PLT Tri-Head LED Floodlight User manual

Installation Instructions
Tri-Head LED Floodlight - Page 1
Any further questions or interests, please visit
www.pltsolutions.com
EASY INSTALLATION HARDWIRE INSTALLATION WITH BRACKET TO J-BOX
A B C D E F
1. 2.
3.
Turn off the switch and circuit breaker before
installing this LED light fixture.
Insert the machine screw (part B) into the center
hole of the crossbar (part E). Attach the crossbar
to your junction box (not included)with the other
2 machine screws (part B).
• Ensure the screw thread on the center hole is
pointing away from the surface.
Remove the protective paper from the adhesive
face of the EVA Gasket (part F).
4.
5.
9.
10.
12.
6.
7.
8.
13.
11.
Pull the supplywires through the gasket opening.
Adhere the EVA Gasket to the crossbar and outer
edge of the round,surface mount junction box.
• Ensure that the center machine screw on the
crossbar is threading through the hole of the
EVA Gasket
Position wall plate over the crossbar. Mount the
light onto the crossbar.
•Secure with nut + silicone gasket (part C).
• Do not overtighten.
Make sure the motion detector head is NOT
upside down. Rotate the motion sensor so the
controls face detection areas.
After mounting the motion-activated light, apply
asilicon sealant compound (not included) around
the perimeter of the cover plate. This will seal
where the back of the cover plate meets the
mounting surface. Sealant will prevent water from
seeping into the J-Box
Connect supplywires to the LED wires and
secure with wire nuts (part D).
•Black to Black (live)
• White to White (neutral)
Connect the yellow/green ground wires from
supplyto the LED light and secure using
Ground Screw (part A) on the crossbar.
Tuck wires into junction box once you confirm
wire connections are secure.
For wet locations,fill the gap of the EVA Gasket
and mounting surface with asealant compound
or asilicon glue (neither included).
Turn on breaker and light switch. When the sensor
detects movement at night within the coverage
area, the securitylight will automaticallyturn on.
• Establish the timesettings and maximum
sensing range with the details below.
Turn Power
ON
Turn Power
OFF
COMPONENTS
Ground Screw Machine Screw Nut + Silicone gasket Wire Nut EVA GasketCrossbar

Installation Instructions
Tri-Head LED Floodlight - Page 2
Any further questions or interests, please visit
www.pltsolutions.com
ESTABLISH SENSITIVITY SETTINGS
To determine which setting is best for your location and whether you need to reposition the LED heads lay down a
measuring tape from light location extending outwards. Next, walk in an arc across the front of the light to set off
the motion detector and turn on the light. You can also walk straight towards the light to determine the distance you
require. Select the appropriate setting based on your findings.
ADJUSTAND ROTATE
WARNING SPECIFICATIONS
To reduce the risk of fire, electricshock or injury to people:
•Not for use with dimmers or 3-way switches. If you have those in place, remove them
and replace with regular electrical switches.
•To avoid damage, do not remove the clear lens over each LED module.
•Do NOT allow the sensor head to touch the LED head housing. Maintain at least a
1-inch space between LED heads and sensor head.
•Turn off the switch and circuit breaker before installing this LED light fixture. Do NOT
rely upon wall switch alone to turn off power.
•Use safety precautions. Safety eyeglasses and gloves are recommended.
There are (3) setting modes you can select to establish the motion detection range:
•13ft - 20ft (4m- 6m)
•20ft - 33ft (6m- 10m)
•33ft - 45ft (10m- 14m)
There are 8 swivel
points to adjust
light position
Wet
Plastic+Metal
1.92lbs
5 years
120V
38W
Voltage
Wattage
Suitable for Locations Ingress
Housing
Weight
Warranty
IMPORTANT SET TIME SETTINGS
•Installation should be performed by a qualified electrician. Please read and
understand the entire manual prior to attempting to assemble, operate or
install this product.
•To protect against water damage and maintain proper light operation, the
motion sensor adjustment controls MUST face downward.
•Wall switch much remain ON continually for the motion detector to work.
•If motion is continually detected, then the light will remain on until after
motion ceases.
•Do NOT mount below 5 feet.
To test the security light, switch the light to TEST mode. Once testing
is complete, switch to:
•30S-LEDs will come on for 30 seconds after motion is detected.
•60S-LEDs will come on for 60 seconds after motion is detected.
•120S-LEDs will come on f or 120 seconds after motion is detected.
LED lights will auto off and return to the auto motion sensor mode
after illumination for aset time period.
