VSX-826-K
RRV4183
AUDIO/VIDEO MULTI-CHANNEL RECEIVER
VSX-826-K
VSX-821-K
VSX-521-K
VSX-421-K
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
This service manual should be used together with the following manual(s).
For SPECIFICATIONS and PANEL FACILITIES, refer to the operating instructions.
Model Type Power Requirement Remarks
VSX-826-K SYXCN5 AC 220 V to 230 V
VSX-821-K SYXCN5 AC 220 V to 230 V
VSX-521-K SYXCN5 AC 220 V to 230 V
VSX-421-K SYXCN5 AC 220 V to 230 V
Model No. Order No. Remarks
VSX-821-K/CUXCNSM RRV4167 VSX-521-K/CUXCNSM
K-ZZZ MAY

2VSX-826-K
12 3 4
A
B
C
D
E
F
12 3 4
1. CONTRAST OF MISCELLANEOUS PARTS
CONTRAST TABLE FOR VSX-826-K/SYXCN5 AND VSX-821-K/SYXCN5
VSX-821-K/CUXCNSM, VSX-826-K/SYXCN5 and VSX-821-K/SYXCN5 are constructed the same except for the following:
Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
The mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
Screws adjacent to mark on product are used for disassembly.
For the applying amount of lubricants or glue, follow the instructions in this manual.
(In the case of no amount instructions, apply as you think it appropriate.)
Nos. indicate the pages and Nos. in the service manual for the base model.
NOTES:
When ordering resistors, first convert resistance values into code form as shown in the following examples.
Ex.1 When there are 2 effective digits (any digit apart from 0), such as 560 ohm and 47k ohm (tolerance is shown by J=5%,
and K=10%).
Ex.2 When there are 3 effective digits (such as in high precision metal film resistors).
56 1
4 7 3
R 5 0
1R 0
RD1/4PU J
RD1/4PU J
RN2H K
RS1P K
56 x 10
1
47 x 10
3
R50
1R0
561
473
RN1/4PC F562 x 10
1
5621 5 26 1
Mark No. Symbol and Description VSX-821-K/CUXCNSM VSX-826-K/SYXCN5 VSX-821-K/SYXCN5 Remarks
PCB ASSEMBLIES
NSP 1..MAIN ASSY 7025HK1011010-IL 7025HK1014020-IL 7025HK1011050-IL
P74-1 2..MAIN ASSY 70280702710H0-IL 7028070271070-IL 7028070271040-IL
P74-2 2..SUBWOOFER ASSY 7028070272070-IL 7028070272080-IL 7028070272080-IL
NSP 1..AMP5 ASSY 7025HK1011017-IL Not used 7025HK1013017-IL
P74-7 2..AMP5 ASSY 7028070241030-IL Not used 7028070241010-IL
NSP 1..AMP7 ASSY Not used 7025HK1014026-IL Not used
P74-7 2..AMP7 ASSY Not used 7028070251060-IL Not used
NSP 1..VIDEO ASSY 7025HK1011016-IL 7025HK1014027-IL 7025HK1011056-IL
P74-9 2..VIDEO ASSY 7028070261060-IL 7028070261080-IL 70280702610A0-IL
NSP 1..CPU ASSY 7025HK1011011-IL 7025HK1014024-IL 7025HK1011051-IL
P74-10 2..CPU ASSY 7028070221030-IL 7028070221080-IL 70280702210D0-IL
P74-13 2..STANDBY ASSY 7028070225030-IL 7028070225080-IL 7028070225090-IL
NSP 1..FRONT ASSY 7025HK1011013-IL 7025HK1014023-IL 7025HK1014023-IL
P74-14 2..FRONT ASSY 7028070211050-IL 7028070211060-IL 7028070211060-IL
NSP 1..AUDIO ASSY 7025HK1011014-IL 7025HK1014021-IL 7025HK1011024-IL
P74-19 2..AUDIO ASSY 7028070181030-IL 7028070181060-IL 7028070181080-IL
NSP 1..USB ASSY 7025HK1014012-IL 7025HK1011015-IL 7025HK1011015-IL
P74-20 2..USB ASSY 7028070201050-IL 7028070201030-IL 7028070201030-IL
NSP 1..D-MAIN ASSY 7025HK1011012-IL 7025HK1014028-IL 7025HK1011052-IL
P74-21 2..D-MAIN ASSY 7028070191030-IL 7028070191060-IL 7028070191070-IL
PACKING SECTION
P71-1 Remote Control (AXD7621) 8300762100010-IL Not used Not used
P71-1 Remote Control (AXD7622) Not used 8300762200010-IL 8300762200010-IL
P71-6 Operating Instructions (En/Frca/Es) 5707000004990-IL Not used Not used
P71-6 Operating Instructions
(En/Fr/Es/De/It/Nl/Ru)
Not used 5707000005000-IL 5707000005000-IL
Operating Instructions (CD-ROM) Not used 6517000000140-IL 6517000000140-IL
P71-7 Box, Gift 60072118200G0-IL 60072118200M0-IL 60072118200L0-IL
>AC Power Cord Not used L068250160020-IL L068250160020-IL
NSP Warranty Card EU Not used ARY7127 ARY7127

3
VSX-826-K
56 7 8
56 7 8
A
B
C
D
E
F
Notes : The numbers in the remarks column correspond to the numbers on the “EXPLODED VIEWS”.
For PCB ASSEMBLIES, Refer to "CONTRAST OF PCB ASSEMBLIES".
EXPLODED VIEWS
EXTERIOR SECTION (for VSX-826-K, VSX-821-K)
EXTERIOR SECTION
(for VSX-821-K, VSX-921-K)
>P74-22 Cord Assy L068125101710-IL Not used Not used
>P74-23 Power Trans 8200960610850-IL 8200960610970-IL 8200960610860-IL
P74-37 Chassis Back 3207213736000-IL 3207213746100-IL 3207213736100-IL
P74-45 Stopper 4380040162010-IL Not used Not used
P74-49 Front Panel 3067215091000-IL 3067215091130-IL 3067215091100-IL
Bushing Not used 2410040353010-IL 2410040353010-IL No. 68
Cn,Wire Not used L000800020220-IL L000800020220-IL No. 69
>Socket,Power AC Not used G430040560021-IL G430040560021-IL No. 70
Screw Not used CBZ30P080FTB CBZ30P080FTB No. 71
Mark No. Symbol and Description VSX-821-K/CUXCNSM VSX-826-K/SYXCN5 VSX-821-K/SYXCN5 Remarks
*14
DF

4VSX-826-K
12 3 4
A
B
C
D
E
F
12 3 4
CONTRAST OF PCB ASSEMBLIES
A
F AUDIO ASSY
7028070181030-IL, 7028070181060-IL and 7028070181080-IL are constructed the same except for the following:
The mounting positions of the additional parts are described in the circuit diagram and PCB diagram of the parent manual.
B
F AMP7 ASSY
Although 7028070251040-IL and 7028070251060-IL are different in part number and they are NOT COMPATIBLE, they consist
of the same service components.
C
F AMP5 ASSY
Although 7028070241030-IL and 7028070241010-IL are different in part number and they are NOT COMPATIBLE, they consist
of the same service components.
D
F MAIN ASSY
70280702710H0-IL, 7028070271070-IL and 7028070271040-IL are constructed the same except for the following:
The mounting positions of the additional parts are described in the circuit diagram and PCB diagram of the parent manual.
E
F SUBWOOFER ASSY
7028070272070-IL and 7028070272080-IL are constructed the same except for the following:
L
F VIDEO ASSY
7028070261060-IL, 7028070261080-IL and 70280702610A0-IL are constructed the same except for the following:
The mounting positions of the additional parts are described in the circuit diagram and PCB diagram of the parent manual.
Mark Symbol and Description 7028070181030-IL 7028070181060-IL 7028070181080-IL Remarks
Q401, Q404 J522020011210-IL Not used J522020011210-IL
Q413, Q418 Not used J522020011210-IL Not used
CN400 CN,WIRE 2mm L002151102621-IL L002151132621-IL L002151102621-IL
JA400 TER,RCA 9pin G607902AA550Y-IL G607902AA141Y-IL G607902AA550Y-IL
Mark Symbol and Description 70280702710H0-IL 7028070271070-IL 7028070271040-IL Remarks
L6, L7 COIL,FILTER-INDUCTOR Not used D330900001330-IL Not used
RY6 RELAY Not used G680120503020-IL Not used
CN9014 CN,WAFER Not used L109012511110-IL Not used
CN2 CN,WIRE Not used L000311020030-IL Not used
CN4 CN,WIRE L000101020310-IL Not used L000101020310-IL
CN9008 CN.WAFER Not used L109012510910-IL Not used
JA104 TER,BOARD PUSH 4p Not used G594408SA030Y-IL Not used
R15-R18 Not used C060010065050-IL Not used
R35, R36 Not used C060047363050-IL Not used
C21, C22, C24, C25 Not used D02047306C060-IL Not used
Mark Symbol and Description 7028070272070-IL 7028070272080-IL Remarks
D9604, D9605 K06606R24P400-IL Not used
JA602 JACK,DIN G403515397000-IL Not used
9601 TUNER,FM/AM E903004100780-IL E903104100780-IL
Mark Symbol and Description 7028070261060-IL 7028070261080-IL 70280702610A0-IL Remarks
Q1084 Not used J520015301210-IL Not used
Q1082 Not used J522101411210-IL Not used
Q1083 Not used J522020011210-IL Not used
D1082, D1084 Not used K005041480030-IL Not used
X1003 CRYSTAL E80014R318080-IL Not used Not used
X1004 CRYSTAL Not used E80017R734410-IL E80017R734410-IL
CN1 CN,WAFER Not used L109012520910-IL Not used
JA1001 TER,RCA 6pin G603610D0400Y-IL G603610A0040Y-IL G603610A0040Y-IL
JA1000 TER,RCA 9pin G607902AD013Y-IL G607902AA013Y-IL G607902AA013Y-IL

5
VSX-826-K
56 7 8
56 7 8
A
B
C
D
E
F
N
F FRONT ASSY
Although 7028070211050-IL and 7028070211060-IL are different in part number and they are NOT COMPATIBLE, they consist
of the same service components.
P
F CPU ASSY
7028070221030-IL, 7028070221080-IL and 70280702210D0-IL are constructed the same except for the following:
The mounting positions of the additional parts are described in the circuit diagram and PCB diagram of the parent manual.
S
F STANDBY ASSY
7028070225030-IL, 7028070225080-IL and 7028070225090-IL are constructed the same except for the following:
T
F D-MAIN ASSY
7028070191030-IL, 7028070191060-IL and 7028070191070-IL are constructed the same except for the following:
The mounting positions of the additional parts are described in the circuit diagram and PCB diagram of the parent manual.
U
F USB ASSY
7028070201050-IL and 7028070201030-IL are constructed the same except for the following:
Mark Symbol and Description 7028070221030-IL 7028070221080-IL 70280702210D0-IL Remarks
IC203 8952521000040-IL 8952921000012-IL 8952521000040-IL
IC201 J040740800240-IL Not used Not used
CN203 CN,WAFER Not used L109012511110-IL Not used
CN205 CN,WAFER Not used L109012521110-IL Not used
Mark Symbol and Description 7028070225030-IL 7028070225080-IL 7028070225090-IL Remarks
Q302 J522101441210-IL Not used Not used
D9302 K06015R044520-IL Not used Not used
>T301 POWER TRANS 8200280150620-IL 8200280150680-IL 8200280150680-IL
>FU301 FUSE GLASS TUBE 20mm N751506301160-IL N751504001160-IL N751503151160-IL
>CN9302 CN.WAFER 7.92mm L108353280290-IL L108011430210-IL L108011430210-IL
Mark Symbol and Description 7028070191030-IL 7028070191060-IL 7028070191070-IL Remarks
IC1311 Not used J080101500010-IL Not used
IC1316 8952521000011-IL 8952921000021-IL 8952521000011-IL
IC9300 Not used J126108618080-IL Not used
>IC1306 Not used J048107300010-IL Not used
IC1302 Not used J044718100010-IL Not used
IC1323 8952521000020-IL 8952921000030-IL 8952521000020-IL
IC1307 Not used TC7SA08FU Not used
IC1312 Not used TC7WHU04FU Not used
Q1319 Not used J522101411210-IL Not used
>Q1318 Not used J500124200010-IL Not used
L1320 COIL,CHIP Not used D311126000030-IL Not used
L1308, L1335 COIL,INDUCTOR Not used D3104R7010200-IL Not used
L1301, L1304, L1323, L1324 Not used D340160811210-IL Not used
L1363, L1364 CHIP BEAD Not used D340160811210-IL D340160811210-IL
X1301 CRYSTAL CHIP Not used E80528R636360-IL Not used
X1302 CRYSTAL CHIP Not used E80527R000050-IL Not used
CN1304 CN.WAFER 2.5mm L102526800400-IL L109012521110-IL L102526800400-IL
CN9304 CN.WAFER 2.5mm Not used L102526800400-IL Not used
Mark Symbol and Description 7028070201050-IL 7028070201030-IL Remarks
IC802 8952921000040-IL 8952921000040-IL

6VSX-826-K
12 3 4
A
B
C
D
E
F
12 3 4
CONTRAST TABLE FOR VSX-521-K/SYXCN5 AND VSX-421-K/SYXCN5
VSX-521-K/CUXCNSM, VSX-521-K/SYXCN5 and VSX-421-K/SYXCN5 are constructed the same except for the following:
Notes : The numbers in the remarks column correspond to the numbers on the “EXPLODED VIEWS”.
For PCB ASSEMBLIES, Refer to "CONTRAST OF PCB ASSEMBLIES".
Mark No. Symbol and Description VSX-521-K/CUXCNSM VSX-521-K/SYXCN5 VSX-421-K/SYXCN5 Remarks
PCB ASSEMBLIES
NSP 1..MAIN ASSY 7025HK1012010-IL 7025HK1012050-IL 7025HK1013010-IL
P78-1 2..MAIN ASSY 70280702710D0-IL 7028070271050-IL 7028070271060-IL
P78-2 2..SUBWOOFER ASSY 7028070272050-IL 7028070272080-IL 7028070272060-IL
NSP 1..AMP5 ASSY 7025HK1011017-IL 7025HK1013017-IL 7025HK1013017-IL
P78-7 2..AMP5 ASSY 7028070241030-IL 7028070241010-IL 7028070241010-IL
NSP 1..BT ASSY 7025HK1009019-IL 7025HK1009019-IL Not used
P78-8 2..BT ASSY 7028070231010-IL 7028070231010-IL Not used
NSP 1..VIDEO ASSY 7025HK1011016-IL 7025HK1011056-IL 7025HK1013016-IL
P78-9 2..VIDEO ASSY 7028070261060-IL 70280702610A0-IL 7028070261040-IL
NSP 1..CPU ASSY 7025HK1012011-IL 7025HK1012051-IL 7025HK1013011-IL
P78-10 2..CPU ASSY 7028070221020-IL 70280702210F0-IL 7028070221010-IL
P78-12 2..BRIDGE B ASSY 7028070223070-IL 7028070223070-IL 7028070223010-IL
P78-13 2..STANDBY ASSY 7028070225030-IL 7028070225090-IL 7028070225090-IL
NSP 1..FRONT ASSY 7025HK1012013-IL 7025HK1012053-IL 7025HK1013013-IL
P78-14 2..FRONT ASSY 7028070211020-IL 70280702110B0-IL 7028070211010-IL
P78-16 2..MIC ASSY 7028070213020-IL 7028070213020-IL 7028070213010-IL
NSP 1..AUDIO ASSY 7025HK1011014-IL 7025HK1011024-IL 7025HK1013014-IL
P78-19 2..AUDIO ASSY 7028070181030-IL 7028070181080-IL 7028070181010-IL
NSP 1..D-MAIN ASSY 7025HK1012012-IL 7025HK1012052-IL 7025HK1013012-IL
P78-21 2..D-MAIN ASSY 7028070191020-IL 7028070191080-IL 7028070191010-IL
PACKING SECTION
P71-1 Remote Control (AXD7619) 8300761900010-IL Not used Not used
P71-1 Remote Control (AXD7618) Not used Not used 8300761800010-IL
P71-1 Remote Control (AXD7620) Not used 8300762000010-IL Not used
P71-5 Microphone (for Auto MCACC setup) APM7008 APM7008 Not used
P71-6 Operating Instructions (En/Frca/Es) 5707000005040-IL Not used Not used
P71-6 Operating Instructions
(En/Fr/Es/De/It/Nl/Ru)
Not used 5707000005050-IL 5707000005090-IL
Operating Instructions (CD-ROM) Not used 6517000000140-IL 6517000000140-IL
P71-7 Box, Gift 60072118200P0-IL 60072118200T0-IL 60072118200V0-IL
>AC Power Cord Not used L068250160020-IL L068250160020-IL
NSP Warranty Card EU Not used ARY7127 ARY7127
EXTERIOR SECTION (for VSX-521-K)
>P78-22 Cord Assy L068125101710-IL Not used Not used
>P78-23 Power Trans 8200960610910-IL 8200960610920-IL 8200960610920-IL
P78-37 Chassis Back 3207213726000-IL 3207213726100-IL 3207213716000-IL
P78-45 Stopper 4380040162010-IL Not used Not used
P78-49 Front Panel 3067215081000-IL 3067215081100-IL 3067215081110-IL
P78-51 Window Display 5077213123110-IL 5077213123110-IL 5077213123100-IL
P78-50 Window Display 5077213113010-IL 5077213113010-IL 5077213113000-IL
Bushing Not used 2410040353010-IL 2410040353010-IL No. 68
Cn,Wire Not used L000800020220-IL L000800020220-IL No. 69
>Socket,Power AC Not used G430040560021-IL G430040560021-IL No. 70
Screw Not used CBZ30P080FTB CBZ30P080FTB No. 71

7
VSX-826-K
56 7 8
56 7 8
A
B
C
D
E
F
EXPLODED VIEWS
EXTERIOR SECTION (for VSX-521-K, VSX-421-K)
DF

8VSX-826-K
12 3 4
A
B
C
D
E
F
12 3 4
CONTRAST OF PCB ASSEMBLIES
A
F AUDIO ASSY
7028070181030-IL, 7028070181080-IL and 7028070181010-IL are constructed the same except for the following:
C
F AMP5 ASSY
Although 7028070241030-IL and 7028070241010-IL are different in part number and they are NOT COMPATIBLE, they consist
of the same service components.
D
F MAIN ASSY
70280702710D0-IL, 7028070271050-IL and 7028070271060-IL are constructed the same except for the following:
E
F SUBWOOFER ASSY
7028070272050-IL, 7028070272080-IL and 7028070272060-IL are constructed the same except for the following:
G
F MIC ASSY
7028070213020-IL and 7028070213010-IL are constructed the same except for the following:
L
F VIDEO ASSY
7028070261060-IL, 70280702610A0-IL and 7028070261040-IL are constructed the same except for the following:
The mounting positions of the additional parts are described in the circuit diagram and PCB diagram of the parent manual.
N
F FRONT ASSY
7028070211020-IL, 70280702110B0-IL and 7028070211010-IL are constructed the same except for the following:
Mark Symbol and Description 7028070181030-IL 7028070181080-IL 7028070181010-IL Remarks
Q422, Q424 J522020011210-IL J522020011210-IL Not used
Q423 J520101411210-IL J520101411210-IL Not used
Mark Symbol and Description 70280702710D0-IL 7028070271050-IL 7028070271060-IL Remarks
CN9012 CN.WAFER L109012510910-IL L109012510910-IL Not used
Mark Symbol and Description 7028070272050-IL 7028070272080-IL 7028070272060-IL Remarks
CN602 CN.WAFER 2.0mm L101100041110-IL L101100041110-IL Not used
9601 TUNER,FM/AM E903004100780-IL E903104100780-IL E903104100780-IL
Mark Symbol and Description 7028070213020-IL 7028070213010-IL Remarks
IC902 J121458000020-IL Not used
IC901 BU4052BCFV Not used
Q900 J522101441210-IL Not used
D9901-D9903 K06605R14P400-IL Not used
CN901 CN.WIRE 2.0mm L002391100010-IL L002381030020-IL
Mark Symbol and Description 7028070261060-IL 70280702610A0-IL 7028070261040-IL Remarks
IC1007 J170747810010-IL J170747810010-IL Not used
Q1012 J520015301210-IL J520015301210-IL Not used
Q1013 J522305200050-IL J522305200050-IL Not used
X1003 CRYSTAL E80014R318080-IL Not used Not used
X1004 CRYSTAL Not used E80017R734410-IL Not used
JA1001 TER,RCA 6pin G603610D0400Y-IL G603610A0040Y-IL G603610A0040Y-IL
JA1000 TER,RCA 9pin G607902AD013Y-IL G607902AA013Y-IL G607902AA013Y-IL
Mark Symbol and Description 7028070211020-IL 70280702110B0-IL 7028070211010-IL Remarks
D8701 K500052009011-IL K500052009011-IL Not used

9
VSX-826-K
56 7 8
56 7 8
A
B
C
D
E
F
P
F CPU ASSY
7028070221020-IL, 70280702210F0-IL and 7028070221010-IL are constructed the same except for the following:
R
F BRIDGE B ASSY
7028070223070-IL and 7028070223010-IL are constructed the same except for the following:
S
F STANDBY ASSY
7028070225030-IL and 7028070225090-IL are constructed the same except for the following:
T
F D-MAIN ASSY
7028070191020-IL, 7028070191080-IL and 7028070191010-IL are constructed the same except for the following:
The mounting positions of the additional parts are described in the circuit diagram and PCB diagram of the parent manual.
Mark Symbol and Description 7028070221020-IL 70280702210F0-IL 7028070221010-IL Remarks
IC203 8952521000040-IL 8952521000040-IL 8952521000040-IL
IC205 J040740800240-IL J040740800240-IL Not used
CN207 CN,WAFER L109012520910-IL L109012520910-IL Not used
Mark Symbol and Description 7028070223070-IL 7028070223010-IL Remarks
CN9901 CN.WAFER 2.0mm L101200101020-IL L101200100320-IL
Mark Symbol and Description 7028070225030-IL 7028070225090-IL Remarks
Q302 J522101441210-IL Not used
D9302 K06015R044520-IL Not used
>FU301 FUSE GLASS TUBE 20mm N751506301160-IL N751503151160-IL
>T301 POWER TRANS 8200280150620-IL 8200280150680-IL
>CN9302 CN.WAFER 7.92mm L108353280290-IL L108011430210-IL
Mark Symbol and Description 7028070191020-IL 7028070191080-IL 7028070191010-IL Remarks
IC1316 8952521000011-IL 8952521000011-IL 8952521000011-IL
IC1323 8952521000020-IL 8952521000020-IL 8952521000020-IL
L1363, L1364 CHIP BEAD Not used D340160811210-IL D340160811210-IL
JA1303 CN.WAFER L109100190160-IL L109100190160-IL Not used
