ElectricPAK
Owner’s Manual
Table of Contents
PRODUCT INFORMATION - - - - - - - - - 3
Description - - - - - - - - - - - - - - 3
UNPACKING & INSPECTION - - - - - - - - 3
Transportation and Storage- - - - - - - 3
Unpacking - - - - - - - - - - - - - - - 4
PHYSICAL INSTALLATION - - - - - - - - - 5
Foundation - - - - - - - - - - - - - - 5
Piping Installation - - - - - - - - - - - 5
ELECTRICAL INSTALLATION - - - - - - - - 6
Pre-Start Verifications - - - - - - - - - 6
MAINTENANCE - - - - - - - - - - - - - - 6
Periodic Maintenance - - - - - - - - - 6

SAFETY INSTRUCTIONS
Physical Installation
2
SAFETY INSTRUCTIONS
This equipment should be installed and serviced by technically
qualified personnel who are familiar with the correct selection
and use of appropriate tools, equipment, and procedures. Failure
to comply with national and local electrical and plumbing codes
and within Pioneer Pump recommendations may result in electri-
cal shock or fire hazard, unsatisfactory performance, or equip-
ment failure.
Know the product’s application, limitations, and potential haz-
ards. Read and follow instructions carefully to avoid injury and
property damage. Do not disassemble or repair unit unless
described in this manual.
Failure to follow installation or operation procedures and all
applicable codes may result in the following hazards:
Risk of death, personal injury, or
property damage due to explosion, fire,
or electric shock.
• Do not use to pump flammable, combustible, or explosive fluids
such as gasoline, fuel oil, kerosene, etc.
• Do not use in explosive atmospheres or hazardous locations as
classified by the NEC, ANSI/NFPA70.
• Do not handle a pump, pump motor, or drive with wet hands or
when standing on a wet or damp surface.
Risk of severe injury or death.
• To reduce risk of electrical shock, disconnect power before work-
ing on or around the system. More than one disconnect switch
may be required to de-energize the equipment before servicing.
• Check local electrical and building codes before installation. The
installation must be in accordance with their regulations as well
as the most recent National Electrical Code (NEC) and the Occu-
pational Safety and Health Act (OSHA).
• Wire pump system for correct voltage.
• Ensure that the system is properly grounded all the way to the
service entrance panel.
• When lifting or moving heavy components, use suitable lifting
equipment, in good condition, rated for at least 5 times the
weight of the materials being moved.
• Capacitors inside the drive can still hold lethal voltage even after
power has been disconnected. Allow adequate time for internal
voltage to discharge before removing cover or working with
internal components.
• This pump has not been investigated for use in swimming pool
or marine areas.
Risk of bodily injury, electric shock, or
equipment damage.
• This equipment must not be used by children or persons with
reduced physical, sensory or mental abilities, or lacking in experi-
ence and expertise, unless supervised or instructed. Children
may not use the equipment, nor may they play with the unit or in
the immediate vicinity.
• Equipment can start automatically. Lockout-Tagout before ser-
vicing equipment.
• Pump system may become hot during operation. Allow pump
system to cool before servicing.
• Operation of this equipment requires detailed installation and
operation instructions provided in this manual for use with this
product. Read entire manual before starting installation and oper-
ation. End User should receive and retain manual for future use.
Risk of damage to pump or other equipment.
• Do not install in corrosive environments.
• Periodically inspect pump and system components. Regularly
check hoses for weakness or wear, making certain that all con-
nections are secure.

PRODUCT INFORMATION
Description
3
PRODUCT INFORMATION
Description
Pioneer ElectricPAKs include a rigidly mounted electric motor and Pioneer pump in either a Pioneer prime
or a standard centrifugal configuration supported by a modular frame intended for fixed installations. The
rigid mount between pump and motor maintains coupling alignment during transportation and operation,
increasing the time between coupling inspections.
For portable applications, drag skid, lifting bail, and quick connect junction box accessories are available.
The drag skid adder is highly recommended.
Refer to the motor manuals and applicable guides for startup, installation, and maintenance. The package
as a whole is not under the same warranty. For warranty information, please see the owner’s manual of each
component.
UNPACKING & INSPECTION
Transportation and Storage
Normal packaging is designed to protect the pump during shipment and for storage up to three months. It
is recommended to store the unit in a clean, dry place, protected from the environment, dirt, and debris.
IMPORTANT: See manufacturer’s recommendations for motor, panel, and pump storage.
1. Ensure the bearings are packed with recommended grease or coated with oil to prevent moisture from
entering the bearing housings.
2. Ensure the suction and discharge flanges are covered to prevent entry of debris.
3. Periodically check oil levels.
4. For cold weather storage, fully drain casing prior to storing.
Unpacking
1. Check for missing and damaged parts. Immediately report any issues to the transport company and
equipment manufacturer.
NOTE: Parts and/or accessories are sometimes individually wrapped or fastened to the equipment.
2. Examine the pump and motor unit upon arrival for shipping damage.
• If there is damage, notify the shipping agent and your sales representative.
Risk of severe injury or death.
• When lifting or moving heavy components, use suitable lifting equipment, in good condition, rated for at least 5 times the
weight of the materials being moved.
• Ensure forklift fork/tines are fully inserted. Failure to do so can lead to product damage, and/or the unit to fall off the forklift
and cause injury or death.
• Use only labeled tie down points to secure unit for transportation. Failure to use labeled tie down points could lead to
equipment damage and/or allow unit to come loose during transit and cause injury or death.
Risk of damage to equipment.
• The pump package must be transported in a level, horizontal position and secured using the identified tie-down points.
• If the pump package is dropped, impacted, or otherwise mishandled, malfunction can occur.

PHYSICAL INSTALLATION
Foundation
4
3. Check that guards are in their proper place and that fasteners are tightened.
4. Use skids for unloading if facilities are not available for lifting the materials off the carrier’s vehicle.
PHYSICAL INSTALLATION
Foundation
For fixed installations, provide a solid, level foundation.
1. Locate the foundation as close as possible to the liquid to be pumped.
• Provide adequate space for operation, maintenance, and inspection of the pump and equipment.
2. Allow the foundation to completely dry and cure before installing the pump system.
3. Use anchor bolts to attach the pump baseplate to the foundation.
1 Lifting Point 2 Tie Down Points 3 Fork Pockets
1
2
3
Proper Lifting Points
Full Fork Insertion
Risk of severe injury or death.
• When lifting or moving heavy components, use suitable lifting equipment, in good condition, rated for at least 5 times the
weight of the materials being moved.
Risk of bodily injury or property damage.
• Pump installation and operation should only be performed by a qualified individual with experience in pump systems.
• Pumps can develop very high pressure in some situations. Gauges should be installed on the suction and discharge to
monitor pressure.
• Ensure that the foundation is rated to accommodate the operating weight of the package and that it is sized sufficiently for
the weight and loads the package will experience.
• Ensure all pipe loads are fully supported independently of the pump. Use properly rated gaskets and flanges and fully
tighten all bolts when connecting to the pump.

ELECTRICAL INSTALLATION
Piping Installation
5
4. Use a machinist's level on the mounting pads for adjustments as the anchor bolts are tightened.
5. Provide leveling nuts or wedges for mounting the baseplate to the foundation.
6. For steel frames or similar structures, set the pump directly over support beams rigid enough to pre-
vent distortion and misalignment.
For portable skid-mounted configurations, make sure the pump set is level.
Piping Installation
Reference pump manual for specific piping installations. In general, complete the following:
• Ensure couplings are aligned.
NOTE: Generally, alignment is not needed because of the ElectricPAK’s motor stool.
• Properly support all suction and discharge piping to avoid strain on the pump.
• Piping should match the pump inlet and outlet connection sizes.
• Do not restrict suction intake.
NOTE: Do not use concentric reducers going into suction.
• Use isolation joints when needed.
• Orient eccentric reducers downwards.
ELECTRICAL INSTALLATION
Refer to the motor and drive manuals for electrical hazards and instructions.
Pre-Start Verifications
These verifications are supplementary to those found in individual assembly equipment manuals. Ensure all
installation and start-up instructions are completed.
1. Check electrical incoming voltage meets requirements and an adequate ground connection exists.
2. Inspect the overall system for damage during installation.
3. Pressurize the system with the site water to remove any trapped air.
4. If there are any water leaks in the piping, isolate the location and tighten the connections.
5. Verify motor and pump bearings and seal are adequately lubricated according to their respective user
manuals.
6. Ensure all guards are in place prior to energizing equipment. Refer to individual assembly equipment
manual’s for start-up and operation.
Eccentric Reducer
Downward Orientation

MAINTENANCE
503.266.4115 |pioneerpump.com
For technical assistance, parts, or repair, please contact:
10000011973 Rev. 000 04/22 Copyright © 2022, Franklin Electric, Co., Inc. All rights reserved.
MAINTENANCE
Periodic Maintenance
Daily:
• Check all piping connections, pipe supports, and equipment fasteners for tightness.
• Verify the electric motor is aligned correctly.
• Inspect guards and replace if damaged.
• Check all oil quality and levels. If contaminated, replace immediately.
• Follow the instructions on all tags, labels, and decals attached to the equipment.
Monthly (or if sooner, every 500 hours of operation):
• Inspect couplings for wear, degradation, and corrosion. Replace as necessary, following the manu-
facturer’s installation instructions.
Risk of severe injury or death.
• To minimize risk of electrical shock, disconnect power before working on or around the system.
• When lifting or moving heavy components, use suitable lifting equipment, in good condition, rated for at least 5 times the
weight of the materials being moved.
• Never stand or be otherwise located below a hanging load.
Risk of bodily injury or property damage.
• A pressurized system can cause a pump to deadhead.
• Rapidly closing the discharge valve can cause a damaging pressure surge. A dampening arrangement should be provided in
the piping.
• Never use the suction valve to throttle the flow.
• Pump may become hot during operation. Allow pump to cool before servicing.
• Safety glasses, cut-resistant gloves, and safety boots should be worn. Use proper protective gloves and clothing when han-
dling heated parts.
Risk of damage to equipment.
• If the pump package is dropped, impacted, or otherwise mishandled, malfunction can occur.
