Plasmon G-Series User manual


Document No. 305291-000 Revision B 8/28/01 i
Plasmon G Series Users Guide
Preface...............................................a
Copyright Notice......................................... a
Changes..................................................... a
Introduction.......................................3
Who?..........................................................3
Where?.......................................................3
Symbols ..................................................... 4
Support ..............................................5
Support Contact......................................... 6
Regulatory Notices...........................7
FCC Compliance Statement ...................... 7
Laser Safety............................................... 8
CDRH Regulations ..................................... 8
Lithium Battery........................................... 8
Power Cord Set Selection.......................... 8
Quick Start Installation and Guide 11
Library Position ........................................ 11
Loading Media.......................................... 11
Mass Loading (Recommended) ........................12
G64 and G104 Stabilizer Plates ........................13
On-Line Automated Import/Export .................... 16
Ten Slot Bulk Magazine ....................................16
Inside the Front Door ...............................17
Power Cable...................................................... 17
SCSI Connection............................................... 18
Initial Power On........................................ 19
Host Computer.................................................. 19
SCSI ID Configuration ...................................... 20
General Product Information..........23
Functional Description..............................23
Library System Models.............................23
Magneto Optical Cartridge.............24
Barcode Label.......................................... 24
Media Cartridge........................................ 25
Major Hardware Components........26
Mailslot..................................................... 30
Operator Panel......................................... 30
Media Store.............................................. 30
Bulk Load Magazine.................................30
Media Transport Assembly (MTA)........... 30
Drives....................................................... 30
SCSI Interface.......................................... 31
Front Access Door ................................... 31
Rear Access Door.................................... 31
Identifying Drives, Columns and Slots .....31
System Overview.............................37
Command Processing..............................37
Media Movement...................................... 37
Importing and Exporting........................... 37
Bulk Loading Media..................................38
Table of Contents

G Series Users Guide Plasmon
ii Document No. 305291-000 Revision B 8/28/01
Library SCSI Configuration............39
Safety................................................43
Laser Safety .............................................43
CDRH Regulations ...................................43
Lithium Battery.........................................43
Power Cable Set Selection.......................44
Power Cable ..................................................... 44
Power Switch .................................................... 44
Rear Door.................................................44
Operator Panel.................................47
LCD Symbols...........................................48
Library System Operating Modes..51
On-line Mode............................................51
Setup Mode..............................................51
Maintenance Mode...................................51
Procedures.......................................52
Using the Operators Panel and Menu......52
Menu Structure................................54
User Menu........................................58
Library Status ..................................59
Config Information..........................60
Unit information ................................................ 61
Serial Numbe .................................................... 62
Date and Time.................................................. 63
Number of Buses .............................................. 64
Changer Address.............................................. 65
Drive Addresses ............................................... 66
Changer Options .............................................. 67
Drive Options .................................................... 69
Passwords ........................................................ 70
Status Information...........................71
Element Status ................................................. 72
Drive States ...................................................... 74
Power-on Hours................................................ 75
Unit Cycle Count ............................................... 76
Drive Load Counts............................................ 77
Function Counts ............................................... 78
Error Information.............................80
Error Log........................................................... 81
Error Statistics .................................................. 82
Event History .................................................... 83
Micro-op Stack.................................................. 84
Network Interface ............................85
IP Address........................................................ 86
Subnet Mask..................................................... 87
Release Magazine............................88
Turn Drive Off..................................89
Turn Drive On ..................................90
Service Drives..................................91
Restore Drives.................................92
Set-up Library..................................93
Config Information (Setup Mode)...94
Unit information ................................................ 95
Serial Number ..................................................96
Date and Time.................................................. 97
Number of Buses .............................................. 98
Changer Address ............................................. 99
Drive Addresses ............................................. 100
Changer Options ............................................ 101
Drive Options.................................................. 105
Passwords ...................................................... 107
Status Information (Set Up Mode)109
Element Status............................................... 110
Drive States .................................................... 112
Power-on Hours ............................................. 113
Unit Cycle Count ............................................ 114
Drive Load Counts.......................................... 115
Function Counts ............................................. 116
Error Information (Set Up Mode)..118
Error Log ........................................................ 119
Error Statistics................................................ 120
Event History.................................................. 121
Micro-op Stack ............................................... 122
Network Interface (Set Up Mode).123
IP Address...................................................... 124
Subnet Mask .................................................. 125
Offline Operations (Set Up mode) 126
Scan Elements ............................................... 127
Unload Drives ................................................. 128
Park Library.................................................... 129
Test Library .................................................... 130
Service Drives................................................ 131
Restore Drives................................................ 132
Cabinet Lights ................................................ 133
Maintenance Mode.........................134
Cabinet Lights................................135
Error Recovery and Diagnostics..139
Component Interaction...........................139
Importing and Exporting.........................140
Bulk Magazine................................................ 140
On-Line Automated Import/Export.................. 140
Error Codes....................................145
Specifications ................................164
Space Planning..............................165
Site requirements..........................167
Packing Instructions.....................168
Install MTA support ........................................ 168
Packaging Preparation ................................... 169
Install ESD cover............................................ 170
Install library ................................................... 170
Install additional foam/ Finish packaging........ 171
Glossary of Terms.........................173
SCSI ............................................................... 176
Unmount ......................................................... 176

Document No. 305291-000 Revision B 8/28/01 Preface a
Plasmon G Series Users Guide
Preface
Thanks for purchasing the Plasmon Magneto Optical Disk
library. This Operators Manual describes the library, its
functions, and its method of use. Please read this manual
thoroughly before operating the system, in order to become
completely familiar with the functions of the control panel,
and to make the most of all the setup configuration functions.
After reading this manual, store it in a safe place for future
reference.
Copyright Notice
© Copyright PlasmonPlasmon2001
The material in this manual is for reference only and is
subject to change without notice. The revision level and
revision date will change whenever a modification to this
manual occurs.
While reasonable efforts have been taken in the preparation
of the material contained in this manual, Plasmon assumes
no liability resulting from any errors or omissions, or from the
use of material contained herein.
Changes
The material in this manual is for reference only and is subject to change without notice,
the revision level and revision date will change whenever a modification to this manual
occurs.
While reasonable efforts have been taken in the preparation of the material contained in
this manual, Plasmon assumes no liability resulting from any errors or omissions, or
from the use of material contained herein.
Plasmon is ISO 9001 certified.

G Series Users Guide Plasmon
bPreface Document No. 305291-000 Revision B 8/28/01

Document No. 305291-000 Revision B 8/28/01 1
Plasmon G Series Users Guide
Chapter One
Introduction Introduction................................................................3
Who? ................................................................................3
Where?............................................................................. 3
Symbols ........................................................................... 4
Support .......................................................................5
Support Contact ............................................................... 6
Regulatory Notices....................................................7
FCC Compliance Statement............................................ 7
Laser Safety..................................................................... 8
CDRH Regulations........................................................... 8
Lithium Battery................................................................. 8
Power Cord Set Selection ................................................ 8

G Series Users Guide Plasmon
2Document No. 305291-000 Revision B 8/28/01

Document No. 305291-000 Revision B 8/28/01 Introduction 3
Plasmon G Series Users Guide
Introduction
This chapter will give a brief overview of the manual.
Who?
This manual is intended for the key operator and trained
service representatives of the service provider that interact
with the Plasmon G Series library system.
Where?
This manual contains chapters that will explain the operation
of the Plasmon G Series library system. Here is a brief
description of the chapters:
CHAPTER ONE
Introduction - Overview description of the manual, who
should read the manual, chapter layout, explanations of the
symbols used in the manual and where to contact for
additional assistance.
CHAPTER TWO
Installation - Guide to installing the Plasmon G Series library
system.
CHAPTER THREE
Description - General description of the Plasmon G Series
CHAPTER FOUR
Safety - Description of the hazard symbols, cautions, safety
features and environmental specifications for the safe
operation of the Plasmon G Series library system.

G Series Users Guide Plasmon
4Introduction Document No. 305291-000 Revision B 8/28/01
CHAPTER FIVE
Operation - Description of the start up initialization and shut
down operations of the Plasmon G Series library system.
CHAPTER SIX
Control Panel Operation - Description of all the menus and
associated operations for the Plasmon G Series library
system.
CHAPTER SEVEN
Media Processing - Description of the single slot import/
export mailslot and the 10 Slot bulk magazine operation.
CHAPTER EIGHT
Error Codes - List of error codes, descriptions and
troubleshooting ideas.
Symbols
CAUTION. Warnings relating to directions which could put
the operator or the system at risk of damage.
WARNHINWEIS. Warnung vor Handlungen, die dem
Anwender oder dem Laufwerk Schaden zufügen könnten.
ATTENTION. Avertissements concernant les manipulations
pouvant présenter un certain risque pour l’opéateur ou le
lecteur.
NOTE. Information relating to important suggestions.
TIP. Hints to achieve optimal performance from the library
system.

Document No. 305291-000 Revision B 8/28/01 Support 5
Plasmon G Series Users Guide
Support
Plasmon recommends that only qualified personnel should
perform the following operations on the Plasmon G Series
library system:
!Prepare for On-Line operation
!Set-up
!Start-up
!Operate
!Shutdown
!Maintenance
!Restart
CAUTION: Untrained personnel operating the Plasmon
G Series library system may create
dangerous situations. This could lead to
physical harm to the operator and/or
physically disable the Plasmon G Series
library system.
CAUTION: Please review and observe all safety rules
concerning the operation of the Plasmon G
Series library system.

G Series Users Guide Plasmon
6Support Document No. 305291-000 Revision B 8/28/01
Support Contact
Should there be a need for further support other than what
this manual provides, please contact one of these two
technical support locations:
For support assistance in North America, South America,
Asia Pacific, contact:
For support assistance in Europe, Africa, Asia, Middle East,
contact:
United States Office
Address Plasmon, Inc.
9625 West 76th Street
Eden Prairie, MN 55344
Telephone (952) 942-2982
Fax (952) 946-4132
Techweb http://www.plasmontech.com
Email [email protected]
European Headquarters
United Kingdom
Address Plasmon Data Limited
Whiting Way
Melbourn, Herts. SG8 6EN
Telephone +44 (0) 1763 262 963
Fax +44 (0) 1763 264 444
Techweb http://tech.plasmon.co.uk
Email [email protected]

Document No. 305291-000 Revision B 8/28/01 Regulatory Notices 7
Plasmon G Series Users Guide
Regulatory Notices
FCC Compliance Statement
The equipment to which this manual pertains has been tested and found to comply with
the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed and used in accordance with
this User’s Guide, may cause harmful interference to radio communications. Operation
of this equipment in a residential area is likely to cause harmful interference in which
case the user is encouraged to try to correct the interference by one or more of the
following measures:
!Reorient or relocate the receiving antenna.
!Increase the separation between the equipment and the receiver.
!Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
!Consult an experienced radio/TV technician for further help, at your
own expense.
This digital apparatus does not exceed the Class A limits for
radio noise emissions from digital apparatus set out in the
Interference-causing equipment standard entitled “Digital
Apparatus,” ICES-003 of the Industry Canada.
Cet appareil numérique respecte les limites de bruits
radioélectriques applicables aux appareils numériques de
Classe A prescrites dans la norme sur le matériel brouilleur:
“Appareils Numériques”, NMB-003 édictée par l’Industrie
Canada.
This library system is in conformity with the EMC directive
and low-voltage directive.

G Series Users Guide Plasmon
8Regulatory Notices Document No. 305291-000 Revision B 8/28/01
Laser Safety
The optical drives used in this unit are certified to comply with DHHS rule 21 CFR
Chapter 1, Sub-chapter J as a Class 1 laser product under the U.S Department of
Health and Human Services (DHHS) Radiation Performance Standard according to the
Radiation Control for Health and Safety Act of 1968. This means that the optical drives
do not produce harmful radiation.
Since radiation emitted inside the optical drive unit is completely confined within
protective housings and external covers, the laser beam cannot escape from the
machine during any phase of user operation.
CDRH Regulations
The Center for Devices and Radiological Health (CDRH) of the U.S. Food and Drug
Administration implemented regulations for laser products on August 2, 1976. These
regulations apply to laser products manufactured from August 1, 1976. Compliance is
mandatory for products marketed in the United States.
Use of controls, adjustments or performance of procedures other than those specified in
this manual may result in hazardous radiation exposure.
Lithium Battery
The Main Control Board and the Front Control Panel contain a lithium battery which
could explode if incorrectly replaced. Replace only with a qualified replacement battery.
Return the old battery to the manufacturer for disposal or dispose of in accordance with
local regulations for the disposal of lithium batteries.
“ATTENTION: IL Y A DANGER D’EXPLOSION S’IL Y A REPLACEMENT INCORRECT
DE LA BATTERIE. REMPLACER UNIQUEMENT AVEC UNE BATTERIE DU MEME
TYPE OU D’UN TYPE RECOMMANDE PAR LE CONSTRUCTEUR. METTRE AU
REBUT LES BATTERIES USAGEES CONFORMEMENT AUX INSTRUCTIIONS DU
FABRICANT.”
Vorsicht! Explosionsgeahr bei unsachgemabem Austausch der batterie. Ersatz nur
durch denselbel oder einen vom Hersteller empfolhenen gleichwertigen Typ.
Entsorgung gebrauchter Batterien nach Angaben des Herstellers.
Power Cord Set Selection
The voltage rating and the current rating of the power cord set shall be higher than the
rated voltage and current of this unit. The voltage of the power cord set shall be higher
than the power source.
For the U.S. and Canada:
Power cord must be UL listed and CSA labeled. Type SJT, SVT, ST, SJO or SO, 3-
conductors, No. 18 AWG, rated 125v, 10A
For Germany and continental Europe:
STROMANFNAHME: 100-240 VAC, 50/60 Hz, 6A.
Für eine 230V-Anwendung, ist eine harmonisierte <HAR> konfektionierte
Leitungsschnur, Typ H05vvf3G1.00, die für 250V/10A oder die Gleichwertigkeit
geeognet ist, zu benutzen.
If there are any questions in regards to the proper cord sets, consult the distributor.

Document No. 305291-000 Revision B 8/28/01 9
Plasmon G Series Users Guide
Chapter Two
Quick Installation
Quick Start Installation and Guide .........................11
Library Position ..............................................................11
Loading Media................................................................11
Mass Loading (Recommended).................................... 12
G64 and G104 Stabilizer Plates.................................... 13
On-Line Automated Import/Export................................ 16
Ten Slot Bulk Magazine................................................ 16
Inside the Front Door .....................................................17
Power Cable.................................................................. 17
SCSI Connection........................................................... 18
Initial Power On..............................................................19
Host Computer.............................................................. 19
SCSI ID Configuration................................................... 20

G Series Users Guide Plasmon
10 Document No. 305291-000 Revision B 8/28/01

Document No. 305291-000 Revision B 8/28/01 Quick Start Installation and Guide 11
Plasmon G Series Users Guide
Quick Start Installation and Guide
This section of the manual will be a guide to installing the
library system and the procedures necessary to quickly put
the library in to an on-line state.
NOTE: Please follow the unpacking instructions found
on the packing material. Verify that all the listed
components are present.
Library Position
Position the library system in a location that allows both the
front and rear door to open completely with out any
obstructions.
Loading Media
Use only Plasmon approved ISO standard 5.25 inch Magneto
Optical media in the library system. Media can be loaded into
the library system using one of three methods.
1. Mass Loading (recommended): This method is intended
as a one time solution to mass load the entire library with
media when the library is Off-Line and there is no power
applied to the library system.
2. Automated Single Media Cartridge Import/Export: This
is intended for importing and exporting a single piece of
media into the library system while the library system is
On-Line.
3. Ten Slot Bulk Magazine (not available with the G64
and G104 models): This is intended for importing and
exporting up to ten pieces of media in a removable
magazine while the library is On-Line.

G Series Users Guide Plasmon
12 Quick Start Installation and Guide Document No. 305291-000 Revision B 8/28/01
Mass Loading (Recommended)
Insure that the library system is turned off and that the power
cable has been disconnected from the wall outlet.
1. Using the enclosed key,
open the rear door of the
library system. The rack
mount version of the
G64 and the G104 do
not have a rear door.
The rear panel must be
removed by removing
the screws.
2. Remove all the shipping
restraints from the media
transport assembly.
CAUTION: Use minimum
force when
removing the
restraints and
packing material from the media transport
assembly.
NOTE: There is not a requirement to load the media in a
specific order. Plasmon does recommend that
the storage slots are filled in a numerical order,
starting with slot number 1.
NOTE: See the library system storage slot map on the
inside of the rear door for the numbering system
of the storage slots.

Document No. 305291-000 Revision B 8/28/01 Quick Start Installation and Guide 13
Plasmon G Series Users Guide
3. Carefully move the library system to the location at which
will be attached to the host computer.
4. Insert the media into the slots. Insert the media with the
shutter end of the media going in first.
5. Completely insert the media into the storage slot until it
contacts the rear of the storage slot.
6. Load all the media storage slots.
7. Close the rear door and lock the door.
NOTE: Insure that there is at least 2.0" of clearance on
the sides of the library system to provide for
proper airflow in order to ventilate the library
system.
8. Lower the leveling feet to the floor to stabilize the library
system.
G64 and G104 Stabilizer Plates
The G64 and G104 will have two stabilizers plates shipped
with each unit. The stabilizer plates are to prevent the G64
and G104 library models from tipping from some accidental
force. Included in the kit will be:

G Series Users Guide Plasmon
14 Quick Start Installation and Guide Document No. 305291-000 Revision B 8/28/01
!two stabilizers
!six 8-32 UNC-2B screws
!six washers
!one 9/64" hex wrench
FIGURE 1. Stabilizer
The stabilizers will be mounted one on each side of the
library system.
1. Take one of the stabilizers and position it with the three
threaded fasteners on underneath side of the library
chasis.
2. Choose one of the 8-32 UNC-2B screws and washer.
3. Manually start the each screw with and tighten with finger
tension.
4. Use the 9/64" wrench to tighten each one of the three
screws. Assure the screws are tighten to 20 inch pound
5. Follow the above steps and attach the stabilizer on the
other side of the library system.

Document No. 305291-000 Revision B 8/28/01 Quick Start Installation and Guide 15
Plasmon G Series Users Guide
CAUTION: If the library system is to be moved from it’s
current position. It is recommended to
remove the stabilizers prior to the move and
re-install them when the library system is in
the new location.
This manual suits for next models
6
Table of contents
Other Plasmon Storage manuals
