Pioneer VSX-1121-K User manual

VSX-1121-K
7.1-Channel THX Select 2 Plus A/V Receiver Featuring AirPlay
®
, Pandora
®
Radio, Virtual Depth, Marvell
®
Video Processing, and 2-Zone A/V
DIRECT ENERGY AMPLIFICATION
›110 W x 7 (20Hz – 20 kHz, THD 0.08% @ 8 ohms FTC)
›8 & 6 Ohm Impedance Select
BUILD
›Advanced Direct Construction
›Trans. Stabilizer
AUDIO FEATURES
›THX Select 2 Plus
›Dolby®TrueHD / Dolby Pro Logic®IIz / Dolby Digital EX / Dolby Digital Plus
›DTS-HD®Master Audio / DTS-ES / DTS Neo:6 / DTS Neural Surround
›Digital Core Engine with Texas Instruments Aureus®DSP
›192 kHz / 24-bit Digital to Analog Converter
›192 kHz / 24-bit Analog to Digital Converter
›Pioneer Advanced MCACC Room Calibration
 • 3DTimeAxisMeasurement
 • PolarityCheck
 • ReverbBeforeandAfterCalibrationResults(OSDandiPad)
 • StandingWaveControl
›Pioneer Sound Enhancements
 • PhaseControlBassManagement
 • PhaseControlPlus
 • Virtual Depth, Height and Surround Back
 • OptimumSurround-AutoBass,Dialog,andSurroundBalancing
 • PQLSBit-stream
 • Auto Sound Retriever (Multi)
 • FrontWideSurroundMovie&Music
 • AutoLevelControl(Multi)
 • AdvancedSurround(15ModeDSP)
 • SoundRetrieverAIR
 • FrontStageSurround
 • HeadphoneSurround
VIDEO FEATURES
›Marvell QdeoTM 1080p/24fps Video Scaler
›Advanced Video Adjust
›StreamSmoother
›Triple HD Noise Reduction
›Video Conversion to HDMI
›HDMI®Features
 • 3DReady(Blu-rayDisc®,BroadcastandGame)
 • AudioReturnChannel
 • DeepColorandx.v.ColorTM
HOME NETWORK FEATURES
›AirPlay
›DLNA Certified®(1.5)
›Internet Radio with vTuner
›PANDORAinternetradio
›Rhapsody®Music Service1
›Sirius®Internet Radio1
›Windows®7 Certified
›HomeMediaGallery
›FLAC192kHz/24-bitAudioFilePlayback
›WAV 192 kHz / 24-bit Audio File Playback
CONNECTIVITY
›MadeforiPod®, iPhone®, iPad®
 • ChargesiPhone,iPad,iPod
 • CombinationUSB/CompositeVideoCableSupplied
 • iPhone,iPad,iPodStoredandStreamingAudio&VideowithAlbumArt
›MemoryAudioPlayback(MP3/WMA/WAV)
›Pioneer Air Jam App
 • ConnectsviaBluetooth®to Share Music and Create Playlists (With iPod
touch, iPhone, iPad)
 • FreeviatheAppStoreSM (OptionalAS-BT200BluetoothAdapterRequired)
›HDMIInputs(7In(6Back,1Front)/1Out)
›Front USB Input
›Ethernet Terminal
›WirelessLANReady(OptionalAS-WL300WirelessLANConverterRequired)
›Sirius XM Radio Ready2
›AdapterPort(OptionalAS-BT100orAS-BT200BluetoothAdapterRequired)
›Component Video Inputs (2 In / 1 Out)
›Digital Inputs (2 Coaxial, 3Optical)
›Analog A/V Inputs (4 A/V, 1 Audio)
›9.2AssignablePre-Outs
›Large Speaker Terminals (9 Channels)
CUSTOM
›Pioneer iControlAV2 App
 • A/VReceiverandBlu-rayDiscPlayerControlFromiPodtouch,iPhone,iPad
• FreeviatheAppStoreSM
›IP Control with Full 2-Way Feedback
›AVNavigatorSystemSet-Up(CD-ROMIncludedforPC)
›FullColorGraphicUserInterface(GUI)
›Zone2AudioPre-Out,SpeakerOutandVideoOut
›RS-232C
›SRIn/Out
›IRIn/Out
›HDMIStandbyThroughforLowPowerConsumption
›Detachable Power Cord
›Auto Power Down
›IlluminatedLearningRemoteControl
1
Subscription Required.
2
Antenna and subscription required and sold separately. Bold denotes step-up features from VSX-1021

VSX-1121-K
7.1-Channel THX Select 2 Plus A/V Receiver Featuring AirPlay
®
, Pandora
®
Radio, Virtual Depth, Marvell
®
Video Processing, and 2-Zone A/V
CONNECTIONS
Rear Panel
PRODUCT SPECIFICATIONS
›W x H x D: 17.13 x 7.28 x 17.36 (inches)
›Weight 30.21 lbs
UPC
›8-84938-13487-3
INTEGRATED TECHNOLOGIES
CARTON SPECIFICATIONS
›W x H x D: 20.87 x 12.20 x 20.87 (inches)
›Weight 37.04 lbs
CUSTOM CONTROL PARTNERS
POWER SPECIFICATIONS
›Power Requirements: AC 120 V/60 Hz
›Estimated Power Consumption: 570 Watts
›Standby Power Consumption: Approx 0.1 to 0.3 Watts
Specifications and design subject to modification without notice.
PIONEER, and the Pioneer logo are registered trademarks of Pioneer Corporation.
Dolby, Pro Logic and the double-D symbol are registered trademarks of Dolby Laboratories.
DTS and the DTS Symbol are registered trademarks and the DTS logos are trademarks of DTS, Inc.
THX, the THX Logo and THX Select 2 Plus are trademarks of THX Ltd., which may be registered in some jurisdictions.
The Bluetooth wordmark is a registered trademark owned by Bluetooth SIG, Inc. And any use of such marks by PIONEER is under license. Bluetooth
wireless technology functionality requires a compatible A2DP profile Bluetooth wireless technology enabled device. Certain Bluetooth features may not be
supported by all compatible Bluetooth wireless technology enabled device, and/or the functionality of such features may be limited in certain devices.
HDMI, the HDMI logo, and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC in the United States
and other countries.
HDMI connection may not allow transmission of copyright-protected material, depending on the capability of the display device and the signal source.
Microsoft, Windows Media, and the Windows logo are trademarks or registered trademarks of Microsoft Corporation.
SIRIUS and related marks are trademarks of Sirius XM Radio Inc.
“Made for iPod,” “Made for iPhone,” and “Made for iPad” mean that an electronic accessory has been designed to connect specifi-
cally to iPod, iPhone, or iPad, respectively, and has been certified by the developer to meet Apple performance standards. Apple is
not responsible for the operation of this device or its compliance with safety and regulatory standards. Please note that the use of
this accessory with iPod, iPhone, or iPad may affect wireless performance.
Apple, AirPlay, the AirPlay logo, iPhone, iPad, iPod and iPod touch are registered trademarks of Apple Inc., registered in the U.S. and other countries.
AirPlay works with iPad, iPhone 4, iPhone 3GS, iPod touch (4th, 3rd and 2nd generations) with iOS 4.2 and iTunes 10.1 (Mac and PC) or later.
DLNA, the DLNA Logo and DLNA Certified are trademarks, service marks, or certification marks of the Digital Living Network Alliance.
Pandora is a registered trademark of Pandora Media, Inc.
Rhapsody and the Rhapsody logo are a registered trademark of Rhapsody International, Inc.
Blu-ray Disc is a registered trademark of the Blu-ray Disc Association.
“x.v.Color” is a trademark of Sony Corporation.
Qdeo is a trademark of Marvell World Trade, L td.
vTuner is a registered trademark of Noting Else Matters Software, Ltd.
Control4 and the Control4 logo are registered trademarks of Control4 Corporation.
Crestron and the Crestron logo are registered trademark of Crestron Electronics, Inc.
AMX and the AMX logo are trademarks of AMX, LLC registered in the U.S. and other countries.
Universal Remote Control logo is a registered trademark of Universal Remote Control, Inc.
RTI logo is a registered trademark of Remote Technologies Incorporated.
Savant Logo is a registered trademark of Savant Systems, LLC.
© 2011 Pioneer Electronics (USA) Inc.
®
