SpectrAlert™Electronic Chime/Sounder
For use with the following models:
Chime/Sounder: 12/24 volt: CH12/24
Add suffix “W”for white models.
INSTALLATION AND MAINTENANCE INSTRUCTIONS
A Division of Pittway
3825 Ohio Avenue, St. Charles, Illinois 60174
1-800-SENSOR2, FAX: [phone]
www.systemsensor.com
General Description
The SpectrAlert series notification appliances are designed to meet the
requirements of most agencies governing these devices, including: NFPA,
The National Fire Alarm Code, UL, FM, CSFM, MEA. Also, check with
your local Authority Having Jurisdiction for other codes or standards that
may apply.
The SpectrAlert series can be installed in systems using 12- or 24-volt pan-
els having DC or full-wave rectified (FWR) power supplies.
NOTICE: This manual shall be left with the owner/user of this equipment.
Fire Alarm System Considerations
Temporal and Non-Temporal Coded Signals:
The American National Standards Institute and the National Fire Alarm
Code require that all horns used for building evacuation installed after July
1, 1996, must produce Temporal Coded Signals. Signals other than those
used for evacuation purposes do not have to produce the Temporal Coded
Signal.
Power Supply Considerations
Panels typically supply DC filtered voltage or FWR (full-wave rectified)
voltage. The system design engineer must calculate the number of units
used in a zone based on the type of panel supply. Be certain the sum of
all the device currents do not exceed the current capability of the panel.
Calculations are based on using the device current found in the subsequent
charts and must be the current specified for the type of panel power sup-
ply used.
Specifications
Voltage Range: DC or Full-Wave Rectified
Chime: 8–33 Volts
Operating Temperature: 32˚F to 120˚F (0˚C to 49˚C)
Sound Output: Sound output levels are established at Underwriters Laboratories in their reverberant room. Always use the sound out-
put specified as UL Reverberant Room when comparing products.
Listings: UL 464; Private Mode
Wire Sizes
The designer must be sure that the last device on the circuit has sufficient
voltage to operate the device within its rated voltage. When calculating
the voltage available to the last device, it is necessary to consider the volt-
age drop due to the resistance of the wire. The thicker the wire, the less
the voltage drop. Generally, for purposes of determining the wire size nec-
essary for the system, it is best to consider all of the devices as “lumped”
on the end of the supply circuit (simulates “worst case”).
Typical wire size resistance:
18 AWG solid: Approximately 8 ohms/1,000 ft.
16 AWG solid: Approximately 5 ohms/1,000 ft.
14 AWG solid: Approximately 3 ohms/1,000 ft.
12 AWG solid: Approximately 2 ohms/1,000 ft.
Example: Assume you have 10 devices on a zone and each requires 50
mA average and 2000 Ft. of 14 AWG wiring (total length=outgoing
+return). The voltage at the end of the loop is 0.050 amps per device x
10 devices x 3 ohms/1,000 ft. x 2000 ft =3 volts drop.
Note: If Class A wiring is installed, the wire length may be up to 4 times
the single wire length in this calculation.

D900-00-00 2 I56-0003-002R
24 Volts 33 Volts
Low Med. High Low Med. High
57 61 52 59 61 64
54 57 60 57 60 62
53 55 58 55 58 60
59 61 64 61 63 66
55 57 60 57 59 62
54 56 59 56 58 61
55 57 61 58 60 63
53 55 58 55 57 60
52 54 57 54 56 59
56 58 62 58 60 64
53 55 58 56 58 62
54 56 60 56 59 61
65 68 70 68 70 74
56 59 62 58 60 64
54 57 60 56 55 61
51 52 58 52 54 60
8 Volts 12 Volts
Tone Low Med. High Low Med. High
1.2K Repeating 1 Second Chime 51 52 55 53 54 56
1.0K Repeating 1 Second Chime 48 50 54 51 52 54
0.8K Repeating 1 Second Chime 47 47 53 49 51 52
1.2K Repeating 1/4 Second Chime 53 54 58 55 57 59
1.0K Repeating 1/4 Second Chime 49 50 54 51 53 54
0.8K Repeating 1/4 Second Chime 48 50 53 50 52 53
1.2K Temporal 3 Chime 51 52 56 52 54 55
1.0K Temporal 3 Chime 48 49 54 49 51 51
0.8K Temporal 3 Chime 46 47 51 48 50 51
1.2K Single Stroke Chime 52 53 58 52 54 56
1.0K Single Stroke Chime 47 48 53 50 51 59
0.8K Single Stroke Chime 47 48 53 49 50 52
3.0K Continuous Mechanical 56 57 61 59 60 67
3.0K Temporary Mechanical 51 52 56 53 54 61
0.5K Continuous Mechanical 48 49 53 51 52 56
0.5K Temporary Mechanical 45 47 51 47 49 53
SpectrAlert Electronic Chime Sound Output Guide
Chime Selection
Chimes are factory set for high volume, 1000Hz, 1 second chime. Tones
may be selected by making the appropriate settings on the Dip Switch
located on the printed circuit board. The settings required for the available
tone options are as follows:
SpectrAlert Chime Switch Settings
The same number of devices using 12 AWG wire will produce only 2 volts
drop. The same devices using 18 AWG wire will produce 8 volts drop.
Consult your panel manufacturer’s specifications, as well as SpectrAlert’s
operating voltage range to determine acceptable voltage drop.
SpectrAlert Electronic Chime Current Draw*
12VDC: 18–31mA
24VDC: 31–61mA
*Average current draw varies with tones selected. Current ratings per
System Sensor testing at 12VDC and 24VDC.
SpectrAlert Chime Tones
Repeating 1-Second Chime
Repeating 1
/4-Second Chime
Temporal 3 Chime
Single Stroke Chime
Continuous 500Hz Mechanical and 3kHz mechanical
Temporal 500Hz mechanical and 3kHz mechanical
Scale:
1 second
Switch 1=on 0=off
1234Hz Type
11111.2k Repeating 1 second chime
10111.0k Repeating 1 second chime
11010.8k Repeating 1 second chime
10011.2k Repeating 1/4second chime
11101.0k Repeating 1/4second chime
10100.8k Repeating 1/4second chime
11001.2k Temporal 3 chime
10001.0k Temporal 3 chime
01110.8k Temporal 3 chime
00111.2k Single Stroke Chime
01011.0k Single Stroke Chime
00010.8k Single Stroke Chime
01103.0k Electromechanical Continuous
00103.0k Electromechanical Temporal 3
01000.5k 500 Hz, Continuous
00000.5K 500 Hz, Temporal 3
VOLUME
SWITCH
56
00
LOW
10MED
11HIGH
NOTE: Factory default setting is 1.0K Repeating 1 Second Chime set at High volume.

D900-00-00 3 I56-0003-002R
4-INCH BACK BOX
BBS
A
A
LOCKING RIB SLOT LOCKING RIB
Chime surface mount:
1. Mount skirt to back box with screws A.
2. Complete field wiring.
3. Insert locking rib on unit into slot on skirt.
4. Press into skirt; unit will make a “click”when it has locked into place.
(Note: Chime and skirt may also be mounted to a 2-inch box using screws
B instead of screws A.)
4-INCH BACK BOX
WALL OPENING MUST
EQUAL PLATE OPENING
D-MP
LOCKING RIB SLOT LOCKING RIB
A
A
Chime with universal mounting plate:
1. Mount plate to back box using screws A, making sure wall opening is
equal to the plate opening. 2. Complete field wiring.
3. Insert locking rib into slot on plate.
4. Press into plate, unit will make a “click”when it has locked into
place.
2-INCH BACK BOX
WALL OPENING MUST
EQUAL PLATE OPENING
S-MP
LOCKING RIB SLOT LOCKING RIB
B
B
Chime direct mount:
1. Mount plate to back box using screws B.
2. Break off four tabs from unit.
3. Complete field wiring, making sure wall opening is large enough for ter-
minals to fit through.
4. Insert locking rib into slot on plate.
5. Press into plate; unit will make a “click”when it has locked into place.
Screw types used for mounting:
A = 8-32 x 3⁄4flat head
B = 6-32 x 15⁄16 pan head
Mounting Diagrams:
Mounting
1. The chime is intended for mounting to a standard 21/2″deep single-
gang box which allows sufficient clearance for conduit entrance.
2. The chime is compatible with DC line supervision, is polarized, and
has terminals marked with polarity. Apply positive supply voltage to
the (+) terminal and negative supply voltage to the (–) terminal. (See
Figure 1.)
3. Mount the chime to the electrical outlet box using the two mounting
screws supplied.
4. Field repair of the chime should not be attempted. Return to factory
for repair or replacement.
*NOTE: Shown with control panel in alarm. Panel polarity reversed in
supervisory condition.
Figure 1:
From
control
panel
or
previous
device*
To
EOL
or
Next
Device
A78-2670-00
A78-2672-00
A78-2671-00
Figure 2: Removal of horns and strobes from mounting plates:
To remove units from mounting plates, insert screwdriver as shown to
unlock snap. While pushing in screwdriver to release the snap, pull back
on the horn/strobe. Hinge the horn/strobe module, disengage the Locking
Rib, and lift the horn/strobe away from the mounting plate.
INSERT SCREWDRIVER
PULL HORN/STROBE UNIT
SNAP INSERT SCREWDRIVER
TO REMOVE
LOCKING RIB
LOCKING RIB SLOT
A78-2673-00

D900-00-00 4 I56-0003-002R
©2000 System Sensor
The chime will not work without power. The chime gets its power from
the fire/security panel monitoring the alarm system. If power is cut off
for any reason, the chime will not provide the desired audio or visual
warning.
The chime may not be heard. The loudness of the chime meets (or
exceeds) current Underwriters Laboratories’ standards. However, the
The Limitations of Electronic Chimes
WARNING
Three-Year Limited Warranty
System Sensor warrants its enclosed electronic chime to be free from
defects in materials and workmanship under normal use and service for a
period of three years from date of manufacture. System Sensor makes no
other express warranty for this electronic chime. No agent, representative,
dealer, or employee of the Company has the authority to increase or alter
the obligations or limitations of this Warranty. The Company’s obligation
of this Warranty shall be limited to the repair or replacement of any part
of the electronic chime which is found to be defective in materials or
workmanship under normal use and service during the three year period
commencing with the date of manufacture. After phoning System Sensor’s
toll free number 800-SENSOR2 (736-7672) for a Return Authorization
number, send defective units postage prepaid to: System Sensor, Repair
Department, RA #__________, 3825 Ohio Avenue, St. Charles, IL 60174.
Please include a note describing the malfunction and suspected cause of
failure. The Company shall not be obligated to repair or replace units
which are found to be defective because of damage, unreasonable use,
modifications, or alterations occurring after the date of manufacture. In no
case shall the Company be liable for any consequential or incidental dam-
ages for breach of this or any other Warranty, expressed or implied what-
soever, even if the loss or damage is caused by the Company’s negligence
or fault. Some states do not allow the exclusion or limitation of incidental
or consequential damages, so the above limitation or exclusion may not
apply to you. This Warranty gives you specific legal rights, and you may
also have other rights which vary from state to state.
chime may not alert a sound sleeper or one who has recently used drugs
or has been drinking alcoholic beverages. The chime may not be heard if
it is placed on a different floor from the person in hazard or if placed too
far away to be heard over the ambient noise such as traffic, air condition-
ers, machinery or music appliances that may prevent alert persons from
hearing the alarm. The chime may not be heard by persons who are hear-
ing impaired.
Please refer to insert for the Limitations of Fire Alarm Systems
