Pioneer CP-2EX User manual

ORDER NO.
PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2006
RRV3366
T – ZZS MAR. 2006 Printed in Japan
SPEAKER STAND
CP-2EXXTW/E5
NOTE
This Product is sold also in CHINA.
This service manual is intended for qualified service technicians; it is not meant for the casual do-it-
yourselfer. Qualified technicians have the necessary test equipment and tools, and have been trained to
properly and safely repair complex products such as those covered by this manual.
Improperly performed repairs can adversely affect the safety and reliability of the product and may void the
warranty. If you are not qualified to perform the repair of this product properly and safely, you should not risk
trying to do so and refer the repair to a qualified service technician.
WARNING
This product contains lead in solder and certain electrical parts contain chemicals which are known to the state of California to
cause cancer, birth defects or other reproductive harm.
Health & Safety Code Section 25249.6 – Proposition 65

2
1234
1234
C
D
F
A
B
E
CP-2EX
7 (x4)
20 (x4)
1
13
13
10
4
3
6
21
21
Screw Set
( 9, 11, 12, 14, 15, 16, 17 )
2
2
19
19
5
Accessory Set
(8, 18)
5
[ PACKING ]
Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
The mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
N
OTES:
1. PARTS LIST

3
1234
1234
C
D
F
A
B
E
CP-2EX
Mark No. Description Part No.
1Protector (Bottom) SHA6095
2Protector (Middle) SHA6096
3Protector (Top) SHA6097
4Protector SHA6098
5Protection Sheet SHC6044
6Protection Sheet SHC6045
7Protection Sheet SHC6046
8Polyethylene Bag S2 SHL1265
9Polyethylene Bag S0 SHL1412
10 Packing Case SHG6210
11 Screw (Bind head, M5 x L36) SBA6048
12 Screw (Bind head, M5 x L62) SBA6050
13 Spike (with attached Nut) SBA6053
14 Screw (Bind head, M6 x L40) SBA6054
15 Spring Washer SBE6005
PACKING and SPEAKER STAND Parts List
16 Washer SBE6006
17 Spike Base SLA1057
18 Operating Instructions SRD6056
(English, French, Spanish,
Simp-Chinese, Trad-Chinese)
NSP 19 Speaker Support • • • • • •
NSP 20 Stem • • • • • •
NSP 21 Stand Base Plate • • • • • •
Mark No. Description Part No.
NSP 10 Packing Case SHG2762
Packing Case SHG6210
NSP Label for Packing Case • • • • • •
NSP 22 Model Label SAN6388
for China Model Only
Mark No. Description Part No.
[ SPEAKER STAND ]
Screw holes
for securing
speaker
(19)
(21)
22
(20)
When using speaker spikes:
(SBA6050)
Speaker
base
16
Speaker
spike base
Fastening nut
15
12
62 mm
Black
Screw holes
for securing
speaker
When not using speaker spikes:
(SBA6048)
Speaker
base
16
Fastening nut
11
36 mm
Black
Screw holes
for securing
speaker
15
Speaker Support
Bottom View
14
40 mm
Black
14
Nut
Spike
13
17
40 mm
Black
Please note that sunken
screw holes are provided
in the speaker support.
(SBA6054)
(SBA6054)
