Infortrend EonStor GS 3000 Series User manual

Infortrend EonStor GS 3000 Series
Hardware Manual
Version 1.0

Legal Information
2
Legal Information
All Infortrend products, including the product customers have purchased from
Infortrend, shall be subject to the latest Standard Warranty Policy available on the
Infortrend website: http://www.infortrend.com/global/Support/Warranty
Infortrend may from time to time modify, update or upgrade the software, firmware or
any accompanying user documentation without any prior notice. Infortrend will
provide access to these new software, firmware or documentation releases from
certain download sections of our website or through our service partners. Customer
shall be responsible for maintaining updated version of the software, firmware or
other documentation by downloading or obtaining from Infortrend, and installing
designated updated code, including but not limited to firmware, microcode, basic
input/out system code, utility programs, device drivers, and diagnostics delivered
with Infortrend product.
Before installing any software, applications or components provided by a third party,
customer should ensure that they are compatible and interoperable with Infortrend
product by checking in advance with Infortrend. Customer is solely responsible for
ensuring the compatibility and interoperability of the third party’s products with
Infortrend product. Customer is further solely responsible for ensuring its systems,
software, and data are adequately backed up as a precaution against possible
failures, alternation, or loss.
For any questions of hardware/ software compatibility, and the update/ upgrade code,
customer should contact Infortrend sales representative or technical support for
assistance.
To the extent permitted by applicable laws, Infortrend shall NOT be responsible for
any interoperability or compatibility issues that may arise when (1) products, software,
or options not certified and supported by Infortrend are used; (2) configurations not
certified and supported by Infortrend are used; (3) parts intended for one system are
installed in another system of different make or model.

Contact Information
3
Contact Information
Customer Support
Contact your system vendor or visit the following support site.
EonStor GS Support
Headquarters
(Taiwan)
Infortrend Technology, Inc.
8F, No. 102, Sec. 3, Jhongshan Rd., Jhonghe Dist., New Taipei City 235, Taiwan
Tel: [phone] Fax: [phone] Email, Technical Support, Website
Americas
Infortrend Corporation
435 Lakeside Dr. Sunnyvale, CA. 94085, USA
Tel: [phone] Fax: [phone] Email, Technical Support, Website
China
Infortrend Technology, Ltd. / Infortrend 北京分公司 Map
北京市朝阳区东四环中路远洋国际中心 D座403 室
Room 403,Block D, Ocean International Center, Dis. Chaoyang, Beijing, China
Tel: [phone] Fax: [phone] Email, Technical Support, Website
Europe (EMEA)
Infortrend Europe LTD.
5 Ringway Centre, Edison Road, Basingstoke, Hampshire, RG21 6YH, UK
Tel: [phone] Fax: [phone] Email, Technical Support, Website
Japan
Infortrend Japan, Inc.
105-0023 東京都港区芝浦 1－7－14 岡家寿ビル 6F
Tel: [phone] Fax: [phone] Email, Technical Support, Website

Copyright Notice
4
Copyright Notice
All rights reserved. This publication may not be reproduced, transmitted,
transcribed, stored in a retrieval system, or translated into any language or
computer language, in any form or by any means, electronic, mechanical,
magnetic, optical, chemical, manual or otherwise, without the prior written
consent of Infortrend Technology, Inc.
Disclaimer
Infortrend Technology makes no representations or warranties with respect to
the contents hereof and specifically disclaims any implied warranties of
merchantability or fitness for any particular purpose. Furthermore, Infortrend
Technology reserves the right to revise this publication and to make changes
from time to time in the content hereof without obligation to notify any person of
such revisions or changes. Product specifications are also subject to change
without prior notice.
Trademarks
Infortrend, the Infortrend logo, EonOne, SANWatch, ESVA, EonStor DS,
EonStor GS, EonNAS, and EonPath are registered trademarks of Infortrend
Technology, Inc. Other names prefixed with “IFT” and “ES” are trademarks of
Infortrend Technology, Inc.
Windows is a registered trademark of Microsoft Corporation.
Mac OS X is a registered trademark of Apple Computer, Inc.
Linux is a trademark of Linus Torvalds.
All other names, brands, products or services are trademarks or registered
trademarks of their respective owners.

Safety Precautions
5
Safety Precautions
Read these instructions carefully before you install, operate, or transport the EonStor
GS RAID system and JBODs.
Installation and Operation
Install the rack cabinet and the associated equipment at a site where
the ambient temperature (special room cooling equipment may be
required) stays lower than:
a. 35C ~ if your system have a BBU (all Dual-Controller
systems come with BBU by default)
b. 40C ~ if your system does not have a BBU
Install the power source socket outlet near the enclosure where it is
easily accessible and ground the rack cabinet.
Secure airflow clearance inside and around the rack cabinet.
- Secure an 18 to 20cm clearance on the rear side.
- Do not cover the enclosure openings.
- Route the cables inside the rack cabinet.
- Do not leave drive bays empty as it will affect airflow efficiency.
Secure each enclosure module using its retaining screws.
Place power cords and other cables away from foot traffic. Do not place
items on top of power cords and make sure they do not rest against
data cables.
Install all modules to the enclosure before powering-on systems.
Ensure that the correct power range is being used before powering-on.
DO NOT remove covers or replaceable modules if they are not faulty.
If the system is not going to be used for a long period of time,
disconnect it from the power mains to avoid transient over-voltage.
For power source redundancy, please make sure that the two PSUs are
plugged into two different power sources (i.e. Different circuit breakers).

Service and Maintenance
Service and Maintenance
Keep the faulty module in place until you have a replacement unit; an
empty module greatly affects the airflow efficiency within the enclosure.
During service operation, place the enclosure on soft and clean surface
to prevent exterior damage. Do not place tools or other items on top.
When transporting the enclosure, repackage all disk drives separately in
the original package foam blocks. Replaceable modules can stay in the
enclosure if you are using the original package; if not, repackage them
separately as well.
Disconnect the power cords before servicing or cleaning the enclosure.
Use a slightly moistened paper sheet or cloth for cleaning. Avoid using
liquid or sprayed detergent.
When replacing components, insert them as gently as possible while
assuring full engagement. Vibration and shock can easily damage hard
drives.
Only qualified service personnel should open the enclosure.
Contact service personnel if any of the following situations occurs:
- The power cord or plug is damaged.
- The enclosure has been exposed to moisture.
- The system has not been working properly.
- The enclosure was dropped against a hard surface.
- The enclosure shows obvious signs of breakage.
To move the enclosure, more than one person might be necessary due
to its weight. Drives should be removed from the enclosure beforehand.
Important Notice
The use of Infortrend certified components is strongly recommended to ensure
compatibility, quality and normal operation with your Infortrend products. Please
contact your distributor for a list of Infortrend certified components (e.g. SFP, SFP+,
HBA card, iSCSI cable, FC cable, memory module, etc.).

ESD Precautions
ESD Precautions
Handle the modules by their retention screws, ejector levers, or the
module’s metal frame/faceplate only. Avoid touching the PCB boards or
connector pins.
Use a grounded wrist strap and an anti-static work pad to discharge
static electricity when installing or operating the enclosure.
Avoid dust, debris, carpets, plastic, vinyl, and Styrofoam in your work
area.
Do not remove any module or component from its anti-static bag before
installation takes place.
Drives must not be stacked on top of each other without their protective
drive trays. Even when drives are fixed in the drive trays, contacting the
exposed PCB or rear-side interface may damage the drives.

About This Manual
About This Manual
The manual introduces hardware components of EonStor GS RAID and JBOD systems. It also
describes how to install, monitor, and maintain them.
For non-serviceable components, please contact our support sites.
Firmware operation: Consult the Firmware User Manual on the CD-ROM.
EonOne software: Consult the EonOne User Manual on the CD-ROM.
Revision History
Version
Date
Description
1.0
Feb. 2016
Initial release

9
Table Of Contents
Legal Information ...................................................................................... 2
Contact Information................................................................................... 3
Copyright Notice........................................................................................ 4
Safety Precautions .................................................................................... 5
Installation and Operation......................................................................... 5
Service and Maintenance.......................................................................... 6
Important Notice........................................................................................ 6
ESD Precautions........................................................................................ 7
About This Manual..................................................................................... 8
Revision History ........................................................................................ 8
Table Of Contents...................................................................................... 9
Introduction ............................................................................................. 14
Product Overview.................................................................................... 14
Model Naming Conventions....................................................................... 14
Model Variations...................................................................................... 15
Major Components.................................................................................. 16
RAID Controller and Interface.................................................................... 16
JBOD Controller and Interface................................................................... 16
Power supply unit with built-in cooling module........................................... 17
The Rear Panel......................................................................................... 18
Dual-Controller Models.............................................................................. 18
Single-Controller Models ........................................................................... 19
Upgrading Single-Controller to Dual-Controller System............................. 19
Connection between RAID and JBOD....................................................... 19
Chassis..................................................................................................... 20
Front Panel................................................................................................ 20
Rear Panel ................................................................................................ 22

10
Internal Backplane..................................................................................... 24
Front Panel Components ........................................................................ 25
LED Panel................................................................................................. 25
Drive Tray Bezel........................................................................................ 26
Rear Panel Components ......................................................................... 27
Controller Module of RAID Models............................................................. 27
Super Capacitor & Flash Backup Module .................................................. 29
PSU & Cooling Module.............................................................................. 30
System Monitoring Features................................................................... 31
Expansion Enclosure Support.................................................................... 31
I2C bus...................................................................................................... 32
Firmware (FW) and EonOne...................................................................... 32
Audible Alarms........................................................................................... 32
Hot-swapping........................................................................................... 33
Hardware Installation .............................................................................. 34
Installation Prerequisites ........................................................................ 34
Installation Procedures Overview........................................................... 35
Unpacking the System ............................................................................ 36
Box contents.............................................................................................. 36
Preinstalled Components........................................................................... 36
Components to be Installed....................................................................... 36
Installing Hard Drives.............................................................................. 37
Hard Drive Installation Prerequisites.......................................................... 37
SAS Interface............................................................................................ 39
Hard Drive Designation.............................................................................. 40
Installing the Hard Drive into Drive Tray..................................................... 41
Installing the Hard Drive Tray into the Enclosure ....................................... 42
Installing Host Boards................................................................................ 43
Installing the Controller.............................................................................. 44
System Connection................................................................................. 45
General Considerations on Making Connections.................................. 45
Host-Side Topologies................................................................................. 46
Host-Side Parameters ............................................................................... 46
Maximum Concurrent Host LUN Connection (“Nexus” in SCSI)................. 47
Maximum Queued I/O Count..................................................................... 48

11
Fibre-Host Connections (including 10Gb FCOE iSCSI) ........................ 49
Fibre-Host Topologies................................................................................ 51
Fibre Cabling............................................................................................. 52
Simple End-to-End Connection.................................................................. 53
DAS (Direct-Attached) Connection ............................................................ 54
Switched Fabric Connection (Dual-Controller)........................................... 56
Switched Fabric Connection (Single-Controller)......................................... 58
SAS-Host RAID Connections.................................................................. 60
DAS (Direct-Attached Storage) Connection with Redundant Host Path ..... 61
DAS (Direct-Attached Storage) Connection to Two Servers....................... 63
iSCSI-Host RAID Connections................................................................ 64
Network & Host Connection Topologies..................................................... 65
High Availability IP SAN with Redundant RAID Controller.......................... 66
Single-Controller with Fault-Tolerant Path.................................................. 68
High Availability IP SAN (Recommended Cabling Method for Remote
Replication) ............................................................................................... 69
High Availability IP SAN with Port Trunk (Remote Replication Enabled) .... 71
Hybrid Host Connections........................................................................ 73
Single Hybrid Unit Connected to FC/iSCSI Hosts...................................... 73
Utilizing Hybrid iSCSI ports for Data Replication........................................ 74
JBOD Connections.................................................................................. 75
JBOD SAS Expansion Configuration ......................................................... 75
Configuration Rules................................................................................... 76
Dual-Controller Expansion Connection...................................................... 78
Single-Controller Expansion Connections.................................................. 79
Management Console Connections ....................................................... 80
Connecting RAID system to external consoles .......................................... 80
Power Connections................................................................................. 81
Checklist.................................................................................................... 81
Power Cords Connections......................................................................... 82
Power On Procedure................................................................................. 82
Power On Status Check............................................................................. 83
Power Off Procedure................................................................................. 84
System Monitoring .................................................................................. 85
Monitoring Features................................................................................ 85
LED Panel................................................................................................. 87
Drive Tray LED.......................................................................................... 89

12
Controller LED......................................................................................... 90
Controller LED for RAID Models................................................................ 90
Controller LED for 12 Gb/s SAS JBOD Models.......................................... 92
iSCSI / Ethernet Management Port LEDs.................................................. 93
10 Gb iSCSI Host Port LEDs (Fibre).......................................................... 94
10 Gb iSCSI Host Port LEDs (RJ45).......................................................... 94
8 Gb Fibre-Host Port LEDs........................................................................ 95
16 Gb Fibre Channel Host Port LEDs........................................................ 96
6G SAS-Host Port LEDs............................................................................ 97
12G SAS-Host Port LEDs.......................................................................... 98
PSU & Built-in Cooling Module LEDs..................................................... 99
Alarms and I2C Bus............................................................................... 100
Audible Alarms......................................................................................... 100
I2C ........................................................................................................... 100
Restoring Default System Settings ...................................................... 101
Restoring Default Settings....................................................................... 101
System Maintenance............................................................................. 103
Replacing the Controller Module(s): Single / Dual / Simultaneous
Upgrade.................................................................................................. 104
Replacing the Host Board..................................................................... 107
Replacing the Memory Module on RAID Systems............................... 108
Replacing the CBM for RAID Models.....................................................110
Replacing the Flash Backup Module.........................................................110
Super Capacitor Fault Conditions and Precautions...................................111
Replacing Flash Backup Module (coupled with SuperCap).......................112
Replacing the Power Supply Module / Cooling Module.......................113
Detecting a Failed PSU ............................................................................113
Replacing Power Supply Unit ...................................................................114
Replacing a Hard Drive ..........................................................................116
Appendix.................................................................................................118
Technical Specifications ........................................................................118
Host Board Interface.................................................................................118
RAID Configurations for RAID Models......................................................119
Fault Tolerance for RAID models............................................................. 120
Power Supply .......................................................................................... 121
Dimensions.............................................................................................. 122
Environment ............................................................................................ 123

13
Certifications.......................................................................................... 124
Summary................................................................................................ 124
Slide Rail Kit Installation Guide............................................................ 125
Slide Rail Kits......................................................................................... 125
Enclosure Installation Prerequisites.................................................... 125
Unpacking the System .......................................................................... 126
Component Installation Procedure....................................................... 126
Tools Required....................................................................................... 126
Rack Ear Mount Kit................................................................................ 127
Kit Contents............................................................................................. 127
Installation Procedure.............................................................................. 128
Slide Rail Kit........................................................................................... 130
Kit Contents............................................................................................. 130
Once Mounted........................................................................................ 134

14
Introduction
Product Overview
This manual introduces EonStor GS 3000 systems that support 3Gbps, 6Gbps and
12Gbps SAS and Near Line SAS, SATA hard drives and SSDs. The enclosure is
designed to utilize 2.5”or 3.5” hard drives. Drive capacity can be expanded by
attaching expansion hard drive enclosures (JBODs).
Model Naming Conventions
The naming rules for RAID and JBOD models are explained in the example below:
RAID: GS3024RCB GS (A) + 30 (B) + 24 (C) + R (D) + C (E) + B (F)
Designation
Description
(A)
GS = EonStor GS systems
JB = JBOD systems
(B)
30 where 0 indicates first generation, 1 indicates second generation and so on
(C)
12 = 2U system, 12 hard drives capable
16 = 3U system, 16 hard drives capable
24 = 2U system, 24 hard drives capable
(D)
R= redundant (dual) controllers
S= single and upgradeable to Dual-Controllers
(E)
C= CBM (Cache Backup Module) with super capacitor and flash module
(F)
B= 2.5”hard drive form factor system
3.5”hard drive form factor system if not mentioned

15
EonStor GS 3012
EonStor GS 3016
EonStor GS 3024B
Model Variations
Comprised of RAID and JBOD models, RAID systems store hard drives and control
the entire storage array while JBOD systems connect to a master RAID system and
allow storage capacity expansion by adding more hard drives. Hard drive limitation(s)
may vary model to model.

16
Major Components
NOTE
Upon receiving your system, check the package contents against the included
Unpacking List. If module(s) are missing, please contact your system vendor
immediately.
RAID Controller and Interface
Each RAID controller comes with pre-installed DIMM module(s).
The traditional battery backup is replaced by an innovative Cache Backup Module
methodology (CBM) which consists of a super capacitor and a flash backup module
(FBM). Cached data is quickly distributed to a flash backup module for permanent
storage with the support of the super capacitor in the event of a power outage. The
advantage of a super capacitor is its very fast charging time. The super capacitor is
charged within a few minutes and available to distribute power to the controller. So
cached data can be saved immediately and permanently in flash backup module
(FBM).
The embedded firmware features intelligent algorithms, such as power-saving
modes, variable fan speeds, and exiled drive handling, making this model a greener
choice.
JBOD Controller and Interface
The enclosure is managed by expander controllers that distribute data flow to
individual disk drives and report operating status through a proprietary enclosure
service via in-band protocols. The enclosure, along with other JBODs, connects to a
RAID system and serves as a building block of a scalable configuration.
In terms of supported protocols, the firmware supports communications with
enclosure devices, SAS/SATA disk drives and as RAID system featuring SAS
expansion ports.
In terms of physical connection, the SAS interface provides ease of cabling through
Mini-SAS connectors. With a backplane adapting SAS or SATA drives, the system
supports enterprise-class SAS, Near-line SAS, cost-effective SATA-II or SATA-III
hard drives or SSDs, and is ideal for adding large capacity to a storage pool.

17
Power supply unit with built-in cooling module
Cooling module is built into the power supply unit (PSU) to protect the system from
overheating. The two hot-swappable PSUs provide constant power to the system.
The modular nature of the system and the easy accessibility to all major components
ensure ease of maintenance.

18
The Rear Panel
Dual-Controller Models
Dual-Controller systems are indicated by an “R”in their model number (please refer
to Model Naming Conventions). Controller A is located on top and controller B at the
bottom for all models. If one controller fails, the second controller module will take
over in a manner that is transparent to application servers.
A
B
EonStor GS 3012R / 3024RB
A
B
EonStor GS 3016R
The top controller (Controller A) is the primary controller. The bottom controller
(Controller B) is the secondary (= redundant) controller which is idle during normal
operation and takes over the management role when Controller A cannot function
properly due to hardware error, controller module removal, etc.
If the failed Controller A restarts or a replacement is installed, Controller A will
temporarily assume the role of the secondary controller.
When the RAID system is rebooted, all system configurations will revert back to the
default state and Controller B returns the primary role to Controller A.

19
Single-Controller Models
Single-Controller models are designated by a “G”or “S”in their model number. The
second controller slot is filled with a dummy cage.
A
EonStor GS 3012 / 3024B
A
EonStor GS 3016
Upgrading Single-Controller to Dual-Controller System
If the model name of a Single-Controller RAID/JBOD is designated with the letter “S”,
it can be upgraded into a Dual-Controller configuration by adding another controller
module and firmware upgrade (see software manual). If the model name is
designated with a “G”, it is not upgradeable to a Dual-Controller configuration.
For details, please contact your vendor for details.
Connection between RAID and JBOD
The following rule applies when connecting RAID and JBOD(s):
Dual-Controller RAID system connects to Dual-Controller JBOD.
Single-Controller RAID connects to Single-Controller JBOD.

20
Chassis
The chassis is rugged constructed and divided into front and rear sections. The
chassis is designed to be installed into a rack or cabinet.
Front Panel
1
3
2
4 6
5
47
EonStor GS 3012
1
3
2
6
4
5
7
EonStor GS 3016
1
3
2
6
4
5
7
EonStor GS 3024B
