Planet Networking & Communication IHD-210PR User manual

High Definition HDMI Extender
over IP with PoE
IHD-210PT / IHD-210PR

High Definition HDMI Extender over IP with PoE
IHD-210PT / IHD-210PR
2
Copyright
Copyright (C) 2017 PLANET Technology Corp. All rights reserved.
The products and programs described in this User’s Manual are licensed products of PLANET
Technology, This User’s Manual contains proprietary information protected by copyright, and this
User’s Manual and all accompanying hardware, software, and documentation are copyrighted.
No part of this User’s Manual may be copied, photocopied, reproduced, translated, or reduced to any
electronic medium or machine-readable form by any means by electronic or mechanical including
photocopying, recording, or information storage and retrieval systems, for any purpose other than the
purchaser's personal use, and without the prior express written permission of PLANET Technology.
Disclaimer
PLANET Technology does not warrant that the hardware will work properly in all environments and
applications, and makes no warranty and representation, either implied or expressed, with respect to
the quality, performance, merchantability, or fitness for a particular purpose.
PLANET has made every effort to ensure that this User’s Manual is accurate; PLANET disclaims
liability for any inaccuracies or omissions that may have occurred. Information in this User’s Manual is
subject to change without notice and does not represent a commitment on the part of PLANET.
PLANET assumes no responsibility for any inaccuracies that may be contained in this User’s Manual.
PLANET makes no commitment to update or keep current the information in this User’s Manual, and
reserves the right to make improvements to this User’s Manual and/or to the products described in
this User’s Manual, at any time without notice.
If you find information in this manual that is incorrect, misleading, or incomplete, we would appreciate
your comments and suggestions.
FCC Compliance Statement
This Equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be determined

High Definition HDMI Extender over IP with PoE
IHD-210PT / IHD-210PR
3
by turning the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and receiver.
– Connect the equipment to an outlet on a circuit different from that to which the receiver is
connected.
– Consult the dealer or an experienced radio/TV technician for help.
CE mark Warning
The is a class A device. In a domestic environment, this product may cause radio
interference, in which case the user may be required to take adequate measures.
WEEE
To avoid the potential effects on the environment and human health as a result of the
presence of hazardous substances in electrical and electronic equipment, end users of
electrical and electronic equipment should understand the meaning of the crossed-out
wheeled bin symbol. Do not dispose of WEEE as unsorted municipal waste and have to collect such
WEEE separately.
Trademarks
The PLANET logo is a trademark of PLANET Technology. This documentation may refer to numerous
hardware and software products by their trade names. In most, if not all cases, these designations are
claimed as trademarks or registered trademarks by their respective companies.
Revision
User’s Manual of PLANET High Definition HDMI Extender over IP with PoE
Model: IHD-210PT / IHD-210PR
Rev.: 1.0 (April, 2017)
Part No. EM-IHD-210 Series_v1.0

High Definition HDMI Extender over IP with PoE
IHD-210PT / IHD-210PR
4
Table of Contents
Chapter 1. Product Introduction.............................................................................5
1.1 Package Contents............................................................................................................5
1.2 Overview..........................................................................................................................6
1.3 Features.........................................................................................................................10
1.4 Product Specifications ...................................................................................................11
1.5 Hardware Interface ........................................................................................................13
1.5.1 Diagrams:.............................................................................................................13
1.5.2 Interfaces:............................................................................................................14
1.6 Device Connection Topology.........................................................................................15
Chapter 2. Hardware Installation..........................................................................17
2.1 Devices Requirements...................................................................................................17
2.2 Installation Instructions ..................................................................................................17
Chapter 3. Preparation..........................................................................................18
3.1 Downloading IPTV Control Center Software .................................................................18
3.2 Setting TCP/IP on your PC ............................................................................................18
3.2.1 Windows XP.........................................................................................................18
3.2.2 Windows 7 ...........................................................................................................21
3.2.3 Windows 10 .........................................................................................................24
Chapter 4. IPTV Control Center Instructions.......................................................27
4.1 System ...........................................................................................................................27
4.1.1 Search..................................................................................................................27
4.1.2 Go to Tx/Rx Setup Page......................................................................................28
4.1.3 Tx Setup Page.....................................................................................................29
4.1.4 Rx Setup Page.....................................................................................................31
4.1.5 Factory Reset ......................................................................................................32
4.1.6 Firmware Upgrade...............................................................................................32
APPENDIX A. Troubleshooting & Frequently Asked Questions ....................35

High Definition HDMI Extender over IP with PoE
IHD-210PT / IHD-210PR
5
Chapter 1. Product Introduction
1.1 Package Contents
The package should contain the following:
Media Extender x 1
Quick Installation Guide x 1
IR Emitter Cable with Transmitter x 1
IR Receiver Cable with Receiver x 1
If any of the above items are missing, please contact your dealer immediately.

High Definition HDMI Extender over IP with PoE
IHD-210PT / IHD-210PR
6
1.2 Overview
Make Advertising Effective and Easy
PLANET IHD-210 HDMI Extender over IP with PoE delivers a great Full-HD video distribution solution
such as bringing an efficient and effective advertising deployment. The IHD-210 series is the
combination of the transmitter, IHD-210PT, and the receiver, IHD-210PR. They can distribute HD
digital content from multiple sources to practically any number of remote displays on a LAN and
deliver ultra high-quality 1080p HDMI video broadcast over IP network. It not only offers vivid 1080p
full motion video, but also ensures the sharp images and text give the viewers the maximum visual
effect and ease of reading. By cascading multiple Ethernet switches as the backbone of the IHD-210
series, it allows displays to be distributed far away from the source devices while sustaining consistent
1080p video and audio quality. The video sources can be rack centralized, decentralized or even a
mixture of both. It thus increases the flexibility, scope and scalability of audio and video distribution via
the Ethernet networks.
IR Extension for Controlling Video Source
The IHD-210 series is a perfect solution for audio and video signal extension via the existing LAN.
Designed with IR transmitter and receiver interface, it allows users to control the video source at the
terminal destination. The IHD-210 series also features bi-directional IR extension and RS232 pass-
through allows the user to cascade the system enabling them to extend the transmission distance
without signal loss or delay. Its numerical LED indication enables users to recognize immediately the
current group ID. It also supports HDMI Local Output function for checking video source conveniently.
Besides, with PoE function, there is no additional power supply needed, and the IHD-210 series thus
reduces the complexity of cable installation.

High Definition HDMI Extender over IP with PoE
IHD-210PT / IHD-210PR
7
Exclusive Video Transmission by IGMP Snooping Technology
One IHD-210PT in local site can drive multiple IHD-210PRs in remote sites without consuming extra
network loading. When connected to PoE switch with IGMP snooping function, the IHD-210 series
can offer selectable 64 channels, so video and audio can be transmitted simultaneously. IGMP
snooping is an integral part of IP multicast and a communications protocol used by hosts and
adjacent routers on IP networks to establish multicast group memberships. IGMP snooping can be
used for one-to-many/many-to-many networking applications such as online streaming video and
gaming, and allows exclusive transmission and more efficient use of resources.
Extended Display Identification Data (EDID) Support
The IHD-210 series adopts Automatic EDID (Extended Display Identification Data) Copy function to
make smooth video distribution over different types of display units. EDID is greatly important as it
contains information about resources’ manufacturer names, serial numbers, product types, maximum
image sizes, color characteristics, factory pre-set timings, frequency range limits, etc. In some cases,
display problems may occur due to incorrect EDID communication between the display monitor and
the transmitting unit or inappropriate EDID data programmed by display manufacturers. Therefore,
with Automatic EDID Copy function, the IHD-210 series allows the system to copy EDID information
from EDID compliant displays and assures accurate display performance.

High Definition HDMI Extender over IP with PoE
IHD-210PT / IHD-210PR
8
Video Channel Setting Matches Well through Network Configuration
The IHD-210 series network can be configured by a central computer over the same LAN within a
certain distance. Fully leveraging the mature Ethernet switches with 802.1Q VLAN function, multi-
casting can be performed to allow more video sources/senders in the network and be remotely
managed. Just adjust and match video channel setting with the simple DIP switch in both the IHD-
210PT and IHD-210PR. The video distribution is easily deployed through Plug and Play.

High Definition HDMI Extender over IP with PoE
IHD-210PT / IHD-210PR
9
High-quality Output and Performance
The IHD-210 series supports Full HD 1080p, HDCP and blu-ray quality, which have been commonly
used for applications that require real-time high video resolution and transmission in long distance. It
also includes security and noise immunity as well as HDMI with 2-ch uncompressed audio function to
offer the superior video distribution.

High Definition HDMI Extender over IP with PoE
IHD-210PT / IHD-210PR
10
1.3 Features
HDMI Network
1080p ultra high-quality video transmitter
Supports IR extension for controlling video source
Supports RS232 bi-directional remote extension
Assigns video sources to any monitor of the video extend system
The selectable 64-channel DIP switch is easily applied for multi-casting group matching
1-to-1,1-to-many and multi-casting broadcasting architectures allow to add more displays
without increasing LAN bandwidth loading
Video Output Characteristics
Compatible with HDTV resolution of 1080p and 1080i
High compression streaming for saving bandwidth
HDCP compliant and blu-ray ready
Supports HDMI local output
Compatible with common screen resolutions from XGA, SXGA, UXGA and WSXGA to Full HD
system
Supports HDMI with 2-ch uncompressed audio
Easy Installation and Management
Numerical LED indication for identifying group ID
IEEE 802.3af/at PoE+ function supported; no additional power supply needed
Automatic EDID (Extended Display Identification Data) configuration
Simple utility for ease of use
Supports multi-casting group with Ethernet Managed Switch (IGMP snooping function required)

High Definition HDMI Extender over IP with PoE
IHD-210PT / IHD-210PR
11
1.4 Product Specifications
Model
IHD-210PT
IHD-210PR
Hardware Specifications
Network Interface
RJ45 port (10/100BASE-TX Ethernet) x 1
Serial Interface
DB-9 female connector for RS232 x 1
Cabling Cat5e/6 UTP cable
LED
Numerical LED display
Buttons
Reset button x 1
Video In Interface
HDMI A Type female connector
x 1
N/A
Video Out Interface
HDMI A Type female connector x 1
IR 3.5mm jack for IR emitter cable
3.5mm jack for IR receiver
cable
Channel Switching
DIP (64 channels)
Standards Conformance
Standards Compliance
IEEE 802.3 10BASE-T
IEEE 802.3u 100BASE-TX
IEEE 802.3af/at PoE+
HDMI Interface Compliance
HDMI 1.4a
Video In Resolution
1080p @ 60/50 Hz
1080p @30/25 Hz
1080i @ 60/50 Hz
720p @ 60/50 Hz
480p @ 60/50 Hz
480i @ 60/50 Hz
N/A
Video Out Resolution
1080p @30/25 Hz
1080i @ 60/50 Hz
720p @ 60/50 Hz
480p @ 60/50 Hz
480i @ 60/50 Hz
Compression
H.264 format for video encoder/decoder.
MPEG 1 Layer II format for audio encoder/decoder
Security
HDCP compliant
Audio
2-ch uncompressed audio
Maximum Distance
100 meters
Management Interfaces
Search Tool
Media Stream Bandwidth
(max.)
15Mbps

High Definition HDMI Extender over IP with PoE
IHD-210PT / IHD-210PR
12
System Expandability (max.)
64 groups
Resolution Identification
EDID (Extended Display Identification Data)
Protocol
TCP, UDP, RTSP, RTP, DHCP, IGMP Snooping, Multicast, IPv4
Environment Specifications
Operating
Temperature: 0~55 degrees C
Relative Humidity: 5~90% (non-condensing)
Storage
Temperature: -10~60 degrees C
Relative Humidity: 5~90% (non-condensing)
Power Supply
IEEE 802.3af/at PoE+
5V DC, 2A
Power Consumption
7W (each unit)
Dimensions (W x D x H)
130 x 82 x 30.25 mm
Weight
290 g
Emission
FCC, CE

High Definition HDMI Extender over IP with PoE
IHD-210PT / IHD-210PR
13
1.5 Hardware Interface
1.5.1 Diagrams:
Transmitter:
Receiver:

High Definition HDMI Extender over IP with PoE
IHD-210PT / IHD-210PR
14
1.5.2 Interfaces:
Transmitter (IHD-210PT)
Receiver (IHD-210PR)
Interfaces Definition:
Position
Description
Function
1 DC 5V
5V/2A DC power input.
Only use one power source, either from DC or from 802.3af/at PoE+
Ethernet switch.
2 Ethernet (PoE)

Connect to a LAN Switch.
IGMP snooping and jumbo frame supported Gigabit IEEE 802.3af/at
PoE+ Ethernet switch is recommended.
LED.
1. LAN LED (green color):
This LED will be flashing while network is accessing via Ethernet.
2. Power LED (orange color):
When the device is powered on, and the device is connected to
Ethernet switch, the LED will be always on.
3
HDMI Out
HDMI Type A female connector for video output.
4 HDMI In HDMI Type A female connector for connecting to the HDMI source (built in
transmitter,
5 IR
Transmitter: 3.5mm jack for IR emitter cable to control video source device.
Receiver: 3.5mm jack for IR receiver cable to receive signal from remote
controller.
6
RS232
DB-9 female connector for RS232 bi-directional remote extension.
7
Channel
Display group indication.
8
Group
Group configuration, 6-bit switch for 64 stream channel selection.
9 Reset Power on the device and press the reset button for over one second to
restore it to factory default settings.

High Definition HDMI Extender over IP with PoE
IHD-210PT / IHD-210PR
15
1.6 Device Connection Topology
PLANET IHD-210PT and IHD-210PR work as a pair to facilitate the management tool and HDMI
display over IP Ethernet with PoE.
Video Extender
The IHD-210PT and IHD-210PR are able to send the same video signal to multi-monitors in different
locations at the same time. It helps to quickly extend the image and commercial to the public
efficiently in such places as expos, food courts, boardrooms, and any public areas.
Efficient Control via Selectable 64-channel DIP Switch
Where there is more than one transmitter in the video extend system, the DIP switch in the IHD-
210PT and IHD-210PR facilitates distinguishing the pair of the transmitter and receiver units in the
same channel. It further enables the broadcasting system to perform multiple video extend systems
simultaneously through matching of the IHD-210PT and IHD-210PR.

High Definition HDMI Extender over IP with PoE
IHD-210PT / IHD-210PR
16
Ideal Solution for Wide Variety of Commercial Installation Environments
The IHD-210 series uses the advanced H.264, which makes it occupy lower bandwidth and play the
video more smoothly. It supports 100m over single cat5e/6 cable at point to point, as well as point to
many and many to many over Ethernet switch. The video extend solution is ideal for live
presentations, public broadcasting, education training, boardrooms, etc.

High Definition HDMI Extender over IP with PoE
IHD-210PT / IHD-210PR
17
Chapter 2. Hardware Installation
2.1 Devices Requirements
1. Monitor: HDCP compliant monitors with HDMI interface for the HDCP video source.
2. Ethernet cable: Cat5/5e/6 UTP cable (EIA/TIA 568B industry standard compliant).
3. PoE Switch: Please see the recommended PoE switch.
4. PC OS: Windows XP/7/8.1/10.
Application
Recommended Ethernet Switch
Video Extend Application
Gigabit PoE Switch with IGMP snooping function
The quality of the output signal will depend largely upon the quality of video source, cable
and display device used. Low-quality cables degrade output signal causing elevated noise
levels. Please use the proper cable and make sure the display device is capable of handling
the resolution and refresh rate selected.
2.2 Installation Instructions
1. Connect the video source to the Transmitter (IHD-210PT) unit’s HDMI In interface.
2. Connect the monitor to the Receiver (IHD-210PR) unit’s HDMI Out interface.
3. Use Cat5e/6 cables (EIA/TIA 568B industry standard compliant) for connection between
Transmitter/Receiver and the IEEE 802.3af/at PoE+ switch.
4. Set an identical ID number on DIP switch for all units of the same group.
5. Connect the IR emitter cable to Transmitter, and connect the IR receiver cable to Receiver.
(optional)
6. Apply the proper power to all connecting devices.
1. Ensure that all devices are powered off before connecting to the unit.
2. Make sure all devices connected are properly grounded.
3. Place cables away from fluorescent lights and air conditioners that are likely to generate
electrical noise.
4. Please allow adequate space around the unit for ventilation.

High Definition HDMI Extender over IP with PoE
IHD-210PT / IHD-210PR
18
Chapter 3. Preparation
3.1 Downloading IPTV Control Center Software
When you install the IHD-210 series in a LAN environment, you can execute IPTV Control Center to
discover IHD-210 series’ IP address and set up related parameters in the device.
Please go to PLANET website and download the IPTV Control Center:
http://www.planet.com.tw/en/support/download.php?view=8184&key=IHD-210#list
3.2 Setting TCP/IP on your PC
The default IP address of IHD-210 series is B class networking:168.254.xxx.xxx. Please set up the IP
address of the connected PC as static IP, such as 169.254.xxx.xxx and the sub mask as 255.255.0.0.
Please refer to the following to set the IP address of the connected PC.
Please do not set more than one IP address in the connected PC.
3.2.1 Windows XP
If you are using Windows XP, please refer to the steps below:
1. From the desktop, right-click My Network Places > Properties.

High Definition HDMI Extender over IP with PoE
IHD-210PT / IHD-210PR
19
2. Right-click on the Local Area Connection and select Properties.
3. Select Internet Protocol (TCP/IP) and click Properties.

High Definition HDMI Extender over IP with PoE
IHD-210PT / IHD-210PR
20
4. Select "Use the following IP address".
IP address: You have to set the same network segment between your PC’s IP address and the
transmitter/receiver.
For example, if the transmitter’s IP is 169.254.0.157, then you should set your PC’s IP address to
169.254.0.xxx where xxx can be any number between 2 and 253. (same as receiver)
Subnet mask: Enter 255.255.0.0.
Please do not set more than one IP address in the connected PC.
