PIXELHUE Flex-View F Series User manual

Flex-View Event Presentation
Switching Solution
Flex-View Seamless Switchers
Event Management Software Triton
Event Controller
User Manual

www.pixelhue.com
i
Copyright © 2023 Pixelhue Technology Ltd. All Rights Reserved.
No part of this document may be copied, reproduced, extracted or transmitted in any form or by any
means without the prior written consent of Pixelhue Technology Ltd (hereinafter referred to as
PIXELHUE).
Trademarks
is a trademark of Pixelhue Technology Ltd.
Brand and product names mentioned in this manual may be trademarks, registered trademarks or
copyrights of their respective holders.
Statement
Thank you for choosing PIXELHUE products. This document is intended to help you understand and use
the products. PIXELHUE may make improvements and/or changes to this document at any time and
without notice. If you experience any problems in use or have any suggestions, please contact us via
the contact information given in this document. We will do our best to solve any issues, as well as
evaluate and implement any suggestions.
This document could contain technical inaccuracies or typographical errors. Changes are periodically
made to the information in this document; these changes are incorporated in new editions of this
document.
The latest edition of user manuals can be downloaded from the official website of PIXELHUE.

Flex-View Event Presentation Switching Solution
User Manual
Contents
www.pixelhue.com
ii
Contents
Contents.............................................................................................................................................................ii
1 General........................................................................................................................................................... 1
1.1 About This Manual................................................................................................................................ 1
1.2 Version History...................................................................................................................................... 1
1.3 Symbols and Pictures........................................................................................................................... 2
2 Safety ............................................................................................................................................................. 4
2.1 General Considerations ........................................................................................................................ 5
2.1.1 General Safety.............................................................................................................................. 5
2.1.2 Environmental Requirements...................................................................................................... 5
2.1.3 Device Safety ............................................................................................................................... 6
2.1.4 Personal Safety............................................................................................................................ 6
2.2 Device Carrying ..................................................................................................................................... 7
2.3 Device Mounting ................................................................................................................................... 7
2.3.1 Mounting on a Desktop ............................................................................................................... 7
2.3.2 Mounting into a Rack................................................................................................................... 8
2.3.3 Grounding..................................................................................................................................... 8
2.4 Cable Requirements.............................................................................................................................. 8
2.4.1 Power Cords................................................................................................................................. 8
2.4.2 Signal Cables ............................................................................................................................... 9
2.4.3 Miscellaneous.............................................................................................................................. 9
2.5 Electrical Safety .................................................................................................................................. 10
2.5.1 Battery ........................................................................................................................................ 10
2.5.2 Electromagnetic Interference ................................................................................................... 10
2.5.3 Anti-Static................................................................................................................................... 10
2.6 Unpacking and Inspection.................................................................................................................. 10
2.6.1 Unpacking .................................................................................................................................. 10
2.6.2 Inspection................................................................................................................................... 10
2.7 Device Labels ...................................................................................................................................... 11
2.8 Notes and Cautions ............................................................................................................................ 11
2.8.1 Installation Notes....................................................................................................................... 11
2.8.2 FCC Caution ............................................................................................................................... 12
2.8.3 Others ......................................................................................................................................... 12
3 Terms and Definitions................................................................................................................................. 13
4 Overview....................................................................................................................................................... 15

Flex-View Event Presentation Switching Solution
User Manual
Contents
www.pixelhue.com
iii
4.1 Solution Overview ............................................................................................................................... 16
4.2 Control Overview................................................................................................................................. 17
4.3 Initial Inspection.................................................................................................................................. 17
5 Hardware Introduction ................................................................................................................................ 18
5.1 F8 ......................................................................................................................................................... 19
5.1.1 Front Panel................................................................................................................................. 19
5.1.2 Rear Panel .................................................................................................................................. 20
5.2 F4 ......................................................................................................................................................... 23
5.2.1 Front Panel................................................................................................................................. 23
5.2.2 Rear Panel .................................................................................................................................. 24
5.3 F4 Lite .................................................................................................................................................. 25
5.3.1 Front Panel................................................................................................................................. 25
5.3.2 Rear Panel .................................................................................................................................. 26
5.4 Input Cards .......................................................................................................................................... 30
5.4.1 SL-DVI Quad Input Card............................................................................................................. 30
5.4.2 HDMI 1.3 Quad Input Card ........................................................................................................ 31
5.4.3 HDMI 1.4 Quad Input Card ........................................................................................................ 32
5.4.4 3G-SDI Quad Input Card ............................................................................................................ 33
5.4.5 12G-SDI Input Card .................................................................................................................... 33
5.4.6 DP 1.1 Quad Input Card............................................................................................................. 34
5.4.7 Dual 4K HDMI 2.0/DP 1.2 Input Card ....................................................................................... 35
5.5 Output Cards ....................................................................................................................................... 37
5.5.1 SL-DVI Quad Output Card.......................................................................................................... 37
5.5.2 HDMI 1.3 Quad Output Card ..................................................................................................... 37
5.5.3 DVI (HDMI 1.4) Quad Output Card............................................................................................ 38
5.5.4 HDMI 1.4 Quad Output Card ..................................................................................................... 39
5.5.5 3G-SDI Quad Output Card.......................................................................................................... 41
5.5.6 12G-SDI Output Card ................................................................................................................. 41
5.5.7 DVI (HDMI 1.4)/OPT Output Card............................................................................................. 43
5.5.8 4K HDMI 2.0/OPT Output Card II.............................................................................................. 44
5.6 MVR Cards........................................................................................................................................... 45
5.7 AUX Cards ........................................................................................................................................... 46
5.7.1 AUX HDMI Output Card ............................................................................................................. 46
5.7.2 AUX SL-DVI Output Card ........................................................................................................... 46
6 Menu Operations......................................................................................................................................... 48
6.1 F8 ......................................................................................................................................................... 49
6.1.1 Home Screen.............................................................................................................................. 49
6.1.2 Main Menu ................................................................................................................................. 51
6.2 F4 ......................................................................................................................................................... 59
6.3 F4 Lite .................................................................................................................................................. 59
6.3.1 Home Screen.............................................................................................................................. 59
6.3.2 Use Menu System...................................................................................................................... 61

Flex-View Event Presentation Switching Solution
User Manual
Contents
www.pixelhue.com
iv
6.3.3 Main Menu ................................................................................................................................. 62
7 Event Management Software Triton .......................................................................................................... 69
7.1 Introduction ......................................................................................................................................... 70
7.1.1 Obtain Software ......................................................................................................................... 70
7.1.2 Install Software.......................................................................................................................... 70
7.2 Software Operations........................................................................................................................... 71
7.2.1 Overview..................................................................................................................................... 71
7.2.2 User Interface Introduction ....................................................................................................... 71
7.2.3 Controls Introduction................................................................................................................. 73
7.2.4 Device ......................................................................................................................................... 74
7.2.5 Input............................................................................................................................................ 82
7.2.6 Output......................................................................................................................................... 90
7.2.7 Screen......................................................................................................................................... 95
7.2.8 Layer ......................................................................................................................................... 101
7.2.9 Multiviewer (MVR for Short).................................................................................................... 122
7.2.10 Settings .................................................................................................................................. 126
8 U3 Event Controller ................................................................................................................................... 130
8.1 Hardware Introduction...................................................................................................................... 131
8.1.1 Overview................................................................................................................................... 131
8.1.2 Front View ................................................................................................................................ 131
8.1.3 Rear View ................................................................................................................................. 132
8.1.4 Side View.................................................................................................................................. 132
8.2 Lights and Status LEDs..................................................................................................................... 133
8.2.1 Lights........................................................................................................................................ 133
8.2.2 Status LEDs.............................................................................................................................. 133
8.3 Touchscreens.................................................................................................................................... 133
8.4 Control Overview............................................................................................................................... 134
8.4.1 Buttons ..................................................................................................................................... 134
8.4.2 Mouse and Keyboard............................................................................................................... 140
8.4.3 Touchscreens .......................................................................................................................... 140
8.5 Connections ...................................................................................................................................... 141
8.5.1 Connect with F8/F4 ................................................................................................................. 141
8.5.2 Connect with F4 Lite................................................................................................................ 141
8.6 Operations ......................................................................................................................................... 142
8.6.1 User Interface Introduction ..................................................................................................... 142
8.6.2 Virtual Event Controller............................................................................................................ 143
8.6.3 Peripheral Management.......................................................................................................... 145
8.6.4 KVM Control............................................................................................................................. 147
8.6.5 How to add devices? ............................................................................................................... 148
8.6.6 How to add screens?............................................................................................................... 148
8.6.7 How to add layers? .................................................................................................................. 149
8.6.8 How to save and load presets?............................................................................................... 151

Flex-View Event Presentation Switching Solution
User Manual
Contents
www.pixelhue.com
v
9 Maintenance and Update.......................................................................................................................... 152
9.1 Device Maintenance ......................................................................................................................... 153
9.1.1 Card Installation and Replacement ........................................................................................ 153
9.1.2 Power Supply Replacement .................................................................................................... 153
9.1.3 Flight Case Installation............................................................................................................ 154
9.2 Firmware Update............................................................................................................................... 155
9.2.1 Update via USB Drive............................................................................................................... 155
9.2.2 Update in Triton ....................................................................................................................... 156
9.2.3 Update on U3 Event Controller................................................................................................ 156
ASpecifications ........................................................................................................................................... 157
A.1 Flex-View Seamless Switchers ........................................................................................................ 157
A.2 U3 Event Controller........................................................................................................................... 158
BInput Source Features .............................................................................................................................. 160
CCard Support List...................................................................................................................................... 163
DTroubleshooting........................................................................................................................................ 164

Flex-View Event Presentation Switching Solution
User Manual
1 General
www.pixelhue.com
1
1 General
Overview
About This Manual
Version History
Symbols and Pictures

Flex-View Event Presentation Switching Solution
User Manual
1 General
www.pixelhue.com
1
1.1 About This Manual
This user manual describes how to operate the flex-view seamless switchers and
event controller, as well as how to use the matched event management software
Triton. This manual is designed to be a reference for your daily use of our products. It
contains a complete description of the hardware and control software, as well as
includes all the necessary instructions on how to update firmware, install and replace
cards and power supplies.
Note
Always check for the latest version of all documents at www.pixelhue.com.
1.2 Version History
Version
Date
Changes
V 2.3.0
2023-3-30
Added the descriptions for 12G-SDI Output Card.
Added the descriptions for the cut and fill, layer
resource usage monitoring and log exporting functions.
Added the descriptions for the input quantization range
parameter.
Updated the user interface pictures in Chapter 7 and
Chapter 8.
Optimized the descriptions for the functions of the TOP
and BOTTOM buttons on the event controller.
V 2.2.0
2022-11-9
Added the descriptions for 12G-SDI Input Card.
Added the descriptions for the HDR format conversion,
sync signal status display, user key, screen frame rate
switching, independent RGB adjustment of brightness
and contrast, device backup and input source backup,
MVR window aspect ratio adjustment functions.
Updated the rear panel pictures of the F series devices.
Updated the descriptions and user interface pictures in
Chapter 7.
Deleted the input, output and screen Gamma
adjustment descriptions.
Deleted the descriptions for 4K HDMI 2.0/DP 1.2 Input
Card.
Deleted the descriptions for 4K HDMI 2.0/OPT Output
Card.
Added the Appendix B Input Source Features.
V 2.1.2
2022-5-16
Updated the virtual event controller and peripheral
management descriptions in Chapter 8.
Added the KVM control descriptions in Chapter 8.
V 2.1.1
2022-4-25
Added the Notes and Cautions section to Chapter 2.

Flex-View Event Presentation Switching Solution
User Manual
1 General
www.pixelhue.com
2
Updated the battery safety descriptions.
Updated some descriptions and data of the input and
output cards.
V 2.1.0
2022-3-10
Added the descriptions for HDMI 1.4 Quad Input Card.
Added the descriptions for 3G-SDI Quad Output Card.
Updated the user interface of the event management
software Triton in Chapter 7.
Optimized the resource algorithms for the 4K/DL layers
and the cropped layers.
Added support for connector capacity switching for the
4K connectors.
Added support for UMD display on the connected
monitors.
Added new layer border effects.
Added support for the output mapping function.
Added support for the HDCP function on the inputs and
outputs.
Added support for the layer copying and mirroring
functions.
Added support for the output connector copying
function.
Added support for controlling multiple F series devices
simultaneously on a single U3 event controller or a
control PC.
Updated the color code descriptions for the preset
buttons on the U3 event controller.
V 2.0.0
2021-9-30
Updated the terms and definitions in Chapter 3.
Added the descriptions for 4K HDMI 2.0/OPT Output
Card II.
Updated the descriptions for DP 1.1 Quad Input Card.
Updated the user interface and descriptions of the event
management software Triton in Chapter 7.
Added the descriptions for flight case installation.
V 1.1.0
2021-3-22
Updated the power modules for the F series devices.
V 1.0.0
2021-1-6
First release
1.3 Symbols and Pictures
Symbol Overview
Danger
Indicates a hazard with a high level of risk, which if not
avoided, will result in death or serious injury.
Warning
Indicates a hazard with a medium or low level of risk, which if
not avoided, could result in minor or moderate injury.

Flex-View Event Presentation Switching Solution
User Manual
1 General
www.pixelhue.com
3
Caution
Indicates a potentially hazardous situation, which if not
avoided, could result in equipment damage, data loss,
performance degradation, or unexpected results.
Note
Provides additional information to emphasize or supplement
important points of the main text.
Picture Overview
Images and pictures given in this manual are used for illustration purposes only. The
actual product may vary due to product enhancement. The content of the images can
be slightly different from reality, such as device types, installed modules, form and
position of software windows on the screen.

Flex-View Event Presentation Switching Solution
User Manual
2 Safety
www.pixelhue.com
4
2 Safety
Overview
General Considerations
Device Carrying
Device Mounting
Cable Requirements
Electrical Safety
Unpacking and Inspection
Device Labels
Notes and Cautions

Flex-View Event Presentation Switching Solution
User Manual
2 Safety
www.pixelhue.com
5
2.1 General Considerations
To ensure that you can use this product correctly and safely, please be sure to
observe the following precautions:
Before performing any operation, make sure that you have read all the operating
instructions provided by the device, especially the instructions that may endanger
the personal safety and device safety, such as dangers, warnings and cautions, to
minimize the probability of accidents.
All the operations must conform to local safety codes. When the safety and
precautionary measures described in this manual conflict with local safety codes,
please follow the local codes.
The personnel responsible for installing and maintaining the device must be
professionals who have been trained and have mastered the correct operation
methods and all safety precautions. Only trained and qualified personnel can
perform device installation and maintenance.
This device must be used in an environment that meets the design specifications;
otherwise, it may cause device failure. The resulting device function abnormalities
or component damage, personal safety accidents, property losses and other
situations are not included within the scope of the device warranty.
2.1.1 General Safety
When operating the device, you must strictly abide by the local laws and
regulations. The safety precautions described in this manual are only a
supplement to the local safety laws and regulations.
The "Danger", "Warning" and "Caution" items described in this manual are only
supplementary instructions for all safety precautions.
To ensure personal and device safety, please strictly follow all the safety
precautions on the device labels and described in this manual when installing the
device.
2.1.2 Environmental Requirements
Ensure adequate air flow in the equipment room.
Take necessary measures to prevent dust, water and static electricity.
Avoid long-term direct sunlight.
Keep the device away from heat and ignition sources.
Do not place the device in an explosive atmosphere.
Do not place the device in a corrosive environment.
Do not place the device in a strong electromagnetic environment.

Flex-View Event Presentation Switching Solution
User Manual
2 Safety
www.pixelhue.com
6
The following table outlines the physical environment where the device can be safely
stored and operated.
Environmental
Requirements
Operating Environment
Storage Environment
Temperature
0°C to 45°C
–20°C to +70°C
Humidity
0% RH to 80% RH,
non-condensing
0% RH to 95% RH,
non-condensing
Air Cleanliness
ISO 14644-1 ISO 9
N/A
2.1.3 Device Safety
Before operating, fix the device on the floor or other stable objects, such as a wall
or mounting bracket.
During transportation and use of the device and its packaging, the device must be
fixed stably to avoid falling.
Do not step on, hit and violently operate the device and its packaging to prevent
damage to the device or packaging box.
Do not block the ventilation openings during operation.
Tighten the board or card screws with a tool.
After the installation, remove the empty packing materials from the device area.
Save the packing box and materials for possible storage and transportation in the
future.
Always wear anti-static wrist bands and insulating gloves when touching the
static-sensitive components.
Avoid dropping any object into the chassis.
Keep the device away from conductors that are easy to induce lightning to avoid
lightning strikes to the device.
Do not make the circuit faces of the boards or cards contact each other.
Do not touch the circuit, components, connectors or wiring slots of the boards or
cards with bare hands.
Do not repair the device without authorization. Only trained professionals can
maintain the device. You can contact Pixelhue at any time if needed.
Always use the spare parts recommended by Pixelhue.
Regularly clean the dust on the heat dissipation holes to prevent the dust from
blocking the holes and thus affect the heat dissipation of the device.
2.1.4 Personal Safety
Place the device in a stable location to prevent personal injury caused by falling.
Avoid bare wires and maintain or replace them in time when they are damaged.
Do not operate the device and connect cables outdoors under thunderstorms.
Do not wear watches, rings, or other metal jewelry when installing spare parts or
maintaining the device.

Flex-View Event Presentation Switching Solution
User Manual
2 Safety
www.pixelhue.com
7
2.2 Device Carrying
Do not relocate a powered device, and do not take any objects that may cause
danger to the relocation.
Always pay attention to the wheels at the bottom of the flight case during
transportation to avoid them being jammed by stones or deformed due to external
forces.
Always hold the handles of the flight case firmly when pushing a flight case with
wheels. Do not stack other devices on the flight case.
The relocated device should be repacked in the original factory packaging.
When handling or placing the boards or cards, bare board components or
modules, always package them individually.
When carrying the device with your bare hands, always wear protective gloves to
avoid injury.
When carrying the device, handle it gently and always hold the handles of the
device or drag the bottom edge of the device. Do not hold the handles of a device
component.
When the device weight exceeds the carrying limit of a single person, carry it with
multiple people or use a carrying tool.
When using a forklift or handcart for transportation, place the device stably to
ensure the device will not tip over.
The following table lists the maximum weights that adults can carry at a time
specified by some organizations for your reference.
Organization
Weight
CEN (European Committee for Standardization)
25 kg/55.13 lb
ISO (International Organization for Standardization)
25 kg/55.13 lb
NIOSH (National Institute for Occupational Safety and Health)
23 kg/50.72 lb
HSE (Health and Safety Executive)
25 kg/55.13 lb
General Administration of Quality Supervision, Inspection and
Quarantine of the People’s Republic of China
Male: 15 kg/33.08 lb
Female: 10 kg/22.05 lb
2.3 Device Mounting
When the device is installed on a desktop or into a rack, the desktop or rack must
bear at least 4 times the device weight.
2.3.1 Mounting on a Desktop
Ensure the stability and grounding of the desktop or working table.
Ensure that the device is placed horizontally and do not turn it over or hang it on
the wall.
Do not place other objects on the device.

Flex-View Event Presentation Switching Solution
User Manual
2 Safety
www.pixelhue.com
8
Do not put water cups, beverages and other containers with liquid close to or on
the device to avoid liquid leakage and thus cause safety hazards.
If any object or liquid accidentally enters the device, stop using the device and
disconnect the power cord and all cables connected to the device immediately,
and then contact the after-sales personnel.
When handling a flight case with wheels, please lock and fix the wheels to prevent
the device from sliding.
When stacking, ensure all the devices are stacked stably to avoid device damage
and personal injury caused by falling.
2.3.2 Mounting into a Rack
The rack must be fixed properly to avoid tilting and falling, and thus cause
personal injury and device damage.
When a device is mounted into a rack, all mounting holes must be fixed with
screws.
Ensure the rack is well ventilated. It is recommended to reserve at least 1U space
between the stacking devices, and the heat dissipation vents must not be
obstructed and keep at least 10 cm distance from other objects.
2.3.3 Grounding
Connect the grounding wire first when installing a device, and disconnect the
grounding wire at last when removing the device.
The connecting surface of the grounding wire and the device must have good
conductivity. Spray painting is strictly prohibited, and there must be sufficient
fastening force between the connecting parts.
Do not operate the device when the grounding conductor is not installed.
There must be no joints in the middle of the grounding wire, and it is strictly
prohibited to install a switch or fuse on the grounding wire.
For devices using a three-pin socket, ensure that the ground terminal in the three-
pin socket is well grounded.
2.4 Cable Requirements
2.4.1 Power Cords
Warning
Do not install or remove the power cord when the device is powered on. When the
power cord core contacts the conductor, an electric arc or spark will be generated
which may result in fire or eye injury.
Protect the power cord properly to prevent it from being punctured to avoid
personal injury or fire caused by a short circuit.
To ensure the safety of the device and personnel, be sure to use the matched
power cord.

Flex-View Event Presentation Switching Solution
User Manual
2 Safety
www.pixelhue.com
9
User-supplied cables must comply with local cable regulations and device cable
requirements.
Before installing or removing the power cord, turn off the device power first.
Check the electrical plug regularly and wipe off the dirt or dust accumulated on
the plug.
Before connecting the power cord, read the labels or markings on the power cord
to make sure it is a matched one.
The device is intended to operate from an AC power source with a voltage range of
AC 100–240V~, 50/60Hz. Various standard plugs are shown in the figure below.
US NEMA5/15
Europe CEE 7
China GB 2099
UK BS 1363
E Earth N Neutral L Live
2.4.2 Signal Cables
Before using a DVI signal cable, check whether the pins on the cable connector
are vertical and even. If not, please replace the cable.
Before connecting the signal cable to the device, check whether there is any
object in the device connector. If yes, remove the object first.
If the signal cable has not been used for a long time, discharge static electricity
before using it.
Under normal working conditions of the device, it is recommended that non-
technical professionals do not perform hot-swapping to avoid device damage.
2.4.3 Miscellaneous
Signal cables must be bound separately from strong current cables or high
voltage cables.
When the temperature is too low, severe shock and vibration may cause brittle
cracking of the plastic sheath of the cable. All cables should be laid and installed
when the temperature is above zero.
If the storage temperature of the cable is below zero, the cable must be moved to
room temperature and stored for more than 24 hours before laying and
installation.
When carrying cables, especially in a low-temperature environment, always handle
the cable with care. Violent handling, such as pushing down the cables directly
from a high place, is prohibited.

Flex-View Event Presentation Switching Solution
User Manual
2 Safety
www.pixelhue.com
10
2.5 Electrical Safety
2.5.1 Battery
The battery is not intended to be replaced.
Always follow the relevant instructions to dispose of batteries.
Disposal of a battery into fire or a hot oven, or mechanically crushing or cutting of
a battery can result in an explosion.
Leaving a battery in an extremely high temperature surrounding environment can
result in an explosion or the leakage of flammable liquid or gas.
A battery subjected to extremely low air pressure may result in an explosion or the
leakage of flammable liquid or gas.
2.5.2 Electromagnetic Interference
Keep the device away from transformers, high-voltage power lines and high-
current devices.
Keep the device away from high-power broadcast transmitters.
If there is a mobile communication transmitter around the device, its interference
degree should meet the requirements of relevant standards. If needed, take
necessary measures to prevent interference, such as shielding and isolation.
When using hand-held wireless communication devices, such as interphones,
keep at least 30 cm away from the device.
2.5.3 Anti-Static
Always wear anti-static wrist bands and insulating gloves when touching the
static-sensitive components.
Always hold the board by the edges to avoid touching the circuits or components,
and do not touch the chip with your hands.
The disassembled board must be packaged with anti-static packaging material
before storage or transportation.
2.6 Unpacking and Inspection
2.6.1 Unpacking
After receiving the device, check whether the packing box is damaged. If there is
any damage, do not open the box and contact the carrier in time to confirm the
damage to the device and matters related to compensation.
After unpacking, save the packing box and materials for possible storage and
transportation in the future.
2.6.2 Inspection
When the packing box is in perfect condition, unpack the box. Check the
appearance of the device for damage. If there is damage, please contact the
salesperson.

Flex-View Event Presentation Switching Solution
User Manual
2 Safety
www.pixelhue.com
11
Check the box contents according to the packing list described in the certificate of
approval. If any item is missing, please contact the salesperson in time.
2.7 Device Labels
Labels
Description
Shock hazard
Multiple power inputs
The device is powered by multiple power supplies.
Disconnect all power cords when the device is powered off.
Warranty void if removed
Do not open the chassis. If this label is damaged, the device
will not be covered by the warranty.
Grounding
The two ends of the grounding wire are connected to the
device and the grounding point respectively, which means
that the device must be grounded through the grounding
point to ensure the normal operation of the device and the
personal safety of the operators.
Sensitive electronic device
Keep the device away from areas with strong
electromagnetic radiation to avoid electromagnetic
interference and thus affect the image output quality.
Device carrying
The device needs to be carried by multiple people.
2.8 Notes and Cautions
2.8.1 Installation Notes
When the product needs to be installed on the rack, 8 screws at least M6*16 should
be used to fix it. The rack for installation shall bear at least four times the total weight
of the mounted equipment.
a) Elevated Operating Ambient - If installed in a closed or multi-unit rack assembly,
the operating ambient temperature of the rack environment may be greater than
room ambient. Therefore, consideration should be given to installing the
equipment in an environment compatible with the maximum ambient
temperature (Tma) specified by the manufacturer.
b) Reduced Air Flow - Installation of the equipment in a rack should be such that
the amount of air flow required for safe operation of the equipment is not
compromised.
c) Mechanical Loading - Mounting of the equipment in the rack should be such that
a hazardous condition is not achieved due to uneven mechanical loading.

Flex-View Event Presentation Switching Solution
User Manual
2 Safety
www.pixelhue.com
12
d) Circuit Overloading - Consideration should be given to the connection of the
equipment to the supply circuit and the effect that overloading of the circuits
might have on overcurrent protection and supply wiring. Appropriate
consideration of equipment nameplate ratings should be used when addressing
this concern.
e) Reliable Earthing - Reliable earthing of rack-mounted equipment should be
maintained. Particular attention should be given to supply connections other
than direct connections to the branch circuit (e.g. use of power strips).
2.8.2 FCC Caution
Any changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class
A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at his
own expense.
2.8.3 Others
This is Class A product. In a domestic environment, this product may cause radio
interference in which case the user may be required to take adequate measures.
This product can only be placed horizontally. Do not mount vertically or upside-
down.
Please read the specifications thoroughly and use the product in accordance with
the requirements. If you have any questions about the specifications, please
contact us immediately. If you use the product improperly, not following the
requirements, or for illegal purposes, you shall be solely responsible for any
consequences arising therefrom.
If the product does not have the relevant certifications required by the countries or
regions where it is to be sold, please contact PIXELHUE to confirm or address the
problem. Otherwise, the customer shall be responsible for the legal risks caused
or PIXELHUE has the right to claim compensation.

Flex-View Event Presentation Switching Solution
User Manual
3 Terms and Definitions
www.pixelhue.com
13
3 Terms and Definitions
PVW
PVW is an abbreviation for Preview. The PVW area displays the pre-
editing content before it is sent to PGM.
PGM
PGM is an abbreviation for Program. The PGM area displays the real-
time output image.
Take
Take is an action of sending the PVW content to PGM with a transition
effect.
Cut
Cut is an action of sending the PVW content to PGM directly, without
any transition effect.
T-Bar
T-bar is a lever that manually controls the progress of sending PVW to
PGM.
LOGO
LOGO is a special layer with the highest priority and is displayed in
front of all other layers. LOGO consumes no processing resources and
displays an unscaled image on the screen.
BKG
BKG is an abbreviation for background. BKG is a special layer that has
the lowest priority and is displayed beneath all other layers. BKG
consumes no processing resources and fills the whole screen.
MVR
MVR is an abbreviation for Multiviewer. An MVR connector is used to
connect a confidence monitor for displaying the specific input or
output content, such as the presenter's laptop.
AUX
AUX is an abbreviation for auxiliary. An AUX connector is used to
output the input source, PVW or PGM, to a specified monitor, such as
a teleprompter.
AOI
AOI is an acronym for Area of Interesting. AOI allows users to view a
specific output area they are interested in.
Aspect Ratio
Aspect ratio is the ratio of a layer/image width to its height. It is
commonly expressed as two numbers separated by a colon, as in 16:9.
Contrast
Contrast defines the difference between the darkest and brightest
areas of an image displayed on the screen. The larger this value is, the
bigger this difference will be.
Gamma
Gamma defines the degree of distortion of the image color. The larger
this value is, the more distorted the color will be.
Hue
Hue defines the gradation or variety of the image color. The larger this
value is, the more intense the color will be.
