PLX Devices DM-100 User manual

Setting up the
DM-100 / SM-Modules
Quick Start Guide
Step by Step
Stand Alone Monitoring Setup

1. Serial Cable 2. USB Cable 3. Power Cable 4. Four Button Remote
5. OLED 52mm Display 6. DM-100 Control Box 7. User Guide and CD
•Items Included
1.
2.
3.
4.
5. 6.
7.

Tip: Find a power source that shuts off with ignition.
DO NOT POWER UP IN TILL INSTALL IS COMPLETE
•Step One
Find and connect to 12-18v power source (as shown below in picture)

Tip: Carefully route the HDD cable. Making sure it does not rub or chafe.
•Step Two
Connect (figure two) into HDD serial port.

Tip: One 4 button remote can operate multiple DM-100’s when the other DM-100’s
are set to slave
•Step Three
Connect 4 Button Remote to Remote input.

Tip: If you have more sensor modules, simply connect them in between the DM-100
and the Sensor Module. Make sure that any subsequent sensor modules added to the
iMFD daisy chain MUST have the termination jumper REMOVED.
Use the 1tf serial cable provided to make the connections.
•Step Four
Connecting SM-Modules to the DM-100
Serial Cable

Tip: Use the “UP” button to toggle through all the available sensors. Some sensor will have
several units measurements available. For example, a fluid temperature sensor will give you the
choice if you want to show degrees Fahrenheit “Fah” or degrees Celsius “Cel.”
•Step Five
Setting up Sensor Module’s for the DM-100 (SM-AFR as Example)
Find screen named
Setup Sensors
Then start Scan
Screen then will
display
Scanning For
Sensors
Screen then will
display
Parameter 1
AFR0 Lam
Press Select to
change values
For your
application

www.plxdevices.com
408-745-7591
•Congratulations! Install is Complete.
Checkout Some of are other iMFD products.
You may now start setting up your DM-100
