Simplified MFG EXFBR User manual

EXFBR
VER 1.5

1 / 7
Thank you for purchasing the EXFBR
The Simplified MFG EXFBR is designed to provide years of reliable service. At
Simplified MFG, we want the experience with this device to be the best possible
and are committed to helping achieve that experience.
Surge protection device recommended
The EXFBR contains sensitive electrical components that may be damaged by
electrical spikes, surges, electric shock, lighting strikes, etc. Use of surge protection
systems is highly recommended to protect and extend the life of your equipment.
A HDSURGE is highly recommended on cable and satellite boxes.
Table of Contents
1. Introduction .....................................................................................................2
2. Features...........................................................................................................2
3. Package Contents..............................................................................................2
4. Specifications....................................................................................................3
5. Operation Controls and Functions .......................................................................4
5.1 Transmitter Panel ...............................................................................................4
5.2 Receiver Panel ...................................................................................................5
5.3 IR Cable Pin Assignments....................................................................................5
5.4 Optical module instructions .................................................................................6
6. Connection Diagram ..........................................................................................6
7. Warranty ..........................................................................................................7
8. Contact ............................................................................................................7

2 / 7
1. Introduction
The EXFBR is a full featured fiber extender that can extend HDMI2.0b (18Gbps)
4K/Ultra HD signal over 33300 feet/10,000 meters over Single-mode fiber. The
EXFBR supports HDMI2.0b 18Gbps 4K/2K @ 60Hz. YUV 4:4:4.
2. Features
•HDMI 2.0b (18Gbps), HDCP 2.2 and DVI 1.0 compliant
•Video resolutions up to 4K2K@50/60Hz (YUV444) up to 18Gbps
•Audio supports LPCM2/5.1/7.1 CH, Dolby Digital/Plus/EX, DTS, DTS-X, Dolby
True HD, DTS-HD Master Audio, and Dolby Atmos
•Transmission up to 33000 feet/10,000 meters over single-mode fiber cable
•Supports HDR10/10+/DolbyVision™
•Control features include 2-Way IR, RS-232, and EDID management
•HDMI loop out on TX
•Audio insertion available on TX and extraction on RX
3. Package Contents
•1 x HDMI over Optical Fiber Transmitter
•1 x HDMI over Optical Fiber Receiver
•1 x Fiber Transmitter Module
•1 x Fiber Receiver Module
•1 x Wideband IR Blaster
•1 x Wideband IR Receivers
•2 x 5V/1A Power Adaptors
•2 x 3-Pin Phoenix Connectors
•1 x User Manual

3 / 7
4. Specifications
Technical
HDMI Compliance
HDMI 2.0b
HDCP Compliance
HDCP 2.2
Video Bandwidth
18Gbps
Video Resolutions
Up to 4K2K@50/60Hz(YUV4:4:4),4K2K@30Hz,1080P@120Hz, and 1080P 3D@60Hz
Color Space
RGB, YCbCr 4:4:4/4:2:2, YUV 4:2:0
Color Depth
8-bit, 10-bit, 12-bit
HDMI Audio Formats LPCM 2/5.1/7.1CH, Dolby Digital, DTS 5.1, Dolby Digital+, Dolby TrueHD, DTS-HD
Master Audio, Dolby Atmos, DTS:X
Operation Range
Up to 33000 feet/10,000 meters over single-mode fiber cable
IR Frequency
20KHz - 60KHz
RS-232 Baud Rate
4800-115200bps
ESD Protection
Human body model — ±8kV (air-gap discharge) & ±4kV (contact discharge)
Connections
Transmitter Inputs:
1x HDMI Type-A female
1x 3.5mm mini-jack for stereo audio
1x 3.5mm mini-jack for IR input
1x 3-pin Phoenix connector for RS-232
1x Micro-USB Service Port
Outputs:
1x HDMI Type-A female loop out
1x SFP module output port for fiber connection
1x 3.5mm mini-jack for IR output
Receiver
Inputs:
1x SFP module input port for fiber connection
1x 3.5mm mini-jack for IR input
Outputs:
1x HDMI Type-A female
1x 3.5mm mini-jack for IR output
1x 3.5mm mini-jack for stereo audio
1x 3-pin Phoenix connector for RS-232
Mechanical
Housing
Metal Enclosure
Color
Black
Dimensions
134mm/5.28” [W] x 68mm/2.68” [D] x 18mm/0.71” [H]
Weight
TX: 280g/9.88oz. RX: 278g/9.8oz.
Power Supply
Universal Voltage (100-240V AC) to 5V/1A (US/EU standards, CE/FCC/UL certified)
Power Consumption
TX: 3.85W (Max) RX: 2.7W (Max)
Oper. Temperature
32 - 104°F / 0 - 40°C
Storage Temperature
-4 - 140°F / -20 - 60°C
Relative Humidity
20 - 90% RH (no condensation)

4 / 7
5. Operation Controls and Functions
5.1 Transmitter Panel
Power Fiber In Loop
HDMI
IR IN IR OUT AUDIO EDID
HDMI
LINE SERVICE
❶❷❸❹❺❻❼❽
POW ER FIBE R
HD MI OUT HDM I IN LINE IN RS-232
TX RX
❾❿⓫⓬⓭⓮
No.
Name
Function Description
1
Power LED
Indicates that the TX has a viable power connection
2
FIBER LED
Indicates a connection from TX to RX via Fiber
3 HDMI LED
IN: Indicates HDMI connection on HDMI IN port
LOOP: Indicates HDMI connection on HDMI OUT port
4
IR IN
Connects to IR RX devices. This signal will be output at RX
5
IR OUT
Outputs IR from IR IN on RX
6
AUDIO Switch
Selects Audio from 3.5mm input or from HDMI. Note: the EXFBR
can be used as an audio only device without an HDMI connection
7
EDID Switch
This selects the EDID shown to the source
11: Copies the Output of the RX
10: Copies the Loop Out of the TX
01: 4K 60Hz. Stereo
00: 1080p Stereo
8
SERVICE Port
Used to update firmware
9
Power 5VDC
Connects to 5VDC power supply
10
FIBER
Supplied SFP module (BL-32TG-10DC) is connected here. Fiber is
connected to this module via a LC connector
11
HDMI OUT
This is essentially a built in splitter, however it can be used to
extract audio with an extractor or manipulate EDID
12
HDMI IN
Connects to HDMI source to be transmitted to RX
13
LINE IN
Stereo audio in can be sent to the RX audio out port
14
RS-232
Allows RS-232 signals to be sent to/from RX/TX

5 / 7
5.2 Receiver Panel
Power Fiber
IR IN IR OUT
SERVICE
HDMI
❶❷❸❹❺❻
POW ER FIBE R
HD MI OUT LINE IN RS-232
TX RX
❼❽❾❿⓫
No.
Name
Function Description
1
Power LED
Indicates that the TX has a viable power connection
2
FIBER LED
Indicates a connection from TX to RX via Fiber
3 HDMI LED
IN: Indicates HDMI connection on HDMI IN port
LOOP: Indicates HDMI connection on HDMI OUT port
4
IR IN
Connects to IR RX devices. This signal will be output at RX
5
IR OUT
Outputs IR from IR IN on RX
6
AUDIO Switch
Selects Audio from 3.5mm input or from HDMI. Note: the EXFBR
can be used as an audio only device without an HDMI connection
7
EDID Switch
This selects the EDID shown to the source
11: Copies the Output of the RX
10: Copies the Loop Out of the TX
01: 4K 60Hz. Stereo
00: 1080p Stereo
8
SERVICE Port
Used to update firmware
9
Power 5VDC
Connects to 5VDC power supply
10
FIBER
Supplied SFP module (BL-32TG-10DC) is connected here. Fiber is
connected to this module via a LC connector
11
HDMI OUT
This is essentially a built in splitter, however it can be used to
extract audio with an extractor or manipulate EDID
12
HDMI IN
Connects to HDMI source to be transmitted to RX
13
LINE IN
Stereo audio in can be sent to the RX audio out port
14
RS-232
Allows RS-232 signals to be sent to/from RX/TX
5.3 IR Cable Pin Assignments

6 / 7
5.4 Optical module instructions
❶SFP-BL35T1-02DC is TX optical module.
❷SFP-BL531T-02DC is RX optical module.
6. Connection Diagram

7 / 7
7. Warranty
Should you feel that this product does not function adequately due to
defects in materials or workmanship, we (referred to as “the warrantor”)
will, for the length of the period indicated below (starting from the original
date of the purchase) either a) repair the product with new or refurbished
parts. Or b) Replace the product with new or refurbished product. All
Simplified MFG products are covered by a 3-year PARTS and LABOR
warranty. During this period there will be no charge for unit repair,
replacement of unit components or replacement of the product if deemed
necessary. The decision to repair or replace is made by the warrantor.
The purchaser must mail in the product during the warranty period. This
limited warranty only covers the product purchased as new and is extended
to the original purchaser only. It is non-transferrable to subsequent
owners, even during the warranty period. A purchase receipt or other
proof of purchase date is required for the limited warranty service.
8. Contact
Sales and Tech Support
P. 833-HDMI-411 (833-436-4411)
E. [email protected]om
Simplified MFG • 550 W Baseline Rd Ste 102-121 • Mesa AZ 85210
© Simplified MFG 2022
