Planet MB502 User manual

OWNER’S OPERATING MANUAL
MB502 6” DELUXE JOINTER
Please keep this instruction manual for future reference. 带格式的

MB502 6” Deluxe Jointer
１
SAFETY RULES
Woodworking can be dangerous if safe and proper operating procedures are not followed.
As with all machinery, there are certain hazards involved with the operation of the product.
Using the machine with respect and caution will considerably lessen the possibility of
personal injury. However, if normal safety precautions are overlooked or ignored,
personal injury to the operator may result. Safety equipment such as guard, push sticks,
hold-downs, feather boards, goggles, dust masks and hearing protection can reduce your
potential for injury. But even the best guard will not make up for poor judgment,
carelessness of inattention. Always use common sense and exercise caution in the
workshop. If a procedure feels dangerous, do not try it. Figure out an alternative
procedure that feels safer. REMEMBER: Your personal safety is your responsibility.
This machine was designed for certain applications only. We strongly recommends that
this machine not be modified and/or used for any application other than that for which it
was designed. If you have any questions relative to a particular application, DO NOT use
the machine until you have first contacted your local dealer to determine if it can or should
be performed on the product.
WARNING:
FAILURE TO FOLLOW THESE RULES MAY RESULT IN SERIOUS
PERSONAL INJURY.
1. FOR YOUR OWN SAFETY, READ INSTRUCTION MANUAL BEFORE OPERATING
THE TOOL. Learn the tool’s application and limitations as well as the specific hazards
peculiar to it.
2. KEEP GUARDS IN PLACE and in working order.
3. ALWAYS WEAR EYE PROTECTION.
4. GROUND ALL TOOLS. If tool is equipped with three-prong plug, it should be plugged
into a three-hole electrical receptacle. If an adapter is used to accommodate a two-prong
receptacle, the adapter lug must be attached to a known ground. Never remove the third
prong.
5. REMOVE ADJUSTING KEYS AND WRENCHES. Form habit of checking to see that
keys and adjusting wrenches are removed from tool before turning it ”on”.
6. KEEP WORK AREA CLEAN. Cluttered areas and benches invite accidents.
7. DO NOT USE IN DANGEROUS ENVIRONMENT. Do not use power tools in damp or
wet locations, or expose them to rain. Keep work area well-lighted.
8. KEEP CHILDREN AND VISITORS AWAY. All children and visitors should be kept a
safe distance from work areas.
9. MAKE WORKSHOP CHILDPROOF - with padlocks, master switches, or by removing
starter keys.

MB502 6” Deluxe Jointer
２
10. DO NOT FORCE TOOL. It will do the job better and be safer at the rate for which it
was designed.
11. USE RIGHT TOOL. Do not force tool or attachment to do a job for which it was not
designed.
12. WEAR PROPER APPAREL. No loose clothing, gloves, neckties, rings, bracelets, or
other jewelry to get caught in moving parts. Nonslip footwear is recommended. Wear
protective hair covering to contain long hair.
13. ALWAYS USE SAFETY GLASSES. Wear safety glasses (must comply with ANSI
Z87.1). Everyday eyeglasses only have impact resistant lenses; they are not safety
glasses. Also use face of dust mask if cutting operation is dusty.
14. SECURE WORK. Use clamps or a vise to hold work when practical. It is safer than
using your hand and frees both hands to operate tool.
15. DO NOT OVERREACH. Keep proper footing and balance at all times.
16. MAINTAIN TOOLS IN TOP CONDITION. Keep tools sharp and clean for best and
safest performance. Follow instructions for lubricating and changing accessories.
17. DISCONNECT TOOLS before servicing and when changing accessories such as
blades, bits, cutters, etc.
18. USE RECOMMENDED ACCESSORIES. The use of accessories and attachments not
recommended by the local dealer may cause hazards or risk of injury to persons.
19. REDUCE THE RISK OF UNINTENTIONAL STARTING. Make sure switch is in “OFF”
position before plugging in power cord.
20. NEVER STAND ON TOOL. Serious injury could occur if the tool is tipped or if the
cutting tool is accidentally contacted.
21. CHECK DAMAGED PARTS. Before further use of the tool, a guard or other part that
is damaged should be carefully checked to ensure that it will operate properly and perform
its intended function - check for alignment of moving parts, binding of moving parts,
breakage of parts, mounting, and any other conditions that may affect its operation. A
guard or other part that is damaged should be properly repaired or replaced.
22. DIRECTION OF FEED. Feed work into a blade or cutter against the direction of
rotation of the blade or cutter only.
23. NEVER LEAVE TOOL RUNNING UNATTENDED. TURN POWER OFF. Do not leave
tool until it comes to a complete stop.
24. DRUGS, ALCOHOL, MEDICATION. Do not operate tool while under the influence of

MB502 6” Deluxe Jointer
３
drugs, alcohol or any medication.
25. MAKE SURE TOOL IS DISCONNECTED FROM POWER SUPPLY while motor is
being mounted, connected or reconnected.
26. WARNING: The dust generated by certain woods and wood products can be injurious
to your health. Always operate machinery in well-ventilated areas and provide for proper
dust removal. Use wood dust collection systems whenever possible.
ADDITIONAL SAFETY RULES FOR JOINTERS
1. WARNING: Do not operate the jointer until it is completely assembled and installed
according to the instructions.
2. IF YOU ARE NOT thoroughly familiar with the operation of jointers, obtain advice from
your supervisor, instructor or other qualified person.
3. KEEP cutterhead sharp and free of all rust and pitch.
4. BEFORE starting machine, check cutterhead guard to make sure it is not damaged and
operates freely.
5. ALWAYS make sure exposed cutterhead behind the fence is guarded, especially when
jointing near the edge.
6. NEVER perform jointing or planning operations with the cutterhead guard removed.
7. MAKE CERTAIN the infeed and outfeed tables are tightened before starting the
machine.
8. NEVER start the jointer with the workpiece contacting the cutterhead.
9. ALWAYS hold the workpiece firmly against the tables and fence.
10. NEVER perform any operation “Free-hand” which means using your hands to support
or guide the workpiece. ALWAYS use the fence to position and guide the work.
11. AVOID awkward operations and hand positions where a sudden slip could cause your
hand to move into the cutterhead.
12. ALWAYS use hold-down/push blocks for jointing material less than 3 inches in height
or planning material thinner than 3 inches.

MB502 6” Deluxe Jointer
４
13. DO NOT perform jointing operations on material shorter than 10 inches, narrower than
3/4 inch or less than 1/2 inch thick.
14. DO NOT perform planning operations on material shorter than 10 inches, narrower
than 3/4 inch, wider than 6 inches or less than 1/2 inch thick.
15. NEVER make jointing or planning cuts deeper than 1/8 inch. On cuts more than 1-1/2
inches wide, adjust depth of cut to 1/16 inch or less to avoid overloading machine and to
minimize chance of kick-back (work thrown back toward you).
16. MAINTAIN the proper relationship of infeed and outfeed table surfaces and cutterhead
knife path.
17. SUPPORT the workpiece adequately at all times during operation; maintain control of
the work at all times.
18. DO NOT back the workpiece toward the infeed table.
19. DO NOT attempt to perform an abnormal or little-used operation without study and the
use of adequate hold-down/push blocks, jigs, fixtures, sops, etc.
20. SHUT OFF power before servicing or adjusting jointer.
21. DISCONNECT jointer from power source and clean the machine before leaving it.
22. MAKE SUFE the work area is clean before leaving the machine.
23. SHOULD any part of your jointer be missing, damaged, or fail in any way, or any
electrical component fail to perform properly, shut off switch and remove plug from power
supply outlet. Replace missing, damaged or failed parts before resuming operation.
24. THE USE of attachments and accessories not recommended by the local dealer may
result in the risk of injuries.
25. SAVE THESE INSTRUCTIONS. Refer to them often and use them to instruct others.
DEFINITIONS OF JOINTING AND PLANING OPERATIONS
Jointing Operations - Jointing cuts or edge jointing is the simplest and most common
operation, which can be done on the jointer, and these cuts are made to square an edge
of a workpiece. The fence is square with the table and the depth of cut is approximately
1/8 inch. The workpiece is positioned on the jointer with the narrow edge of the workpiece
on the infeed table and the major flat surface of the workpiece against the fence, as shown

MB502 6” Deluxe Jointer
５
in Fig.2. The workpiece is moved from the infeed table, across the cutterhead to the
outfeed table. The hand over the outfeed table presses the work down so that the newly
formed surface will make perfect contact with the table. The hand over the infeed table
(usually the right hand) exerts no downward pressure, but simply advances the work to
the cutterhead. Both hands exert pressure to keep the work in contact with the fence.
Fig. 2
Planning Operations – Planning or surfacing are identical to the jointing operation except
for the position of the workpiece. For planning, the major flat surface of the workpiece is
placed on the infeed table of the jointer with the narrow edge of the workpiece against the
fence, as shown in Fig.3. The workpiece is moved from the infeed table, across the
cutterhead to the outfeed table establishing a flat surface on the workpiece. Always use
push blocks when performing planning operations.
Fig. 3

MB502 6” Deluxe Jointer
６
UNPACKING AND CLEANING
WARNING: JOINTER WEIGHT IS APPROXIMATELY 175 LBS. CARE MUST BE
TAKEN WHEN LIFTING JOINTER ONTO STAND. A MINIMUM OF TWO PEOPLE WILL
BE REQUIRED TO LIFT THE MACHINE. Your new jointer is shipped complete in one
carton. Carefully unpack the jointer and all loose items. Fig.4 and Fig.5, illustrate the
jointer and all loose items supplied with your machine. Remove the protective coating
from the table surface and all unpainted parts. This coating may be removed with a soft
cloth moistened with kerosene (do not use acetone, gasoline or lacquer thinner for this
purpose).After cleaning cover the table surface with a good qualitypaste wax. Buff out the
wax thoroughly to prevent it from rubbing into the workpieces.
Fig. 4
Fig. 5

MB502 6” Deluxe Jointer
７
Loose Parts List
1 Fence
2 Jointer
3 Dust chute
4 Dust cover w/ dust collector adapter
5 Cutterhead guard
6 Hardware package (refer to following list for details)
7 For legs for stand
8 Two lower end braces for stand
9 Two lower side braces for stand
10 Two top side braces for stand
11 Two top end braces for stand
12 V-belt
13 Motor pulley
14 Motor with switch
15 Motor pulley and belt guard
29 Two push blocks
Parts List for Hardward Package
Carriage bolts M8x12 for assembling stand and dust chute to stand 36
Hex nuts M8 for assembling stand and dust chute to stand 36
Flat washers 8 for assembling stand and dust chute to stand 36
Carriage bolt M8x30 for assembling motor to dust chute 4
Hex nuts M8 for assembling motor to dust chute 4
Flat washers 8 for assembling motor to dust chute 4
Flat washers 10 for assembling motor to dust chute 4
Lock washers 8 for assembling motor to dust chute 4
Screws M5x16 for assembling switch box to stand 2
Hex nuts M5 for assembling switch to stand 2
Lock washer 5 for assembling switch to stand 2
Feet for stand legs 4
Special studs for assembling jointer to stand 3
Round handle for infeed and outfeed table adjustment 2
ASSEMBLY INSTRUCTIONS
WARNING: FOR YOUR OWN SAFETY, DO NOT CONNECT THE JOINTER TO THE
POWER SOURCE UNTIL THE JOINTER IS COMPLETELY ASSEMBLED AND YOU
HAVE READ AND UNDERSTOOD THE ENTIRE OWNERS MANUAL.

MB502 6” Deluxe Jointer
８
ASSEMBLING STAND
1. Assemble two 11-34” long top end braces (A) Fig. 6, two 15-3/4” long top side braces
(B), two 16-1/2” long lower end braces (C), and two 20-1/2” long side braces (D) to four
legs (E) as shown, using the thirty-two 1/2” long carriage bolts, flat washers, and hex nuts.
Only tighten hex nuts finger tight at this time. IMPORTANT: The top lips of two upper end
braces (A) must fit on top of the top lips of two upper side braces (B).
2. Assemble four rubber feet (F) Fig. 6, to the bottom of each leg (E) as shown.
Fig. 6
ASSEMBLING DUST CHUTE TO STAND
1. The front of the stand is indicated by switch opening (B) Fig. 7, making the outfeed
end of the stand (C) and the infeed end (A).
2. Assemble dust chute (D) Fig. 7, to outfeed end of stand (C) as shown, using four 1/2”
long carriage bolts (F), flat washers, and hex nuts. Only tighten hex nuts finger tight at
this me.
Fig. 7

MB502 6” Deluxe Jointer
９
ASSEMBLING MOTOR AND SWITCH BOX TO STAND
1. The motor (B) Fig.8 is assembled to the bottom of the dust chute using the four 1-1/4”
long carriage bolts (A) (not shown on the drawing), flat washers, lock washers and hex
nuts. Do not completely tighten hex nuts at this time, as the motor must be adjusted
for proper alignment and belt tension later.
2. Assemble the switch box (C) Fig. 8, to the inside of switch opening (B) (refer to Fig. 7)
using the two 3/8” long screws, and flat washers.
Fig. 8
ASSEMBLING JOINTER TO STAND
1. WARNING: JOINTER WEIGHTIS APPROXIMATELY 75KGS. CARE MUST BE
TAKEN WHEN LIFTING JOINTER ONTO STAND. A MINIMUM OF TWO PEOPLE
WILL BE REQUIRED TO LIFT THE MACHINE.
2. The infeed end of the jointer is fastened to the two holes (A) Fig. 9, and the outfeed
end of the jointer is fastened to hole (B) on the two top end braces. NOTE: Dust chute
(C) is on outfeed end of jointer. Line up the three threaded holes on the bottom of the
jointer with the three holes (A) and (B) in the stand end braces.
Fig. 9

MB502 6” Deluxe Jointer
１０
3. Using the supplied wrench, fasten the jointer to the top of stand using the three lock
washers and special studs. Two of the special studs for the infeed end of the machine,
and one special for the outfeed end of machine.
4. Once the jointer is completely secured to stand, push downward on the top of jointer
until the stand adjusts to the floor surface. Then using the supplied wrench, tighten all
stand hardware.
ASSEMBLING DUST CHUTE COVER W/ DUST COLLECTOR ADAPTER
Assemble dust chute cover with dust collector adapter (A) Fig.10 to jointer stand using
screws. IMPORTANT: Top of dust chute cover with dust collector adapter (A) must be
inside top end brace (D) of stand and should completely cover the top of the dust chute.
WARNING: During operation, the dust chute cover with dust collector adapter (A) must
always be assembled as shown and should only be removed for cleaning.
Fig. 10
ASSEMBLING MOTOR PULLEY
Assemble motor pulley (A) Fig. 11 to motor shaft with the hub of the pulley in the outer
position as shown. Make sure key (B) in inserted in the keyway of the motor pulley and
shaft.
Fig. 11

MB502 6” Deluxe Jointer
１１
ASSEMBLING BELT, ALIGNING PULLEYS, AND ADJUSTING BELT TENSION
1. Loosen two screws on cutterhead pulley guard, and remove cutterhead pulley guard .
2. Place the belt in groove of cutterhead pulley Fig.12, and motor pulley.
Fig. 12
3. Make certain the motor pulley Fig.12, is aligned with the cutterhead pulley. If
necessary, the motor pulley can be moved in or out on the motor shaft to provide
proper alignment. To tighten two setscrews.
4. Correct belt tension is obtained when there is approximately 1” deflection at the center
span of the belt using light finger pressure.
5. If an adjustment is required for belt tension, the motor can be raised or lowered to
obtain the correct belt tension. Then tighten motor mounting hardware after tension is
applied, making sure alignment of the pulleys is not disturbed.
6. Replace cutterhead pulley guard Fig.12, which was removed in STEP 1.
ASSEMBLING MOTOR PULLEY AND BELT GUARD
Assemble the motor pulley and belt guard (A) Fig.13, to the jointer base using the four 1/2”
long screws, and four lock washers.
Fig. 13

MB502 6” Deluxe Jointer
１２
WARNING: MAKE CERTAIN MOTOR PULLEY IS NOT CONTACTING GUARD.
ASSEMBLING FENCE
1. Insert hexagon rod (A) Fig. 14, of fence assembly into bracket (B) on jointer as shown.
Fig. 14
NOTE: If fence does not slide in and out easily, loosen two screws (X) Fig. 14, and adjust
bracket (B). Then tighten two screws (X).
2. Assemble rear cutterhead guard (C) Fig. 15, to end of hexagon rod using the 5/8” long
screw (D) and washer (E).
Fig.15
3. Thread fence locking handle assembly (F) Fig. 22, and flat washer (G) into hole (Z)
Fig.21. Lock handle (F) Fig.22, is spring-loaded and can be repositioned by pulling out the

MB502 6” Deluxe Jointer
１３
handle and repositioning it onto the serrated nut located under the handle.
4. Thread fence-tilting handle (H) Fig. 16, to threaded hole in back of fence as shown.
Fig. 16
ASSEMBLING CUTTERHEAD GUARD
1. Remove setscrew (A) Fig. 17, from post (B) of cutterhead guard (C).
2. Assemble cutterhead guard (C) Fig. 17, to the jointer by inserting post (B) down
through the hole in the infeed table. NOTE: A spring is supplied in knob assembly (D)
that returns the guard (C) over the cutterhead after a cut has been made. Turn knob
(D) to provide tension on the spring before inserting post (B). Make certain the spring
engages in the slot of the post. If spring tension is too much or too little, adjust the
spring accordingly by removing the guard and rotating knob (D).
Fig. 17

MB502 6” Deluxe Jointer
１４
3. Thread set screw (A) Fig. 18, which was removed in STEP 1, back into post (B) to
keep cutterhead guard (C) in position during jointer operation.
4. Fig. 18, illustrates the cutterhead guard (C) assembled to the infeed table.
Fig. 18
EXTENSION CORDS
1. In the event of an electrical malfunction or breakdown, grounding provides a path of
least resistance for electric current to reduce the risk of electric shock. This tool is
equipped with an electric cord having equipment grounding conductor and a grounding
plug. The plug must be plugged into a grounding outlet. The plug must be plugged into a
matching outlet that is properly installed and grounded in accordance with all local codes
and ordinances.
2. Do not modify the plug provided. If it will not fit the outlet, have the proper outlet
installed by a qualified electrician.
3. Improper connection of the equipment-grounding conductor can result in a risk of
electric shock. The conductor with insulation having an outer surface that is green with or
without yellow stripes is the equipment-grounding conductor. If repair or replacement of
the electric cord or plug is necessary, do not connect the equipment-grounding conductor
to a live terminal.
4. Check with a qualified electrician or service personnel if the grounding instructions are
not completely understood or if in doubt as to whether the tool or outlet is properly
grounded.

MB502 6” Deluxe Jointer
１５
5. Use only 3-wire extension cords that have grounding plugs, and the receptacles must
accept the tool’s plug.
6. Have a damaged or worn cord repaired or replaced immediately by a qualified
technician.
CONNECTING JOINTER TO POWER SOURCE
POWER CONNECTIONS
A separate electrical circuit should be used for your tools. Have a certified electrician
replace or repair a worn cord immediately. Before connecting the motor to a power line,
make sure the switch is in the “OFF” position and be sure that the electric current is of the
same characteristics as stamped on the motor nameplate. Running on low voltage will
damage the motor.
WARNING: DO NOT EXPOSE THE TOOL TO RAIN OR OPERATE THE TOOL IN
DAMP LOCATIONS.
GROUNDING INSTRUCTIONS
CAUTION: THIS TOOL MUST BE GROUNDED WHILE IN USE TO PROTECT THE
OPERATOR FROM ELECTRIC SHOCK.
In the event of a malfunction or breakdown, grounding provides a path of least resistance
for electric current to reduce the risk of electric shock.This tool is equipped with an electric
cord having an equipment-grounding conductor and a grounding plug. The plug must be
plugged into a matching outlet that is properly installed and grounded in accordance with
all local codes and ordinances.
Do not modify the plug provided – if it will not fit the outlet; have the proper outlet installed
by a qualified electrician.
Improper connection of the equipment-grounding conductor can result in risk of electric
shock. The conductor with insulation having an outer surface that is green with or without
yellow stripes is the equipment-grounding conductor. If repair or replacement of the
electric cord or plug is necessary, do not connect the equipment-grounding conductor to a
live terminal.
Check with a qualified electrician or service personnel if the grounding instructions are not
completely understood, or if in doubt as to whether the tool is properly grounded.

MB502 6” Deluxe Jointer
１６
Use only 3-wire extension cords that have grounding type plugs and receptacles that
accept the tool’s plug.
Repair or replace damaged or worn cord immediately.
CAUTION: IN ALL CASES, MAKE CERTAIN THE RECEPTACLE IN QUESTION IS
PROPERLY GROUNDED. IF YOU ARE NOT SURE HAVING A CERTIFIED
ELECTRICIAN CHECK THE RECEPTACLE.
OPERATING CONTROLS AND ADJUSTMENTS
STARTING AND STOPPING JOINTER
The safety magnetic switch (A) Fig. 19, is located on the topside brace of the stand. To
turn the machine “ON”, push button “I” on switch (A). To turn the machine “OFF”, push the
button “O” on the switch (A). The magnetic switch is a no volt switch, if power source is cut
off accidentally, you have to push the button “I” to restart the unit again.
Fig. 19
OUTFEED TABLE ADJUSTMENTS
For most jointing operations the outfeed table must be exactly level with the knives at their
highest point of revolution. This means that the knives must be parallel to the outfeed table
and project equally from the cutterhead. To move the outfeed table up of down, loosen
lock screw Fig. 20, and turn hand knob (B). When the outfeed table is exactly level with
the knives at their highest point of revolution, tighten lock screw (A).

MB502 6” Deluxe Jointer
１７
Fig. 20
KNIFE AND OUTFEED TABLE ADJUSTMENTS
In order to do accurate work, the knives must be exactly level with the outfeed table. To
check and adjust, proceed as follows.
1. DISCONNECT MACHINE FROM POWER SOURCE.
2. Place a steel straight edge on the outfeed table, extending over the cutterhead.
3. CAREFULLY rotate the cutterhead by turning the belt by hand. The knives should just
touch the straight edge.
4. If the knife is high or low at either end, slightly turn the four screws, in the knife-locking
bar clockwise to loosen using the wrench. Then adjust the height of the knife by turning
the knife raising screws, counterclockwise to lower and clockwise to raise the knife. NOTE:
If the knife is to be lowered it will be necessary to carefully push down on the knife after
screws have been turned.
5. Repeat these procedures for adjusting the remaining two knives if necessary.
6. If the knives are set too low, the result will be as shown in Fig. 21, and the finished

MB502 6” Deluxe Jointer
１８
surface will be curved.
Fig. 43
7. If the knives are set too high, the work will be gouged at the end of the cut, as shown in
Fig. 44.
Fig. 44
8. As a final check, run a piece of work slowly over the knives for 6 to 8 inches. The wood
should rest firmly on both tables as shown in Fig. 45, with no open spaces under the
finished cut.

MB502 6” Deluxe Jointer
１９
Fig. 45
ADJUSTING TABLE GIBS
“Gibs” are provided to take up all play between the mating dovetail ways of the base and
the infeed and outfeed tables. The “gib” for the infeed table is shown at (A) Fig. 46, and
the “gib” for the outfeed table is shown at (B) Fig. 47. Proper “gib” adjustment is necessary
for the correct functioning of the jointer. The “gibs” were adjusted at the factory and should
require no further adjustment. If, However, it becomes necessary to adjust the “gibs”
proceed as follows.
1.To adjust the infeed or outfeed table “gibs”, loosen three locknuts (F) Fig. 46, for the
infeed table or two locknuts (G) Fig. 47, for the outfeed table.
2. Tighten or loosen three gib adjustment screws (C) Fig. 46, as necessary for the infeed
table or two gib adjustment screws (D) Fig. 47, as necessary for the outfeed table; starting
with the lower screw first and as you proceed to the top screw, gently raise the outboard
edge of the table that is being adjusted. This will offset any tendency for the table casting
to “droop or sag” and permit the gib to be adjusted to a secure fit.After the gibs have been
adjusted, tighten locknuts (F) Fig. 46, (G) Fig. 47.
IMPORTANT: Do not leave the adjusting screws too loose. It should take a little bit of effort
to move the tables up or down. Jointers are finishing machines and you cannot expect to
get good accuracy or finish if the tables are set loose and sloppy.
FENCE OPERATION
The fence can be moved across the table and can tilt 45 degrees right or left at any
position on the table as follows.
1. To move the fence across the table, loosen lock handle (A) Fig. 48, slide fence to the
desired position on the table and tighten lock handle (A). As the fence is moved across
the table, the rear cutterhead guard (B) covers and guards the cutterhead in back of
the fence. NOTE: Lock handle (A) is spring-loaded and can be repositioned by pulling
