Planet HDP-1160PT User manual

720p SIP Vandalproof Door Phone with PoE
HDP-1160PT
1
720p SIP Vandalproof Door
Phone with PoE
HDP-1160PT

720p SIP Vandalproof Door Phone with PoE
HDP-1160PT
2
Copyright
Copyright  2019 by PLANET Technology Corp. All rights reserved. No part of this publication may be
reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or computer
language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or
otherwise, without the prior written permission of PLANET.
PLANET makes no representations or warranties, either expressed or implied, with respect to the contents
hereof and specifically disclaims any warranties, merchantability or fitness for any particular purpose. Any
software described in this manual is sold or licensed "as is". Should the programs prove defective following
their purchase, the buyer (and not PLANET, its distributor, or its dealer) assumes the entire cost of all
necessary servicing, repair, and any incidental or consequential damages resulting from any defect in the
software. Further, PLANET reserves the right to revise this publication and to make changes from time to time
in the contents hereof without obligation to notify any person of such revision or changes.
All brand and product names mentioned in this manual are trademarks and/or registered trademarks of their
respective holders.
Federal Communication Commission (FCC) Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
1. Reorient or relocate the receiving antenna.
2. Increase the separation between the equipment and receiver.
3. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
4. Consult the dealer or an experienced radio technician for help.
FCC Caution
To assure continued compliance, use only shielded interface cables when connecting to computer or
peripheral devices. Any changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)

720p SIP Vandalproof Door Phone with PoE
HDP-1160PT
3
This device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
FCC Radiation Exposure Statement
This equipment complies with FCC radiation exposure set forth for an uncontrolled environment. In order to
avoid the possibility of exceeding the FCC radio frequency exposure limits, human proximity to the antenna
shall not be less than 20 cm (8 inches) during normal operation.
Safety
This equipment is designed with the utmost care for the safety of those who install and use it. However,
special attention must be paid to the dangers of electric shock and static electricity when working with
electrical equipment. All guidelines of this and of the computer manufacture must therefore be allowed at all
times to ensure the safe use of the equipment.
CE Mark Warning
This is a Class B product. In a domestic environment, this product may cause radio interference, in which
case the user may be required to take adequate measures.
WEEE Regulation
To avoid the potential effects on the environment and human health as a result of the presence of
hazardous substances in electrical and electronic equipment, end users of electrical and
electronic equipment should understand the meaning of the crossed-out wheeled bin symbol. Do
not dispose of WEEE as unsorted municipal waste and have to collect such WEEE separately.
Revision
User’s Manual of 720p SIP Vandalproof Door Phone with PoE
Model: HDP-1160PT
Rev: 1.00 (November, 2019)
Part No. EM-HDP-1160PT_v1.0

720p SIP Vandalproof Door Phone with PoE
HDP-1160PT
4
Table of Contents
Chapter 1. Product Introduction ..................................................................................................................... 6
1.1 Package Contents ....................................................................................................................... 6
1.2 Overview ...................................................................................................................................... 6
1.3 Specifications ............................................................................................................................. 10
Chapter 2. Hardware Interface .................................................................................................................... 12
2.1 Physical Descriptions ................................................................................................................ 12
2.2 Hardware Installation ................................................................................................................. 15
2.3 Initial Utility Installation .............................................................................................................. 16
Chapter 3. Web-based Management ........................................................................................................... 17
3.1 Introduction ................................................................................................................................ 17
3.2 Web Configuration ..................................................................................................................... 17
3.3 SIP Configuration....................................................................................................................... 17
Chapter 4. Basic Function ........................................................................................................................... 19
4.1 Making Calls .............................................................................................................................. 19
4.2 Answering Calls ......................................................................................................................... 19
4.3 End of the Call ........................................................................................................................... 19
4.4 Auto-Answering ......................................................................................................................... 20
4.5 DND ........................................................................................................................................... 21
4.6 Call Waiting ................................................................................................................................ 22
Chapter 5. Advanced Function .................................................................................................................... 24
5.1 System ....................................................................................................................................... 24
5.1.1 Information ................................................................................................................. 24
5.1.2 Account ...................................................................................................................... 25
5.1.3 Configurations ............................................................................................................ 26
5.1.4 Upgrade ...................................................................................................................... 27
5.1.5 Auto Provision ............................................................................................................ 27
5.1.6 FDMS ......................................................................................................................... 30
5.1.7 Tools ........................................................................................................................... 30
5.2 Network ...................................................................................................................................... 31
5.2.1 Basic ........................................................................................................................... 32
5.2.2 VPN ............................................................................................................................ 33
5.2.3 Web Filter ................................................................................................................... 35
5.3 Line ............................................................................................................................................ 37

720p SIP Vandalproof Door Phone with PoE
HDP-1160PT
5
5.3.1 SIP .............................................................................................................................. 37
5.3.2 Basic Settings............................................................................................................. 41
5.4 Intercom Settings ....................................................................................................................... 42
5.4.1 Features ..................................................................................................................... 42
5.4.2 Audio .......................................................................................................................... 44
5.4.3 Video .......................................................................................................................... 45
5.4.4 MCAST ....................................................................................................................... 49
5.4.5 Action URL ................................................................................................................. 50
5.4.6 Time/Date ................................................................................................................... 51
5.5 Security Settings ........................................................................................................................ 53
5.6 Function Keys ............................................................................................................................ 55
Appendix A: Troubleshootings........................................................................................................................ 59
Appendix B: How to use ICF-1800 to open door via DTMF code .................................................................. 61

720p SIP Vandalproof Door Phone with PoE
HDP-1160PT
6
Chapter 1. Product Introduction
1.1 Package Contents
The package should contain the following:
■ 1 x HDP-1160PT
■ 1 x Quick Installation Guide
■ 1 x Mounting Label
■ 1 x Screw Kit
■ 1 x Connector
■ 1 x Wrench
■ 1 x Screw Driver
If any of the above items are missing, please contact your seller immediately.
1.2 Overview
Security is Ensured with PLANET Video Door Phone
PLANET HDP-1160PT Vandalproof Video Door Phone is designed for homes and other purposes that need a
visitor’s identification for the sake of security. With its high-quality audio and video, the identification and voice
of the visitor can be clearly seen and heard once the visitor press the call button of the door phone. The
HDP-1160PT works like an intercom. As its name implies, it is vandalproof and has a video feature.
It supports the standard IETF SIP protocol and ONVIF protocol for easy operation and interfaces with the
VoIP and IP surveillance world in an instant it connects you with. It delivers excellent picture quality in 720p
HD resolutions with 112-degree wide angle. The door phone has infrared night vision that can capture any
unusual activity in low light. It also supports HD voice and G.722 codec that relax bandwidth limitation and
provide clear communications. It provides the flexibility and control required for high-quality visitor
management, property protection, intercom, and message service.

720p SIP Vandalproof Door Phone with PoE
HDP-1160PT
7
Easy Communication via Intercom
The two-way intercom function provided by the HDP-1160PT allows you to see the visitors and also
communicate with them. The HDP-1160PT includes 2 short-in detect port and 2 short-out control port for
connecting with external devices such as door lock or door sensors. When the visitors press the call button at
your door, you can press the unlock button on your mobile phone or PLANET VTS-700P 7-inch SIP Indoor
Touch Screen PoE Video Intercom to open the door for your visitors.
A Door Guard for Extreme Conditions
The HDP-1160PT is an extremely durable IP intercom that can withstand even the most demanding
conditions. Its Industrial design with -40 to 70 degrees C operating temperature and resilience to dust, water
(IP65) and vandalism (IK10) provides maximum security.

720p SIP Vandalproof Door Phone with PoE
HDP-1160PT
8
AEC (Acoustic Echo Cancellation)
Acoustic Echo Cancellation (AEC) technology is adopted in PLANET’s HDP1160PT Door Phone and
VTS-700P 7-inch SIP Indoor Touch Screen PoE Video Intercom to enable users to minimize the voice/sound
signal distortion shown in the diagram below, thus guaranteeing the best-in-class sound quality.
Standard Protocol Compliance
The HDP-1160PT supports IETF Session Initiation Protocol 2.0 (RFC 3261) and ONVIF protocol for easy
integration with general voice over IP system and video management system. The IP PBX/NVR device is able
to broadly interoperate with equipment provided by VoIP/IP surveillance infrastructure providers, thus
enabling them to provide their customers with better multimedia exchange services.

720p SIP Vandalproof Door Phone with PoE
HDP-1160PT
9

720p SIP Vandalproof Door Phone with PoE
HDP-1160PT
10
1.3 Specifications
Product HDP-1160PT
Video
Image Device 2 megapixels with 1/2.7” color CMOS
Video Compression H.264
Resolution Main stream: 1280 × 720@25fps
Sub stream: 704 × 576(D1)@25fps
Viewing Angle 112° (H), 84° (V)
Minimum Illumination 0.1lux with infrared illumination
IR Illuminations IR LED x 2, effective up to 5 meters
*The IR distance is based on the environment.
Audio
Audio Streaming Two-way audio
Microphone Built-in microphone and speaker input
Narrowband Codec G.711a/u, G.723.1, G.726-32K, G.729AB
Wideband Codec: G.722
DTMF In-band, Out of Band DTMF (RFC2833) and SIP INFO
Audio Output Full-duplex Acoustic Echo Canceller (AEC) – a tail length of
96ms in hands-free mode
Audio Features
Voice Activity Detection (VAD)
Comfort Noise Generation (CNG)
Background Noise Estimation (BNE)
Packet Loss Concealment (PLC)
Dynamic Adaptive Litter Buffer up to 300ms
Protocol and Security
Protocols
IETF SIP (RFC 3261 and companion RFCs), SIP2.0 over
UDP/TCP/TLS, RTP/RTCP/SRTP, STUN, DHCP, LLDP,
PPPoE, 802.1x, L2TP, OpenVPN, SNTP, FTP/TFTP,
HTTP/HTTPS and TR-069
Security
Network access authority authentication: 802.1x
Web Filter, Transport Layer Security (TLS)
Secure Real-time Transport Protocol (SRTP)
NAT traversal: STUN mode

720p SIP Vandalproof Door Phone with PoE
HDP-1160PT
11
HTTP/HTTPS web server, HTTPS certificate manager
Network and Provisioning
Network Interface 1 x 10/100BASE-Tx RJ45 Ethernet interface, auto-MDIX
IP Configuration Static/DHCP/PPPoE
VPN L2TP / OpenVPN
Deployment/Maintenance
Auto-provisioning via FTP/TFTP/HTTP/HTTPS/DHCP
OPT66/SIP PnP/TR-069
Web Management Portal
Web-based Packet Dump
Configuration Import and Export
Firmware Upgrade
Syslog
General
Keypad 1 DSS button (speed dial button)
Power Requirements Power over Ethernet (IEEE 802.3af/at), class 2 and DC12V/
Net Weight 1015g
Dimensions (W x D x H) 195 x 120 x 34 mm
Emission CE, FCC
Connectors
1 10/100Mbps Ethernet, RJ45
1 audio output interface
1 recording output interface
2 short-circuit input interfaces
2 relays: Max. DC30V,1A; AC125V,0.5A
2 indoor magnetic switches
1 Tamperproof protection/alarm
Active switching output: 12V/500mA DC (only 1 relay support)
Installation Wall-mount type
External Power Supply 12V±15%/1A DC
Environments
Storage Temperature -40~70°C
Operating Humidity 10~90%

720p SIP Vandalproof Door Phone with PoE
HDP-1160PT
12
Chapter 2. Hardware Interface
2.1 Physical Descriptions
Product Dimensions (W x D x H) 195 x 120 x 34 mm
Net Weight 1015g
Front Panel
Num
ber Interface Description
1 Wall-mount Housing IP65 and IK10 outdoor housing for rigorous environment
2 CMOS Sensor Video signal acquisition and transmission
3 IR LED Emits infrared light to provide light source in dark places
3 Speaker The door phone has a built-in speaker for convenient
communication and alert use
4 DSS Key
(Speed dial button)
For speed dial, multicast, intercom, IP broadcast and other
functions
5 Mic The door phone has a built-in microphone hidden in the
pinhole located on the front panel

720p SIP Vandalproof Door Phone with PoE
HDP-1160PT
13
Function Key LED State
Type LED State
DSS Key (Speed dial button)
Normally on Successfully registered
Quick flashing Registration failed/network abnormal
Slow flashing In call
Interface Description
Open the rear case of the device, there is a row of terminal blocks for connecting the power supply, electric
lock control, etc. The connection is as follows:
Number Description Wiring port description
(example above)
1 Ethernet interface: Standard RJ45 interface, 10/100M
adaptive; it is recommended to use Cat 5e cable -
2 Power interface: 12V,1A input Left: positive (+)
Right: grounded (-)
3, 5
Two groups of short-circuit input detection interfaces:
For connecting switches, infrared probes, door
magnets, vibration sensors and other input devices
Left: IN
Right: OUT
4, 6 Two groups of short-circuit output control interface:
Used to control electric locks, alarms, etc.
Left (NC): Normally Close
Contact
Center (COM): Common Contact

720p SIP Vandalproof Door Phone with PoE
HDP-1160PT
14
Right (NO): Normally Open
Contact
7, 8 Two groups of gate magnetic detection Left: grounded
Right: door magnetic input
9
Recording output interface: Mix the device and the
sound of the far-end call. One is the recording signal
line, and the other is the ground line.
(Please be sure to ground the line, otherwise there will
be noise)
Left: grounded
Right: recording output
10
External active speaker interface: External active
speakers for audio power amplification. One is the
audio signal line, and the other is the ground line.
(Please be sure to ground the line, otherwise there will
be noise)
Left: grounded
Right: external active speaker
The HDP-1160PT requires either IEEE 802.3af/at PoE or DC power from the power connector.
Power Connector
The picture shows the two-pin connector that comes with system power source of 12V DC, 1A (maximum for
the two-pin connector).
1 2
+12V DC GND
Power Connector

720p SIP Vandalproof Door Phone with PoE
HDP-1160PT
15
2.2 Hardware Installation
Wall mounting steps:
A. Use the given screw tool to remove the cover.
B. Place the back cover on the wall and mark the four holes on the wall with a pencil.
C. Drill the marked four holes, place the back cover on the wall, and slightly hammer the plastic anchors
through the four holes.
D. Get the power cord and network cable connected, and secure it tightly with the screws.
. A B C D
Wall Mounting Steps of HDP-1160PT
Caution
While drilling or fixing the HDP-1160PT, hold it tight or else it may drop that may
accidentally hurt the installer.

720p SIP Vandalproof Door Phone with PoE
HDP-1160PT
16
2.3 Initial Utility Installation
There are two methods as shown below to search the HDP-1160P.
Method 1:
Open the Planet Door Phone Finder Utility. Press the Refresh button to search the HDP-1160PT and find the
IP address.
Method 2:
Press and hold the DSS key for 10 seconds.When the speaker beeps rapidly, press the DSS key again
quickly. When the beep stops, the intercom will report the IP address by voice.
Default Setting
Default IP Address 172.16.0.1
Default Web Port 80
Default Login User Name admin
Default Login Password 123
Report IP address Hold the DSS key for 10
seconds to report IP address by
voice
Searching Tools Planet Door Phone Finder

720p SIP Vandalproof Door Phone with PoE
HDP-1160PT
17
Chapter 3. Web-based Management
Please take a few minutes to read through this guide to familiarize with the steps required to set up your door
phone. This chapter provides setup details of the door phone Web-based Interface.
3.1 Introduction
When the device and your computer successfully connect to the network, enter the IP address of the device.
You will see the Webpage management interface login screen. Enter the user name and password and click
the button to enter the settings screen.
Door phone can be configured with your Web browser. Before configuring, please make sure your PC is in the
same IP segment as the door phone.
3.2 Web Configuration
The login username and password are admin and 123, respectively.
Enter “admin” for user name and “123” for password to access
interface.
3.3 SIP Configuration
At least one SIP line should be configured properly to enable the telephony service. The line configuration is
like a virtualized SIM card. Just like a SIM card on a mobile phone, it stores the service provider and the
account information used for registration and authentication. When the device is applied with the configuration,
it will register the device to the service provider with the server’s address and user’s authentication as stored

720p SIP Vandalproof Door Phone with PoE
HDP-1160PT
18
in the configurations.
The SIP line configuration should be set via the Web configuration page by entering the correct information
such as phone number, authentication name/password, SIP server address, server port, etc. which are
provided by the SIP server administrator.
 Web interface: After logging into the phone page, enter [Line] >> [SIP] and select SIP1/SIP2 for
configuration, click apply to complete registration after configuration, as shown below:

720p SIP Vandalproof Door Phone with PoE
HDP-1160PT
19
Chapter 4. Basic Function
4.1 Making Calls
After setting the function key to “Hot Key” and the “Number”, press the function key to immediately call out the
set number, as shown below:
For more details on configuration, refer to 5.6 Function Key.
4.2 Answering Calls
After setting up the automatic answer and the automatic answer time, you will hear the ringing bell within the
set time and the call will be automatically answered after the timeout. When canceling automatic answering,
the call will not be automatically answered after the timeout .
4.3 End of the Call
You can hang up the call through the Release key (you can set the function key as the Release key) or turn on
the speed dial button to hang up the call. For more details on configuration, refer to 5.6 Function Key.

720p SIP Vandalproof Door Phone with PoE
HDP-1160PT
20
4.4 Auto-Answering
The user can turn off the auto-answer function (enabled by default) on the device webpage, and the ring tone
will be heard after the shutdown, and the auto-answer will not time out.
Web interface: enter [Intercom Settings] >> [Features], Enable auto answer, set mode and auto answer
time and click submit.
Auto-Answering
Field Name Description
Auto Answer Mode
Disable Turn off the automatic answer function; the call will not time out to answer automatically.
Line 1 Line 1 has an automatic call timeout.
Line 2 Line 2 has an automatic call timeout.
Line 1 & Line 2 Line 1 and line 2 have an automatic call timeout.
Lines and IP
Call Call will be automatically answered after the timeout.
