Plymovent Wireless User manual

www.plymovent.com
EN User manual
WIRELESS CONTROL SYSTEM
EN Wireless

706303/081915/A Wireless Control System 1
TABLE OF CONTENTS
Table of Contents ...........................................................................................................1
General Precautions........................................................................................................2
Preface .........................................................................................................................4
1 Introduction ..................................................................................................................4
1.1 General Description ........................................................................................................4
1.2 Product Combinations .....................................................................................................4
1.3 Technical Specifications - Receiver....................................................................................4
1.4 Technical Specifications - Transmitter................................................................................4
1.5 Ambient Conditions ........................................................................................................4
1.6 Transport of The Unit ......................................................................................................4
2 Product Description ........................................................................................................4
2.1 Operation......................................................................................................................4
3 Safety...........................................................................................................................5
4 Installation....................................................................................................................6
4.1 Unpacking.....................................................................................................................6
4.2 Electric Connection.........................................................................................................6
4.3 Primary Wiring Procedure................................................................................................6
5 Maintenance..................................................................................................................6
6 Troubleshooting .............................................................................................................6
7 Spare Parts ...................................................................................................................6
8 Electrical Diagram ..........................................................................................................6
9 Disposal........................................................................................................................7

706303/081915/A Wireless Control System 2
GENERAL PRECAUTIONS
ATTENTION
Allow only qualified personnel familiar with adjustable
frequency AC drives, and associated machinery to
plan or implement the installation, start-up and
subsequent maintenance of the system. Failure to
comply can result in personal injury and/or equipment
damage.
ATTENTION
To avoid an electric shock hazard, verify that the
voltage on the bus capacitors has discharged before
performing any work on the electrical controls,
switches and/or drives if applicable.
ATTENTION
Incorrectly applied or installed electrical controls,
switches and/or drives can result in component
damage or a reduction in product life. Wiring or
application errors, such as, undersizing the motor,
incorrect or inadequate AC supply, or excessive
ambient temperatures can result in malfunction of the
system.
ATTENTION
The electrical controls, switches and/or drives may
contain ESD (Electrostatic Discharge) sensitive parts
and assemblies. Static control precautions may be
required when installing, testing, servicing or repairing
this assembly. Component damage can result if ESD
control procedures are not followed.
IMPORTANT USER INFORMATION
Read this document in entirety before you install, configure,
operate, or maintain this product. Users are required to
familiarize themselves with installation and wiring instructions in
addition to requirements of all applicable codes, laws and
standards.
Activities including installation, adjustments, putting into service,
use, assembly, disassembly, and maintenance are required to be
carried out by suitably trained personnel in accordance with
applicable code of practice.
If this equipment is used in a manner not specified by the
manufacturer, the protection provided by the equipment may be
impaired.
In no event will Plymovent be responsible or liable for indirect or
consequential damages resulting from the use or application of
this equipment.
The examples and diagrams in this manual are included solely
for illustrative purposes. Because of the many variables and
requirements associated with any particulate installation,
Plymovent cannot assume responsibility or liability for actual use
based on the examples and diagrams.
No patent liability is assumed by Plymovent with respect to use
of information, circuits, equipment, or software that may be
described in this manual. Throughout this manual, when
necessary, notes may be used to make you aware of safety
considerations.
The operation of exhaust extraction systems can be affected by
various factors including but not limited to proper design of the
system, operating procedures, service and maintenance. Fume
exhaust exposure levels should be checked upon installation and
periodically thereafter to ensure that they fall within applicable
regulations and exposure limit values.
Plymovent systems are made code compliant, please ensure the
system is properly designed, operated, serviced and maintained.
WARNING!
Identifies information about practices or circumstances
that can cause an explosion in a hazardous
environment, which may lead to personal injury,
death, property damage, or economic loss.
ATTENTION
Identifies information about practices or circumstances
that can lead to personal injury or death, property
damage, or economic loss. Attentions help you
identify a hazard, avoid a hazard, and recognize the
consequent.
IMPORTANT
Identifies information that is critical for successful application
and understanding of the product.
SHOCK HAZARD
Labels may be on outside or inside of the equipment,
for example control box, to alert people that
dangerous voltage may be present.
ARC FLASH HAZARD
Labels may be on outside or inside of the equipment,
for example control box, to alert people to potential
Arc Flash. Arc Flash will cause severe injury or death.
Wear proper Personal Protection Equipment (PPE).
Follow ALL regulatory requirements for safe work
practices and for Personal Protective Equipment (PPE).
BE SURE THAT ALL INSTALLATION, OPERATION,
MAINTENANCE AND REPAIR PROCEDURES ARE
PERFORMED ONLY BY QUALIFIED INDIVIDUALS.

706303/081915/A Wireless Control System 3
EN - ORIGINAL INSTRUCTION
All rights reserved. The information given in this document has been collected for the general convenience of our clients. It has been based on general data
pertaining to construction material properties and working methods known to us at the time of issue of the document and is therefore subject at anytime to
change or amendment, and the right to change or amend is hereby expressly reserved. Changes may be made with or without notification, it is the users
responsibility to ensure they have attained the most recent copy of this document for their files. The instructions in this publication only serve as a guideline
for installation, use, maintenance and repair of the product mentioned on the cover page of this document. This publication is to be used for the standard
model of the product of the type given on the cover page. Thus the manufacturer cannot be held responsible for any damage resulting from the application
of this publication to the version actually delivered to you. This publication has been written with great care. However, the manufacturer cannot be held
responsible, either for any errors occurring in this publication or for their consequences.

706303/081915/A Wireless Control System 4
PREFACE
Using this manual
This manual is intended to be used as a work of reference for
professional, well trained and authorized users to be able to
safely install, use, maintain and repair the product mentioned on
the cover of this document. This user manual should always be
kept with the product, as well as a duplicate copy be kept by the
fire department or city service department after installation.
Pictograms and symbols
The following pictograms and symbols are used in this manual:
ATTENTION
A remark with additional information for the user. A
remark brings possible problems to the user’s
attention.
CAUTION!
Procedures, if not carried out with the necessary
caution, could damage the product, the workshop or
the environment.
WARNING!
Procedures which, if not carried out with the
necessary caution, may damage the product and/or
cause serious personal injury.
CAUTION!
Risk of electric shock.
WARNING!
Fire hazard! Important warning to prevent fire.
Text Indicators
Listings indicated by “-” (hyphen) concern enumerations.
Listings indicated by “•” (bullet point) describe steps to perform.
Service and Technical Support
For information about specific adjustments, maintenance or
repair jobs which are not dealt with in this manual, please
contact the supplier of the product. Make sure you have the
following specifications at hand:
- product name
- Sales order sold on
- Unit using in conjunction with, for example, an OS-3
You can find this data on the identification plate.
1 INTRODUCTION
1.1 General Description
The Wireless Receiver and Transmitter system add-on is
designed to meet all local laws for radio frequency use. This
system allows simple and expandable wireless integration with
all Plymovent control systems.
1.2 Product Combinations
This product can be used in conjunction with all Plymovent
control boxes and most Plymovent remote triggering systems.
1.3 Technical Specifications - Receiver
L x W x H 6” x 4.5” x 2.5” (152.4mm x
114.3mm x 63.5mm)
Mounting Hole Diameter Slotted, hole diameter 1” (25.4mm),
slot .25” (6.35mm)
Mounting Hole Location Slots 7.5” (190.5mm) OC centered
along 4.5” (114.3mm) profile
4 corner mounting holes 6 5/8” x 3
1/4” (168.27mm x 82.55mm)
Weight 2 lbs (.907 kg)
Box Rating NEMA 12
Compliant With UL listed enclosure, unit operates at
24 VAC and does not require UL
compliance*
Input Power 12-24 V DC/AC
*For most up-to-date UL information, including on Plymovent,
please visit the online certifications directory at www.ul.com.
1.4 Technical Specifications - Transmitter
L x W x H 2.375” x 1.5” x .5” (60.325mm x
38.1mm x 12.7mm)
Weight 1 oz. (.028 kg)
Input Power 3 VDC Battery
Refer to the available product data sheet for detailed
product specifications.
1.5 Ambient Conditions
Operating temperature:
- min.
- nom.
- max.
- 41°F (5°C)
- 68°F (20°C)
- 104°F (40°C)
Max. relative humidity 80%
Storage conditions - 41-104°F (5-40°C)
- relative humidity max. 80%
Suitable for outdoor use no
1.6 Transport of The Unit
The Wireless Control System is designed to be used primarily in
conjunction with the Plymovent OS-3 control box.
The manufacturer cannot be held liable for any damage to the
unit due to shipping or mishandling. Always handle the unit and
the accompanying options and/or accessories, if any, with care.
2 PRODUCT DESCRIPTION
2.1 Operation
The Wireless Controller Receiver is designed to be connected to
a Plymovent control box. This unit is designed to draw its power
from the control box and provide a set of dry contacts by which
the control box can be triggered. These contacts are activated by
a properly wired and programmed transmitter at a distance of up
to 500 feet away. This transmitter must be used in conjunction
with a normally open (NO) switch, for example a pressure or
temperature switch, micro-switch or other such item.

706303/081915/A Wireless Control System 5
2.1.1 Wireless Transmitter
The Wireless Transmitter is to be used with a normally open
(NO) set of dry contacts, such as what is provided in a
Plymovent Micro-switch, pressure switch or temperature switch.
3 SAFETY
General
The manufacturer does not accept any liability for damage to the
product or personal injury caused by ignoring the safety
instructions in this manual, or by negligence during installation,
use, maintenance, and repair of the product mentioned on the
cover of this document and any corresponding accessories.
Specific working conditions or used accessories may require
additional safety instructions. Immediately contact your supplier
if you detect a potential danger when using the product.
The user of the product is always fully responsible for
observing the local safety instructions and regulations.
User Manual
- Everyone working on or with the product must be familiar with
the contents of this manual and must strictly observe the
instructions therein. The management should instruct the
personnel in accordance with the manual and observe all
instructions and directions given.
- Never change the order of the steps to perform.
- This user manual should always be kept with the product, as
well as a duplicate copy be kept by the fire department or city
service department after installation.
- The examples and diagrams in this manual are included solely
for illustrative purposes. Because of the many variables and
requirements associated with any particular installation,
Plymovent cannot assume responsibility or liability for actual
use based on the examples and diagrams.
- No patent liability is assumed by Plymovent with respect to use
of information, circuits, or equipment described in this manual.
- Reproduction of the contents of this manual, in whole or in
part, without prior written permission of Plymovent is
prohibited.
Pictograms and Instructions On The Product (if
present)
- The pictograms, warning and instructions attached to the
product are part of the safety features. They must not be
covered or removed and must be present and legible during
the entire life of the product.
- If pictogram, instructions or labels on the product become
damaged, missing or illegible immediately discontinue use of
the unit and replace or repair damaged or illegible pictogram,
warnings and instructions.
- Contact your local authorized service technician for support.
Users
The use of this product is exclusively reserved to authorized,
trained and qualified users. Temporary personnel and personnel
in training can only use the product under supervision and
responsibility of skilled technicians.
Intended Use1
The product has been designed to be used in conjunction with a
Plymovent control box to operate a Plymovent exhaust
extraction fan. Using the product for other purposes is
considered contrary to its intended use. The manufacturer
accepts no liability for any damages or injury resulting from such
use. The product has been built in accordance with state-of-the-
art standards and recognized safety regulations. Only use this
product when in accordance with its intended use and the
instructions explained in the user manual.
Technical Specifications
The specifications given in this manual must not be altered from
the information given here within. This information is subject to
change at any time with or without notice.
Modifications
Modification of (parts of) the product is not allowed.
Installation
- The installation of this product is exclusively reserved to
authorized, well-trained and qualified electrician.
- All installations must meet any and all applicable local laws,
regulations, standards and requirements.
- It is the responsibility of the installing party to ensure that all
codes are met during the installation of this control system.
Any inspections required are the sole responsibility of the
installing party.
- Inspect the product and check it for damage.
- Verify the functioning of the safety features.
- Never install the product in front of entrances and exits which
must be used for emergency services.
- Make sure that the workshop, in the vicinity of the product,
contains sufficient approved fire extinguishers.
- It is recommended that the wireless receiver be mounted at
approximately 8 feet (2.4m) above finished floor level directly
above the Plymovent control box.
Use
- Check the working environment. Do not allow unauthorized
persons to enter the working environment.
- Protect the product against water and humidity.
- Stay alert and keep your attention to your work. Do not use
the product when you are under the influence of drugs, alcohol
or medicine.
- Make sure the room is always sufficiently ventilated;
this applies especially to confined spaces.
Service, maintenance and repairs
WARNING!
Maintenance should only be performed by authorized,
qualified and trained persons (skilled) using
appropriate work practices.
WARNING!
Electrocution hazard
Disconnect mains before servicing. Failure to do so
could result in serious personal injury or death.
1 “Intended use” as explained in EN-ISO 12100 is the use for which the technical
product is suited as specified by the manufacturer, inclusive of manufacturers
directions in the sales brochure. In case of doubt, it is the use which can be
deduced from the construction, the model and the function of the technical
product which is considered normal use. Operating the machine within the limits
of its intended use also involves observing the instructions in the user manual.

706303/081915/A Wireless Control System 6
4 INSTALLATION
WARNING!
Do not attempt installation of this unit unless you are
familiar with the necessary tools, equipment, utility
connections and potential hazards. Installation should
be performed only by a qualified service provider.
Failure to do so could result in reduced performance
of the unit, serious personal injury or death.
WARNING!
Fire hazard
Never install the control box in areas with flammable
gases.
4.1 Unpacking
Check that the product is complete. The package should contain:
Article No. Description
704502 Wireless Receiver Unit with 18 AWG 4 conductor
prewired cable 10’ long, and antennae
704506 Wireless Transmitter Unit with Pressure Switch
(PC-500) and 2 conductor lead with .187 female
disconnect terminals installed
4.2 Electric connection
Connect the Wireless Control System in accordance with the
separately supplied electrical diagram.
CAUTION!
Electric connection to be executed in accordance with
local requirements. Ensure compliance with the EMC
regulatory arrangements.
4.3 Primary Wiring Procedure
4.3.1 Wireless Receiver Wiring Connections
Connect the red wire labeled 12-24V to terminal 24V on terminal
strip TB1, connect the black wire labeled GRND to terminal 0 on
terminal strip TB1, connect the blue wire labeled C to terminal 1
on terminal strip TB1, connect the orange wire labeled NO to
terminal 2 on terminal strip TB1 inside OS-3 control box.
4.3.2 Wireless Transmitter
The Wireless Transmitter comes with 2 electrical leads which are
connected to a pressure and/or temperature switch used with
emergency response vehicle exhaust systems. When these
contacts are triggered a green light will illuminate on the front of
the transmitter. This light will indicate the unit is transmitting.
For other applications, an optional micro-switch for hose reel or
recoil balancer can be connected to the transmitter. Please
consult Plymovent for further details.
4.3.3 Programming the Wireless Receiver and
Transmitters
Step 1: Power unit on
Step 2: Locate the “Learn” button on top left corner of the circuit
board labeled SW1.
Step 3: Press the “Learn” button and the learn light will
illuminate.
Step 4: Locate the transmitter to be programmed and touch the
2 pigtail leads together. The “Learn” LED will flash and turn off.
The transmitter is now programmed.
Repeat steps above for additional transmitter units up to 24
total.
WARNING!
Procedures which, if not carried out with the
necessary caution, may damage the product and/or
cause serious personal injury.
5 MAINTENANCE
The Wireless Transmitter requires a Size 2032 battery to be
changed as needed.
6 TROUBLESHOOTING
If the Wireless Control System does not function correctly,
please first verify that the batteries on the transmitters are
installed correctly and in good working order. If this does not
resolve the issue, then please contact your local authorized
dealer/technician.
7 SPARE PARTS
Article No. Description
704502 Wireless Receiver Unit only
704504 Wireless Transmitter Unit only
704000 PC-500 Engine Pressure Switch only
8 ELECTRICAL DIAGRAM
Please refer to Figures 8.1-8.2.
Fig. 8.1 Plymovent OS-3 Control Box Terminal Detail

706303/081915/A Wireless Control System 7
Fig. 8.2 System Detail
9 DISPOSAL
After life of the product, dispose it of in accordance with state or
local regulations.

706303/081915/A Wireless Control System 8

www.plymovent.com
706303/081915/A Wireless Control System
