Pioneer Elite VSX-49TXi User manual

ORDER NO.
PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2002
STANDBY/ON
OFF ON
STANDBY
DVD/LD TV/DVD SAT VIDEO
VIDEO AUDIO
VCR VCR2 VCR3 CD TUNER PHONO
MAC3
CD-R/
TAPE1/MD
MULTICH
INPUT
LISTENING MODE SELECTOR
MASTER VOLUME
INPUT SELECTOR
VSX-49TXi
AUDIO/VIDEO MULTI-CHANNEL AMPLIFIER
UP
DOWN
VSX-49TXi
RRV2644
AUDIO/VIDEO MULTI-CHANNEL RECEIVER
VSX-49TXi
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
Model Type Power Requirement Remarks
VSX-49TXI KU/CA AC120V
For details, refer to "Important symbols for good services" .
T-ZZR AUG. 2002 printed in Japan

VSX-49TXi
2
1234
1234
C
D
F
A
B
E
SAFETY INFORMATION
This service manual is intended for qualified service technicians ; it is not meant for the casual do-it
-
yourselfer. Qualified technicians have the necessary test equipment and tools, and have been traine
d
to properly and safely repair complex products such as those covered by this manual.
Improperly performed repairs can adversely affect the safety and reliability of the product and ma
y
void the warranty. If you are not qualified to perform the repair of this product properly and safely, yo
u
should not risk trying to do so and refer the repair to a qualified service technician.
WARNING
This product contains lead in solder and certain electrical parts contain chemicals which are knownto the state of California to cause
cancer, birth defects or other reproductive harm.
Health & Safety Code Section 25249.6 – Proposition 65
NOTICE
(FOR CANADIAN MODEL ONLY)
Fuse symbols (fast operating fuse) and/or (slow operating fuse) on PCB indicate that replacement parts must
be of identical designation.
REMARQUE
(POUR MODÈLE CANADIEN SEULEMENT)
Les symboles de fusible (fusible de type rapide) et/ou (fusible de type lent) sur CCI indiquent que les pièces
de remplacement doivent avoir la même désignation.
ANY MEASUREMENTS NOT WITHIN THE LIMITS
OUTLINED ABOVE ARE INDICATIVE OF A POTENTIAL
SHOCK HAZARD AND MUST BE CORRECTED BEFORE
RETURNING THE APPLIANCE TO THE CUSTOMER.
2. PRODUCT SAFETY NOTICE
Many electrical and mechanical parts in the appliance
have special safety related characteristics. These are
often not evident from visual inspection nor the protection
afforded by them necessarily can be obtained by using
replacement components rated for voltage, wattage, etc.
Replacement parts which have these special safety
characteristics are identified in this Service Manual.
Electrical components having such features are identified
by marking with a on the schematics and on the parts list
in this Service Manual.
The use of a substitute replacement component which does
not have the same safety characteristics as the PIONEER
recommended replacement one, shown in the parts list in
this Service Manual, may create shock, fire, or other hazards.
Product Safety is continuously under review and new
instructions are issued from time to time. For the latest
information, always consult the current PIONEER Service
Manual. A subscription to, or additional copies of, PIONEER
Service Manual may be obtained at a nominal charge from
PIONEER.
1. SAFETY PRECAUTIONS
The following check should be performed for the
continued protection of the customer and service
technician.
LEAKAGE CURRENT CHECK
Measure leakage current to a known earth ground (water
pipe, conduit, etc.) by connecting a leakage current tester
such as Simpson Model 229-2 or equivalent between the
earth ground and all exposed metal parts of the appliance
(input/output terminals, screwheads, metal overlays, control
shaft, etc.). Plug the AC line cord of the appliance directly
into a 120V AC 60Hz outlet and turn the AC power switch
on. Any current measured must not exceed 0.5mA.
(FOR USA MODEL ONLY)
Leakage
current
tester
Reading should
not be above
0.5mA
Device
under
test
Test all
exposed metal
surfaces
Also test with
plug reversed
(Using AC adapter
plug as required)
Earth
ground
AC Leakage Test

VSX-49TXi 3
5678
5678
C
D
F
A
B
E
[ Important symbols for good services ]
In this manual, the symbols shown-below indicate that adjustments, settings or cleaning should be made securely.
When you find the procedures bearing any of the symbols, be sure to fulfill them:
2. Adjustments
To keep the original performances of the product, optimum adjustments or specification confirmation is indispensable.
In accordance with the procedures or instructions described in this manual, adjustments should be performed.
3. Cleaning
For optical pickups, tape-deck heads, lenses and mirrors used in projection monitors, and other parts requiring cleaning,
proper cleaning should be performed to restore their performances.
5. Lubricants, glues, and replacement parts
Appropriately applying grease or glue can maintain the product performances. But improper lubrication or applying
glue may lead to failures or troubles in the product. By following the instructions in this manual, be sure to apply the
prescribed grease or glue to proper portions by the appropriate amount.For replacement parts or tools, the prescribed
ones should be used.
4. Shipping mode and shipping screws
To protect the product from damages or failures that may be caused during transit, the shipping mode should be set or
the shipping screws should be installed before shipping out in accordance with this manual, if necessary.
1. Product safety
You should conform to the regulations governing the product (safety, radio and noise, and other regulations), and
should keep the safety during servicing by following the safety instructions described in this manual.

VSX-49TXi
4
1234
1234
C
D
F
A
B
E
CONTENTS
SAFETY INFORMATION..................................................................................................................................... 2
1. SPECIFICATIONS ............................................................................................................................................ 6
2. EXPLODED VIEWS AND PARTS LIST ............................................................................................................ 8
2.1 PACKING ................................................................................................................................................... 8
2.2 EXTERIOR SECTION.............................................................................................................................. 10
2.3 CHASSIS SECTION ................................................................................................................................ 12
2.4 REAR PANEL SECTION.......................................................................................................................... 14
2.5 HEAT SINK SECTION.............................................................................................................................. 16
2.6 FRONT PANEL SECTION ....................................................................................................................... 18
3. BLOCK DIAGRAM AND SCHEMATIC DIAGRAM..........................................................................................20
3.1 BLOCK DIAGRAM ................................................................................................................................... 20
3.2 OVERALL WIRING DIAGRAM................................................................................................................. 28
3.3 FM/AM TUNER MODULE........................................................................................................................ 30
3.4 A/V I/O ASSY........................................................................................................................................... 32
3.5 COMPOSITE ASSY................................................................................................................................. 34
3.6 S-VIDEO ASSY........................................................................................................................................ 36
3.7 V-CONVERT ASSY.................................................................................................................................. 38
3.8 COMPONENT ASSY ............................................................................................................................... 40
3.9 VIDEO CON., MIC AMP, MIC, FRONT A/V and H.P. ASSYS .................................................................. 42
3.10 ANALOG IN & A/D ASSY(1/3) ............................................................................................................... 44
3.11 ANAALOG IN & A/D ASSY(2/3)............................................................................................................. 46
3.12 ANAALOG IN & A/D ASSY(3/3)............................................................................................................. 48
3.13 DISPLAY, INPUT SEL, MULTI JOG and VOL ASSYS ........................................................................... 50
3.14 VR & PRE OUT ASSY(1/3).................................................................................................................... 52
3.15 VR & PRE OUT ASSY(2/3).................................................................................................................... 54
3.16 VR & PRE OUT ASSY(3/3).................................................................................................................... 56
3.17 MOTHER ASSY ..................................................................................................................................... 58
3.18 DSP ASSY(1/5)...................................................................................................................................... 60
3.19 DSP ASSY(2/5)...................................................................................................................................... 62
3.20 DSP ASSY(3/5)...................................................................................................................................... 64
3.21 DSP ASSY(4/5)...................................................................................................................................... 66
3.22 DSP ASSY(5/5)...................................................................................................................................... 68
3.23 DSP3 ASSY ........................................................................................................................................... 70
3.24 DAC10 ASSY(1/2).................................................................................................................................. 72
3.25 DAC10 ASSY(2/2).................................................................................................................................. 74
3.26 POWER AMP(L) and POWER AMP(C) ASSYS .................................................................................... 76
3.27 POWER AMP(R), POWER AMP(BR) and POWER AMP(G) ASSYS.................................................... 78
3.28 LOCAL SUPPLY ASSY.......................................................................................................................... 80
3.29 AC PRIMARY, POWER SW, SP(A), FL SUPPLY and STANDBY ASSYS ............................................. 82
3.31 1394 MODULE(1/2) ASSY..................................................................................................................... 86
3.32 1394 MODULE(2/2) ASSY..................................................................................................................... 88
4. PCB CONNECTION DIAGRAM ..................................................................................................................... 90
4.1 FM/AM TUNER MODULE........................................................................................................................ 91
4.2 A/V I/O ASSY........................................................................................................................................... 92
4.3 COMPOSITE ASSY................................................................................................................................. 93
4.4 S-VIDEO ASSY........................................................................................................................................ 94
4.5 V-CONVERT ASSY.................................................................................................................................. 95
4.6 COMPONENT ASSY ............................................................................................................................... 96
4.7 VIDEO CONNECT ASSY......................................................................................................................... 97
4.8 MIC AMP, MIC, FRONT A/V and HEADPHONE ASSYS......................................................................... 98
4.9 ANALOG IN & A/D ASSY ...................................................................................................................... 100
4.10 DISPLAY, INPUT SEL, MULTI JOG, FL SUP. and STANDBY ASSYS ................................................. 102
4.11 VR & PRE OUT ASSY ......................................................................................................................... 106
4.12 MOTHER ASSY ................................................................................................................................... 108
4.13 DSP ASSY ........................................................................................................................................... 112
4.14 DAC10 ASSY ....................................................................................................................................... 114
4.15 DSP3 ASSY ......................................................................................................................................... 116
4.16 POWER AMP(L) and POSISTER(L) ASSYS....................................................................................... 117
4.17 POWER AMP(R) and POSISTER(R) ASSYS...................................................................................... 119
4.18 POWER AMP(C), POWER AMP(BR) and POWER AMP(G) ASSYS.................................................. 121
4.19 LOCAL SUPPLY and DSP DIODE ASSYS.......................................................................................... 122
4.20 AC PRIMARY, POWER SW and SP(A) ASSYS................................................................................... 124
4.21 TRANS(A), TRANS(B), DIODE and FUSE ASSYS ............................................................................. 126
4.22 SP(B) ASSY......................................................................................................................................... 127
4.23 1394 MODULE ASSY .......................................................................................................................... 128

VSX-49TXi 5
5678
5678
C
D
F
A
B
E
5. PCB PARTS LIST..........................................................................................................................................129
6. ADJUSTMENT ..............................................................................................................................................143
7. GENERAL INFORMATION ...........................................................................................................................144
7.1 DIAGNOSIS............................................................................................................................................144
7.1.1 Teat mode.........................................................................................................................................144
7.1.2 Disassembly.....................................................................................................................................148
7.2 PARTS ....................................................................................................................................................152
7.2.1 IC......................................................................................................................................................152
7.2.2 DISPLAY ..........................................................................................................................................160
7.3 REMOTE CONTROL UNIT.....................................................................................................................162
7.3.1 EXPLODED VIEWS and PARTS LIST .............................................................................................162
7.3.2 Remote SCH ....................................................................................................................................164
7.3.3 Remote PCB Diagram......................................................................................................................166
7.3.4 Remote PARTS List..........................................................................................................................168
8. PANEL FACILITIES .......................................................................................................................................169

VSX-49TXi
6
1234
1234
C
D
F
A
B
E
1. SPECIFICATIONS
Amplifier Section
Continuous average power output of
160 watts* per channel, min., at 6
ohms, from 20 Hz to 20,000 Hz with no
more than 0.09 %** total harmonic
distortion (front).
Continuous Power Output (6 Ω)
Front ........ 160 W + 160 W (20 Hz-20 kHz, 0.09 %, 6 Ω)
Center .................... 160 W (20 Hz-20 kHz, 0.09 %, 6 Ω)
Surround ...... 160 W + 160 W (20 Hz-20 kHz, 0.09 %, 6 Ω)
Surr. back ..... 160 W + 160 W (20 Hz-20 kHz, 0.09 %, 6 Ω)
Continuous Power Output (8 Ω)
Front ........ 130 W + 130 W (20 Hz-20 kHz, 0.09 %, 8 Ω)
Center .................... 130 W (20 Hz-20 kHz, 0.09 %, 8 Ω)
Surround ........... 130 W + 130 W (20 Hz-20 kHz, 0.09 %, 8 Ω)
Surr. back .......... 130 W + 130 W (20 Hz-20 kHz, 0.09 %, 8 Ω)
Audio Section
Input (Sensitivity/Impedance)
PHONO MM .........................................4.7 mV/47 kΩ
LINE ..................................................... 382 mV/47 kΩ
Phono Overload level (T.H.D.0.1 %, 1kHz)
PHONO MM...................................................... 120 mV
Frequency Response
PHONO MM..................... 20 Hz to 20,000 Hz ±0.3 dB
LINE ....................................... 5 Hz to 100,000 Hz dB
Output (Level/Impedance)
LINE ...................................................... 382 mV/2.2 kΩ
Tone Control
BASS ..................................................... ±6 dB (100 Hz)
TREBLE ................................................. ±6 dB (10 kHz)
LOUDNESS ............................ +4/+2 dB (100Hz/10 kHz)
(at volume position -40dB)
Signal-to-Noise Ratio (IHF, short circuited, A network)
PHONO MM......................................................... 86 dB
LINE ................................................................... 105 dB
Signal-to-Noise Ratio [EIA, at 1 W (1 kHz)]
PHONO MM......................................................... 83 dB
LINE ..................................................................... 93 dB
* Measured pursuant to the Federal Trade Commission’s
Trade Regulation rule on Power Output Claims for
Amplifiers.
** Measured by Audio Spectrum Analyzer.
+0
–3
Video Section
Input (Sensitivity) .......................................... 1 Vp-p/75 Ω
Output (Level/Impedance) ............................. 1 Vp-p/75 Ω
Signal-to-Noise Ratio .............................................. 70 dB
Frequency Response ...................... 5 Hz to 10 MHz dB
Component Video Section
Input (Sensitivity) .......................................... 1 Vp-p/75 Ω
Output (Level/Impedance) ............................. 1 Vp-p/75 Ω
Signal-to-Noise Ratio .............................................. 70 dB
Frequency Response ...................... 5 Hz to 40 MHz dB
FM Tuner Section
Frequency Range ............................ 87.5 MHz to 108 MHz
Usable Sensitivity ......... Mono: 13.2 dBf, IHF (1.3 µV/75 Ω)
50 dB Quieting Sensitivity .........................Mono: 20.2 dBf
Stereo: 38.6 dBf
Signal-to-Noise Ratio ................... Mono: 73 dB (at 85 dBf)
Stereo: 70 dB (at 85 dBf)
Distortion ........................................ Stereo: 0.5 % (1 kHz)
Alternate Channel Selectivity ................... 60 dB (400 kHz)
Stereo Separation ........................................ 40 dB (1 kHz)
Frequency Response ................... 30 Hz to 15 kHz (±1) dB
Antenna Input ......................................... 75 Ωunbalanced
AM Tuner Section
Frequency Range ............................ 530 kHz to 1,700 kHz
Sensitivity (IHF, Loop antenna) ........................... 350 µV/m
Selectivity ................................................................. 25 dB
Signal-to-Noise Ratio ................................................ 50 dB
Antenna ........................................................ Loop antenna
Miscellaneous
Power Requirements ............................... AC 120 V, 60 Hz
Power Consumption ................................... 720 W, 965 VA
Power Consumption in Standby mode ................... 0.65 W
AC Outlet
SWITCHED ...................................... 100 W (0.8 A) MAX
Dimensions ..................... 440 (W) ×203 (H) ×476 (D) mm
(17-5/16 (W) ×8 (H) ×18-3/4(D) in.)
Weight (without package) ................... 29.3 kg (64 lb 6 oz)
Furnished Parts
FM wire Antenna .............................................................1
AM Loop Antenna ........................................................... 1
“AA” IEC LR6 batteries .................................................... 4
Remote Control Unit ........................................................1
Touch Pen ........................................................................ 1
Cushion for Remote .........................................................4
Microphone ......................................................................1
U-shaped connectors ....................................................... 2
Operating Instructions ......................................................1
NOTE:
Specifications and the design are subject to possible
modifications without notice, due to improv ements.
+0
–3
+0
–3
Maintenance of External Surfaces
•Use a polishing cloth or dry cloth to wipe off dust
and dirt.
•When the surfaces are dirty, wipe with a soft
cloth dipped in some neutral cleanser diluted five
or six times with water, and wrung out well, and
then wipe again with a dry cloth. Do not use
furniture wax or cleaners.
•Never use thinners, benzine, insecticide sprays
or other chemicals on or near this unit, since
these will corrode the surfaces.

VSX-49TXi 7
5678
5678
C
D
F
A
B
E
Accessories
Remote control unit
(AXD7295)
AM loop antenna
(ATB7009) FM wire antenna
(ADH7010) (APM7003)
AA siz Microphone
(ADG7061)
AC power cord
(AZA7350)
Touch pen
(AEB7167)
Cushion for Remote x4
e IEC LR6
batteries (x4)
+
VOL +
ENTER
FUNCTION
TV
CONTROL
MUTING
MASTER VOLUME
SYSTEM
OFF
MULTI
OPERATION
STANDBY/ON
–
VOL –
CH –
CH +
FUNCTION
use lock
RECEIVER
DVD/LD
VCR1
/DVR
VCR2
VCR3
TV
REMOTE
SETUP
CD-R/
TAPE1
CD
TUNER
VIDEO
SAT
TV
CONTROL
LIGHT

VSX-49TXi
8
1234
1234
C
D
F
A
B
E
2. EXPLODED VIEWS AND PARTS LIST
2.1 PACKING
Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
The mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
Screws adjacent to mark on product are used for disassembly.
For the applying amount of lubricants or glue, follow the instructions in this manual.
(In the case of no amount instructions, apply as you think it appropriate.)
NOTES:
9
8
10
7
13
14
13
2
3
Refer to " 7.3 Remote control unit Section."
5
5
VSX-49TXi
16
15
17
6
411 (2/2)
12 (2/2)
11(1/2)
12(1/2)
1

VSX-49TXi 9
5678
5678
C
D
F
A
B
E
PACKING parts List
Mark No. Description Part No.
> 1 Power Cord ADG7061
2 FM Wire Antenna ADH7010
3 AM Loop Antenna ATB7009
4 Remote Control Unit AX10KU AXD7295
5 Handle Cover AHX7034
6 Alkaline Dry Cell Battery VEM1021
(LR6, AA)
7 Operating Instructions (English) ARB7268
8 Caution Sheet SP, E ARM7056
NSP 9 Warranty Card EL ARY1026
10 Cushion for Remote AEB7167
11 Top Pad AHA7362
12 Bottom Pad AHA7363
13 Spacer AHB7057
14 Packing Case AHD8122
15 Packing Sheet DHL1022
NSP 16 Polyethylene Bag Z21-038
(0.03 x 230 x 340)
17 Microphone APM7003

VSX-49TXi
10
1234
1234
C
D
F
A
B
E
2.2 EXTERIOR SECTION
A
A
D
C
D
C
11
1
12
12
12
23
4
2
2
12
13 14
16
4
4
25
18
7
8
17
19
17 19
19
17
17 18
19
19
12
4
3
13
14
15
13
25
3
22
21
31
24
30
27
32
32
26
9
10
5
28
20
20
B
B
Refer to "2.3 CHASSIS SECTION."
Refer to "2.5 HEAT SINK SECTION."
Refer to "2.6 FRONT PANEL
SECTION."
6
9
10

VSX-49TXi 11
5678
5678
C
D
F
A
B
E
EXTERIOR SECTION parts List
Mark No. Description Part No.
NSP 1 Top Plate BK ANE7298
2 Side Alum BK AAH7095
NSP 3 Side Panel Sheet AMR7284
NSP 4 Tape PNM1249
5 UL Caution Card AAX-313
NSP 6 Energystar Label AAX7876
NSP 7 Bottom Plate B ANF7030
NSP 8 Bottom Plate A Cu ANF7029
9 Insulator Assy VXA2368
10 Screw ABA1054
11 Screw BBT30P060FCC
12 Screw FBT40P080FZK
13 Screw ABA7079
14 Screw RBA1099
15 Screw VBA1056
16 Screw ABA1011
17 Screw ABA1050
18 Screw ABA1193
19 Screw IBZ30P090FCC
20 Washer VEC1254
NSP 21 Label VRW162
22 License Label ARW7194
23 Screw BBZ30P080FCC
24 65 Label ARW7050
25 Screw BBT30P100FCC
NSP 26 ICP Caution Label ARW7151
NSP 27 Fuse Caution Label ARW7175
NSP 28 ICP Caution Label ARW7150
29 Binder ZCA-BK1
30 1394Module AXQ7243
31 Nylon Rivet AEC-525
32 Side Panel Sheet B AMR7414

VSX-49TXi
12
1234
1234
C
D
F
A
B
E
2.3 CHASSIS SECTION
D
E
E
C
B
F
F
C
E
E
B
A
A11
70
75
70
10
9
43
43
38
39
27
43
46
46
31
29
57
46 30
58
45
33
43
53
67
41
41
43
43
24
33
45
55
68
18
43
43
6
55
32
55
55
28
45
25
24
24
22
23
48
57
68
68
65
65
5
59
60
25
43
43
43
43
43
48 69
49
69
17
47
14
15
14
47
16
69
69
69 69
69 49
69 17
43 1843
46
43
45
45
43
43
43
43
61
62
43
42
66
40
53
44
1
43
44
52
51
3
4
64
12
52
13
20
2
21
19
45
53
46
26 45
27
43
7
54
35 36
50
37
65
56
63
5637
50
43
36
46
46
35
54
34
8
T
S
R
U
H
AA
AI
AL
AK
AM
AN
78
73
80 62
81
72
26
71
79
82
82
76
74
77
68
D
43
46
Refer to "2.4 REAR PANEL SECTION".
CONTACT SIDE
NON-CONTACT
SIDE

VSX-49TXi 13
5678
5678
C
D
F
A
B
E
CHASSIS SECTION parts List
Mark No. Description Part No.
1 MOTHER Assy AWX8142
2 DIODE Assy AWX7841
3 TRANS (A) Assy AWX7838
4 TRANS (B) Assy AWX8057
5 FUSE Assy AWX7843
6 MIC AMP Assy AWX7872
7 DSP DIODE Assy AWX7958
8 LOCAL SUPPLY Assy AWX7887
9 DAC10 Assy AWK7725
10 DSP Assy AWK7762
11 DSP3 Assy AWK7727
> 12 Power Transformer (T1) ATS7320
NSP 13 PCB Holder B ANG7388
14 Capacitor (C1, C2) ACH7164
15 Rubber Spacer AEB7244
NSP 16 Earth Plate ANG7381
NSP 17 Joint Plate ANG7382
NSP 18 PCB Base RNE1849
19 Trans Frame ANA7142
20 Radiation Sheet AEE7043
NSP 21 Trans Stabilizer ANG7378
NSP 22 Side Frame L AWA7133
NSP 23 Side Wall L AND7041
NSP 24 Wire Clip (A) VEC1355
NSP 25 Insulator Frame B ANG7377
26 Glass Tube ADN7006
27 Cord Holder RNH1005
28 Panel Stay AND7045
NSP 29 Fan Holder B ANG7373
NSP 30 Wire Saddle DEC1450
NSP 31 Side Wall R AND7043
NSP 32 Flat Cable Clamp AEC7376
NSP 33 Insulator Frame A ANG7376
34 Sub Heat Sink ANH7154
NSP 35 PCB Holder D ANG7392
36 Mica Sheet S AEE7042
37 Bushing 26 AEC7128
NSP 38 PCB Spacer AEC7156
NSP 39 Shield Case A ANK7093
NSP 40 Side Frame R ANA7135
NSP 41 Tape PNM1249
NSP 42 Shield Case B ANK7107
43 Screw ABA1011
NSP 44 PCB Holder C ANG7389
45 Screw BBZ30P080FCC
46 Screw IBP30P090FCC
47 Screw VBA1056
48 Screw ABA1054
49 Screw ABA1082
50 Screw ABA7076
51 Trans Label AAX7897
52 Screw ABA1014
53 Screw BBT30P060FCC
54 Screw ABA1050
55 Screw ABA1192
56 Screw ABA7084
57 Screw RBA1099
NSP 58 PCB Frame B ANG7386
> 59 Fuse (FU4, 4A) VEK1023
> 60 Fuse (FU5-FU8, 2A) VEK1019
61 J29 FFC (17P) ADD7329
(Mother CN5807-DISPLAY CN3001)
62 J30 FFC (11P) ADD7330
(Mother CN5806-MIC AMP CN3207)
63 J16 8P Connector Assy ADX7379
(Local Supply CN4001-FUSE CN1802)
64 J17 3P Connector Assy ADX7380
(Local Supply CN4002-TRANS(B) CN1701)
NSP 65 Binder ZCA-BK1
NSP 66 Card Spacer REC1156
67 PCB Holder PNW2100
68 Locking Card Spacer VEC2234
69 Screw ABA7017
70 PC Support DEC1772
71 Oval head Terminal wire ADX7366
72 J1601 5P,7P Parallel wire ADX7385
73 J5805 9P Connector Assy ADX7378
(Local Supply CN4004-Mother CN5805)
74 5802 Crimp Connector Assy PF06PP-R27
(Mother CN5827-Mother CN5828)
75 PCB Spacer VEC1508
NSP 76 Trans Frame Spacer AEC7400
> 77 Fuse (FU9-FU10, 1A) VEK1014
78 J4001 2P Connector Assy ADX7407
(Local supply CN4005-DSP CN704)
79 Washer ABE-053
80 Acetate tape AEH7017
81 Clamp DEC1759
82 Glass Tube(6x95) ADN7010
Mark No. Description Part No.

VSX-49TXi
14
1234
1234
C
D
F
A
B
E
2.4 REAR PANEL SECTION
13
28
27
19 16
16
16
14
21
17
16
16
16
18
16
23
1
15
4
19
19
22
3
5
6
7
8
9
10
11
12
19
19
2
20
A
Q
L
G
E
F
D
C
B
AJ
AD
AB
34
37
29
26
33
30
25
32
36
24
31
35
CONTACT SIDE
NON-CONTACT
SIDE

VSX-49TXi 15
5678
5678
C
D
F
A
B
E
REAR PANEL SECTION parts List
Mark No. Description Part No.
1 FM/AM Tuner Module AXQ7237
2 SP (B) Assy AWX8151
3 AC PRIMARY Assy AWX7834
4 SP (A) Assy AWX8148
5 VIDEO CONNECT Assy AWX7876
6 V-CONVERT Assy AWX8160
7 COMPONENT Assy AWX7953
8 S-VIDEO Assy AWX8159
9 COMPOSITE Assy AWX7942
10 A/V I/O Assy AWX7938
11 VR & PRE OUT Assy AWX7888
12 ANALOG IN & A/D Assy AWX7878
13 Rear Panel ANC8139
14 Screw with Terminal AKE-031
15 AC Inlet Assy ADX7395
16 Screw BBZ30P080FCC
17 Hexagonal Screw ABA7078
18 Screw ABA1193
19 Screw ABA1011
> 20 Fuse (FU1, 12A/125V) AEK-306
21 Short Pin Plug AKM7005
22 J23 FFC (14P) ADD7334
(SP(A) CN1104-Mother CN5801)
23 J22 FFC (13P) ADD7333
(Yuner CN2705-Mother CN5802)
24 Speaker Sheet 49 AAK7959
25 Cushion Circle AED7052
26 J101 3P Connector Assy D20PYY0365E
(AC Primary CN1105-Power SW CN1301)
27 J5001 8P Connector Assy ADX7382
(VR OUT CN5005
- Power AMP(BR) CN4811)
28 J5002 14P Connector Assy ADX7381
(VR OUT CN5006
- Power AMP(L) CN4801
and Power AMP(R) CN4802)
29 Binder ZCA-BK1
30 1394 Module AXQ7243
31 Fiber washer RBF1045
32 Tape AEH7015
33 Screw BCZ30P060FCC
34 Shield plate AMR7445
35 Acetate tape AEH7018
36 Shield cushion AEB7274
37 Acetate tape ZTA-156A-19

VSX-49TXi
16
1234
1234
C
D
F
A
B
E
2.5 HEAT SINK SECTION
3
1
14
15
8
15
15
12
12
12
18
10
10
11
11
10
10
10
10
19
22
22
16
17
17
17
17
13
13
16
16
16
20
19
4
5
6
14
12
18
7
9
12
12
15
15
15
2
Y
V
X
Z
W
AG
AH
21
20 21

VSX-49TXi 17
5678
5678
C
D
F
A
B
E
HEAT SINK SECTION parts List
Mark No. Description Part No.
1 POWER AMP (L) Assy AWX7882
2 POWER AMP (R) Assy AWX7883
3 POWER AMP (BR) Assy AWX7885
4 POWER AMP (C) Assy AWX7884
5 POWER AMP (G) Assy AWX7886
6 POSISTER (L) Assy AWX7844
7 POSISTER (R) Assy AWX7846
8 Heat Sink L ANH7148
9 Heat Sink R ANH7162
10 Mica Sheet L AEE7048
11 Mica Sheet M AEE7046
NSP 12 PCB Holder A ANG7387
NSP 13 Heat Sink Holder ANG7375
14 Screw ABA1011
15 Screw IBP30P090FCC
16 Screw BMZ30P060FCU
17 Screw RBA1099
18 Screw ABA7076
19 Screw ABA7083
20 Over head Terminal wire(RED) ADX7383
21 Over head Terminal wire(BLUE) ADX7384
22 Washer WA32F100M050

VSX-49TXi
18
1234
1234
C
D
F
A
B
E
2.6 FRONT PANEL SECTION
F
G
A
B
C
E
G
D
D
E
F
C
A
B
1
45
46
46
46
45
44
46
43
3
46
47
53
49
39
43
45
37
35 50
48
33
27
51
30
29
51
28
40
26
27
40
31
41 2
4
41
49
45
38
48
36
34
27
46 46
46
9
46
46
22
24
46
10
46
46
1816 46
22
24
25
23
8
46
22
24
46
23
17
11
12
13
14
49
49
15
13
49
49
14
7
54 6
21
20
52
46
5
19
42
M
J
N
O
P
K
I
AC AE
AF
66
66
60
59
58
33
55
55
55
55
55
55
62
63 56
57
61
56
57
56
23
64
65

VSX-49TXi 19
5678
5678
C
D
F
A
B
E
FRONT PANEL SECTION parts List
Mark No. Description Part No.
1 DISPLAY Assy AWX8140
2 HEADPHONE Assy AWX7874
3 FRONT A/V Assy AWX8189
4 MIC & OPT Assy AWX7875
5 STANDBY Assy AWX7901
6 POWER SW Assy AWX7840
7 FL SUPPLY Assy AWX7871
8 INPUT SEL Assy AWX7868
9 MULTI JOG Assy AWX7869
10 VOL Assy AWX7870
11 Front Panel ANB7301
12 Pioneer Badge B PAN1376
13 Rotary Knob L BK AAA7018
14 Plate ANG7198
15 Rotary Knob S BK AAA7015
16 Display Panel AAK7932
17 Panel Base L BK AMB7788
18 Panel Base R BK AMB7791
19 Power Button AAD7440
20 Power Button M AAD7442
21 Washer ABF7008
NSP 22 VR Stabilizer ANG7383
23 Cord Holder RNH-184
24 Nut NK90FCU
NSP 25 Earth Spring ABK7031
26 Door Panel BK ANB7273
NSP 27 Door Cushion AED7051
28 Door Plate AAH7077
29 FL Lens I OR AAK8069
30 Inner Panel AAH7087
31 LED Lens AAK7931
32 ••••
33 LED Lens PNW2019
34 Panel Base C BK AMB7785
NSP 35 Door Hinge L ANG7379
NSP 36 Door Hinge R ANG7380
37 Door Holder L AMR7373
38 Door Holder R AMR7374
39 Damper Assy AXA7108
40 Screw ABA7074
41 Magnet AMF7004
NSP 42 Input Holder ANG7384
NSP 43 Earth Spring ABH7208
44 Shield plate D AMR7390
45 Screw BBZ30P100FZK
46 Screw BBZ30P080FCC
47 Screw ABA7053
48 Screw BBT30P060FCC
49 Screw ABA1050
50 Screw BBZ20P060FMC
51 Screw ABA7076
52 J33 FFC (3P) ADD7331
(DISPLAY CN3002-STANDBY CN1903)
53 J35 FFC (4P) ADD7332
(SP(A) CN1206-HEADPHONE CN3203)
54 J1101 Parallel Wire 3P D20PYY0365E
(POWER SW CN1301-AC PRIMARY CN1105)
55 Fiber Washer VEC1254
NSP 56 Earth Metal Fitting DE007VC0
NSP 57 Earth Metal Fitting DE012VF0
58 J32 8P Connector Assy ADX7390
(Front A/V CN3204-MIC AMP CN3206)
59 J99 4P Connector Assy ADX7421
(MIC & OPT CN3202-MIC AMP CN3205)
60 J31 5P Connector Assy ADX7386
(MIC & OPT CN3201-Mother CN5804)
61 J1801 4P Connector Assy ADX7377
(FL Supply CN1901-FUSE CN1803)
NSP 62 Panel spacer left L AMR7411
NSP 63 Panel spacer left S AMR7408
NSP 64 Panel spacer right L AMR7412
NSP 65 Panel spacer right S AMR7409
66 Fiber washer AEC7403
Mark No. Description Part No.

VSX-49TXi
20
1234
1234
C
D
F
A
B
E
3. BLOCK DIAGRAM AND SCHEMATIC DIAGRAM
3.1 BLOCK DIAGRAM
AFM/AM TUNER
MODULE
RMOTHER
ASSY(1/5)
LANALOG IN &
A/D ASSY
R
MOTHER
ASSY(2/5)
R
MOTHER
ASSY(3/5)
R
MOTHER
ASSY(4/5)
SDSP ASSY
IMIC & OPT
ASSY(2/2)
H
MIC AMP
ASSY
I
MIC & OPT
ASSY(1/2)
JFRONT A/V
ASSY
B
A/V I/O ASSY
ANT
DVD/LD
L
VCR1
PLAY L
VCR2
PLAY L
VCR3
PLAY L
TV L
SAT L
IC2001 TC9164AF
A/V Function Selector
IC2002 TC9162AF
A/V MR
Function Selector
PHONE
L
CD L
27
MR VOL
MIC AMP
DIR & DIT
DSP 1 & 2
DSP U-COM
RF Demodulator
IC2051-1/2
UPC4570C
IC2053-2/2
BA4558F
IC2052
M62429FP
3
3
2
2
1
1
L CH
CN2705
(13P)
7 7
CN5802
(13P) CN5814
(20P) CN3401
(20P)
TXL TXL
VFUNCL
MR OUTL
RECL
20 20
CN2002
CN5821
CN3205
CN3202
JA3202
SETUP
MIC
CN5820
MIC FV L
1 12
1
22
12
F OPT
OPT5 IN
2
8
5
CN2001
(17P)
CN5806
(11P)
CN3207
(11P)
CN2001
(17P)
(17P)
(17P)
14
8
4
26
25
24
22
VCR3
REC L
MR
OUT L
VCR1
REC L
VCR2
REC L
VIDEO
L
COAX
IN
OPT
IN
JA1
JA2
DIGITAL
IN
21
18
23
IC3422 TC9163AF
Audio Function Selector
IC3901 BU4052BCF
Audio MR
Function Selector
IC3401 TC9163AF
A/D Mode Selector
IC3461 AK5383VS
Surround
D/A Converter
27
26
24
20
8 7
20
17
19
TAPE1
PLAY L 23
13
11
17
TAPE2
PLAY L 19
TAPE1
REC L 18
TAPE2
REC L
FL IN 22
21
25
IC3423-2/2
M5220P
5
67
SL IN
IC3462-2/2
UPC4570C
5
67
IC3701-2/2
6
57
IC3702-2/2
6
57
IC3424-1/2
UPC4570C
5
67
IC3201-1/2
M5220FP
Q3204
3
21
27
15
14
20
22
415
5
23
24
26
27
IC3421 AK5383VS
Front
D/A Converter
IC3502-2/2
NJM2068D
6
57415
5
IC3441 AK5383VS
C/SW
D/A Converter
IC3601-2/2
6
57
IC3602-2/2
6
57415
5
IC3481 AK5383VS
Back
D/A Converter
IC3801-2/2
6
57
IC3802-2/2
6
57415
5
17
19
18
26
24
23
5
18
25
22
21
20
19
17
1
711
MIC
MIC
CN3206
CN3204
33 FV L
SLOUT
FLOUT
COUT
SBLOUT
FV L
VFUNC
INL
MR LOUT
MC CIN
CN3401
(20P)
8MC SBLIN
4
16
12
EX FLOUT
SBLOUT COUT FLOUT SLOUT
EX
SBLOUT
EX COUT
CN3402
(17P)
6
EX SLOUT
10
14
2
ADFFDT
ADSRDT
ADCWDT
CN3403
(30P) CN5816
(30P) CN5810
(17P)
5
ADSBDT
AF DATA
AS DATA
AC DATA
AB DATA
1
3
7
5
1
3
7
6
2
4
8
CN702
(17P)
CN703
(9P)
CN705
(22P)
CN401
(22P)
CN709
CN707
CN5809
(9P)
CN5804
(5P)
CN3201
(5P)
12
16
14
10
5
AO
1394 MODULE
Refer to section
"3.1.4 1394 MODULE Block".
(S)
(C)
(SB)
(S)
(F)
(F) (F)
(F)
(S)
(C)
(SB)
(F)
(MR)
(MR)
(REC)
(REC)
(REC)
(REC)
(MR)
