Pliant MICROCOM 900XR User manual
For more information visit
www.plianttechnologies.com
QUICK START GUIDE
CUSTOMER SUPPORT
Pliant Technologies oers technical support via phone and
email from 07:00 to 19:00 Central Time (UTC−06:00), Monday
through Friday.
+1.844.475.4268 or +1.334.321.1160
customer[email protected]
You may also visit our website (www.plianttechnologies.com)
for live chat help. (Live chat available 08:00 to 17:00 Central
Time (UTC−06:00), Monday through Friday.)
Additional Documentation
This is a quick start guide. For additional
information, visit our support website. (Scan
this QR code with your mobile device to
navigate there quickly.)
COPYRIGHT © 2021 Pliant Technologies, LLC. All rights reserved. The
Pliant® word mark, the Pliant “P” logo, and MicroCom® are registered
trademarks of Pliant Technologies, LLC. Any and all other trademark
references within this document are property of their respective owners.
Document Reference: D0000620_C
IN THIS BOX
WHAT’S INCLUDED WITH MICROCOM 900XR
RECEIVER?
• Receiver
• ADPT-2.5-3.5: 2.5 mm Male to 3.5 mm Female Adapter
Cable
• USB-C Charging Cable
• Quick Start Guide
• Lanyard
ACCESSORIES
OPTIONAL ACCESSORIES
• PBT-RECCHG-10: 10-Bay Drop-In Pack Charger
• PAC-USB5-CHG: 5-Port USB Charger
• PHS-IE-REC: Listen-only Eartube
• PHS-OE-REC: Over the Ear Listen-Only Earpiece
RECEIVER
OPERATION
• Lock - To toggle between Lock and Unlock, hold the Lock
button for 4 seconds. A lock icon appears on the LCD when
locked. Lock prevents user access to change the mode or
enter the menu.
• Volume Up and Down - Use the +and -buttons to control
the headset or speaker volume. “VOL” and a numeric
indicator will display the receiver’s current volume setting on
the LCD. You will hear a beep when volume is changed. You
will hear a dierent, higher-pitched beep when maximum
volume is reached.
• Mode - Long-press the Mode button to access the menu.
• Channel - Short-press the Channel button to toggle
between the channels enabled on the recevier.
• Out of Range Tones - The user will hear three quick tones
when the beltpack logs out of the system, and they will hear
two quick tones when it logs in.
Battery
• Battery life: Approx. 10 hours
• Charging LED on the receiver will illuminate red while
charging and will turn o when charging complete (LED is
only visible when looking at recevier from an angle).
SETUP
1. Connect a headset to the receiver or use the internal
speaker.
Note: Most standard 3.5 mm headsets using the included 2.5 mm
to 3.5 mm adapter are compatible.
2. Power on. Press and hold the Power button for 2
seconds, until the screen turns on.
3. Access the menu. Press and hold the Mode button for
4 seconds to enter the menu. Short-press Mode to scroll
through the settings, and then scroll through setting
options using Volume +/-. Press and hold Mode to save
your selections and exit the menu.
a. Select a group. Select a group number from 00–51.*
Receivers must have the same group number as the
CrewPlex system to communicate.
b. Confirm beltpack’s security code. Receivers must have
the same 4-digit security code as the CrewPlex system to
communicate.
4. Access the tech menu.** Press and hold the Mode and
Channel buttons for 4 seconds to enter the tech menu.
Short-press Mode to scroll through the settings, and then
scroll through setting options using Volume +/-. Press
and hold Mode to save your selections and exit the tech
menu.
a. Select a mode. Receivers must match the mode of the
MicroCom XR system to communicate.
Note: Once you save the mode, the receiver will power o.
b. Power on. Receiver will now be in the mode chosen from
the tech menu.
5. Select Channel A or B.
*For PMC-REC-900AN receivers, select a group number 00-24.
**Repeater mode is the default setting. See the MicroCom XR
Manual for more information about modes.
Menu Options
The following settings are adjustable from the receiver menu.
*For PMC-REC-900AN receivers, select a group number 00-24.
**Channel B not available in Roam Mode.
The following settings are adjustable from the recevier tech
menu.
*The modes available in the MicroCom XR Recevier are described
below:
• Repeater Mode (RP): connects users working beyond line of
sight from one another by locating the Master beltpack in a
prominent central location
• Roam Mode (RM): connects users working beyond line of sight
and extends the range of the MicroCom system by strategically
locating the Master and Submaster beltpacks.
• Standard Mode (ST): connects users where line of sight
between users is possible.
Menu Setting Default Options
Group* 00 00-51
Channel A On On, O
Channel B** On On, O
Security Code 0000 Alpha-numeric
Tech Menu Setting Default Options
Mode* RP ST, RP, & RM
