User’s Manual of ICS-2x00T Serial Device Server Series
1
RS232/RS422/RS485
Industrial Serial Device Server
ICS-2100T / ICS-2105AT/
ICS-2102T / ICS-2102ST/
ICS-2200T / ICS-2400T

User’s Manual of ICS-2x00T Serial Device Server Series
2
Trademarks
Copyright © PLANET Technology Corp. 2021.
Contents are subject to revision without prior notice.
PLANET is a registered trademark of PLANET Technology Corp. All other trademarks belong to their respective owners.
Disclaimer
PLANET Technology does not warrant that the hardware will work properly in all environments and applications, and makes no
warranty and representation, either implied or expressed, with respect to the quality, performance, merchantability, or fitness for
a particular purpose. PLANET has made every effort to ensure that this User's Manual is accurate; PLANET disclaims liability
for any inaccuracies or omissions that may have occurred.
Information in this User's Manual is subject to change without notice and does not represent a commitment on the part of
PLANET. PLANET assumes no responsibility for any inaccuracies that may be contained in this User's Manual. PLANET makes
no commitment to update or keep current the information in this User's Manual, and reserves the right to make improvements to
this User's Manual and/or to the products described in this User's Manual, at any time without notice.
If you find information in this manual that is incorrect, misleading, or incomplete, we would appreciate your comments and
suggestions.
FCC Warning
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated
in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and
used in accordance with the Instruction manual, may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the
interference at his own expense.
CE Mark Warning
This equipment is compliant with Class A of CISPR 32. In a residential environment this equipment may cause radio
interference.
Energy Saving Note of the Device
This power required device does not support Standby mode operation. For energy saving, please remove the power cable to
disconnect the device from the power circuit. In view of saving the energy and reducing the unnecessary power consumption, it
is strongly suggested to remove the power connection for the device if this device is not intended to be active.
WEEE Warning
To avoid the potential effects on the environment and human health as a result of the presence of
hazardous substances in electrical and electronic equipment, end users of electrical and electronic
equipment should understand the meaning of the crossed-out wheeled bin symbol. Do not dispose of
WEEE as unsorted municipal waste and have to collect such WEEE separately.
Revision
PLANET ICS-2x00T Series User's Manual
Model:ICS-2100T / ICS-2105AT/ ICS-2200T / ICS-2400T
Revision: 1.0 (Auguest, 2021)
Part No: EM-ICS -2x00T_v1.2

User’s Manual of ICS-2x00T Serial Device Server Series
3
TABLE OF CONTENTS
1.INTRODUCTION ....................................................................................................................5
1.1 Packet Contents.............................................................................................................................................5
1.2 Product Description........................................................................................................................................6
1.3 How to Use This Manual ..............................................................................................................................10
1.4 Product Features..........................................................................................................................................11
1.5 Product Specifications..................................................................................................................................13
2. INSTALLATION ...................................................................................................................16
2.1 Hardware Description...................................................................................................................................16
2.1.1 Front Panel..........................................................................................................................................................16
2.1.2 Front Panel..........................................................................................................................................................18
2.1.3 LED Indications ...................................................................................................................................................19
2.1.4 Wiring the Power Inputs.......................................................................................................................................20
2.1.5 Serial Port Pin Define..........................................................................................................................................21
2.2 Installing the Industrial Serial Server............................................................................................................22
2.2.1 Installation Steps.................................................................................................................................................22
2.2.2 DIN-rail Mounting.................................................................................................................................................23
2.2.3 Wall Mount Plate Mounting..................................................................................................................................25
3. INDUSTRIAL SERIAL SERVER MANAGEMENT...............................................................26
3.1 Requirements...............................................................................................................................................26
3.2 Web Management........................................................................................................................................27
3.2.1 Logging in to the Industrial Serial Server.............................................................................................................27
3.3 Remote Management...................................................................................................................................29
3.4 PLANET Smart Discovery Utility..................................................................................................................30
4. WEB CONFIGURATION......................................................................................................32
4.1 Main Web Page............................................................................................................................................35
4.2 System..........................................................................................................................................................36
4.2.1 System.................................................................................................................................................................36
4.2.2 Port......................................................................................................................................................................38
4.2.3 Device..................................................................................................................................................................39
4.2.4 Time.....................................................................................................................................................................39
4.2.5 Console ...............................................................................................................................................................40
4.2.6 Fault Alarm ..........................................................................................................................................................40
4.2.7 Digital Input and Output.......................................................................................................................................41

User’s Manual of ICS-2x00T Serial Device Server Series
4
4.3 Accessible IP................................................................................................................................................42
4.4 Network ........................................................................................................................................................43
4.5 Port Config....................................................................................................................................................45
4.5.1 Serial setup..........................................................................................................................................................46
4.5.2 Operation mode...................................................................................................................................................47
4.5.2.1 Disable mode ............................................................................................................................................47
4.5.2.2 Remote Pair Master/Slave mode...............................................................................................................48
4.5.2.3 RF2217 mode............................................................................................................................................50
4.5.2.4 Serial Telnet mode.....................................................................................................................................51
4.5.2.5 TCP Server mode......................................................................................................................................54
4.5.2.6 TCP Client mode.......................................................................................................................................57
4.5.2.7 UDP mode.................................................................................................................................................59
4.5.2.8 Virtual COM mode.....................................................................................................................................61
4.5.2.9 Modbus Converter Server mode ...............................................................................................................64
4.5.2.10 Modbus Converter Client mode...............................................................................................................66
4.6 SNMP Setup.................................................................................................................................................68
4.7 Maintenance.................................................................................................................................................69
4.7.1 Change Password...............................................................................................................................................69
4.7.2 Load Default........................................................................................................................................................69
4.7.3 Firmware Update.................................................................................................................................................70
4.8 Save and Restart..........................................................................................................................................71
5. SOFTWARE VCOM UTILITY............................................................................................... 72
5.1 Installing the VCOM Utility............................................................................................................................72
5.2 Search Devices ............................................................................................................................................74
5.3 Virtual COM..................................................................................................................................................75

User’s Manual of ICS-2x00T Serial Device Server Series
5
1. INTRODUCTION
Thank you for purchasing PLANET ICS-2100T Industrial Serial Device Server series. “Industrial Serial Server” is used as an
alternative name in this Quick Installation Guide.
ICS-2100T IP30 Industrial 1-Port RS232/RS422/RS485 Serial Device Server (1 x 10/100TX, -40~75 degrees C)
ICS-2102T IP30 Industrial 1-Port RS232/RS422/RS485 Serial Device Server (1 x 100FX SC, 2km, -40~75 degrees C)
ICS-2102ST IP30 Industrial 1-Port RS232/RS422/RS485 Serial Device Server (1 x 100FX SC, 30km, -40~75 degrees C)
ICS-2105AT IP30 Industrial 1-Port RS232/RS422/RS485 Serial Device Server (1 x 100FX SFP, -40~75 degrees C)
ICS-2200T Industrial 2-Port RS232/RS422/RS485 Serial Device Server
ICS-2400T Industrial 4-Port RS232/RS422/RS485 Serial Device Server
“Industrial Serial Server” mentioned in this Guide refers to the above models
1.1 Packet Contents
Open the box of the Industrial Serial Server and carefully unpack it. The box should contain the following items:
The Industrial Serial Server x 1
User’s Manual x 1
Wall Mounting Kit x 1
Dust Cap (RJ45 / SFP)
DIN-rail Bracket w/Screws x 1
If any of these are missing or damaged, please contact your dealer immediately; if possible, retain the carton including the
original packing material, and use them again to repack the product in case there is a need to return it to us for repair.

User’s Manual of ICS-2x00T Serial Device Server Series
6
1.2 Product Description
Cost-effective Solution for RS232/422/485 Serial-to-Industrial Ethernet Application
PLANET ICS-2x00T Serial Device Server series is speciallydesigned to convert RS232, RS422 or RS485 serial communication
to Industrial Fast Ethernet networking so as to extend the network distance efficiently and inexpensively. There are one/two
10/100BASE-TX RJ45 ports available in the ICS-2x00T series for your network needs. The ICS-2x00T series is a time-saving
and cost-effective solution for users and system integrators to quickly transform their serial devices into the Ethernet network
with no need of replacing the existing serial devices and software system.

User’s Manual of ICS-2x00T Serial Device Server Series
7
Remote Management
As the ICS-2x00T series provides an easy serial-to-Ethernet connectivity and connection to a TCP/IP network, the remote
network system can thus be managed efficiently via its Web, Telnet and VCOM management interfaces. It supports both
application and serial operation modes for alarm or IP address connection, which saves the network administrator’s time in
detecting and locating network problems without visual inspection of the cabling and devices. Multiple connection options are
available for large networking environment as well.
Stable Performance under Difficult Environments
The ICS-2x00T series provides a high level of immunity against electromagnetic interference and heavy electrical surges which
are usually found on plant floors or in curbside traffic control cabinets. Its operating temperature ranging from -40 to 75 degrees
C allows the ICS-2x00T series to be placed in almost any difficult environment.
The ICS-2x00T series with the compact IP30-/IP40-rated metal case allows either DIN-rail or wall mounting for efficient use of
cabinet space. The ICS-2x00T series also provides an integrated power supply source with a wide range of voltages (12 to 48V
DC) ideally suitable for worldwide operation with high availability applications requiring dual or backup power inputs.

User’s Manual of ICS-2x00T Serial Device Server Series
8
Dual Power Input for High Availability Network System
The ICS-2x00T series features a strong dual power input system with wide-ranging voltages (12V~48V DC or 9 to 48V DC / 24V
AC) incorporated into customer’s automation network to enhance system reliability and uptime. In the example below, when
Power Supply 1 fails to work, the hardware failover function will be activated automatically to keep powering the ICS-2x00T
series via Power Supply 2 without any break of operation.

User’s Manual of ICS-2x00T Serial Device Server Series
9
Effective Alarm Alert for Better Protection
The ICS-2x00T series comes with a FaultAlarm feature which can alert the users when there is something wrong with the Serial
Device Server. With this ideal feature, the users would not have to waste time finding where the problem is. It will help to save
time and human resource. The ICS-2x00T series provides event alert function to help to diagnose the abnormal device owing to
whether or not there is a break of the network connection, or the rebooting response.
Digital Input and Digital Output for External Alarm (ICS-2400T only)
With digital input and digital output on its front panel, an external alarm can help users via the digital input to detect and log
external device status (such as door intrusion detector), and then immediately send an event alarm to the administrator. The
digital output can be used to alarm the administrator if the ICS-2400T serial port shows connection failure or power failure.

User’s Manual of ICS-2x00T Serial Device Server Series
10
1.3 How to Use This Manual
This User’s Manual is structured as follows:
Section 2, INSTALLATION
It explains the functions of the ICS-2X00T and how to physically install the ICS-2X00T.
Section 3, INDUSTRIAL SERIAL SERVER MANAGEMENT
The chapter explains how to manage the ICS-2X00T in different ways.
Section 4, WEB CONFIGURATION
It describes how to configure by web interface.
Section 5,SOFTWARE VCOM UTILITY
It describes how to use software VCOM in the Virtual COM mode.

User’s Manual of ICS-2x00T Serial Device Server Series
11
1.4 Product Features
Serial Interface
One/Two/four DB9 interfaces support RS232, 2-wire RS485, 4-wire RS485 and RS422 operations
Asynchronous serial data rates up to 921600bps
Data mode including VCOM, RFC2217, TCP Server, TCP Client, UDP, Remote Pair and Serial Telnet modes
Ethernet Interface
One/Two 10/100BASE-TX RJ45 interfaces with auto MDI/MDI-X function or 100BASE-FX SFP interface
(ICS-2105AT)
Ethernet ports support Ethernet switch or cascading operation for easy wiring
Management
IPv4 and IPv6 dual stack management
Remote Management Interfaces
- IP-based Web management
- Telnet console management
- Windows-based VCOM utility supports searching, monitoring and configuration setting
IP NTP (Network Time Protocol) and DNS management
Standard TCP/IP interface and versatile operation modes
Software Protocol supports ARP, ICMP, TCP/IP, UDP, HTTP server, DHCP client, Telnet server/client
Serial Operation mode selected via management interface
Pair Connection mode for connecting two serial devices over a network
Allows a maximum of 4 hosts to be accessed in TCP client mode
Firmware upgrade via HTTP protocol
Accessible IP security control to prevent illegal users
Event notification
- Remote syslog server
- SNMP trap
- Built-in buzzer
- Relay output alarm
- Digital output (ICS-2400T only)
DHCP client for IP address assignment
PLANET Smart Discovery utility automatically finds the client devices on the network
Industrial Case and Installation
IP30 metal case
IP40 metal case (ICS-2400T only)
DIN-rail and wall-mount designs
Redundant power design
−9 to 48V DC or 24VAC, redundant power with reverse polarity protection (ICS-2100T/2012T/2102TS/2105AT)

User’s Manual of ICS-2x00T Serial Device Server Series
12
−12 to 48V DC, redundant power with reverse polarity protection (ICS-2200T/2400T)
Supports 6000 VDC Ethernet ESD protection
-40 to 75 degrees C operating temperature
Free fall, shock-proof and vibration-proof for industries
Supports extensive LED indicators for network diagnosis
Reset button for resetting to factory default
Digital Input and Digital Output (ICS-2400T only)
2 digital inputs (DI)
2 digital outputs (DO)
Integrate sensors into auto alarm system
Transfer alarm to IP network via email and SNMP trap

User’s Manual of ICS-2x00T Serial Device Server Series
13
1.5 Product Specifications
Product ICS-2100T ICS-2105AT ICS-2102T
ICS-2102ST ICS-2200T ICS-2400T
Serial Interface
Serial Ports 1 x DB9 male for RS232
1 x 4-pin Terminal block for RS422 / RS485 2 x DB9 male 4 x DB9 male
Serial Standards
RS232 / 4-wire RS422 or RS485 / 2-wire RS485
Baud Rate (Data Rate) 50bps to 921Kbps
Data Bits 5, 6, 7, 8
Parity Type 1, 1.5, 2
Stop Bit
Odd, Even, None, Space, Mark
Flow Control RTS/CTS and DTR/DSR (RS232 only)
XON/XOFF
Signals
RS232: TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND
RS422: Tx+, Tx-, Rx+, Rx-, GND
4-wire RS485: Tx+, Tx-, Rx+, Rx-, GND
2-wire RS485: Data A (+), Data B (-), GND
Pin Assignment
Serial Line Protection --
2KV isolation protection
1.5KV (level 2) surge protection
15KV ESD protection
Ethernet Interface
Ethernet Ports 1 x RJ45 1 x SFP 1 x SC 2 x RJ45 2 x RJ45
Standard 10/100BASE-TX 100BASE-FX 10/100BASE-TX 10/100BASE-TX
Distance 100m
2km to 120km,
vary on SFP
modules
ICS-2102T: 2km
ICS-2102ST:
30km
100m 100m
Switch Architecture - - Store-and-Forward-
Address Table - - 1K
ESD Protection 6KV
Surge Protection
2KV
Hardware
Installation DIN-rail kit and wall-mount ear
Enclosure IP 30 metal IP40 metal
Dimensions (W x D x H)
32 x 97 x 135 mm 56 x 87 x 135 mm
Weight 392g 390g 393g 477 g 625 g

User’s Manual of ICS-2x00T Serial Device Server Series
14
LED Indicators
System: Power 1, Power 2, Fault, SYS, I/O(ICS-2400T only)
TP/SFP Port: Link/Active
Serial Port: Tx and Rx
Power Requirements 9~48V DC / 24V AC, redundant power with reverse
polarity protection
12~48V DC, redundant power with
reverse polarity protection
Power Consumption
Full Loading
9VDC: 0.35A
(3.15 watts)
12VDC: 0.28A
(3.36 watts)
24VDC: 0.12A
(3 watts)
48VDC: 0.08A
(3.84 watts)
Full Loading
9VDC: 0.44A
(3.96 watts)
12VDC: 0.33A
(4 watts)
24VDC: 0.17A
(4.08 watts)
48VDC: 0.1A
(4.8 watts)
Full Loading
9VDC: 0.44A
(3.96 watts)
12VDC: 0.33A
(4 watts)
24VDC: 0.17A
(4.08 watts)
48VDC: 0.1A
(4.8 watts)
Full Loading
12VDC: 0.326A
(3.8 watts)
24VDC: 0.176A
(4.2 watts)
48VDC: 0.114A
(5.4 watts)
Full Loading
12VDC: 0.419A
(5.1 watts)
24VDC: 0.227A
(5.4 watts)
48VDC: 0.136A
(6.5 watts)
Connector Removable 6-pin terminal block for power input
Pin 1/2 for Power 1, Pin 3/4 for fault alarm, Pin 5/6 for Power 2
DI and DO N/A
2 digital inputs:
Level 0:
-24V~2.1V
(±0.1V)
Level 1: 2.1V
~24V
(±0.1V)
Input Load to 24V
DC, 10mAmax.
2 digital outputs:
Open collector to
24V DC, 100mA
max.
Alarm Provides one relay output for power failure
Alarm relay current carry ability: 1A@ DC 24V
Reset Button < 5 sec: System reboot
> 5 sec: Factory default
Management
Management Interfaces
Web management
Telnet Console management
Windows-based VCOM Utility management
PLANET Smart Discovery Utility
IP Version IPv4 and IPv6
Operation Mode
TCP Server
TCP Client
UDP Client
Virtual COM
RFC2217

User’s Manual of ICS-2x00T Serial Device Server Series
15
Telnet Server
Pair Connection – Remote (Slave)
Pair Connection – Local (Master)
Modbus converter server / client
Virtual COM Utility
Platform Supports
Windows-based only:
Windows XP
Windows Server 2003
Windows 7
Windows Server 2008
Windows 8 (Must install the latest version of WinPcap)
Windows Server 2012 (Must install the latest version of WinPcap)
Windows 10
Alert System log / SNMP Trap Built-in buzzer and RTC
Security
Allows maximum 4 accessible IP address hosts/ranges
SNMP MIBs RFC1213 MIB-II
RFC1317 RS232-like MIB
Standards Conformances
Regulatory Compliance FCC Part 15 Class A,
CE Certification Class A
Stability Testing
IEC60068-2-32 (Free fall)
IEC60068-2-27 (Shock)
IEC60068-2-6 (Vibration)
Standards
IEEE 802.3 10BASE-T
IEEE 802.3u 100BASE-TX/100BASE-FX
IEEE 802.3x flow control and back pressure
RFC 768 UDP
RFC 793 TFTP
RFC 791 IP
RFC 792 ICMP
RFC 854 Telnet
RFC 958 NTP
RFC 1591 DNS (client only)
RFC 1908 SNMPv2c
RFC 2068 HTTP
RFC 2131 DHCP Client
RFC 2732 Format for Literal IPv6 Addresses in URL's
RFC 3315 DHCPv6 Client
RFC 3513 IPv6 Addressing Architecture
RFC 3596 DNSv6
RFC 4443 ICMPv6
EIA/TIA RS232/422/485
Regulatory Approval RoHS
Environment
Operating Temperature
-40 ~ 75 degrees C
Storage Temperature -40 ~ 85 degrees C
Humidity 5 ~ 95% (non-condensing)

User’s Manual of ICS-2x00T Serial Device Server Series
16
2. INSTALLATION
This section describes the hardware features and installation of the Industrial Serial Servers' components on the desktop or rack.
For easier management and control of the Industrial Serial Servers, familiarize yourself with its display indicators, and ports.
Front panel illustrations in this chapter display the LED indicators. Before connecting any network device to the Industrial Serial
Servers, please read this chapter completely.
2.1 Hardware Description
2.1.1 Front Panel
The front panels of the Industrial Serial Servers are shown in Figure 2-1-1.
Front Panels
ICS-2100T ICS-2105AT

User’s Manual of ICS-2x00T Serial Device Server Series
17
ICS-2200T ICS-2400T
Figure 2-1-1: Front Panels of Industrial Serial Servers
■Fast TP/ SFP interface
10/100BASE-TX copper, RJ45 twisted-pair: Up to 100 meters.
100BASE-FX SFP interface, Up to 2km~120km, vary on SFP modules.
■Serial Interface
Supports RS-232, RS-422, RS-485 2-wire and RS485 4-wire.

User’s Manual of ICS-2x00T Serial Device Server Series
18
2.1.2 Front Panel
The Reset Buttons of the Industrial Serial Servers are shown in Figure 2-1-2.
ICS-2100T ICS-2105AT
ICS-2200T ICS-2400T
Figure 2-1-2: Reset Button of Industrial Serial Servers
■Reset button
On the bottom panel, the reset button is designed for rebooting the system and stopping the buzzer. The following is the
summary table of the reset button functions:
Reset Button Reset Button Pressed and
Released Function
System Reset
< 5 sec: System reboot Reboot the Industrial Serial Server
> 5 sec:Factory default
Reset the Industrial Serial Server to Factory
Default configuration. The Industrial Serial
Server will then reboot and load the default
settings as shown below:
。Default Username: admin
。Default Password: admin
。Default IP address: 192.168.0.100
。Subnet mask: 255.255.255.0
。Default Gateway:
192.168.0.254
Buzzer Reset >1 sec Stop the buzzer

User’s Manual of ICS-2x00T Serial Device Server Series
19
2.1.3 LED Indications
The front panel LEDs indicate instant status of power and system status, fan status, port links and data activity; they help
monitor and troubleshoot when needed.
LED indication
■System
LED
Color
Function
PWR 1 Green Lights Power 1 is activated.
PWR 2 Green Lights Power 2 is activated.
Fault Red Lights Indicates either Power 1 or Power 2 has no power.
SYS Green Blinks System is booting.
Lights System is ready.
I/O Red Blinks Digital I/O event is triggered.
■10/100BASE-TX/100BASE-FX Port
LED Color Function
LNK/
ACT Green
Lights Indicates that the port is linked up.
Blinks Indicates
that the switch is actively sending or receiving data over
that port.
■Serial Ports (P1~P4)
LED Color Function
TX Green Blinks Serial port is transmitting data.
RX Amber Blinks Serial port is receiving data.

User’s Manual of ICS-2x00T Serial Device Server Series
20
2.1.4 Wiring the Power Inputs
The upper panel of the Industrial Serial Server indicates a DC inlet power socket and consists of one terminal block connector
within 6 contacts. Please follow the steps below to insert the power wire.
1. Insert positive/negative DC power wires into Contacts 1 and 2 for Power 1, or Contacts 5 and 6 for Power 2. Figure 2-1-3
to 2-1-5 show PWR1 and PWR2 of the Industrial Serial Server.
ICS-2100T/ICS-2105AT/ICS-2102T/ICS-2102ST: 9~48V DC or 24V AC
Figure 2-1-3 ICS-2100T/ICS-2105AT Upper Panel
ICS-2200T: 12~48V DC
Figure 2-1-4 ICS-2200T Upper Panel
ICS-2400T: 12~48V DC
Figure 2-1-5 ICS-2400T Upper Panel
2. Tighten the wire-clamp screws for preventing the wires from loosening.
