Playvision HDV-E50S2 User manual

HDMIExtender
oversingle50m/164ftUTPCables with DualIRControl
Usermanual

1
Thankyoufor purchasingthis product.For optimumperformance and safety,please read these
instructions carefully before connecting,operatingor adjustingthis product.Please keep this manual for
future reference.
nIntroduction
The HDMIextender over 1UTP cables with IR control is the right way to send your HDMIsignal over
longdistances.Instead of usingexpensiveHDMIcables, this device lets you use your existingCat5e/ 6
cables/sockets while also performingthe samefunctions liketransferring1080P videoand new lossless
compressed (Dolby TrueHD, Dolby Digital Plus and DTS-HD Master Audio) digital audio, all with a
bandwidth up to 165MHz. And if that weren tenough, you can use your existingremote to control your
device throughan IRblaster.
nFeatures
1. Compliant with HDMI1.3, HDCP1.1and DVI1.0standards.
2. Supports digital video formatsin 1080p and new lossless compressed (Dolby TrueHD, Dolby

2
Digital Plus and DTS-HD Master Audio) Digital audio
3. Equalizes and recovers incomingTMDSdata before re-transmittingit in highquality, regardless of
the incomingsignal quality.
4. Supports HDMI1.4with 3D fuction.
5. Super IRcontrol system, IRtransport channel can be forward or backward.
nPackage
1. HDMITransmitter 1pcs
2. HDMIReceiver 1pcs
3. Windband IRTx cable 1pcs
4. windband IRRx cable 1pcs
5. 5V1ADC Power Supply Adaptor 2Pcs
6. Product Manual 1pcs

3
nSpecifications
Support Resolution480i ~1080p50/60,VGA~UXGA
HDMITransmitter ports 1xHDMI,1x IR Tx, 1x IRRx, 1xCat5e/6
HDMIReceiver ports 1xHDMI,1x IRTx,1x IRRx, 1xCat5e/6
Power Supply5V1ADC
ESDProtectionHumanbody model±8kV(air-gap discharge) ,
±4kV(contact discharge)
Dimension 80mmx41mmx25 mm
Weight 150g
OperatingTemperature0°C~40°C/32°F~104°F
StorageTemperature-20°C~60°C/-4°F~140°F
elativeHumidity20~90% RH(Non-condensing)

4
nConnect andOperate
Connect the signal source such as Blu-RayPlayer,PlayStation 3,audio/video receiver,cable or satellite
receivers and computers equipped with HDMI output interfaces withashort high-speed HDMIcable to
the HDMITransmitterinput. HDMIcable length should not exceed 16 ft.
Connect the HDMITransmitter output RJ-45 ports usingsingle Cat 5e or Cat 6UTPcables to included
Receiver.Itis strongly recommended that factory terminated cable assemblies be used and their length
shall not exceed 164 ft respectively for the 50 mextenders.
Connect the HDMIoutput fromthe Receiver to high-definition display devices such as HD-LCD,
HD-DLP and HD projectors with HDMIinput interfaces. Use high-speed HDMIcables that are
recommended for the distances that are required for each connection. HDMIcable length should not
exceed 16 ft.
The source can be controlled fromthe display.This is accomplished by usingan optional IR Receiver

5
pigtail pointingaway fromthedisplay,which can be connected to the receiver portion of theextender.
The IRTransmitter pigtail is then connected tothe Transmitter of the extender and pointed at the source.
HDMI TransmitterEDID Switch:Select 3D or 2D EDID.
HDMI ReceiverEQ Switch:
LOW:For 0-20mCAT5E/6 Cable.
High:For 20-50mCAT5E/6Cable.
nApplicationExample

6
