Planet Audio P9690B User manual

30
30
11
To ensure safety while driving
and to comply with laws,
drivers should not watch video or
operate the video device while driving.
7. Specification
General Specification
Power Supply Requirement..................................................DC 12V
Maximum Power Output...................4 x 80W(measured at DC 14.4 V)
Dimensions(w x hx d)............................................7”W x2”H x 6.5”D
DVD Deck Specification
Format...................................DVD/VCD/MP4/JPEG//MP3/WMA/CD
Video System........................................................................NTSC
Audio System..............................................................24 bit/96KHz
Loading System.......................................................... Auto Loading
Mounting Angle.................................................................0 to +/-30
Video Specification
Video Type...................................................................16:9 and 4:3
Video Output level......................................Composite:1.0•• 0.2Vp-p
Load impedance: 75ohms
Horizontal Resolution................................................................500
Audio Specification
+0
Audio Output(Analog audio)..........................................2.0 -1.0Vrms
Frequency Response.............................20Hz ~20KHz(at 1KHz 0dB)
S/N Ratio(Audio).............................................•• 90dB(at 1KHz 0 dB)
Separation..............................................................................50dB
Radio Specification
FM Section
Frequency range.......................................87.5MHz -107.9MHz(US)
87.5MHz - 108.0MHz(EU)
Usable sensitivity......................................................................3uV
I.F Frequency....................................................................10.7MHz
AM Section
Frequency....................................................530KHz - 1710KHz(US)
522KHz - 1620KHz(EU)

2
29
29
!
CAUTION
RISK OF ELECTRICSHOCK
DO NOT OPEN
!
CAUTION: TO REDUCE THE RISK OF ELECTRICSHOCK, DO NOTREMOVE
COVER (OR BACK).NO USER SERVICEABLE PARTS INSIDE. REFER
SERVICING TOQUALIFIED SERVICE PERSONNEL.
The lightening flashwith arrowhead symbol,within an equilateraltriangle, is
intended the alertthe user tothe presence ofuninsulated dangerous voltage
within the productsenclosure that maybe of sufficientmagnitude to constitute
a risk ofelectric shock to persons.
The exclamation pointwithin an equilateral triangle is intended to alert user to
the presence ofimportant operating and maintenance (servicing) instructions
in the literatureaccompanying the appliance.
CLASS 1 LASER PRODUCT
Laser product symbol:located on the rear panel of the unit, indicate this player is a class
laser product, onlyuse weak laser and no hazardous radiation outside of the unit.
1.Read through thisinstruction manual before installation and use.
2.Do not openthe cover or touch any of the components exposed out of the unit, only for
qualified technicians.
3.Do not exposethe unit under direct sunlight or nearby objects that radiate heat to avoid
damage the unit.
4.Do not placethe unit in moist and humid conditions, which effect the pick-up ofthe unit
lead to outof work.
5.Place the uniton a flat surface and ventilative condition. Please ensure the ventilation
holes are notcovered to avoid overheating and malfunction.
6.Clear the paneland case with soft dry cloth only, do not apply anykind of thinner,
alcohol or sprays.
WARNING: TOREDUCE THE
RISK OF FIREOR ELECTRIC
SHOCK, DO NOTEXPOSE
THIS APPLIANCETO RAIN OR
MOISTURE.
PRECAUTION
6. Trouble Shooting
Please read theuser manual carefully before using the DVD player. If you have any trouble
in using thisplayer, try to troubleshoot by using the recommended suggestions mentioned
below . Ifyou are still having difficulty, please contact the company or the technical service
center authorized byus. For your safety, donot open the cover and attempt to repair the player
by yourself, ifthat. It will cause electrical shock and harm.
NO PICTURE, SOUNDAND INDICATION
* Ensure thatthe power switch is on.
* Ensure thatthe power cable is not damaged or the fuse is not blown.
* Ensure thatthe power is connected properly.
NO SOUND BUTPICTURE OK
* Ensure thatthe player audio output has a good connection with the TV audio input.
* Check whetherthe audio connector is damaged.
* Check whetheryou have turned down the volume.
* Ensure thatyou have set the right AUDIO setup of the player.
* Ensure thatthe audio is not under mute.
NO PICTURE BUTSOUND OK
* Ensure thatthe player video output has a good connection with the TV video input.
* Ensure thatyou have turned your TV tothe AV input channelconnecting to your player.
* Check whetherthe video connector is damaged.
* Ensure thatyou have set the right VIDEO settings of the player.
BLACK ANDWHITE PICTURE OR SCREEN ROLLING
* Ensure thatyou have set the right TVSYSTEM (e.g. PAL, NTSC) setting.
FLAWS OF PICTURE OR SOUND
* Check whetherthe AUDIO setting is right.
* Check whetherthe disc is scratched or stained.
* Check whetherthe AV connector andthe output terminal is stained.
* Check whetherthere is condensation inside the Lens. If so, leave the player off for an hour
or so, thentry again.
* Check whetherthe installation angle is less than 30.
DISPLAY NO DISC ORBAD DISC
* Ensure thatyou have put the disc on the tray.
* Check whetherthe disc is put in the reverse side.
* Check whetherthe disc is distorted.
* Check whetherthe disc is stained or scratched badly.
* Ensure thatthe disc format is compatible to the player.
* Ensure thatthe temperature inside the car is not too high. If so, cool off until theambient
temperature returns to normal.
* Replace anotherdisc to insert it into the disc compartment.
REMOTE CONTROL HAS POOR RESPONSERANGE OR DOES NOT WORK
* Check thebatteries of remote control and make sure that they are not flat.
* Direct theremote control to the IR sensor of the player.
* Check whetherthere are some obstacles between the remote control and IR sensor.
SOME FUNCTION BUTTONSDO NOT WORK
* Turnoff the power, then turnon again.
* Reset theunit to zero, then turn on again.
* Remove thefront panel from the unit, then install it again and then turn on again.
THE RADIO DOESNOT WORK
* Check whetherthe antenna cable is connected firmly. Or manuallytune for astation.

3
28
28
Contents
1. Before Operation...........................................................................................4
1.1 Glossary................................................................................................ 4
1.2 Precautions............................................................................................4
1.3 Maintenance andCleaning of Discs..........................................................5
1.4 Battery Informationof the Remote Control.................................................5
1.5 The RemoteControl Description..............................................................6
1.6 Locations andNames of the Controls.......................................................7
1.7 Description ofthe Rear Cabinet....................... ........................................8
1.8 Unit Installation......................................................................................9
2. Common Operation......................................................................................10
3. Radio Operation..........................................................................................12
4. Basic Disc,USB or SD Operation...................................................................14
4.1 Begin Playback......................................................................................14
4.2 Pause Playback.....................................................................................15
4.3 Stop Playback.......................................................................................15
4.4 Select Chapter/Track with theUP/DN or the >>|/|<< Buttons......................15
4.5 Select Chapter/Track with theNumber Buttons.........................................16
4.6 Select Chapter/Track with theRoot/PBC Menu.........................................16
4.7 Terminate the Playback..........................................................................16
4.8 Playback withSpeed..............................................................................17
4.9 Playback withSlow Speed......................................................................17
4.10 Playback withStill Frame......................................................................17
4.11 Playback Repeatedly............................................................................17
4.11.1 One/All Repeat..................................................................................17
4.11.2 A-B Repeat........................................................................................18
4.12 Playback inScan Mode..........................................................................18
4.13 Playback froma specified Chapter/Track or a Specified Time....................18
4.14 Playback inRandom..............................................................................19
4.15 Playback inDifferent Angle....................................................................19
4.16 Playback inZoom Mode........................................................................19
4.17 Change theCaption Language.............................................................. 19
4.18 Change theAudio Language................................................................. 19
4.19 Program Playback...............................................................................20
4.20 Playback thePicture CD in JPEG Format...............................................20
4.21 Operation aboutfile style of video.........................................................21
4.22 ESP and ID3 Function..........................................................................21
4.23 USB andSD Reader Operation.............................................................21
4.24 The DVD System Menu Setup Operation................................................22
4.25 The Parental Control............................................................................26
5. Bluetooth Handfree System(Option).............................................................27
6. TroubleShooting.........................................................................................29
7. Specifications.............................................................................................30
4.3 To redial the last phone number dialled
(1) Short press TEL button . It will show a line on the display.
(2) Short press REDIAL button, It will dial the last phone number.
5. Accept/Reject/End Call
5.1 When ringing, short press TEL button to accept the call
5.2 When ringing, short press HANG UP button to reject the call
5.3 When talking, short press HANG UP button to end the call
Note: During ringing, the phone number appears.
6. Dialling or receiving call during sleep mode
When the car audio is on sleep mode (Acc on and standby), to call out
(with mobile phone) or receive a call, the car audio will temporarily power on.
7. To transfer the audio of a file played by Mobile Phone to the Car Audio Player
In the connection status between the Bluetooth devices of the Car Audio Player
and a Mobile Phone, if the mobile phone can play audio files and support A2DP,
when the Mobile Phone plays an audio file(For some Mobile Phones, you must
select Play by BT first), the audio of the playing file will be transferred to the
Car Audio Player.
In A2DP mode, if the Bluetooth device of the Mobile Phone support AVRCP, the
functions of the >>|, |<< , PLAY/PAUSE , EJECT, MUTE, EQ, LOUD, VOL and SEL
buttons are the same as one in disc mode(no fast forward/backward functions for
the >>|/|<< buttons). The other buttons available in disc mode are not available.

4
27
27
1. Before Operation
1.1 Glossary
PBC (playback control)
It is akind of signal(menu) recorded in the disc with SVCD or VCD2.0
format used for the playbackcontrol. For the discs contained PBC, It can
playback interactive softwarewith the menu displayed on TV.
Title
Generally, the title isthe important partof DVD disc. for example, the
theme part ofmovie is title 1, the part described how to make movie istitle
2, the castis title 3, etc. Every title contain a serial number that iseasy to
lookup.
Chapter
A title can be divided into several blocks, so that every block can be operated
as a unit,the unit is called chapter. The chapter contain a unit at least.
Track
It is the biggest component of VCD. Generally, every song ofa disc
is a track.
1.2 Precautions
Safety
1. The unit is designed for negative terminal of the battery which is
connected to the vehicle metal. Please confirm it before installation.
2. Do not allow the speaker wires to be shorted together when the unit is
switched on. Otherwise it may overload or burn out the power amplifier.
3. Do not install the detachable panel before connecting the wire.
4. The protective case is to safely keep the front panel(see the photo).
Environment
1. Do not use this unit when water and moisture is near it.
2. If moisture forms inside the Lens, it may not operate properly. To correct
this problem, wait about one hour for the moisture to evaporate.
3. If the car interior is extremely hot, do not use the player until the car has
been driven for a while to cool off the interior.
FRONT PANEL
PROTECTIVE CASE
5. BLUETOOTH HANDFREE SYSTEM(Option)
1. Pairing and connection
1) Turn on the Bluetooth mode of the mobile phone;
3) For some mobile phones, they can automatically connect with the BT device of the
car audio system after pairing is ok; for some mobile phones, they need to select the
paired BT device and press the CONNECTION button . When connection is ok, the
LCD of the car audio system will show LINK OK.
* when pairing is failed, long press the MODE button on the front panel or PAIR button
on the remote control to enter pairing mode, then the LCD will display PAIR STAR,
then pair and connect with mobile phone again.
*
2.
In the connection status, find the paired and connected Bluetooth Device, then press
the disconnection button to disconnect.
In the disconnection status, find the paired and disconnected Bluetooth Device, then
press the connection button to connect.
3. In the connection status: Mobile phone transfers to the car audio whenever a dialling
takes place; Mobile phone transfers to the car audio whenever receiving a call.
4. Dialling when in connection status
4.1 Dial with the mobile phone directly.
4.2 Dial with remote control with the following procedures:
(1) Short press TEL button, then a line will appear on LCD.
(2) Input telephone number with number buttons 0-9
* Short press CLEAR button to cancel the wrongly input number if necessary
(3) Short press TEL to execute the dialling.
2) Select the item of Finding the BLUETOOTH Device and press enter. Once the device
and unit are paired, the unit will display the name of the device. Select the device and
press enter, and the unit will ask for a password which is 0000. After entering 0000,
press enter and after the pairing is complete the unit will display "Pairing is OK".
In Disc mode, press and hold the PAIR button for 3 seconds to enter Pairing mode.
Using the mobile phone for connecting and disconnecting.

5
26
26
1.3 Maintenance and Cleaning of Discs
Disc Maintenance
1. To h
1.
Do not use petrel, thinner, commercially cleaner or anti-static spray used to
plastic LP to wipe disc.
keep the disc clean, andle the disc by its edge, do not touch the disc
surface of the play side.
2. Do not stick paper or tape on the disc. If there is glue (or analog) on the
disc surface, must wipe it up before using.
3. Do not expose the disc to direct sunlight, or nearby heat sources such as
caliduct, or leave it in a car parked in direct sunlight where there can be a
considerable rise in temperature.
4. Put the disc inside disc case to keep temperature after finishing playback.
Disc Cleaning
Before playing, wipe the disc with a clean lint. wipe the disc outwards from
the disc center.
2.
1.4 Battery Informationof the Remote Control
Replace Battery inthe Remote Control:
Note about theBattery of the Remote Control:
1.
3.Do not shortthe battery.
4.Do not throwthe battery into the fire.
5.Toavoid the riskof accident, keep the battery out of reach of children.
1.Before using theremote control for the first time, pull the insulating
sheet out of the remote control as the direction indicated by the
arrow.(see fig.1)
2.Press the movableblock hold as the direction indicated by the A arrow
(See fig.2), then pull the battery holder out of the remote control as
the direction indicated by the B arrow(see fig.2).
3.Replace the oldbattery by a new battery with (+) polarity side upward.
(See fig.3).
4.Insert the batteryholder to the original position in remote control.
(See fig.3).
Improper use ofbattery may cause overheating or explosion. so that
Result in injury or fire .
2.Battery leakage maycause damage to the remote control(Battery
Life: 6 months with normal use in normal room temperature).
Fig.1 Fig.2 Fig.3
4.25 Parental Control
Q:After inserting DVD disc into disc compartment, a dialogue window will appear
asking for a password of 4 digits. Why ?
A:This is because the disc movie you are playing was rated with the Parental
Control, and the current rating level of DVD player is lower than one of current
disc. You must input right password and enter it to entry Parental Control setup
menu and then set a equal or higher rating level than one of current disc. So that
you can playback the disc.
! NOTE
* If you have not changed the password, the factory preset password for the DVD
player will be empty. So that you should input a desired password and input it
again to verify it to enter the Parental Control setup menu.
* For the rating level setup of Parental Control of the DVD player, please refer to
the relative content of LOCK setup menu for details.
Accessories: Parental Control
The Parental Control function of a DVD player can control the playback of movie
rated level in a disc. You can set the DVD player to be a certain rating level with
SETUP MENU on TV screen. If the rating level set in the disc is higher than one set
in the DVD player, the DVD player can not playback the disc. Sometimes the Parental
Control sequences in some discs are different from each other. The rating level setup
can be protected by the password. Therein, if you select Unlock item, the Parental
Control function will be invalid, the content of disc will be played totally.
The disc movie can be designed as that the DVD player will playback the different
version of content of a same movie according to the different rating level set by
Parental Control. Depend on the DVD feature of seamless switching described above,
the scenes that are not fitting for children will be cleared or replaced by the other
fitting scene automatically.
All rating levels of Parental Control are as follows:
Unlock
1 Kid Safe
2 G
3 PG
4 PG 13
5 PG R
6 R
7 NC 17
8 Adult

6
25
25
1.5 Remote Control Description
40
41
16. SEARCH BUTTON
17. RDM BUTTON
18. RPT BUTTON
19. SUBTITLE/REDIAL BUTTON
20. TITLE/PAIR BUTTON
21. ANGLE/ST/# BUTTON
22. ZOOM BUTTON
23. AUDIO BUTTON
24. CLK BUTTON
25. A-B BUTTON
26. INT BUTTON
27. EQ BUTTON
28. LOC/SLOW-FWD/* BUTTON
29. MUTE BUTTON
30. STOP BUTTON
31. VOLUME- BUTTON
32. < BUTTON
33. OK BUTTON
34. VOLUME+ BUTTON
35. BAND BUTTON
36. PROG BUTTON
37. OSD BUTTON
38. LOUD BUTTON
39. TEL/STEP BUTTON
40. TA BUTTON
41. AF BUTTON
1. BACK BUTTON
2. MENU/PBC BUTTON
3. POWER BUTTON
4. ^ BUTTON
5. >>| BUTTON
6. > BUTTON
7. |<</CLEAR BUTTON
8. v BUTTON
9. SEL BUTTON
13. SETUP BUTTON
14. MODE BUTTON
15. APS/HANGUP BUTTON
10. PLAY/PAUSE BUTTON
11. NUMBER(0~9,+10
-10) BUTTONS
12. 10+/PTY BUTTON
1
2
3
4
5
6
7
98
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
39
36
37 38
4.24.6 DIGITAL SETUP
DYNAMIC RANGE
After selecting thecompression mode of LINE OUT, set the item, so you can
adjust the linearcompression ratio. If you set it to be FULL, the Peak-to-Peak
value of theaudio signal is the minimum; if you set it to be OFF, the Peak-to-
Peak value isthe maximum.
DUAL MONO
It is forselecting a desired audio output mode for the left and right ways of signal.
It is mainlyfor Karaoke of Ac3. There are 4 modes in all as follows:
STEREO, MONO L,MONO R, MIX MONO.

724
1.6 Locations and Names of Controls
20 22
The figure of front panel
SD
2119
1. POWER &MUTE BUTTON
2. MENU BUTTONS
3. UP/TEL BUTTON
4. DOWN/HAND UPBUTTON
5. SEL &VOL BUTTON
6. LCD
7. REL BUTTON
8. IR SENSOR
9.BAND/LIST BUTTON
10. APS BUTTON
11.1/PLAY/PAUSE BUTTON
12. 2/INT BUTTON
13.3/RPT BUTTON
14. 4/RDM BUTTON
15. 5/-10 BUTTON
16. 6/+10 BUTTON
17. AUXIN JACK
18. USB JACK
19. Card slot
20. DISC solt
21. RESET BUTTON
22.EJECT BUTTON
The figure of the Unit Chassis Facet After removing the Front Panel
26 7 13 3
45 17 18
8
161015
11
9
14
1
12
4.24.4 VIDEO SETUP
BRIGHTNESS
It is foradjusting the brightness of the video output.
CONTRAST
It is foradjusting the contrast of the video output.
HUE
It is foradjusting the hue of the video output.
SATURATION
It is foradjusting the saturation of the video output.
SHARPNESS
It is foradjusting the sharpness of the video output.
4.24.5 SPEAKER SETUP
DOWNMIX
It is for selecting your desired sound effect when there is no center speaker
and subwoofer.There are 3 modes: LT/RT, STEREO, VSS.
LT/RT: When playinga disc with PRO LOGIC Dolbystereo effect, choose the
item, so itwill output audio signal with vivid theatre effect.
STEREO: If you choose the item, when outputting audio signal with5.1 channels,
it will output the left and right channels of signal ; when outputting audio signal
with 2 channels, it will output the common 2 channels of stereo signal.
VSS: If you choose the item, when playing a disc recordedwith 5.1 channels,
the main channelspeakers can output audio signal with VSS effect.

.
2. Select theRATING item and then press the > button to enter it, then usethe
direction buttons to select your desired rating level, then press the OKbutton
to confirm.
3. Select thePASSWORD item again and then press the > button to enter it, then
input the password, and then press the OK button to lock thenew setting of
the rating level of the Parental Control.
DEFAULT
This item isfor making all setup items change back to originalstatus.
4.24.2 LANGUAGE SETUP
OSD LANGUAGE
This item isfor selecting the language of the SYSTEM MENU and all operating
prompt interface displayedduring playback.
AUDIO LANG
This item isfor selecting a audio language.
SUBTITLE LANG
This item is for selecting a subtitle language.
MENU LANG
This item is for selecting a disc menu language.
4.24.3 AUDIO SETUP
AUDIO OUT
there is onlyANALOG mode, i.e. SPDIF/OFF, not optional.
KEY
It is for selecting your desired basic music tone(from low to high).
8
1.7 Description of the Rear Cabinet
Connecting the parkingbrake line to the parking brake system built in the car
Parking brake
Parking brake switch
(inside the car)
To metallic bodyor chassis of thecar
Note:1. Parking wire mustbe connected, and theparking brake must beengaged in order for the monitor to work
2. Use the clipend of the Groundwire provided by manufacturerto connect Mounting Screw, use the otherend of the
Ground wire to connectthe negative pole ofthe power source. Otherwise,the video on screen may have interference.
Parking brake wires(Green)
Rear View Camera
In any mode, the video signal will switch to camera mode (if applicable)when car is in reverse.
After taking the car out of reverse, it will resume to its previous mode.
Analog on-site backup Analog on-site backup
PIC
ANGLE
Warning:
Always check thesurrounding environment. Objects might be reversed. The rear view
camera is designedonly to assist while reversing. Due to the limitations of the camera
angle and range,it may cause accidents if the driver relies solely on the reverse camera
and display.
23

9
1.8 UNIT INSTALLATION
INSTALLATIONINSTRUCTIONS
TO BOOST UPTHE CAPABILITY OF
ANTI-JAMMING, PLEASE FIX THE
METAL STRAPON THE METAL
CONNECTED TO THE CHASSIS OF
THE CAR.
METAL STRAP
DASH BOARD
SLIDING METALHOUSING
TO DRAW THECHASSIS OUT OF THE
SLIDING METALHOUSING, INSERT
THE LEFT ANDRIGHT KEY PLATES
INTO THE TWOSIDES OF CHASSIS.
FRONT PANEL
PLASTIC TRIM OUT
UNIT CHASSIS
SELECT THE PROPER TABS
OF THE SLIDING METAL
HOUSING TO FIX THE
SLIDING METAL HOUSING.
NOTE REMOVE THE DECK TRANSPORT
SCREWS BEFORE INSTALLINGIT.
THE UNIT INSTALLATION IS ANTI-THEFTONE. THE UNIT CHASSISWEARS ASLIDING METAL HOUSING. FIRSTLY CONNECTTHE
POWER LINES, SPEAKER LINESAND AUTOANTENNA ACCORDINGTO MANUAL REQUIREMENT, THEN INSTALLTHE SLIDING METAL
HOUSING IN ACAR ACCORDING TOTHE DIAGRAM.
REMOVE THE SLIDING METAL HOUSING
EJECT BUTTON
RESET BUTTON
The Description of the Fixed ISO Female Connector
CONNECTOR A
1.
2.
3.
4. Memory +12V(yellow)
5. Auto Antenna(blue)
6.
7. 12V (To Ignition Key)(red)
8. GROUND(black)
CONNECTOR B
1. Rear Right Speaker (+)
2. Rear Right Speaker (-)
3. Front Right Speaker (+)
4. Front Right Speaker (-)
5. Front Left Speaker (+)
6. Front Left Speaker (-)
7. Rear Left Speaker (+)
8. Rear Left Speaker (-)
FUSE 10 A
22
22
4.24 DVD SystemMenu Setup Operation
1. Press theSETUP button on the remote controller to access the DVD System
Menu on themonitor.
2. There are 6 setuppages in all for the System Menu. Press the > or < button
to select andesired setup page.
3. Press the ^ or v button to select an setup item in the selectedsetup page.
4. Press the> button to enter the setup item. Then press the v or ^ button to select
a desired modeof the setup item, finally press the OK button to confirm it.
* Press the< button to return to the upper level.
* Press theSETUP button again or use the direction buttons to highlight the
item of theEXIT SETUP and then pressthe OK buttonto exit the System Menu.
For the DVDSystem Menu, thereare 6 setup pages in all. They display as follows:
4.24.1 SYSTEM SETUP
TV TYPE
The setup itemis for matching TV screen size.
4:3 PS: Choosethe item when connecting a TV set with 4:3 screen. When playing
the pictures with16:9 size, the left and right parts of the video will be cut out,
and display infull screen.
4:3 LB: Choosethe item when connecting a TV set with 4:3 screen. When playing
the pictures with16:9 size, the top and bottom parts of the TV screen will be
turned into ablack square respectively.
16:9: Choose theitem when connecting a TV set with 16:9 wide screen.
PASSWORD
This setup itemis for locking or unlocking the rating level of the Parental Control.
The defaulted stateis locked. The defaulted passwordis 0000.
You can set a new password that you like: Selectthe PASSWORD item andthen
press the >button to enter it, then input the original password 0000, and then
press the OKbutton to unlock it. Press the > button to enter it again, then input
a new passwordthat you like and then press the OK button to make it effective.
Before the otherpersons see the Manual, you should get the password in mind
and cut outthe part of PASSWORD in the Manual.
RATING
The item isfor setting a new rating level of the Parental Control.
1. Select thePASSWORD item and thenpress the > button to enter it, then input
the password mentionedabove, and then press the OK button to unlock the
setting of therating level of the Parental Control.

10
10
2. Common Operation
1. To turn on/off the unit
Under power off mode, press the POWER buttonto turn on the unit.
Under power onmode, press and hold the POWERbutton on the front panel
or briefly pressthe POWER button on the remotecontroller to turn off the unit.
2. To select function mode
Press the MENUbutton to turn to mode select,then rotate VOLknob to select
TUNER, DISC(After inserting a disc), USB(After inserting aUSB storage),
Card(After inserting a SD card),AUX or BLUETOOTH mode.
After selecting ,press SELto confirm and turn to your selection.
Note: This unit has front and rear USB. Only one will work at a time.
3. To adjust soundlevel
Rotate the VOLknob on thefront panel orpress the + or - button on the remote
controller to directly adjust the volume level.
4. To mute sound
Press the MUTEbutton on the remote controller toturn on/off MUTE mode.
Briefly pressing thePOWER button on the front panelalso can turnon/off
MUTE mode.
In MUTE mode, the MUTE mode canbe released by pressing the following
buttons: MUTE, VOLor +/-, SEL, MODE.
5. To display andadjust the clock time
Press the CLKbutton to display clock time on the monitorof the front panel.
To adjust the time, please turn to setupmode time setting.
6. To select apreset EQ mode
Press the EQbutton to select the preset musicequalizer curves: POP, ROCK,
CLAS, EQ OFF . The sound effect will be changed.
7. To remove thefront panel
Press the RELbutton on thefront panel todetach the front panel from the
unit, then you can removethe front panel.
8. To turn on/off LOUDNESS mode
Press the LOUDbutton to turn on/off LOUDNESS mode.
When turning onLOUDNESS mode, it will enhance bass level immediately
when the bassis not enough.
9. To reset theunit
when the buttons are not effective or sound
is distorted, press the RELbutton to detach the front panel from the unit and
remove it, then
.
display is incorrect, or the function
use a smallpoint to press the RESETbutton, which will reset
to factory default, and re-instate the correct functions
21
21
When you select a JPEG file sort icon, press the ^ or > button to select the
first JPEG file, then press the v button to select the desired JPEG file, finally
press the OK or PLAY/PAUSE button to display the JPEG picture in full
screen from the selected JPEG picture.
3. During JPEG playback, press one of the >/</^/v buttons to change the angle
of viewing picture that is displaying as follows:
>: 90 deg cw; <: 90deg ccw; ^:UP<-->DOWN; v: LEFT<-->RIGHT
During JPEG playback, press the PROG button to change the mode of
refresh picture.
During JPEG playback, press the STOP button to stop playing and return to
the root menu.
* During JPEG playback, the following buttons are not available: SLOW-FWD,
SUBTITLE, TITLE, ANGLE, STEP, AUDIO, RDM, INT and A-B.
* In JPEG mode, the other operations are same as ones in MP3/WMA mode.
4.21 Operation about file style of video
1. The root menu is displayed on TV when beginning to switch on DISC mode, then
it will automatically play the first file.
During playback, press the STOP button to stop playing and return to the root menu.
2. When displaying the root menu, press the direction buttons to select your desired
FOLDER or file, then press the OK or PLAYbutton to open the FOLDER, or play the
selected file.
When displaying the root menu, you can also use the number buttons to select the
serial number of the file and play the file.
* The ANGLE, PROG, RDM, INT and TITLE/PBC button are not valid.
* The other functions are same as ones in DVD disc; but the RPT function is same as
one in MP3/WMA.
4.22 ESP and ID3 Function
There is ESP function for all formats of discs.
In MP3/WMA mode, during playback, the information of the file name,
folder name, song s title, artist and album will be scrolling on the LCD display.
As long as the current playing MP3 music contains relevant ID3 tag information
in version 1.0/2.0 format, the 3 items underlined above will be scrolling on the
LCD display; otherwise, they will not.
4.23 USB and SD Reader Operation
Power on the DVD player, then insert the USB storage or SD Card
(firstly flip down the front panel), and then the monitor will display the root
menu of the USB storage or SD Card.
All the operations are same as ones of the corresponding format.
When you want to pull out the Card, firstly push it,
and then pull it out.

11
11
10.Toadjust sound modes
To adjust thesound modes, briefly and repeatedly pressthe SEL button
on the frontpanel to selectone of the sound modes such as : VOL, BAS
(without preset EQ),TRE (without preset EQ), BAL,FAD and EQ.
Note: this functionexcept in playmode select.
11. Return control
Press the buttonor MENU buttonto up to the previous menu.
12. To do setup
In setup mode,select the GENERAL, CLOCK,
OSD LANGUAGE,AUDIO, VIDEO, RADIO as follow:
GENERAL SETUP
Logo: this functionallows to choose the starting screen.
Beep: choose thebuttons' sound on/off.
CLOCK SETUP
Clock mode: select24 HOUR or12 HOUR.
Clock time: adjustthe clock.
LANGUAGE SETUP
OSD Language: onlybe English.
AUDIO SETUP
MBP:choose between MBPLEFT/RIGHT/OFF.
Loud: choose betweenLoudness ON/OFF.
EQ: choose betweenthe different types of EQ.
VIDEO SETUP
Brightness
Contrast
Saturation
Hue
RADIO SETUP
Radio region: choosethe radio zone.
RDS setting: ON/OFF
CLOCK SETUP
LANGUAGE SETUP
AUDIO SETUP
VIDEO SETUP
RADIO SETUP
GENERAL SETUP
20
4.19 Program Playback
It allows youto enter the order in which you want some chapters/tracks in
DVD/VCD/MP3/WMA/CD disc to play.
1 During playback,press the PROG button to enter a program interface as
follows:
2 Use thedirection buttons to move cursor onto the desired place for inputting
the sequence number.
3 Use thenumber button to input desired sequence number of title/chapter/
track with desired sequence.
4 Use thedirection button to move cursor onto Play item, then press the OK
button to play the programmed titles/chapters/tracks in programmed order;
only pressing thePLAY button also canplay the programmedtitles/chapters
/tracks in programmed order.
* To exit program playback, firstly press the STOP button, then press the PLAY
button to enter sequence playback; or press the PROG button twice again.
* To remove the all programmed sequence numbers, move the cursor onto
Clear item, then press the OK button.
* To change the programmed sequence, move the cursor onto the item you
want to change, input the desired sequence number.
* During VCD playback, if it is in PBC ON mode, at the same time of entering
the state of program playback, it turns off PBC mode.
4.20 Playback Picture CD in JPEG Format
1. The root menu is displayed on the monitor when beginning to switch on
DISC mode. At the time, it plays MP3/WMA file.(the TITLE or MENU button
is not available).
In the root menu, the left file sort icon is for MP3/WMA file; the middle file sort
icon is for JPEG file; the right file sort icon is for VIDEO file. If one of these 3
file sort does not exist, you can not move cursor onto the file sort icon.
2. When displaying the root menu, press the direction buttons to select your
desired FOLDER, file or file sort icon, then press the OK or PLAY button to
open the FOLDER, or play the selected file, or play only this sort of file.
When displaying the root menu, you can also use the number buttons to
select the serial number of the file and play the file.

12
12
3. Radio Operation
1. BAND BUTTON
Press the BAND button on the front panel to select your desired
radio band of FM1, FM2, FM3, AM1 and AM2, and the selected
band will be displayed on the monitor of the front panel, press
1-6 buttons to select your favour.
Press and hold this button again to select RDS function such as :
PTY, AF, TA, ST, LOC, LOUD by rotate VOL knob.
2. TUNE/SEEK UP/DOWN BUTTONS
1) Press and hold the UP/ DN button to automatically search up/
down for a available station from the current frequency.
2) Briefly press the UP / DN button to manually search up or down
with step by step for your desired station from the current
frequency.
3. APS BUTTON
1) When pressing and holding the APS button, the radio searches from the lowest frequency
and checks the signal strength level until 1 cycle search is finished. And then the 6 strongest
stations are preset to the corresponding preset number memory bank. The AS operation
is implemented in each bank of the selected band. When the AS operation is finished,
the radio executes the preset scan, and after preset scanning for one cycle, it will stop
scanning and broadcasting the No.1 station for Fm1.
(It can store 3x6 stations for FM and 2x6 stations for AM in all)
2) When pressing the APS button briefly on the front panel or the remote control, the radio
searches for each preset station from the M1. When the field strength level is more than the
threshold level of the stop level, the radio holds at that preset number for few seconds with
releasing mute, and then searches again. After finishing a circle of searching, it will stop
searching on the M1.
NOTE: In FM band, FM1,FM2,FM3 is checked one at a time.
In AM band, AM1, AM2 is checked one at a time.
4. PRESET STATION [ 1-6 ] BUTTONS
1) To memorize the current frequency on the current band, press and hold any one of the six
Number buttons (1-6) .
2) To recall the memory station on the current band, press one of the Number buttons [1-6] .
5. STEREO/MONO BUTTON
Press the ST button on the remote control to select the STEREO or MONO sound mode for
FM band.
6. LOC BUTTON
1) When the signal of distant radio stations are very weak and the receiving effect is bad
during tuning, check whether there is the word LOC on LCD. If there is the word LOC on LCD,
press this button to turn off the LOC function, then tune again for the distance radio station;
2) When the signals from the local radio stations are too strong, this could lead to interference.
press this button to turn on the LOC function, and the LOC icon will be lit up on the LCD.
Re-tune for the local station required.
Radio interface-1
Radio interface-2
19
19
4.14 Playback in Random
When playing DVD/VCD(PBCOFF)/MP3/WMA/CD discs, pressthe RDM
button to switchbetween RANDOM (ON)/RANDOM OFF. When in RANDOM
(ON) mode, it will play in random.
4.15 Playback in Different Angle
1. When playing VCD/MP3/WMA/CD discs, the ANGLE buttonon the IRremote
control is not available.
2. When playing DVD discs, press the ANGLEbutton repeatedly onthe IR
remote control toview in different angle.(This functionis only forthe DVD
discs with ANGLE function)
4.16 Playback in Zoom Mode
In DVD/VCD mode, during playback,press the ZOOM button continuously
to enlarge acertain area of the images on the screen with these multiples:
ZOOMx2,ZOOMx3,ZOOMx4,ZOOMx1/2,ZOOMx1/3,ZOOMx1/4,ZOOM OFF.
Press one ofthe ^/v/>/< buttons to select the areayou want to enlarge.
4.17 Change Caption Language
When playing DVDdiscs, press the SUBTITLE button repeatedly to select
the language ofthe caption or turn off the caption.(depend on the disc used.)
When playing VCD/MP3/WMA/CDdiscs, the button is not available.
4.18 Change Audio Language
1. When playing DVD discs, press the AUDIObutton repeatedly onthe IR
remote control to select the desired language type(depend on the disc used)
2. When playing VCD discs, press the AUDIObutton repeatedly toselect the
sound mode of the MONO L, MONO R, and Stereo, no language function.
3. When playing CD/WMA/MP3 discs, the AUDIO button is invalid.

13
13
7. PTY (PROGRAM TYPE) BUTTON
Press the PTY button briefly to select oneof the following modes:
PTY MUSIC group- - PTYSPEECH group- - PTY OFF
When PTY group is on, press the VOL+ or VOL- button on the remote
controller or rotatethe VOL knob on thefront panel to select one of PTY
programs: <-->NEWS<-->AFFAIRS<-->INFO<-->SPORT<-->EDUCATE
<-->DRAMA<-->CULTURE <-->SCIENCE<--> VARIED<-->WEATHER<-->
FINANCE<-->CHILDREN<-->SOCIAL<-->RELIGION<-->PHONE IN<-->
TRAVEL<-->LEISURE<-->DOCUMENT< -->PTY NONE<-->POP M< -->
ROCK M<-->EASY M<-->LIGHT M<--> CLASSICS<-->OTHER M<-->
JAZZ<-->COUNTRY<-->NATION M<-->OLDIES<-->FOLK M<-->
When PTY group is on, pressing the 6 number buttons also can select one of
PTY programs as above.
After selecting one of the PTY programs, it will display SEEK PTY and
automatically search forthe station of the PTY program. If the station of
the PTY program does notexist, it will display PTY NONE and then return
back to the normal station.
8. AF [ALTERNATIVE FREQUENCIES] BUTTON
When pressing theAF button briefly, the AF switching mode isselected and
the state of the AF switching mode is displayed by AF segment in display.
Segment off: AF switchingmode off.
Segment on: AF switching mode on, and has RDS information.
Segment flashing: AF switching mode on, but RDS information is not
received yet.
When theAF switching mode is selected, the radio checks thesignal strength
of the AF all the time. The interval of checking time of each AFs depends on
the signal strengthof the current station, from a few minute for the strong
station to afew seconds for the weak station. Every time thata new AF is
stronger than thecurrent station, it switches over to that frequency for very
short time, and the NEW FREQUENCY is displayed for 1-2 second. Because
the mute timeof the AF switching or the checking timeis very short, it is
almost inaudible in case of normal program. (When AF flash on LCD, it will
search for the stronger RDS station. If AF and TP flash on LCD, it can only
search for the traffic announcement station).
In FM mode, when AF is on, SEEK, (SCAN), AUTO-MEMORY function can
only receive andsave the RDS program.
9. TA [TRAFFICANNOUNCEMENT] BUTTON
Press the TAbutton briefly to turn on TAsearch mode.
When traffic announcement is transmitted:
1).If the unit is in Disc Play mode, it will switch to radio mode temporarily.
2).Temporarilyswitch over to an EON linked station when EONdetects a
traffic announcement on that other program, and TA, TP will be displayed
on LCD
* TA interruption function:
The current traffic announcement is cancelled by pressing TAbutton
briefly.
* When TAis on, SEEK, (SCAN), AUTO MEMORY function can be received
or saved only when traffic program identification code has been received.
18
18
4.11.2 A-B Repeat
Press the A-B button if you want to repeat a specific segment ona disc
that you define:
1. Press the A-B button at a point (A) where you want it to be the start point
of the repeat segment. Press the A-B button again ata point (B) where you
want it to be the terminal point of the repeatsegment. Then it will playthe
segment repeatedly.
2. To cancel the A-B repeat mode and resume normal playback, press the A-B
button for the third time.
Note:
During VCD/MP3/WMA/CD playback,points Aand B must be within the
same track.
During DVD playback, points Aand B can be selected from different chapters.
4.12 Playback in Scan Mode
1. When playing VCD(PBC OFF)/CD discs, press the INT button to play the
previous 10 secondspart of each track on thedisc. Press theINT button
again to resumenormal playback.
2. When playing DVD/MP3/WMA discs, the INT button is not available.
4.13 Playback from a specified chapter/track or a specified time
1. When playing DVD discs, press the SEARCH button to display ainterface
and highlight thetitle item, then use the number buttons to input the serial
number of thetitle; use the direction buttons tohighlight the chapteritem,
then use thenumber buttons to input the serialnumber of thechapter; you
can still usethe direction buttons to highlight thetime item, thenuse the
number buttons toinput the desired time to startplayback; finally pressthe
OK or PLAY button to play the selected chapter or play from theselected time.
2. When playing VCD/MP3/WMA/CD discs, press the SEARCH button to display
a interface andhighlight the track item, then use the number buttons to input
the serial numberof the track; you can still use thedirection buttons to high-
light the timeitem, then use the number buttonsto input thedesired time to
start playback; finallypress the OK or PLAY button to play the selected track
or play fromthe selected time.

14
14
4. Basic Disc, USB or SD Operation
4.1 Begin playback
1. Press the POWER button briefly to turn onthe DVD player.
After turningon the DVD player, please turn on the monitor, andensure that
the video output of the monitor is the video input from the DVD player
connected with the monitor.
? Common Question
Q: There is nothing displayed on TV screen when the DVD player is turned on.
How to solvethe problem?
A: Ensure that the TV is set to correct video input(notTV channel); for
example, if youmake VIDEO1 INPUTof TV and DVD playerconnected
with each other, then you need set TV to VIDEO1.
2. Press the RELEASE button to detach the front panel from the unit.
3. Insert a disc into the DISC SLOT(Label surfaceup), then flip up the
front panel untilit clicks intoplace.
NOTE
1. For some discs that are seriously scratched or poor manufacturing or
recording quality, it may not play.
2. If the player can not read disc under normal condition, please try to
eject and reload the disc again.
3.
nsert an USBor SD Card into their slots respectively, then the root menu
will be displayed on the monitor and it will play audio file automatically
if the USB or SD Card include audiofiles.
Remark:
1) In addition to normal CD and DVD, this unit supports to play CD-R,
CD-R/W, DVD-R and DVD-R/W as well; however, depending on the
conditions of therecording equipment, recording program or the disc
itself, some CD-R, CD-R/W, DVD-R or DVD-R/W may not play.
2) When dealing with CD-R, CD-R/W, DVD-R or DVD-R/W recording,
too high recording speed may result in poor signal quality and therefore,
it is recommendable to select as lower as possible recording speed.
4. Play USB & Card
I
17
17
4.8Playback with Speed
During normal playback,press and hold the UP/DN button on the front panel
or the >>|/|<< button on the remote controller continuously to fast forwards
or backwards at the following speeds: x2, x4, x8, x20, normal.
During speed playback,press the PLAY button to resume normalplayback.
4.9Playback with Slow Speed
During playback ,press the SLOW_FWD button to executethe Slow
Forward function.
With each consecutive pressing of the SLOW_FWD button, the playback
speed decreases. The speed levelsin Slow Forward as follows:
x1/2,x1/3,x1/4,x1/5,x1/6,x1/7,normal.
During slow forward,press the PLAY button to resume normalplayback.
The function is only for video.
4.10Playback with stillframe
If the unit is currently runningDVD/VCD disc, pressthe STEP button
consecutively to display the still frameforward with stepby step.
Press the PLAY button to resume normal playback.
4.11.Playback Repeatedly
4.11.1 ONE/ALL Repeat
1. In the mode of DVD disc playback:
Press the RPT button to select REP CHAPTER, REP TITLE, REP ALL
or REP OFF.
2. In the mode of VCD(PBC OFF)/CD disc playback:
press the RPT button to select REP ONE, REP ALL or OFF.
When it is in the stateof PBC ON, during VCDdisc playing, the RPT
button are not available.
3. In the mode of MP3/WMA disc playback:
Press the RPT button to select REP ONE, REP DIR, REP ALL or OFF.

15
15
Audio interface-2
Keyboard interface
:select to pauseplayback.
: select tostop playback .
: select either one for next or
previous chapter/track.
: Same asthe REPEAT button on the
remote control.
: To select RDMon/off.
: To select audiolanguage.
: To select LOUDon/off.
4.2 Pause Playback
When playing DVD/VCD/CD/MP3/WMAdiscs,
press the PAUSE button on IR remote control
to pause the playback, press the PLAY button
to resume normal playback.
4.3 Stop Playback
When playing DVD/VCD/MP3/WMA/CD discs,
press the STOP button once to pausethe
playback, then press the PLAY button to
resume the normal playback; press the STOP
button twice to stop the playback, then press
the PLAY button to start playbackfrom the
beginning of the first chapter/track.
4.4 Select Chapter/Track with UP/DNor >>| / |<< Button
Press the UP/DN button on the front panel or the >>| /|<< button on the
remote control during playback to select the next or last chapter/track to
playback.
Note: Press the UP/DN or the >>|/|<< button multipletimes to advance
multiple chapters/tracks forward or backward.
Press OSD onthe remote to turn on function select.
16
16
Audio interface-1
USB interface
4.5 Select Chapter/Track with NumberButtons
When playing DVD/VCD(PBC OFF)/MP3/WMA/CD discs, press one of the 1~9
number buttons to directly select and play the 1stto 9th track /chapter.
If you want to play the track/chapter with serialnumber bigger than 9,
For example 1, to play the 13th track/chapter,justpress 1 and then press 3,
you can also press the 10+ button and thenpress 3; to play the 23thtrack/
chapter, just press 2 and then press 3or press the 10+ button twiceand then
press 3.
For example 2, to play the 107 track/chapter,just press 1 and press 0 and
then press 7 on the remote.
Note: pressing and holding the +10 or -10 buttonswill allow you to play thenext
10 or last10 chapter/track(only forMP3/WMA).
4.6 Select Chapter/Track with Root/PBCMenu (If theused disc includes
root/PBC menu)
When playing DVD discs:
1. Press the TITLE button on the remote control to display the title list.
2. Press the direction buttons toselect your desired title, and thenpress the OK
or PLAY button to open the root menu of the selected title.
3. Press the direction buttons toselect your desired chapter, finallypress the
OK or PLAY button to play the selected chapter.
During playback, pressing the MENU button can directly displaythe root
menu of the title that is playing.
In VCD mode
1. When startingto turn onthe PBC function, it will play from the beginning of
the disc tillit display thePBC menu on TV screen, if the discincludes PBC menu.
2. Press thenumber buttons toselect your desired track to play.
In MP3/WMAmode
1. The root menu isdisplayed on the monitor screen allthe time(and the TITLE
or MENU buttonis not available).
2. Press thedirection buttons toselect your desired FOLDER, then press the
OK or PLAY button to open theFOLDER, and then press the directionbuttons
to select yourdesired file, finallypress the OK button to play the selected file.
In CD mode,the TITLE, PBC, MENU buttonsare disabled.
4.7 Terminate Playback
1. Press theRELEASE button todetach the front panel from the unit, then press
the EJECT button to ejectdisc, and then remove the disc and flip upthe front
panel till hearinga clip.
2. Press andhold the POWERbutton on the front panel or briefly press the
POWER button onthe remote controllerto turn off the DVDplayer.
