Freecom Data Tank User manual

A new denition of multiple-drive storage
The new Freecom DataTank provides you with up to
2TeraByte (2000GB) of hard drive storage capacity! The
ideal platform to store all your valuable data on. The
easy to use conguration tool allows you to choose
between RAID 0 (striping, combines the capacity of both
disks into one volume; you will see the total capacity
as one driveletter in your operating system), RAID 1
(mirroring, one disk copies the other automatically, so
you always have a safe copy of your data; you will see
one driveletter in your operating system for half of the
total drive capacity) or JBOD (dual drive letter, both disks
will appear as separate drive letters in your operating
system). Large storage capacity is one thing, but what
about security? Freecom oers the rst drive with an
Encryption button; at the touch of this button you can
access a password protected encrypted partition on the
DataTank; your data is encrypted in 128 bit AES standard,
which was developed in close cooperation with the US
government and is widely recognized as impossible to
crack. The DataTank also features Freecom’s SYNC button,
for synchonizing les between computer and DataTank
and vice versa. Equipped with Hi-speed interfaces, the
Freecom DataTank gives you speed, space and security,
all in one device! At Freecom we create storage solutions
from a user’s perspective, where convenience and quality
are key factors.
Free your mind.
Dual disk high capacity storage solution
•High capacity storage solution for professional and home use
•Winner of the iF Product Design Award 2007 for outstanding design!
•Available in up to 2TB (2000GB) storage capacity
•One Button Data Encryption – 128 bit hardware data encryption !!
•One Button Data Synchronization – always have the latest version of your les
•Congurable as RAID 0 (striping, 2 drives as one volume), RAID 1 (mirroring, 1 disk mirrors
the other) or JBOD (assign multiple drive letters using the total disk capacity)
•Hi-Speed interfaces: USB 2.0, FireWire 800 and FireWire 400.
•High quality aluminium enclosure with optimal internal airow management
•Silent, ball bearing temperature controlled cooling fan with dual thermo sensor
•Compact design, 20 x 9.6 x 12.4 cm
•Two years manufacturers warranty and unlimited free helpdesk support
Ideal for home and oce use
Oce use:
•The ideal storage location for oce documents such as large graphics les, administrative
archives etc.
•Ideally suited for AV-professionals: use the DataTank to store and edit large,
uncompressed video and music les
•Use the DataTank for backups without using up the bandwith of your network
•Create an almost unlimited amount of storage space by daisy-chaining via Firewire
•Always have a copy of your data available when using it as RAID 1 system
•Protect your data against malicious intrusions using hardware encryption
Home use:
•Store all your photo, music, video les on one location
•Make a backup of PC’s in your home network
•Store a drive image of a clean OS installation on the DataTank and recover it in case of
your PC’s hard drive failure
WWW.FREECOM.COM
data tank
EXtERnaL duaL disk HaRd dRiVE /
3.5” / usB 2.0 / FiREWiRE 800 & 400
Win & MaC
AWARD

1TB 2TB
Art. No. EU/UK 27456 29420
EAN code EU/UK 4021801274564 4021801294203
Color Silver Silver
Ref. MM/PW/08-02-2008
PRODUCT SPECIFICATIONS FREECOM DATATANK:
CApACiTy 1TB (2x 500GB) - 2TB (2x 1TB)
inTeRfACe USB 2.0, FireWire 800, FireWire 400
HARD DRive Type 3.5” SATA, 7200rpm, low noise, low power consumption
peRfoRmAnCe Average seek time < 8.9ms
Track to track seek time 0.8ms
Average latency: 4.17 ms
Rotational speed: 7200rpm
Buer size: Min. 8MB
DATA TRAnsfeR speeD max. 480 Mbit/s (USB 2.0), max. 800 Mbit/s (FireWire 800),
max. 400 Mbit/s (FireWire 400)
RAiD sysTem user selectable, RAID 0 (fast, one drive volume), RAID 1
(safe, two drive volumes, mirroring), JBOD (dual drive letter)
HARDWARe DATA enCRypTion 128 bit AES
WeigHT 2900 gr. / 101 Ounce
Dimensions 200 x 96 x 124 mm / 7.9 x 3.8 x 4.9 inch
mTBf 50000 P.O.H.
enviRonmenTAl speCifiCATions Operating temperature: 10º C / 35º C
Storage temperature: -20º C / 80º C
suppoRTeD opeRATing sysTems Windows 2000 / XP / Vista, MAC OS X v. 10.3
The DataTank is Windows NTFS preformatted for instant use under
Windows2000 / XP / Vista; MAC OS X users need to initialize the
DataTank in HFS+ after connecting.
minimum sysTem RequiRemenTs pC: Pentium III / AMD Duron 900MHz or higher, 256MB RAM (Vista:
512MB) or higher, CD-ROM drive, available USB 2.0, USB 1.1 port* or
FireWire 800 (9 pin) / FireWire 400 (6 pin) port, Windows 2000 / XP /
Vista
mAC: PowerPC G3/G4/G5, Power Book G3/G4 or Intel Mac, 256MB
RAM or higher, available USB 2.0, USB 1.1 port* or FireWire 800 (9 pin)
/ FireWire 400 (6 pin) port, OS X v.10.3 or higher
level 0 / 1 / JBoDDuAl DisKone BuTTon DATA
synCHRoniZATion
one BuTTon DATA
enCRypTion
pACKAge inCluDes:
•Freecom Data Tank Dual Disk 3.5” Hard Drive (NTFS pre-formatted (Win))
•Power adapter
•USB connection cable
•FireWire 800 & 400 connection cables
•Manual & Software CD
•Quick Install Guide
All devices meet the highest industry standards; CE, FCC and RoHS
NTI SHADOW SOFTWARE:
NTI Shadow for PC and Mac is an easy-to-use backup application that automatically protects your photo, music, video, and various data les. It makes data restoration
as easy as dragging and dropping les from one place to another. For real-time, continuous data backup, set Shadow to save your les/folders every time they change.
You can also specify your backup schedule by the minute, hour, day, week and start time(s) and also choose a specic or even a customized le type with Shadow’s new
advanced le ltering.
Not only does Shadow allow users to automatically copy les from their PCs to various devices in real time, but it also preserves the les in their native format - meaning no
additional software is necessary to restore les. Shadow works transparently in the background without disturbing you while you work, and does not take up important
system resources.
