The mission for our flagship receiver was simple: the ultimate reproduction
of HD audio, which creates surround sound so rich, so dense, no analog
amplifier alone can do the job properly. So we created the Hybrid Digital
Amplifier. Developed with ICEpower, the leader in digital amplifier design, this
breakthrough is at the heart of the SC-09TX. The receiver combines the best
of digital and analog technology. It is an achievement that marks a new era in
high-definition stereophonic fidelity.
HD AmplificAtion AnD BuilD
1,400W Total System Power ›
Continuous Power Output (FTC): ›
200W x 7 (20Hz - 20kHz, .05% THD @ 8 – Ω, All
Channels Driven)
Class D Direct Energy HD Amplier ›
ICE Class-D Analog Amplier module ›
Ultra Rigid Separated Construction ›
5 Mode Speaker Conguration ›
HD SurrounD SounD
AIR STUDIOS Monitor Reference ›
THX Ultra 2 PLUS ›
Dolby ›® TrueHD, Dolby Digital Plus, DTS-HD® Master Audio /
High-resolution Audio
Dual 3rd Generation SHARC ›® Processors + 48 bit Freescale DSP Engines
Full Band Phase Control ›
Advanced MCACC with 9 Band EQ ›
Symmetric EQ ›
Precision Distance ›
Standing Wave Control ›
Sampling Rate Converter HDMI Jitter Reduction – Burr Brown ›
HDMI ›® Audio – Ultra low Jitter PLL and Digital Clock Circuits
Wolfson ›TM 192 kHz/24 bit DAC’s
DSD to PCM Converter ›
HD connectivity
HDMI ver 1.3a – 6 In / 2 Output ›
Deep Color / 30-bit / 36-bit 4:4:4 color depth ›
Full Digital Video Converter for HDMI ›
Video Scaler – Marvell 1080p / 60Hz ›
Component Video – 5 In / 2 Out (Main & Sub Room) ›
DigitAl SourceS &
proceSSing
Home Media Gallery – Music / Photo / Video ›1
iPod ›® Player Audio – USB 7 Analog AV
Play Audio Files from USB ›
XM-HD ›® & SIRIUS® Satellite Radio Ready with OSD & Control*
11 Digital Audio In (6 Opt. / 4 Coax.) / 3 Digital Out (2 Opt. / 1 Coax.) ›
2 x i.Link Audio I/O with PQLS ›
Front Stage Surround Advance ›
Advanced Sound Retriever (for enhanced playback from ›
portable audio devices)
Neural-THX ›® Surround, THX Loudness Plus
cuStom ApplicAtionS
Front LCD Display – Set-up / Video Monitor ›
Network GUI ›
PC Display (Room reverb., Speaker Delay and MCACC Parameters) ›
USB Firmware Upgradable ›
3 Zone / 2nd Zone OSD / 2nd Zone DVC ›
2nd Zone HD-Video via Component ›
RS232C / IR I/O - 4 In / 4 Out / 12 V Trigger x 4 (assignable) ›
8AV / 6A Analog Inputs – includes Phono ›
LCD Learning & Preset Remote ›
SC-09TX
10.2-Channel Flagship A/V Receiver Featuring
Class D Direct Energy HD Amplifier
Simulated Screen
*XM Connect-and-Play antenna and subscription service (each sold separately) required to
receive XM and XM-HD Surround Radio. Sirius antenna and subscription service (each sold
separately) required to receive Sirius radio.

PIONEER, ELITE and the Pioneer and Elite logos are registered trademarks of Pioneer Corporation.
Specifications and design subject to modification without notice.
1 Previously existing or new home network, Microsoft Windows®XP, and Microsoft Windows®Media
Connect software (Free for licensed users of Microsoft Windows®operating system through Win-
dows®Updates) required for all Home Media Gallery features. For best results use wired connection.
Manufactured under license from Dolby Laboratories, “Dolby”, “Pro-logic”, “Surround EX”, and the
Double-D symbol are trademarks of Dolby Laboratories.
“DTS” is a registered trademark of DTS, Inc. and “DTS-HD Master Audio.
HDMI and the HDMI logo are registered trademarks of HDMI Licensing LLC.
THX and the THX logo are trademarks of THX Ltd., which may be registered in some jurisdictions. All
rights reserved.
Microsoft, Windows Media, and the Windows logo are registered trademarks of Microsoft Corporation.
XM and XM Connect-&-Play are registered trademarks of XM Satellite Radio Inc.
SIRIUS and related marks are trademarks of Sirus Satellite Radio Inc.
iPod is a trademark of Apple Computer, Inc., registered in the U.S. and other countries.
The AIR STUDIOS logo is a trademark of Air Sudios, Inc.
Neural Surround™ is a trademark of Neural Audio Corporation.
Sharc is a registered trademark of Analog Devices, Inc.
Faroudja and DCDI are registered trademarks of Genesis Microchip Inc.
PlaysForSure and the PlaysForSure logo are registered trademarks of Microsoft Corporation.
i.LINK and the i.LINK logo are trademarks of Sony Corporation.
ICEpower and the ICEpower logo are registered trademarks of Bang & Olufsen ICEpower a/s.
HDMI connection may not allow transmission of copyright-protected material, depending on the
capability of the signal source.
connectionS
Rear Panel
