2
5
4
5
63 6
5
5
5
7
77
4
1
910 1011 11888 8
4
Refer to
"2.8 CHASSIS SECTION".
