Plikc ASTRO WIFI User manual

Multifunctional astronomic timer PLK202020
astro wi
Instructions manual
For Spanish or Italian manual
send an email to: [email protected]

Plikc S.r.l. - Via del Lago Terrione, 83 - 00165 Roma
2
INDEX
Astro wi 3
Connections 4
Keys 4
Download APP 5
Registration 5
Pairing the Device 6
App Functions: Switch 7
Countdown 7
Daily/Weekly program 8
Cyclical Programming 8
Random Programming 9
Delayed Programming 9
Astronomic Programming 10
Activity Log 11
Relay Status 11
Red Led Function 12
Button ock 12
Pairing with Alexa 13
Pairing with Google Asistant 14
Measures 15
Technical specications 16
Precaution for Installation and use 16
DICHIARAZIONE DI CONFORMITÀ
Dichiara sotto la propria responsabilità che la macchina sopraindicata è conforme alle disposizioni delle
seguenti direttive e successivi emendamenti:
Dichiara inoltre che la persona autorizzata a costituire il fascicolo tecnico, stabilita nella Comunità Europea è
Il Fabbricante: “Plikc S.r.l.” Via del Lago Terrione, 83 – 00165 Roma (RM)
della Macchina:
Denominazione Modello Matricola / N° serie Anno di costruzione
TIMER ASTRONOMICO DIGITALE ASTRO WIFI PLK202020
2021
2014/30/UE
Direttiva EMC - Direttiva compatibilità elettromagnetica
2014/35/UE
Direttiva LVD - Direttiva bassa tensione
2011/65/UE
Direttiva RoHs
2014/53/UE
Direttiva RED
Ragione sociale
Plikc S.r.l.
Indirizzo
Via del Lago Terrione, 83 - 00165 Roma
Data
24/03/2021
Luogo
Roma (RM)
Firma
L’amministratore

Plikc S.r.l. - Via del Lago Terrione, 83 - 00165 Roma
3
The single channel astronomic timer plikc astro wi allows the remote control of
devices connected with it all over the world. You just need to download on your
smartphone cell or tablet “plikc smart” app, available for free on Android and iOS
stores. With a stable wi- Connection you will able to manage all listed functions
to control, for instance, neon signs, external lights or every other system or
electronic device. The timer, also, has a useful astronomic function thet allows to
manage such devices acording with dawn and dusk considering the actual time
and geographic coordinates of the location.
The best way to set up and learn fastly how to use our devices is watching our
tutorial videos on Plikc Youtube channel. Find it and subscribe.
To stay always updated, please give us a like on our facebook and instagram
pages.
WARNING: carefully read the instructions. And follow them carefully du-
ring the installation and the use of the product.
ASTRO WIFI

Plikc S.r.l. - Via del Lago Terrione, 83 - 00165 Roma
4
• Connect the two power cables o the terminals N & L
• Connect the load to the terminals 1 & 2
Please Note: If useful, connect to terminal S (Bridged to N) a possible external button
that replies the Physical button function.
In case of doubts please call [phone] or whatsApp us to [phone].
CONNECTIONS
NUM.1 - TERMINAL S
See upper Note
NUM.2 - GREEN LED
Indicate the wi status. When it blinks fastly it means that it’s waiting for
connection. When it stays on it’s connected to wi. When however it’s off
it means that it’s not connected to wi.
NUM.3 - RED LED
Indicate the relay status. Qwhen it’s on the relay is on. When it’s off the
relay is OFF (excepts different set up given by the user through the APP
see pag. 12)
NUM.4 - PHYSICAL BUTTON
It’s the ON & OFF relay selector for the manual managing of the device. If
at the rst switching on of the device The button is pressed for 5 seconds,
the timer serh for the wi network. If however, it’s pressed for more than 5
seconds when the device is already connected, the reset starts.
KEYS:
Warning: Always unplug
or disconnect the product
from the electricity before
connecting the timer.

Plikc S.r.l. - Via del Lago Terrione, 83 - 00165 Roma
5
Scan QR code to download the app from An-
droid or iOS stores. Otherwise write “plikc
smart” inn the app store browser.
DOWNLOADING THE APP
It’s possible to manage all kind of plick wi devices by using “Plikc Smart” APP including the astro
wi.
Please Note. It is possible only to connect the device to 2,4Ghz wi networks
Once downloaded, open the “Plikc Smart” APP and procede through a quick registration. Needed
only for the rst use.
REGISTRATION
• Press Create a new acount.
• Read the privacy policy and press on “I agree”.
• Enter the mail address you want to use for the registration and press on “Get the verication
code”.
• Enter the 6-digit code received in your email within 60 seconds (also check the SPAM folder).
• Set your password made of al least 8 characters containing at least a letter and a number.
Please Note: If your already registered enter “log in with your account”.

Plikc S.r.l. - Via del Lago Terrione, 83 - 00165 Roma
6
1. Press “Add devices” or the + button up on the
right.
2. When the “plikc astro” device icon appear on
the display, press “Add”.
3. Choose the wi network and enter the pas-
sword.
4. Wait for the pairing of the “plikc astro wi” devi-
ce to the “plikc smart” app.
5. When the green symbol appeears press
“forward”.
6. The device has been paird successfully, then
press “End” up on the right.
Please Note: after paired “plick astro wi” with a
smartphone or a tablet all app set up will be repor-
ted on the device.
PAIRING THE DEVICE

Plikc S.r.l. - Via del Lago Terrione, 83 - 00165 Roma
7
Press ON/OFF button to turn on or turn off the devi-
ce. When “plikc astro wi” is ON the RED LED is on.
You can turn on the device with “Power” button too,
down on the left.
Press “Functions” button to enter the advanced
menu that, manage all programming, timer and
astronomic functions.
APP FUNCTIONS: SWITCH
COUNTDOWN
The “Countdown” function allow the user to enter a countdown. When the countdown end the device
turn off. The countdown can last from a minute to 23 hours and 59 minutes.
Select “countdown” Select on the timer the
hours (h) and the minutes
(m). Press “play” button
The countdown goes on. You
can reset it with “Reset” but-
ton or cancel it pressing the
“trash” icon

Plikc S.r.l. - Via del Lago Terrione, 83 - 00165 Roma
8
CYCLICAL PROGRAMMING
The “Cyclical planning” function allow to set up programmed operations for a period of time. To pro-
gram it rst ou have to set up the duration (in minutes and/or hours) of the turning on cycles (ON)
and turning off ones (OFF). Then, set up the hour of beginning and of end of these operations. And
also you can select the days and weeks you want to play it. You can program many cycles too. To
erase them you only need to press on the program for some seconds and conrm.
Select “Cyclic Plan-
ning” and press“Add”
Set up he beginning and end , select
the days you want to use the cycle,
set up the turn on/off time and press
“Save”.
The Cycle will remain on
display to be abled and di-
sabled with the proper com-
mand.
DAILY/WEEKLY PROGRAM
Entering “Program” it’s possible to create several weekly and/or daily programs that stay on the
menu ready to be started at any time. To delete them just press the program for some seconds and
conrm.
Select “Program” And press
“add a program”
Set up the time, select the days you
want to turn on the timer, set up the
button status (ON-OFF) and press
“save”
The program will stay in me-
mory ready to be abled or
disabled by the proper com-
mand.

Plikc S.r.l. - Via del Lago Terrione, 83 - 00165 Roma
9
RANDOM TIME
The “Random” function allows the user to program randomly in a period of time. In this lapse of time,
th device will produce a series of operations of casual lenght and frequency. In this function the work
schedule acnnot be less than 30 minutes.
Select “Random” and
push “Add”
Enter the range of time and
the days of the week when
the device will execute the
random program.
The random range will remain
in memory to be executed
with the proper command.
You can add multiple cycles.
DELAYED PROGRAMMING
Enabling this function,the device will start the delayed shotdown automation. So, every time you turn
on the device, it will shotdown after the set period. You can delay the shotdown from a minimum of
2 seconds to a maximum of 60 minutes.
Select “Delay” and enter
the managing display.
Activate the delay through
the button and select the de-
lay time.
Activating the device from the
main switch, a note indicating
when the device will shotdown
automatically will appear on the
display.

Plikc S.r.l. - Via del Lago Terrione, 83 - 00165 Roma
10
ASTRONOMIC PROGRAMMING
The “Astronomic” function turn on and off the device at dawn and dusk based on geolocation. It’s
also possible to anticipate or delay the operation of turning on and of, until 5 hours before or after
dawn or dusk.
Select “Astronomic” and
enter the managing pa-
nel.
Select sunrise, before or after
and how much advance or de-
lay. Then press on the days of
the week you will activate the
program. Choose ON or OFF.
Finally press “Save”.
Select sunset, before or after
and how much advance or de-
lay. Then press on the days of
the week you will activate the
program. Choose ON or OFF.
Finally press “Save”.
After having activated
the astronomic function,
press “Position”.
Geolocate the device and
colplete the procedure
pressing “Save”.

Plikc S.r.l. - Via del Lago Terrione, 83 - 00165 Roma
11
Select “Set up” Select “Acticity log” View your astro wi plick acti-
vities (Switching on/off)
ACTIVITY LOG
RELAY STATUS
Select “Relay Status” Select timer status when the electric power
return
Setting up the “Relay Status” it’s possible to choose how the device has to run after the sudden
shotdown of the electric power.

Plikc S.r.l. - Via del Lago Terrione, 83 - 00165 Roma
12
Select “Red Led Functions” Select:
Option 1 - The led switch on when the timer is on ON;
Option 2 - The led switch off when the timer is on OFF;
Option 3 – The ledalways stay OFF.
With the “Red Led Functions” option it’s possible choose if and when turn on aforementiones Led.
RED LED FUNCTIONS
BUTTON LOCK
With the “Button lock” option you can avoid some turning on/off program unpleasant manipulations,
even unintentional.
When the text block is activated, indeed, the physical button on your device is neutralized.
T.E.C. It will run normally after pressing it 5 times in a row.
Select “Button lock” Activate and desactivate the lock

Plikc S.r.l. - Via del Lago Terrione, 83 - 00165 Roma
13
PAIRING WITH ALEXA
1. Press the “pen” button up on the right
2. Press on Alexa icon
3. Press on “Log in with Amazon Account”
4. Press on “PAIR”
5. You are now connected to Alexa, press “back” or the “left arrow” symbol
1. Open “Alexa” APP, press devices and press “+” symbol up on the right
2. Press on “Add Device”
3. Scroll downward until the option “Other”
4. Press “Find Devices”; after 45 seconds the app will nd 1 device.
5. Press “Set Up Device”
1. Press “Add group” if you want to pair the devie in a group, otherwise press “Skip”
2. Once set up the device prese on “Done”

Plikc S.r.l. - Via del Lago Terrione, 83 - 00165 Roma
14
1. Press the “pen” symbol up on the right
2. Press on Google icon
3. Press on “Use the verication code”
4. Press on “Copy”
1. Open the “Google Home” App on your smartphone
2. Press on “+” symbol up on the right
3. Press on “Set Up Device”
4. Press on “Compatible with Google”
5. Press the magnifying up on the right , enter “Plikc” and then presson logo “Plikc Smart” logo
down.
PAIRING WITH GOOGLE ASSISTANT

Plikc S.r.l. - Via del Lago Terrione, 83 - 00165 Roma
15
1. Paste the PIN code copied before
2. Press the arrow symbol
3. Press on “Accept”
4. Select plikc astro and then press “Next”
5. Select a house symbol and press “Next”
The written values have to be meant in
milimeters
1. Select a room and press “Next”
2. You are now connected to Google Assistant, you’ll nd your device on the main screen
MEDIDAS

Plikc S.r.l. - Via del Lago Terrione, 83 - 00165 Roma
16
TECHNICAL SPECIFICATIONS
• Voltage: AC/DC 48-240V (AC50/60hz);
• Current: 16A – 250V;
• Power Consuption: P on: 1.5W;
• Resistive load: Max 16A;
• Stand by Power: Psb: <0.5W;
• Insulation Voltage: Ui: 450V;
• Overcurrent: Uimp: 4kV;
• Over voltage category: III;
• Chip Wi-Fi Dualband: networks 2,4ghz;
• Bluetooth: 4.2;
• Security Protocol: WEP, WPA/WPA2;
• Supply Terminals: L – N (Max 2.5mm2);
• Output Terminals: 1 – 2 (Max 2.5mm2);
• Relay Contact: 1NO (AC1 16A/250V);
• Range operating temperature: from -20°C to 60°C;
Precauciones durante la instalación y uso
• The plick astro wi astronomic timer is designed for inner installation.
• Do not install in open air or all’aperto or in places directly exposed to rain.
• Do not install in places with elevated moisture.
• Plikc astro wi can run only one device. Connection of more devices do not
garantee a proper functioning.
• Switch off the main power before connecting a device.
• Pay utmost atention Prestare la massima attenzione when making wiring
with devices or the grid: an incorrect connection or an unreilable shielding
can caus damage to the device and endanger your safety.
• Do not open the shell, discovering the internal circuit. The user cannot hack
the device penalty the end of the warranty;
• Before assembly, read carefully the instructions and unplug the main power
supply.
• The installation should be executed by authorised technician qualied to
mount electric devices in his country following his own country rules.
• Changes to the product could cause loss of warranty.
• The device only works with WIFI network at 2,4Ghz.
• Failure to comply with these instruction can cause injury, electric shock,
burns anbd other damages. Plikc S.r.l. is not reponsible for the lack of re-
spect of these instructions.
• The aforementioned company reserves the right to change these instructions.
