PL&T PLT-10270 User manual

FLOOD LIGHTS
Features & Specifications
INTENDED USE – RGB LED floodlight fixtures feature the latest Red/Green/Blue color
changing technology, meaning this flood light can be any color at any time and under your
total control. With a remote control, these LED floodlights allow you to choose one color or
automatically cycle through a range of colors with a click of a button. Special effects
include flash, strobe, slow fade, and more! These RGB LED floodlights are ideal for
landscape, architectural, and stage lighting applications.
There are several techniques that can be implemented by using flood light fixtures in
landscape lighting. The easiest methods are simply positioning flood lights as an uplight or
downlight, but there are more advanced techniques.
Wall washing: Used to spread a uniform light across large areas, such as the facade of a
building.
Wall grazing: Used to highlight the patterns of stone walls, tree trunks, climbing vines, or
other objects with textured surfaces. Accomplished by placing the light fixture about a foot
away from the highlighted object and pointing the light straight up.
Shadowing: Achieved by positioning the light to cast the shadow of an object in front of it
onto a wall.
REMOTE CONTROL - The effortless push of a button can trigger marvelous light displays.
There are two remote control options, infrared (IR) and radio frequency (RF) remotes, for
your lighting installations.
IR Remote - IR stands for Infrared waves which range from 300 GHz to 400 THz in the
scale. You want to use an IR remote when you are able to be close to the device. This type
of remote needs to be in line-of-sight of the fixture. The signal is not likely to be intercepted
by other remote frequencies.
RF Remote - RF stands for Radio Frequency waves which range from 3 KHz to 300 GHz in
the frequency scale. This remote works through walls, floors, and doors. RF remotes are
remotes of convenience, better suited to those moments when you won’t or can’t get close
to the receiver, such as outdoor applications. Many RF remotes can control several fixtures
with a single remote.
CONSTRUCTION – High-density aluminum alloy housing with a bronze corrosion-resistant
powder coat finish for lasting durability. Transparent and weather resistant lens. Housing is
sealed against moisture and environmental contaminants (IP65 rated). Designed to protect
each fixture from inclement weather.
OPTICS – High-performance RGB LEDs maintain a 35,000 hour lifespan. Provides
even and bright illumination across a wide area.
ELECTRICAL – Integral heat sink, Input voltage of 120-277 VAC, 50/60Hz. Consider
adding a surge protector to protect your fixtures from power surges in your electrical
system as an added insurance policy to your investment.
MOUNTING – Trunnion option for adjustable wall, pole, or roof mounting; ideal for flag and
sign lighting. Adjustable knuckle mount with optional ground stake for landscape
applications.
LISTINGS – UL Certified to safety standards for wet locations. Rated for -40°C to 45°
C ambient temperature. IP-65 Rated.
WARRANTY – 5-year warranty. PLT products that are damaged or defective will be
repaired or replaced at PLT’s choosing for a period of 5 years. Contact
1-800-624-4488 for more information.
Dimensions
Height: 9.4 in.
Width: 11.3 in.
Depth: 5.9 in.
Weight: 5.95 lbs
SKU# Beam Angle Wattage Voltage Mounting Life Hours Warranty
PLT-10270 120 Degree 120-240
IP Rating
IP65 Ceiling/Wall/Pedestal 35,000 5 Years
60
11.3
9.4
21 Button RF Remote
5.9

Button function
Off: Power off
On: Power on
R: Color change to Red
G: Color change to Green
B: Color change to Blue
W: Color change to White
Flash: Auto-change colors, fast skip
Strobe: Auto-change colors, slow skip
Fade: Auto-change colors, fast shade
Smooth: Auto-change colors, slow shade
Other no-letter buttons: For color-mix.
The following is Radio Frequency control diagram.
25M Max

Installation and use
Packing Spec
Gross weight Pcs/box Gross weight Pcs/carton
BR-FL60W-01(ID:TA-RF) 2.87 kg 1 12.83 kg 4
Through the 720H accelerated aging test,high and low temperature prediction in the rated under the working conditions after 35000H,will
provide an average 70% optic maintenance ratio(L70).
Item
Remarks
1.White light series: WW (3000-3500K) NW (4000-4500K) CW (5000-6500K)
2.Luminous flux tolerance for ±10%
3.Products shall be subject to any changes without prior notices.
L295*W240*H170 L500*W370*H320
Attention
1.Please turn off the power supply befor installation or changing assembly parts.
2.The input voltage and the lamp should be adapted. After connecting the power line, please make sure the wiring section is insulated.
3.Non-professionals, must not install or dismantle the lamps.
4.All the floodlights during installation and in use should not be put with glass cover vertically upside.
Box Carton
Measurement（mm）Measurement(mm)
3.Connect the power wire from the Main lineto the power wire of the lamp,and then
make treatment for water reistance. Pls note that the Brown color wire is Live
wire,Blue wire is Null line,the yellow and green wire is Earth line.
4.Turn on the power supply to ensuer the light is working,Installed.
1.First,adujust the angle you need,finally fasten the floodlights with screws 2.Install the LED Floodlight onto the wall or ground,punch hole on the wall orground,prepare
the expansion screw,and then fasten the floodlight
360°
Light attenuation map
0.92
0.93
0.94
0.95
0.96
0.97
0.98
0.99
1
1.01
0 90 180 270 360 450 540 630 720
(Hours)
Relative Luminous Flux
