Pknight WIFI-DMX Easynode PLUS User manual

User Manual
wifi-dmx easynode
PLUS

Introduction:
Congratulations and
thank you for purchasing the Pknight WiFi-
DMX EasyNode. The plug is a wireless bridge
between your WiFi device and all lighting
products equipped with DMX512.It is the ideal
solution for film and television video lights or
for any event where you don’t want data cables
to be seen,and when it is not easy to run data
cables to your xture(s) location. The EasyNode
creates its own local secure Wi-Fi network so
that you can use Your iPhone or iPad or Android
phone or a laptop or Tablet PC as a lighting
controller using many DMX apps.
The app we can use:
Customer Support:
Pknight
Products,LLC provides a toll free customer
support,to provide set up help and to answer
any question should you encounter problems
during your set up or initial operation.You may
also visit us on the web at www.Pknightpro.com
for any comments or suggestions.
E-mail: [email protected]/[email protected]
We will contact you within 24 hours
Pknight® WIFI-DMX EasyNodePknight® WIFI-DMX EasyNode
Introduction Introduction
Pknight
®
WiFi-DMX EasyNode Manual Page 1
Pknight
®
WiFi-DMX EasyNode Manual Page 2
*important*
Default IP Address:192.168.4.1
Default Hotspot Password:PKNIGHT.WIFI
*note*There are many other apps not on the list
own production free app

Indicators General Instructions
1Battery Indicator
5Charging Port
Connect the provided power supply to
this hole.5V DC
3Antenna
2Power Switch Button
Single click to turn on, double click to
turn off
4Channel Button
Short press this button, the controller will
change the WiFi frequency.
Pknight
®
WiFi-DMX EasyNode Manual Page 3
Pknight
®
WiFi-DMX EasyNode Manual Page 4
First double-click the power switch
button to turn off the power, then
press and hold the signal channel
button, click the power switch button
again to turn on the power, wait for
5 seconds the controller will restore
the factory settings.
6Signal Channel Indicator
these frequencies are displayed in 7 colors
(red,magenta,yellow,white,blue,green,cyan)
Pknight® WIFI-DMX EasyNodePknight® WIFI-DMX EasyNode
2
5
6
1
4
3

Indicators Setting
led indicator diagram
7 colors
*note*
If the led indicator blinks quickly, the
DMX signal output is normal, otherwise,
it is abnormal. Please recheck!
All setup is done by the device with
the apps installed.
Turned on the Pknight® WIFI-DMX EasyNode,
you should be able to find the “PKNIGHT.
WIFI+64123” network using the Wi-Fi settings
on your mobile network equipment. (*note*The
red number 64123 is the unique identication of
this controller) The default password to join is
“PKNIGHT.WIFI”.After joining the network you
can start the DMX app. The gure below is the
interface of luminair.
Pknight
®
WiFi-DMX EasyNode Manual Page 5
Pknight
®
WiFi-DMX EasyNode Manual Page 6
Pknight® WIFI-DMX EasyNodePknight® WIFI-DMX EasyNode
PKNIGHT.WIFI
Channel Indicator
Greenyellow blue cyanwhiteMagentaRed

Pknight
®
WiFi-DMX EasyNode Manual Page 7
Pknight
®
WiFi-DMX EasyNode Manual Page 8
Pknight® WIFI-DMX EasyNodePknight® WIFI-DMX EasyNode
Setting Setting
PKNIGHT.WIFI
Here we have completed the work of signal
connection, if you want to change this controller
WiFi name and password, open the web browser
of your device and enter 192.168.4.1, a view will
appear similar to the following gure.
It is recommended that you change the
name or password or both for the security
of your lighting system.
*note*
1
2
3
4
WiFi SETTING

Pknight
®
WiFi-DMX EasyNode Manual Page 9
Pknight
®
WiFi-DMX EasyNode Manual Page 10
Pknight® WIFI-DMX EasyNodePknight® WIFI-DMX EasyNode
Setting Multiple modes
1
4
If you want to connect an external router,
you need to enter the router's WiFi name
and password, and not only that, you need
to make sure the checkbox( ) is not
checked if you want to make this connection
take effect.(used only in router mode)
4Check the independent mode to disable
the router's WiFi connection and allow data
to be received through its own hotspot.
Usually, we use it as a switch to disconnect
the router’s WiFi and use its own hotspot to
connect with other devices.
2Here is the controller itself WiFi or hotspot
information, it can be customized, The
network name can be 1-32 characters
in length and the password can be 8-16
characters in length. Only alphanumeric
characters or space characters are allowed.
If you forget the WiFi password, you
can go back to page 5 and refer to
the function button to restore factory
settings.
3If the wifi of the external router cannot be
connected, the hotspot will start after a delay
of 25 seconds. It can also be customized.
Turn off the power and then turn it
back on for the changes to take effect.
Easylink mode
Phone or tablet...
Unlimited number
connected
connected connected
connected
connected

Pknight
®
WiFi-DMX EasyNode Manual Page 11
Pknight
®
WiFi-DMX EasyNode Manual Page 12
Pknight® WIFI-DMX EasyNodePknight® WIFI-DMX EasyNode
Multiple modes Multiple modes
In easylink mode,just make sure that the LED
lights of each controller have the same color, and
then connect the hotspot signal of any controller
with a mobile phone.now it's good to go.
Router mode
In router mode, we want to build such a local
area network, our mobile phone or tablet
computer and multiple controllers are connected
to the 2.4G WiFi signal of the router. Buying
a better router and assigning different wifi
channel of controller will also optimize the
stability and speed and range of the system's
signal transmission.
different wifi channel of controller refer to
different color of led indicator
connected
Router
Phone or tablet...
connected
connected
connected
WiFi SSID:pknight
Password:PKNIGHT.WIFI
connected
Stand Alone Mode
Stand Alone Mode
Stand Alone Mode
Stand Alone Mode
How to do?
The easylink mode is perfect for
the system construction of film and
television lights.
The most cost-effective wireless dmx
kit on the market
The most convenient wireless dmx
kit on the market
In Easylink mode,no need to do any
web configuration, just adjust the
indicator light of the controller to the
same color.

Pknight
®
WiFi-DMX EasyNode Manual Page 13
Pknight
®
WiFi-DMX EasyNode Manual Page 14
Pknight® WIFI-DMX EasyNodePknight® WIFI-DMX EasyNode
Multiple modes Multiple modes
pknight
PKNIGHT.WIFI
1
5
2
3
4
How to do?
It's easy for our mobile phone or tablet PC.Let's
follow the picture to set up the controller's
network.First connect the mobile phone to the
hotspot signal of the controller.Than open the
mobile browser to do the operation as shown in
the gure below
1Enter 192.168.4.1 in the browser
2Select the "WiFi" function bar
3Enter the WiFi information of the router
4Uncheck the Stand Alone checkbox
5Save Change
Follow the steps in the gure above to
connect all the controllers to the router
one by one,the color indicator flashes
on the controller should try different.
Disconnect the power to the controller
for 3 seconds, then reconnect it,At this
point, if your settings are correct, the
controller will automatically connect to
the router’s WiFi signal,If not, please
check again.
Open the mobile WiFi interface, wait
for the router WiFi signal to appear and
connect to this signal.
Now it's good to go!

Warranty
A. 1 months upon date of purchase,
if there is function problem, we should
offer the same item subjuect to goods
and packing maintain perfect.
B. 3 Years upon date of purchase,
we will guarantee to keep the goods
in repair. (not including ttings)
C. Guarantee service is subject to
normally using.
C. Please do not rotate the antenna
arbitrarily in case of damaging it.
All of damage by man-made (tear
open the housing, tear off the sticker,
unnormally using), or losing this
manual, we will not guarantee.
2022.1.17revised edition
To optimize the performance of this
product, please read these operating
instructions carefully to familiarize
yourself with the basic operations of
this unit. These instructions contain
important safety information regarding
the use and maintenance of this unit.
Please keep this manual with the unit,
for future reference.
Pknight
®
WiFi-DMX EasyNode Manual Page 15

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not
cause harmful interference, and (2) this device must accept any interference received, including interference that may cause
undesired operation
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of
the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
Warning: changes or modifications not expressly approved by the party responsible for compliance could void the user's
authority to operate the equipment
Radiation Exposure Statement
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.
This equipment should be installed and operated with minimum distance 20cm between the radiator and your body.
