plugg +garage User manual

programmable remote control + access management app
Instruction manual
English

Index
Welcome
1. Quick guide to symbols
2. Manual contents
3. Getting started with +garage
4. Protecting +garage
4.1. Using +garage correctly
5. In the box
6. Description of +garage
6.1. Activating +garage
7. Turning +garage on and o
8. Access management app
9. Using +garage for the rst time
9.1. Downloading the app
9.2. Charging +garage
9.3. Connecting +garage
9.4. Acquiring codes
9.5. Using +garage
9.6. Storing access codes
9.7. Icons used
9.8. Managing codes
9.9. Sharing codes
9.10. Completing set up
10. Cleaning
11. Standards conformity
12. Technical specications
13. Disposal
Congratulations,
you’re plugged!
+garage
Portable cap
Desktop cap
Programmable remote unit
Micro Usb/Usb cable
EN

Welcome
Plugg is intelligent things
Thank you for choosing Plugg and +garage, a program-
mable remote control to use with an iPhone and in stand-a-
lone mode. +garage acquires the access codes from remote
controls already in use. It can then open doors and gates
when you arrive, making use of the Apple device‘s locali-
sation services. The access management app memorises
the codes, transfers them to your +garage and turns it into
a smart device. You can associate the codes to the places
and share them via e-mail to other +garage users, perma-
nently or for a limited. Read the instruction manual carefully
to nd out how to connect your +garage, install the app
and use the plugg safely. Remember to update the manual
by downloading regularly from plusplugg.com/en/support/
downloads.
1. Quick guide to symbols
The manual contains all the information for proper use of
+garage and to ensure extended product life. So that you
can immediately see how important the symbols are, the
text is organised in chapters, with bullet points and symbols:
• A normal bullet point list denotes simple actions.
The order in which the actions are presented is not
obligatory, but recommended.
1. Numbers mean that the list explains a more compli-
cated procedure that must be carried out in the order
indicated.
CAUTION: Important information regarding proper
use of the device, in order to ensure user safety.
INSTRUCTIONS: This symbol is used when it is
necessary to explain sections of the instruction
manual.
INFORMATION: Additional information for correct
use and maintenance.
DO NOT USE IF PACKAGE IS DAMAGED
MANUFACTURER
DISPOSAL
RECYCLING +garage
RoHS CONFORMITY
EN

2. Manual contents
The instructions in this manual have been prepared with the
aim of providing end users with the necessary information to
operate +garage correctly: they describe how the plugg works
and contain instructions and tips on how to:
• Learn about +garage
• Setting up and activating +garage
• Modify set up parameters
• Acquire an access code
• Store access codes
• Manage opening doors and gates
• Share codes
• Protect the device from damage
• Avoid danger and use +garage safely
Before using the plugg, please read the instructions
and guidelines carefully in order to use the +garage
safely and to prolong the life of the product.
This manual is an integral part of the +garage by
plugg. After downloading it, please look after it
carefully and protect it from damage. Remember to
update it regularly by downloading from plusplugg.
com/en/support/downloads.
3. Getting started with
+garage
+garage is an intuitive remote control that does not require
programming - its dedicated app enables you to acquire
access codes from xed code remote controls remotes
and rolling code remotes from selected producers. The app
memorises and transfers them to the plugg +garage to open
your doors and gates when you arrive, using the buttons in
a stand-alone mode through the GPS function. You can also
all the codes with other +garage users simply by sending an
e-mail directly from your iPhone. To acquire the code from an
original remote control, connect +garage to the Apple device
onto which you have downloaded the access code mana-
gement app, after completing the rst charging cycle for the
plugg‘s internal battery.
+garage must be used according to the manufac-
turer‘s safety guidelines.
Using +garage in any way not described in the ma-
nual is regarded as improper use, and +garage will
not be held liable for any inaccuracy, malfunction or
damage to person or persons resulting from this.
4. Protecting +garage
4.1. Using +garage correctly
Remember to read the following instructions carefully
in order to protect your +garage plugg from damage
and ensure it works properly.
Always remember to follow the safety instructions to
avoid any risk of danger.
• Protect +garage from impact and mechanical stress
• Do not leave +garage near sources of heat
• Do not leave +garage in surroundings that are too
damp or dusty, and keep it away from water
• Do not connect or disconnect your +garage with
damp or wet hands (especially if caused by oils
or fats)
Remember to use +garage as explained in the chap-
ters „Getting started with +garage“ and „Protecting
+garage“.
Do not connect your Apple device to +garage if
• The external case of +garage is damaged
• +garage has been exposed to liquids or
excessive humidity
• You think that your +garage is not functioning
correctly and you need technical assistance
To ensure maximum safety when remote unit is used,
the operator should follow the intructions contained
in this manual.
EN

5. In the box
Before using +garage you must make sure that the package
contains all the items on the list and that there is no sign of
damage. If you have any doubts, do not operate the plugg
and contact your reseller or Plugg client services directly.
The box containing your +garage also includes:
• +garage programmable remote unit
• Desktop cap
• Portable cap
• Micro Usb/Usb cable
• Keyring strap
• International guarantee
Do not use your +garage device if the packaging has
been damaged in any way.
6. Description of +garage
+garage is a plugg, a hardware device that connects to com-
patible new generation smartphones. The +garage remote
control unit is simple to use with an iPhone after the dedica-
ted app has been downloaded from App Store and installed.
The access management app makes +garage a smart devi-
ce. It enables you to acquire codes and associate them with
places by selecting the geographical location on the active
maps using your iPhone‘s localisation services. This lets you
open doors and gates when you arrive, and share the codes
via e-mail with other +garage users. The sharing can also be
restricted to a limited period if desired.
6.1. Activating +garage
+garage is very easy to set up with just a short series of
actions:
• Download and install the +garage access
management app from App Store
• Connect +garage to your iPhone
• Enable the localisation services for +garage
• Acquire the security codes
• Congure preferences
7. Turning +garage on and o
You do not need to turn +garage on and o, as all its func-
tions are controlled from the connected iPhone.
8. The access
management app
The access management app will guide you through the in-
itial setup. This includes acquiring codes, geo-referenced ac-
tivation of door and gate openings and setting preferences.
+garage is much more than a remote control - it manages all
your access points and shares them in an extremely intuitive
way, using only the Plugg device and your iPhone.
The compatible device must have enough free memory
to allow the app to be installed and store the acquired
access codes.
The Apple device paired with your +garage must be
using the latest operating system. If you need to update
this, please refer to Apple guidelines.
EN

9. Using +garage for the
rst time
9.1. Downloading the app
The access management app is available for free download
from App Store. You must download it and open the appli-
cation to proceed with your +garage activation.
9.2. Charging +garage
+garage is powered by an internal lithium ion battery that
must be recharged regularly using a Micro Usb/Usb cable.
The battery is partially charged when you purchase your
+garage - before pairing the plugg you must complete a full
charge cycle.
To prolong the life of the internal LiPo battery:
• only recharge partially and frequently
• do not allow the battery to discharge completely
• carry out a complete charge cycle regularly
For more information go to:
plusplugg.com/en/support/faqs
9.3. Pairing +garage
In order to use your +garage you must connect it to your
iPhone using the 30-pin or lightning connector. The app will
detect the plugg automatically. The connection will take a
few seconds to complete, then the device is ready for you to
acquire the codes from your original remote units.
9.3. Acquiring codes
It is very easy to acquire the access codes from a remote
unit in use. Tap the +garage garage in the middle of the main
screen while holding down your remote unit‘s „open“ button.
The app quickly recognises the code and transfers it to your
iPhone.
+garage is compatible with xed code remote con-
trols. Before acquiring the code, check the specica-
tions of the of your door or gate opening device.
+garage is compatible with rolling code remotes
made by some selected producers. For more in-
formation, check the website at plusplugg.com/en/
support/downloads and plusplugg/en/support/faqs
9.4. Using +garage
When an access code has been acquired, you can immedia-
tely check the opening and closing of the associated door or
gate simply by tapping the active buttons on the app‘s main
screen. Access these controls using the +garage icon in the
basic menu at the bottom.
If you have enabled the localisation services for +garage,
when you arrive doors and gates will open automatically,
making use of your iPhone‘s GPS function.
EN
Chapter continues on the next page à

9.6. Store access codes
You can acquire an unlimited number of codes and use
the code management system to select the ones you want
to use and quickly display its conguration and the place
where it is active.
9.7. Icons used
The app uses simple icons to indicate the enabled status of
some commands:
Meaning Icon
Automatic opening enabled
Known location associated
with access code
Code transferred to plugg
Code shared with time limit
Button selected for opening with
+garage stand-alone
9.8. Managing codes
The dedicated app enables you to manage all the details
identifying an access code and its activation for +garage.
Proceed with:
• Attributing an identication name
• Selecting the “open“ button in stand-alone mode
• Transferring the access code to your plugg
• Selecting location on geo-referenced map
• The type of remote unit (automatic, manual)
• Automatic opening on arrival
9.9. Share codes
All acquired codes can easily be shared directly from your
iPhone with other +garage users:
• Insert your e-mail
• Add the addressee‘s e-mail details
• Specicy an access validity date
• Attach a personal message
When you conrm, the addressee will be sent an email
containing the link that will enable them to transfer the code
to his or her plugg.
EN
Chapter continues on the next page à

9.10. Completing set up
In the “setup“ menu you can specify some simple preferences:
• Enable automatic opening on arrival via
the GPS system
• Enable notices associated with the +garage connec
tion, acquiring the code and using the virtual button
• Restoring initial +garage settings
10. Cleaning
The +garage device is easy to clean, and does not need any
special maintenance:
• You can clean the screen with a cloth. If it is very
dirty, you can use any common household detergent
• Do not use any aggressive detergents, thinners,
petrol of sti brushes
• Do not immerse your +garage in water, as it is
not waterproof
11. Standards conformity
+plugg srl declares that the +garage programmable remote
control conforms to the Essential Safety Requirements and
the guidelines set out in:
• Directive 1999/5/EU on radio equipment and
telecommunications terminals (R&TTE)
• Directive 2011/65/EU on restrictions of use of
dangerous substances (RoHS)
• Directive 2012/19/EU on disposal of electrical and
electronic equipment (RAEE)
The +garage also complies with the international technical
standards listed in the declaration of conformity. The decla-
ration of conformity can be found and downloaded in digital
format at the following website: plusplugg.com/en/supports/
downloads.
EN

12. Technical specications
Compatible with iPhone 4, iPhone 4s,
iPhone 5 with lightning connector
Operating system Apple iOS 6.0 or later
Charging method micro Usb/Usb cable
Frequency 433 92MHz and 868.35Hz
Battery internal LiPo battery
Number of buttons 2
Compatibility xed code units and selected
rolling code units
Operating temperature
range
from -10°C to +45°C
from 14°F to +113 °F
Memory memory in connected iPhone
Dimensions (mm) 58.55 x 32.2 x 9.4
Weight (g) 15 g
13. Disposal
The packaging is reusable and can be recycled. The packa-
ging materials and the product must be disposed of in ac-
cordance with applicable laws in force in the country of use.
The product should not be disposed of with other
household waste at the end of its lifecycle. To avoid
damage to the environment or health caused by unsuit-
able methods of disposal, you must separate the device
from other types of waste and recycle it in responsibly
to encourage sustainable reuse of the materials. You
can contact the specialist outlet where the product was
purchased or the local organisation responsible for
recycling electrical or electronic equipment.
Remember to dispose of the +garage packaging materi-
als according to existing guidelines in your country.
+garage complies with RoHS regulations.
+plugg srl - via Carloforte 60, 09123 Cagliari (CA) - Italy
[phone] - [e-mail]
Made for iPhone4, iPhone 4s, and iPhone 5.
iPhone is trademark of Apple Inc., registered in U.S. and other countries.
Designed and Made in Italy by Plugg
+plugg srl
via carloforte, 60
cagliari (CA), italy
p.iva 29194000298
t. [phone]
f. [phone]
plusplugg.com
[email protected]
EN
